News items September 2013

Recently Concetti have scored successes with their new fully automated FFS bag filling lines for light bulk density powders. Upgrading an old-style valve bagger to the FFS technology allows the bag shape and dimension to be optimised, thus producing drastic improvements in the whole logistic chain, and appealing cost saving. Previously, these powders were packed into paper valve bags but after preliminary tests, Concetti proposed a “Continua 600” Tubular Form, Fill, Seal machine with screw fed gross weigher for 10 to 15Kg bags. Concetti has now implemented the use of special dosing augers to increase the product density, increase performance and optimise the bag dimensions. With de-aeration lances to remove air from the product during and after filling, the “Continua” produces a more compact bag. Sack mouth cleaning ensures a perfect seal every time and corner sealing can be added to further improve the finished bag shape. The unit is fitted with stainless

SMC, the world’s leading pneumatics provider and the original inventor of slide tables, has unveiled a new generation air slide table to meet the demands of today’s marketplace. The new MXQ-Z series has four body types in one guide – double ported, low thrust with high rigidity, single side ported and interchangeable height – offering customers greater versatility. The MXQ-Z is also up to 44% lighter and 23% smaller in height thanks to a thinner table made of a specialised, extremely tough stainless steel material which has no impact on its rigidity. In addition, the compact design and low centre of gravity takes away unnecessary movement on the guide unit and eliminates the risk of bends, distortions, oscillations and vibrations. The double piston rod construction also delivers significantly better uniform running characteristics as well as higher extending and retracting forces. Its clever construction doesn’t stop there; thanks to its compact, symmetrical

Theme-based presentations and demonstrations at Ahoy Rotterdam The tenth anniversary edition of Solids Rotterdam (Ahoy, 2 and 3 October) will be complemented and supported by a great parallel event. In collaboration with partner Bulk, IP&D Experts (Independent Powder and Drying Experts) will organise a conference with presentations and demonstrations in the field of powders and membrane technology. Visitors can attend the congress on both days and attendance also guarantees free admission to the Solids 2013 trade show – enabling visitors to identify solutions that will enable them to put into practice the theory learned in the congress sessions. The programme will mainly be of interest to process and plant engineers, plant managers and R&D managers. The sessions will be moderated by Chairman David Hollestelle and will include lectures by academics as well as speakers from industry, public authorities, universities and colleges in The Netherlands and abroad. A buffet lunch will be given at the stand of our media partner

Interactive seminar seduces visitors to test their own products on explosivion risks During Solids Rotterdam on 2 and 3 October 2013, Adinex will take visitors into the world of explosion risks. They will get the possibility to test their own products on explosivity in the Hartmann machine, while getting comprehensive information about the correct precautions against explosion risks. The explosion risks strongly depends on certain characteristics of the materials one works with, as well as installations which include possible inflammation sources. The precautions discussed during the seminar are both preventive as constructive and will provide more insight into different ways of analysing explosion risks. Adinex is one of the parties in the seminar programme that is specialised in technical damage expertise. They focus on executing damage expertise jobs. Monitoring new developments within this industry is something which, for Adinex, is inexplicably connected to their field of work. It is because of this reason that their attendance at Solids

Seminar Technotrans is about a preventive policy regarding wear and tear and corrosion Besides a wide range of exhibitors, Solids Rotterdam offers a comprehensive seminar programme. The subjects of these free lectures will vary from decreasing explosion risks to the prevention of corrosion. On Wednesday 2 October Technotrans, Institute for Technology Transfer, will bring up this subject in their lecture “Stagnation and losses due to corrosion, do not fit in this day and age”. The aggressive and capricious way corrosion often behaves, are a continuous concern when talking about sustainability, productivity and safety. Technotrans’ seminar provides information about the latest developments to counteract wear and tear and corrosion. Because corrosion can manifest in various ways and because of multiple reasons, the industry often confused and unaware of the costs. Fortunately, the technical growth is a continuing factor as well and these solutions provide us with more and more ways to predict the speed of corrosion and the residual life of the installation/machine

Extra date The general bulk materials handling course on 1 - 3 October is full so we have organised a second session to take place 30 October to 1 November. For details and online booking see the link below. Register now to secure your place.

