News items April 2012

A new Dimension of Screening Technology Description: - protective, control or classifying sieve - single-deck and double-deck execution - continuous screening process - 10 size variants - 2 or 3 fractions - screening surface 0.24 - 3,75 m² (single-deck execution) - screening surface 0.48 - 7.50 m² (double-deck execution) - available with conformity to ATEX Range of Application: As a protective, control and classifying sieve for pourable, dry bulk goods in production and in laboratories. Vibration screening machines type JEL VibSpeed are used in all areas of the chemical, pharmaceutical, food, plastics and similar industries. Operation: The screening process is continuous. The machine works without dust development and at a low noise level. After opening the cover and loosening the clamping device on the front side, the sieve inserts can be removed to the top without any problem. The direction of vibration is based on the arrangement of the vibration motors. They are adjustable in intervals

Sensor-controlled EC servo screwdriver - now even better DEPRAG presents its new generation of screwdrivers to its trade fair public When, from 22 to 25 May, AUTOMATICA 2012, the 5th international automation and mechatronics industry show, opens its doors in the new Exhibition Hall in Munich, the key players in the automation solutions sector will be showing off their wares on 55,000 square meters of floor space. In the quest to manufacture higher quality products faster and more cost-effectively this unique exhibition will be showcasing a host of innovative solutions and the latest trends in product process optimisation. In the screwdriving technology section, on stand 311, Hall A1, DEPRAG SCHULZ GMBH u. CO. will be presenting the latest generation of its successful MINIMAT®-EC servo screwdrivers. This 311E series of transducer-controlled screwdrivers, with its AST40 sequence controller, replaces the current EC-Servo system which has been proving its worth over many years in a wide variety of applications. Transducer-controlled

doubrava industrial plants achieved the CWB certifications as the third company in Austria. This certificate is stringently required to export steel to Canada. It ensures that consistent, always updated standards and relevant regulations of the regulatory authorities are met. Last year doubrava got a big order for Canada. An international, italian Group, successfully in building material supply industry, pins on the quality and reliability of doubrava industrial plants for a serveral time. In a two-month, highly intensive working process, the welding preparations were performed by Mr. Norbert Wolkerseder, doubravas welding specialists. For the test itself, a handful of specially trained professionals were retrained in addition. The welders had a one-week test to proof their skills. All candidates passed the exam with flying colors and were able to convince the examiner of their abilities. Thus doubrava industrial plants expanded its international operations to another country.

Ingeniously simple level controls for bulk solids with UWT rotating paddle switches PNP Electronics The new PNP electronics for the Rotonivo® 3000 and Rotonivo® 4000 ranges uses 3-wire electronics technology with a non-contact output, open collector, PNP. The maximum output current is 0.4A. These electronics can be connected to any standard PLC with 24V DC power supply and PNP input card. The detection signal – the sensor switched to either ‘full/occupied’ or ‘empty/unoccupied’ – is not via micro switches as in the past, but using Hall sensors. Via two Potentiometers, both detection signals 1 and 0 can be time delayed. Additionally a jumper can be switched between FSH and FSL. Heating protection has been installed in the electronics in order for the device to be used in temperatures of less than -20 ° C. Universal Electronics Every electrical device has to be designed for an operating voltage specified by the manufacturer. Because of the high diversity of electronics, international compatibility cannot be ensured. Companies around

Hall 5, Booth A 32 The partner country for this year’s Hannover Messe Trade Fair – China – also plays an integral role for the Masterflex Group. The Asian management company Masterflex Asia Pte. Ltd. is currently being established in Singapore with a new subsidiary near Shanghai in China soon to follow. The Hannover Messe Trade Fair therefore provides an excellent platform to generate many new promising contacts in the Asian business world and also to help propel the Masterflex Group’s expansion in the Asia-Pacific region even further. Innovative products displayed at this year’s trade show booth will include: A major highlight at this year’s show will be the innovative heated hose system, “templine”, which boasts a unique and highly efficient design with several heating strands spiralling around the entire length of the hose, which are fixed in place by a robust yet extremely flexible textile braiding. This results in a constant “heat shield“ for the complete

For vertical transport of humid, sticky and hot product a vertical screw conveyor is a good option. This vertical screw conveyor works on centrifugal force combined with the conveying of the screw. By this high speed execution the screw will be emptied, minimal product will be left in de screw conveyor. Alternative is low speed whereby the product by repression vertical is transported. Product is fed by a horizontal screw conveyor. The lift height of this conveyor is 5,5 mtr This conveyor is executed in stainless steel 1.4301 en executed with exhausting hood for release of vapour. JAVO Procestechniek builds on specification.

The Sodimix is a patented powdered activated carbon (PAC) dust absorption system that eliminates dust created in dry-to-slurry processes. The filtration system is completely dust free, without product loss and can be easily mounted on existing dry-to-slurry processes. The Sodimix is applied mainly as additional equipment for preparation tank to the production of activated carbon suspension. This activated carbon suspension is used in the area of the drinking water processing as well as in flue gas cleaning.

in only 10 minutes METTLER TOLEDO introduces a calibration method for moisture analysers, based upon a refence substance. For reliable results and traceability, the SmartCal(TM) solution provides a method to calibrate a moiture analyser oin only 10 minutes. For more information see www.mt.com/smartcal

