News items April 2013

The Berthold analyzer Micro-Polar Moist LB 568 provides an accurate and reliable online measurement of the carbon content in fly ash. The real-time information about the proportion of unburnt ash can be used to improve the combustion rate and boiler efficiency. The state-of-the-art analyzer is installed on a high-temperature resistant measurement chute below the electrostatic filters. The fly ash measurement is carried out by means of microwaves, which are highly sensitive to the carbon particles in the fly ash. Varying bulk densities can be compensated using radiometric technology.

Every component comes from a single source in this assembly unit built by DEPRAG The rear doors of the goods lorry clank shut and the engine purrs. A consignment of carefully packed components for a new assembly system is leaving the DEPRAG factory in Amberg. Behind it lie 14 weeks of work - from the date of the order to acceptance - and it is now on its way to the customer. Systems engineer Markus Solfrank loves his “constantly exciting” job. And as the brand new assembly system leaves the factory gates, his satisfaction in having done a good job is tinged with a little sadness. It will take another six hours for the client’s service personnel to assemble the compact rotary indexing machine - it measures less than four metres in every dimension - and put it into operation. Once complete, the semi-automatic assembly unit will start assembling high quality door fittings. “In a cycle time of under ten seconds it joins the door hinges, monitors them for quality and sends them on, ready for packing”, said Markus Solfrank, as he explained

Invition to engineers and researchers The Program Committee for the 9th annual Comsol Conference on multiphysics simulation is pleased to invite engineers and researchers from around the globe to begin submitting abstracts describing their designs, projects and achievements for presentation at the Conference. This year`s European Conference will be held at the Beurs-World Trade Center Rotterdam, on October 23-25. The COMSOL Conference connects more than 2,000 engineers, researchers and scientists worldwide, providing them with the chance to showcase their work, share innovative technologies and best practices, as well as with the opportunity to meet with the makers of Comsol Multiphysics. The Conference focuses on advancing cross-discipline and multiphysics simulation by providing Conference attendees with a multitude of hands-on minicourses, networking opportunities, keynote talks from industry leaders, and over 850 user presentations. Highlights of the Conference Include: # Multiphysics minicourse

KOBOLD diaphragm level indicators are used to monitor the fill level of almost any powdered, granular or crystalline bulk solids. When the desired fill level is reached, the pressure of the bulk material on the diaphragm activates a micro-switch with toggle function, which can be used as a normally open or normally closed contact at an operating voltage of 220 V and a maximum of 15 A. The corrosion-resistant diaphragm is contained in light metal housing with a flange ring, allowing it to be easily screwed into existing flange connectors. A built-in spiral spring provides the necessary initial tension for the diaphragm. A variety of spiral springs or diaphragms are used depending on the specific weight and structure of the bulk material. The built-in ordinary spring activates at a control pressure of just 0.2 - 0.5 kg. The range of standard diaphragms includes NBR diaphragms (0.5 mm or 1 mm thick) for predominantly powdered materials with a low specific weight such

CIP is the abbreviation of “cleaning in place” and stands for the cleaning of complete plant installations (pipeline circuits, hoppers, silo’s, etc…) without dismantling or opening any equipment. The main principle consists out of circulating chemical composed liquids and rinse water through your processing installation. The main goal of a CIP installation is to remove all of your product residues and exclude any microbiological, allergen, color or taste issues. J-Tec has already installed a wide array of CIP installations during its 40 years of industrial processing activities in as well the dairy, the baby food and the drinks processing industries. These applications improved without any doubt the hygienic aspects of the executed projects. Furthermore they also lowered the environmental impact, reduced manual efforts, encountered the wear of the equipment and entailed considerable cost savings. Recently we designed and installed a state of the art

News from the world of dust removal The newsletter INFA-AKTUELL of Infastaub is online und can be subsribed from your right now. We keep you up-to-date about de-dusting with the newsletter INFA-AKTUELL. We inform you about customer projects, new products of Infastaub, innovative approaches to de-dusting in the different industries, events, employees, etc. We also keep you up to date at the POWTECH. From April 23rd to April 25th, 2013, we expect you in hall 5 at stand 341 with the newest trends and developments in dust removal. We also have a highlight for you at the most important event for the bulk solid industry: You can win a soccer table for your company! Take part in our competition „Quick exchange of filter cartridges at the AJP 224P“. The fastest candidate wins the soccer table.