Magnetrol International and APM Automation Solutions Ltd. (Tel Aviv, Israel) have completed a market-changing agreement designating Magnetrol as a global private label distributor of APM`s groundbreaking bulk solids measurement technology. The non-contact, dust penetrating bulk solids measurement technology will now be distributed around the globe through Magnetrol`s numerous international offices and distribution network, a partnership that will allow both companies to significantly advance the solids measurement market. APM’s revolutionary technology accurately measures volume of stored solid contents, by mapping multiple measurement points on the material surface and generating an accurate reading of the content, thus helping companies and factories to improve inventory management and optimize the process flow of their operations using true and reliable measurement. Magnetrol’s CONTOURTM product works with almost every solid and bulk powder material,

Prefabricated installation for North Africa Being part of Katoen Natie, a world leader when it comes to port activities, logistics and semi-industrial services, has its advantages. Katoen Natie has over 4.8 million m² of warehouses located throughout 25 countries, worldwide. As a member of this international player, we’re able to use its facilities for the benefit of our projects. For example: A manufacturer asked us to engineer and build a blending line in a North-African country. The installation consists out of 4 main parts: dry material handling, CIP, kneading and bagging. Our know-how about how to treat the given product, combined with our experience in international projects, was decisive for awarding us this contract. The dry material handling level consists out of a bag discharging station, a mixer and a pneumatic conveying line equipped with a metal detection system. The conveying line feeds a loss in weight feeder installed above a kneader. Next to the dry handling ap¬plication we also

Innovative Slide Gate Valves and Diverter Valves Vortex will be exhibiting a wide range of dry bulk handling valve solutions at SOLIDS 2013 in Rotterdam, 2-3 October. From fine powder handling to heavy duty aggregates, every Vortex product incorporates design features to improve dependability, durability, ease of maintenance, while minimizing the need for spare parts. Unlike typical valve “suppliers”, Vortex has the capability to customize and tailor valves for individual applications and challenging installations. Vortex sets the same high standards for product quality as customer service and support. Vortex’s client-focused quality management system is registered to ISO 9001:2008 and covers every aspect of product quality and technical services, from initial inquiry to product performance. Please visit us at stand B1006.

Pneumatic & Gravity Flow Conveying The Vortex Roller Gate is the best choice for handling dry material in gravity flow or low-pressure applications. This gate is available in a wide variety of configurations including rectangular sizes and customer specific hole patterns. It has live-loaded seals that extend the service life by compensating for wear. These seals provide an excellent material seal across the gate and to atmosphere. They can also be replaced while the valve is in-line. Similar slide gates have seals made of soft packing, rubber or felt, which rapidly erode away allowing product leakage. • Handles powders, granules, and pellets • Positive seal of dust and fine powders • No pinch points or exposed moving parts for safe operation • Wear compensating hard polymer seals • Seal access ports for replacement while in-line • Accurate metering of material with optional control • Serviceable while in-line • Material construction options available • Standard sizes:

Dilute phase pneumatic conveying (Pressure or vacuum) The Vortex Quantum Series Wye Line Diverter is specifically engineered to handle dry bulk solids in vacuum or dilute phase pneumatic conveying systems with pressures up to 15 psig (1 barg) depending on size. A full flow orifice provides unrestricted conveying of material. The live-loaded seals are shielded from abrasion by a metal insert, this create a positive sealing in both vacuum and pressure conveying systems. The Challenge of Comparison: The Vortex Quantum Series Wye Line Diverter provides a number of significant advantages over traditional diverter valves. The trouble spots inherent in conventional diverter valves have been designed out of the Vortex Quantum Series Wye Line Diverter, valves providing leak-tight design, low installation weight, automatic operation, totally enclosed actuating mechanisms and abrasion-resistant design for long term, reliable service. Ordinary flapper-style diverter valves rely on elastic seals which are exposed to blast abrasion

Top-Sensors T1 line is now also available with Ethernet or Profibus The Top-Sensors T1 line is now also available with Ethernet or Profibus. With the Ethernet version you are able to communicate remotely via your local area network (LAN). Profibus is a commonly known communication protocol in the process industry. You will find an overview on our website. Also datasheets can be downloaded from here.

On the programme for 2 October: topics ranging from air dehydration and sustainable processes to qua On 2 and 3 October 2013, Solids Rotterdam will feature an extensive seminar programme organised jointly by IP&D and Bulk. The programme for 2 October will provide the show visitor with technical knowledge and best practices. In close cooperation with easyFairs and Bulk, IP&D will present a comprehensive workshop / seminar programme on the first day of the show (2 October) in a separate area at Ahoy. A recent start-up of independent powder and drying experts, IP&D has assembled a roster of respected speakers and topics of immediate relevance to professionals working in the field of fluids and bulk goods. The following renowned companies have agreed to share their knowledge and experience with seminar attendees: HB Group: Air dehydration pays for itself with powder towers; BioBase: Pilot plant for fast up-scaling of sustainable processes; Rockwell Automation: More production capacity and better quality control due to multi-variable process control; Ystral: The

Universal level indicator for any bulk solids level measurement application The MOLOSroto level indicator series consists of 12 different devices types that can be configurated with a lot of options and equipped with many accessories. This means that MOLLET Füllstandtechnik offers a unique diversity of rotary blade level indicators that are exactly adapted to the individual measurement task and turns them into a universal level measurement device for all kind of bulk solids. For example housing material, power supply, versions for process temperatures up to 500 °C or pressures up to 10 bar, a lot of process connections and blade shapes can be selected individual in the catalog. Of course all sensors can be ordered with ATEX approvals for the use in any kind of gas and dust explosive areas. For application with even higher requirements special devices are developed and offered. The shown customized MOLOSroto rotary paddle guarantees reliable measurement results for example in a test reactor with process temperatures above 1.200 °C. MOLOSroto

A recipe analysis and concept engineering from KSE Process Technology revealed that Felleskjøpet Rogaland Agder (FKRA) is capable to increase their production up to 10% by fitting new systems into the current factory. By deploying multiple ALFRA dosing and weighing systems the amount of manual additives and manual loading of silos is significantly reduced. Micro and small components are dosed out of thirty flexible silos from an ALFRA Flexible Component Dosing system and an ALFRA Small Component Dosing system out of thirty flexible silos. After that the components are transported a few floors up with a vacuum transport to an ALFRA check weigher who, after weight control, directly discharges in the main mixer. Construction expenses are spared because the new systems are placed in the current factory. Additionally FKRA is able to produce automatic overnight. So the staff can fully focus on producing efficient and qualitatively. The first systems are scheduled

DYNO-MILL type ECM- AP 05 for scale-up to production With the latest DYNO®-MILL type ECM-AP 05 LABORATORY mill is the WAB program of the ECM AP grinding mills even more complete! After the revolutionary introduction of the highly efficient grinders DYNO®-MILL ECM AP types, Willy A. Bachofen AG Machine Fabrik ( WAB ) recently expanded the range with the LAB mill ECM AP 05. A renewed grinding process at the highest level with proven performance in the field of dispersion, ultrafine nano wet milling and wet milling on thousands of installed ECM APs worldwide. The new separation system of the ECM -AP displays a unique forced recirculation of the grinding beads. The circulation of the beads is caused by the newly developed invert wall, that leads the beads to an axial flow over the screen. After the DYNO - DSE accelerator the beads immediately return towards the grinding chamber wall. Along with a number of other improvements , the new separation system provides numerous benefits for our customers. regards to the