The company Kithara Software from Berlin closes a gap and creates a coherent real-time cycle with image acquisition, image processing and output under Windows® through the new Vision Module. Previously, it was already possible to react to images in real-time which were acquired by GigE Vision® cameras. In order to obtain real-time for this process, the Kithara real-time driver signals the existence of the entire image to the network controller within a few microseconds after receiving the last parts of the image. The new software component now enables the immediate image processing in real-time by user’s image processing algorithms, as well as by the comprehensive image processing library HALCON™ from the Munich-based company MVTec. In this way, more than 1800 processing operators are available in real-time that enable the implementation of high-performance machine vision applications. The »RealTime Suite«, already used for many years by numerous manufacturers

Applications requiring pressures of up to 30 bar and temperatures of up to 230°C demand a lot from design and fabrication. AVA has taken the challenge. As of now, the brand-new AVA reactor HVM 5 is available for trials. The machine has three stands; these as well as the vertical agitator, a pressure control valve, nozzles for pressure, temperature, and ventilation are mounted on the machine‘s lid. The reaction container has a double jacket an is screwed to the lid from below. The reactor is heated from below with a special high-temperature heater plate as well as with thermal oil via the double jacket. Of course, the whole reactor is thermally insulated. The reactor‘s launching was a great success: A first series of trials over several days in order to modify biomass for the development of food and pharmaceuticals was conducted to the customer‘s full satisfaction.

New brand names from MOLLET Füllstandtechnik Based on their experience our customers combine values like confidence, trustworthiness and safety with the products of MOLLET. Confidence is predicated on fair prices, high quality products and long term customer relationships. The trustworthiness results from absolute delivery reliability, fast reaction times and substantiated statements for our customers. For 30 years our owner-managed mid-sized company named MOLLET has provided innovative ideas and convincing products for more safety around bulk solids and has of course offered customized solutions as well. That gives our customers the good feeling to have chosen the right product. In order to communicate these core values of our brand even better, all product lines of MOLLET Füllstandtechnik GmbH get a new sounding brand name on the occasion of the 30th company anniversary. These brand names have been subject to high requirements. They should document the long history of the company, make a reference to the

Laboratory fluid bed all-rounder now available in its 100% explosion pressure proof PRO version Glatt"s ProCell LabSystem – the most flexible laboratory fluid bed unit on the market – will be introduced in a fully explosion pressure proof PRO version at POWTECH 2013. Integrated in a mobile main unit, this modular lab all-rounder thus allows the use of all process options for batch and continuous fluid bed, spouted bed or rotor processes for a great variety of material systems such as powders entailing the risk of dust explosion up to hybrid mixtures. This compact and modular lab system allows you to process all dusts of the classes St-1 and St-2 as well as organic solvents. Users can benefit from considerable savings in safety reviews prior to trials or production while being prepared for the processing of future product generations. Using the proven concept of "avoiding ignition sources" an explosion is very unlikely. If an explosion occurs nevertheless, it will be enclosed within the explosion pressure proof ProCell LabSystemPRO and there

In February 2013, almost 9 years after introducing VEGAPULS 68, the first radar sensor for bulk solids, VEGA have delivered the 100,000th sensor. "This production milestone carries forward the success story of radar level sensors in process automation. Today, they are the all-round level transmitter for liquids and bulk solids," commented Günter Kech, Managing Director. "Radar technology is on a success trajectory and we will ensure that it stays there, by further simplifying the level measurement of bulk solids with radar in the future." The 100,000th bulk solids radar instrument is a VEGAPULS SR 68. The landmark sensor went to Bühler AG in Switzerland. This Swiss technology group is using it for level measurement in a 25-metre-high cement silo. Radar for solids VEGA Grieshaber KG launched VEGAPULS 68, the first radar sensor specifically tailored to applications in the bulk solids industry, on the market in 2004. Compared to radar sensors

for sale at Surplus Select Stainless Steel Silo, year of manufacture 2011, ss 304, 2 m3, capacity 1-4 m3/h, 2x shaftless output screw conveyor, 290 mm diameter, pitch 290 mm, propeller blade 60x25 mm, the screws are supported over the entire length by an abrasion resistant HMPE 1000 liner, 2x 0.75 kW drives with forced cooling (suitable for control with frequency converter), inlet hopper 1.5 x 1.2 m, inlet height 2.4 m

Hall 4, Booth 4-223 Brabender Technologie GmbH & Co. KG from Duisburg, Germany, a traditional POWTECH exhibitor and one of the world"s leading suppliers of gravimetric metering feeders, are presenting three thematically related product groups from their delivery program. 1. The "Brabender Food Line" The metering feeders from the "Brabender Food Line" have been developed in close cooperation with leading food companies with special regard to all relevant standards, guidelines and recommendations for the food industry (DIN EN 1672-2, EHEDG, FDA, etc.). The product line includes proven Brabender metering feeders in special food grade design, for instance loss-in-weight feeders like the Brabender FlexWall®Plus Feeder with its paddle-massaged flexible hopper, screw feeders with stirring agitators, vibrating tray feeders, plus the sturdy Brabender weigh-belt feeder for high feed rates despite compact dimensions. 2. The "Brabender Hygienic Line" The