To complement its range of air preparation equipment ASCO Numatics introduces a new range of Series 342 Stainless Steel Filter Regulators to complement the existing range of air service equipment. Suitable for inlet pressures up to 10 bar, the 1/4” and 1/2” NPT filter regulators have a fully stainless steel construction and comply with the requirements of ASTM A351/NACE MR 01.75. The moulded reinforced diaphragms offer a large flow and the fine pitch/dual springs ensure accurate and steady regulation, regardless of input or output pressures. With a 316L stainless steel filtering element (25μm & 5μm), the regulators are suitable for compressed air and gases. A finned diverter guarantees effective moisture removal. The regulator bowl has a manual bleed to drain condensate. An automatic drain is available as an option. The smooth design facilitates easy mounting and there is a separate connection for the optional pressure gauge. In addition to an impressive flow rate ranging from 2380 to 4430 l/min,

Revolutionising Site Monitoring and Maintenance 4B Components have created a new hazard monitoring solution that will revolutionize the industry by introducing a greater level of transparency and record keeping. Hazardmon.com is a secure cloud based industrial monitoring solution that allows any registered user to login and see all their facilities in real-time from anywhere in the world. This product offers seamless integration with 4B’s communication BUS system – the T500 Elite “Hotbus”. Hazardmon.com Platform Features • The website is designed to be modern, simple and user friendly. • Secure and encrypted login and data transfer of industrial strength – 256bit SSL. This ensures website security and data safety. • No on-site server or PLC needed. No upkeep and upgrade costs. No hardware to replace or backup. The F500 unit sends data directly to our server in the cloud. • All the data is stored in the cloud and backed up in multiple locations making the data extremely secure. The end user

Effective October 1, 2013, K-Tron, a global leader in feeding, dosing, and pneumatic conveying equipment and systems, will operate under the brand name Coperion K-Tron. Coperion was acquired by US-based Hillenbrand, Inc. in December 2012. K-Tron has been a part of Hillenbrand’s Process Equipment Group since 2010. `Operating under the Coperion name is a decisive and indispensable component of our corporate strategy, which aims to further expand our position in the global market,” said Thomas Kehl, President of Coperion. “This brand strategy will allow our customers to comprehend our globally unique range of products more easily. It also enables us to more easily utilize the forces of globalization to our own advantage.` The decision to integrate K-Tron into Coperion represents the next logical step in Coperion’s strategy, began in 2001 with the introduction of the name Coperion. This integrative name expresses the uniqueness of Coperion`s position

A technical plant tour in combination with your trade show visit! M+R - the trade show for measurement and control instrumentation for the processing industry - organizes a technical plant tour through ArcelorMittal. Practical info: M+R Gent 2013 When? Thursday 24/10/2013 Where? Flanders expo, hall 3 - Maaltekouter 1, 9051 Ghent (Belgium) (Please note that the tour programme is given in Dutch and you will need to pay a fee of 50 EUR - The visit to the trade show is for free).

Mixers humidifying fly ashes are part of AVA’s daily routine, however, recently the demand for converting fly ashes into suspensions has been increasing significantly. This requires the fly ashes to be over-humidified in order to obtain a pumpable final product, which subsequently may be dumped or used as stowing material. A further benefit of this method is that highly reactive ashes may be humidified to such degree that they react to completion and still are dust-free. One of these AVA plants in a semi-mobile design has just commenced operation in Croatia. The ashes are suspended in an AVA continuous mixer with a throughput of 35t/h, and subsequently dumped directly via a pump. AVA has delivered a package unit containing the mixer, a water dosing system, and a control unit.