Between April 23rd to April 25th 2013, PENKO Engineering B.V. will present their new product line at the Nürnberg Messe POWTECH 2013 in Nürnberg, Germany. The new product lines include the following: • PENKO 960 Indicator • SGM700 Amplifier series • PENKO 1020 range of products • FLEX2100 Controller range of products • FLEX Controller range of products All new products are fully aligned with each other. PENKO instruments cover the entire automated spectrum of a process control environment, from reading out and indicating a weight value to the simultaneous process of checking and controlling a maximum of 4 different weighers. By joining multiple instruments, control concepts for up to 256 weighers can be built. In addition to the complete range of weighing instruments, weight controllers and process automation systems, PENKO also is an all-round load cell supplier, covering the brands Ascell, Flintec, Revere, Sensortronics, Tedea Huntleigh and

FRITSCH - Milling and Sizing! FRITSCH, an internationally respected manufacturer of application-oriented laboratory instruments for sample preparation and particle sizing, is again one step ahead. Convince yourself and discover the new models of the FRITSCH premium line as well as further interesting innovations in the field of particle sizing live during POWTECH 2013 - Hall 5 • Booth 5-362 FRITSCH Size-reduction Discover the new dimension in grinding with the new high-tech laboratory mills FRITSCH premium line: - Jaw Crusher PULVERISETTE 1 premium line The most powerful FRITSCH Jaw Crusher ever: up to 3 kW drive power ensure an exceptionally high throughput during pre-crushing of hard and very hard brittle materials. - Disk Mill PULVERISETTE 13 premium line For efficient fine grinding of hard-brittle to medium-hard solids: even more powerful and safer with easy reproducible gap width setting via display. You should be excited! FRITSCH Particle Sizing Discover the new dimension

Automatic order picking with Prorunner mk5 Qimarox has developed a new automated order picking system ‘Collect & Sort’, which can handle up to a thousand products, containers, or cartons per hour. Central to this system is the Prorunner mk5, the successful vertical transport system from the company that evolved from Nedpack in 2012. Products from conveyor channels at different levels are fed out fully automatically and placed on the correct outfeed conveyor in the direction of the forwarding department or palletising station. Qimarox’ ‘Collect & Sort’ automated order picking system consists of several levels of conveyor channels in which products can be stored. A short roller conveyor module moves back and forth at the front of the conveyor channels on each level. This module retrieves the items in the correct order from the conveyor channels and transports them to the Prorunner mk5, the vertical transport system of Qimarox. This system receives the products from all levels and places them in the

ALL DURAG flame monitors for permanent operation have SIL3 Following the product families of the compact flame monitors D-LX 200 and D-LX 100, TÜV Süd Industrie Service have now also confirmed that the separate design DURAG flame monitors fulfil the requirements for permanent operation up to SIL3. With the product families D-LE 103, D-LE 603, D-GT 800, D-UG 120, and D-UG 660 now all DURAG GmbH flame monitors for permanent operation are confirmed with SIL3. Also for the separate design devices (flame sensor and control unit) this high SIL level was achieved with a proof test interval of 15 years. An important basis for the good rating is the two channel design of the DURAG control units which is already used for more than 20 years. The two channel architecture of the devices ideally unifies high safety together with high availability.

Further development of the Master-PUR hose range now provides even more benefits for the customer All good things come together in one great hose range. Due to a key modification of the Master-PUR hoses, they now become Multifunctional Hoses, which combine both microbe resistance and antistatic properties in one. This makes the product range much clearer for the customer and therefore easier when ordering. The product range will still be called Master-PUR as before, but will now offer greater advantages. The wealth of complex requirements for connection solutions in today’s industry is almost unlimited. That’s why the Master-PUR range has always been so popular and widely applied. As suction and transport hoses made from pure polyester polyurethane with a twist/dislocation-proof spring steel helix moulded directly into the hose, they are extremely versatile and durable, offering applications in almost any industrial conditions. The hose range comes in a wide spectrum of wall thicknesses, from lightweight and medium through to heavy-duty, reinforced versions. In