Improves hygiene and prevents loss of ingredients Companies that take delivery of the ingredients used for their production processes in bags of between 10 kg and 90 kg actually lose between 0.4% and 1% of these often expensive ingredients due to the residues left behind when the bags are emptied. Dinnissen has developed a new system for emptying such bags especially for these companies. With this system, companies can remove up to 99.9% of the contents when emptying these bags. By doing so, they not only prevent the loss of these ingredients but also improve hygiene and working conditions in a great many ways in and around the production area. Dinnissen’s new system is suitable for bags of 10 kg to 90 kg and empties them down to practically the last particle. The bag emptier prevents contamination within the production process and also prevents the ingredients from being dispersed into the surroundings. The system is particularly well-suited for processing expensive and contamination-sensitive ingredients such

Koninklijke Verpakkingsindustrie Stempher B.V. has been manufacturing paper valve sacks and open mouth sacks for over 100 years, and is one of the first companies in Europe to supply digitally glued paper sacks. A new revolutionary development offers many benefits to the customer companies filling these sacks. “Investment in this new digital production line offers Stempher more options to serve major paper valve sack customers”, says Mr. Arjen van de Werve, the company’s Managing Director. “A major advantage of these sacks is that we guarantee the dust seal - even when filling them with very fine powders. Also, the new technology of the sacks on the filling lines enables very quick processing, as in terms of size and construction, the sacks are highly constant and stable. The vastly improved airation possibilities also ensure quicker filling of the sacks. The very flat head and bottom finish substantially facilitates post-fill labelling or print, with a

For an optimized pelletizing process Automatik Plastics Machinery launches the new elastomer feed roller EL 24 for pelletizing systems with temperature resistance up to 170°C. This elastomer feed roller is especially designed to meet high demands in terms of abrasion and thermal loading. It has a higher thermal load capacity compared to conventional rollers in use. The EL 24 also offers better frictional resistance and compression behavior than conventional elastomer feed rollers. The new roller is also easy to be recognized due to its white color. In addition, and important for the semiconductor industry, it is also silicon-free. In compounding and masterbatch processes, feed rollers are exposed to various materials. The products are soft, brittle, abrasive and/ or very hot. Demands on the feed rollers are very high, particularly in relation to abrasive materials incorporating reinforcers such as fiber-glass or high temperature additives. Besides that, feed rollers are also subject to

Fromw powder to rocks - RETSCH provides the suitable sieve shaker Retsch’s line of sieve shakers is the most comprehensive offering with regards to sieving motions, measuring ranges and sieve diameters, thus covering virtually any bulk material – from agglomerating powders to solid rocks. Lately, two new models have been added to the range: The new Air Jet Sieve AS 200 jet is particularly suitable for sieve cuts of powdered materials which require efficient dispersion and desagglomeration. The option to store up to 10 SOP and the automatic vacuum regulator (accessory) guarantee reproducible and meaningful results. Innovative features such as the Open Mesh function, the selection of the nozzle speed as well as optional use of standard 2` high test sieves perfects the new air jet technology. With the sieve shaker AS 450 control RETSCH have designed their first siever for 400 mm and 450 mm sieves which operates with a three-dimensional sieving motion. It can be used for dry and wet sieving. The optimized electromagnetic drive

The premium version with very high throughput The most powerful FRITSCH Jaw Crusher ever: up to 3 kW drive power ensure an exceptionally high throughput during pre-crushing of hard and very hard brittle materials. The crushing jaws are completely retractable resp. removable for easy cleaning. And the integrated dust exhaust channels provide optimal working conditions. Ideal for pre-crushing in the areas: Mining and Metallurgy, chemistry, geology and mineralogy, glass industry, ceramics industry, rocks and solids. Overview of the premium features: premium Extra powerful with up to 3 kW drive power premium Extremely robust for toughest loads premium Easy zero-point and gap width adjustment via double eccentric premium Well-conceived Clean Design for easiest cleaning – with integrated dust exhaust channels and removable fixed and completely retractable movable crushing jaw premium Optimal sound insulation due to foam-filled side walls Absolutely simple and reproducible to operate: The gap width adjustment