April 23-25 at the Exhibition Centre in Nuremberg Germany: Hall 1, Stand 318. Following our appearance at the European Coatings Show, you’ll find us once more on an international stage: April 23–25 at the POWTECH exhibition in Nuremberg, Germany. The International Trade Fair for Mechanical Processing Technologies and Instrumentation opens its gates again at the Exhibition Centre. At our stand, we present higher intelligence in fine particle technology for a great variety of industries: whether glass & ceramics, chemicals or construction, or the regaining of precious materials. You may look forward to smart engineering you’ll only find at NOLL’s: systems and special processing in the micron and nano range, e.g. increasing surface area and surface activation, structure-preserving processes or selective grinding. You find us in Hall 1, Stand 318. Individual consulting and personal commitment are our trademark. We would like to plan enough time at the stand for your particular questions and wishes. Please call +49-8234-96615-0

Commissioned at the trade fair, and directly into production: since the European Coatings Show we`ve NOLL met with overwhelming project-related response at the European Coatings Show 2013 in Nuremberg’s Exhibition Centre. Most visitors – many of them new clients – had arranged an appointment before the trade fair to talk to our experts at the stand. Remarkably, our guests brought very specific challenges into the meetings. They approached us for special processing, be it for pigments, additives or fillers. On the spot, we laid down the appropriate processing procedures and scheduled our timing for production. Clients also commissioned test series at the NOLL technical laboratory, where we will develop customized procedures before going into production of industrial-size quantites. It was an international audience which gathered at the NOLL stand at COATINGS, including several visitors from the Asian region. Many a guest we’ll meet again: we were happy to provide complimentary entry tickets for POWTECH, the international trade fair for mechanical processing

Capacitive Level Limit Switch for bulks Capacitive liquid level monitors type NSC of KOBOLD Messring GmbH, Hofheim, offer protection against overfilling of bulk solids. Monitoring of minimum level is also possible at low levels and with light media with low medium density. Different solids e.g. cement, sand, flint or also animal feed can be monitored. The tested measuring system is based on properties of a capacitor. Hereby the level monitor metallic electrode and metallic tank wall assume the tasks of condenser plates. When room between these two plates is filled by a medium, voltage potential changes. Voltage change (very reliably) signalises excess and undercut of limit value. Switching point is determined by position of probe head. Two different device versions enable optimum positioning of the probe head in respective applications. Probe length can be individually chosen corresponding to respective maximum level switching point.With PTFE-coated rigid probe, the model NSC-R. Thereby a maximum of

How operators not only increase production safety but also reduce costs by using groundbreaking protection against dust explosions and what part new standards play. New, groundbreaking methods of calculation: less volume means smaller venting areas The KSt value, among others, is influenced considerably by the dust concentration. In terms of designing pressure relief suitable for practice, a realistic dust concentration for spray-driers is assumed. This is different to the concentration with which maximum violence of explosion is to be expected. Extensive analysis and concentration measurements by experts from the VDI working party allow for a new, groundbreaking method of calculation. This leads to significant reductions in the venting area required, de facto to smaller or a lower number of bursting discs. However, since every protection system is connected to the container to be protected, the risk of undesired product contamination is a concern due to the

Safety valves provide numerous advantages, opening when pressure becomes too high and automatically closing after venting. However, an immense drawback is that safety valves are very maintenance-intensive, and present the disadvantage of not providing leak tightness. In turn, this results in huge material wastage and rising emission rates. Just in the Netherlands, this results in an annual loss of raw materials loss of gases and liquids of approximately 106,000 tons. With a calculated average price of 700,00 EUR/ton, this results in a loss of 75 mio. EUR/year. When adding the leakage losses resulting from shaft sealing, an additional 383.000 tons/year is achieved; e.g. an amazing 268 mio. EUR, only for the Netherlands. The American Environmental Protection Agency (EPA) has discovered that 40.000 tons of volatile organic compounds (VOCs) alone have been annually emitted in the USA. Besides the economic damage, environmental contamination also remains a topic. Based

OCS Checkweighers introduces a new generation of dynamic, stainless steel checkweighers designed for the food industry at this year"s IFFA in Frankfurt/Main. Besides EC-Essential, the compact standard model for safe and reliable weighing of up to 150 pieces per minute, the exhibit also features HC-M and HC-A, two higher specified, successful checkweigher models that meet the most stringent requirements in modern, dynamic weighing technology in terms of accuracy and throughput. The latest generation manufactured from stainless steel and designed for damp room environment enables the best possible product inspection for these so called wipe down conditions. For the more demanding wash down cleaning regimes in the fresh food sector, OCS Checkweighers presents its Wash Down model (HC-M-WD), especially designed for intensive and frequently repeated high pressure cleaning cycles. These checkweighers with sophisticated performance features comply with the food