Experience Pallmann at the Ifat hall C2 203/302 The all-rounder “TIGER” PSRT 1000 x 1250 robust single-shaft shredder on the stand is one of Pallmann’s principal machines for the sector. It is ideal for separating tyre rubber from steel inlays, cleaning tyre wire, shredding safety flooring, carpets, electric cables, electronic waste, rubber seals with steel inlays, and much more. This comprehensive range of uses means that the TIGER can be retrofitted to many existing systems or used as a stand-alone machine. In many cases, its exceptional shredding performance means users no longer need to invest in additional pre- and post-shredding equipment. Stand-out elements of the shredder are its highly durable shredding components, and knives that can be used in both rotation directions. The patented construction design makes it possible to change the rotation direction at regular intervals. This keeps the knives sharp, contributing to consistent product quality and keeping maintenance requirements to a minimum. The

Contamination-free reduction to nano particle size - NOLL meets the most sophisticated requirements: More and more prestigious market leaders cooperate with NOLL. We create material characteristics that substantially enhance their products’ value, and are specialists for the nano range <2 µm. No matter how hard the challenges of nano size processing – our patented opposed jet mill MultiNo® resolves them masterfully. Its working principle is based on the propulsion of particles by compressed air. Colliding at high speed, the particles are reduced in size. The benefits of “product-on-product” grinding: no product contamination by other materials, gentle processing and minimized wear-and-tear costs due to abrasion-free grinding. MultiNo® is ideally suited for the ultra-fine grinding of dry materials up to Mohs hardness 10 and is used for processing in the micron and nano range <2 µm - 200 µm. Abrasive, gluey, adhesive, temperature-sensitive and high-purity products: we achieve – without the abrasion of grinding elements – excellent and contamination-free

VAS convinces Dyckerhoff Following the successful startup in their cement plants Esch (LUX) and Göllheim (DE), Dyckerhoff AG, a company rich in tradition, has now commenced with the international rollout of Axians"s logistics solution VAS. The new system is currently being implemented on the basis of a template in a further cement plant in Germany, as well as at the plants in the Ukraine. In several workshops, the different requirements of the plant"s processes were analyzed and redefined. The template rollout is now being launched at all sites on the basis of these newly optimized and harmonized logistics processes. This is especially essential for the value flows between VAS and Dyckerhoff AG"s central SAP system. Since 2004, Dyckerhoff AG has belonged to the Italian Buzzi Unicem Group. "We conduct a major part of the logistics processes using SAP. A significant criterion in selecting the new solution was the approved and easy interconnection to the SAP Sales and Distribution module. In the

Automation solution for the traffic route construction sector Axians is providing Eurovia, the leading European road construction group, with its Dispatch Automation System VAS. With a customised template, the asphalt specialist is optimising its logistics processes holistically, including company-specific procedures and seamless connection to its SAP system. In order to satisfy the requirements of the asphalt sector, Axians further developed their dispatch automation system with the know how of parent group VINCI Energies. All Eurovia processes concerning the flow of money and goods are deposited in a universal template that applies globally to all factories. Country- and sector-specifics can be quickly introduced and activated, thus securing the transboundary standardisation of the goods movement processes. Eurovia has already put VAS into operation at their site in Hoerdt, Alsace, and will roll out the solution in around 400 Eurovia factories in France by 2019, with support from Axians IAS (Industrial Application & Services).

Resilient seated butterfly valve type Z 011-A with inflatable liner. TECHNICAL DATA The sealing system `INFLAS` was developed for highly abrasive or very sensitive media. It is available for all resilient seated EBRO butterfly valves with interchangeable seat. In closed position, the liner will be pressed against the disc using low air pressure.The media is sealed off securely. Before opening the disc, the chamber is vented behind the liner. This creates an air gap between the liner and the disc, hence low torque is required to open the valve. GENERAL APPLICATIONS - Bulk goods - Food industry - Pneumatic conveying systems - Weighing technology ADVANTAGES Extremely low wear of parts even in contact with abrasive media Low sized actuators due to reduced torques Low grinding/-clamping of sensitive media between disc and liner

Speed Switches Calibration & Testing Tool 4B has launched a new maintenance tool that makes the testing of 4B speed switch sensors quick, easy and accurate. The SpeedMaster™ is the only device that accurately tests the calibration of speed switches and their alarm and shutdown underspeed relays. The SpeedMaster™ operates in two modes; input mode provides the user with the machine’s actual running speed, and output mode allows the user to test the speed switch at set underspeed trip points for real time verification of the monitoring system`s alarm and shutdown functions. There is no need to remove the sensor from the machine shaft or change any system connections in order to use the SpeedMaster™. Maintenance and safety personnel can now quickly, easily and accurately test 4B speed switches during recommended inspection schedules. The new Patent Pending technology of the Speedmaster will change the way plants use underspeed monitoring systems and will make the plants safer.

The new vibratory sieve shaker AS 450 basic from RETSCH RETSCH offer the most comprehensive range of sieve shakers world-wide, providing the ideal instrument for any type of material, from agglomerating powders to pebble stones. The new vibratory sieve shaker AS 450 basic now enhances the product range by a budget priced model for sieving large quantities up to 15 kg. The siever accepts sieve diameters up to 450 mm and covers a measuring range from 25 µm to 125 mm. Time and amplitude are digitally set, ensuring the reproducibility of the sieving process. The AS 450 basic is the economical solution for users who need to sieve larger amounts of dry material with reliable results. For more demanding requirements such as calibration certificate, wet sieving or processing up to 25 kg of sample material, the AS 450 control is the sieve shaker of choice. Benefits AS 450 basic: • Efficient electromagnetic drive with 3D movement • Digital setting of time and amplitude • Suitable for dry sieving • Excellent separation

Transporter moves 3 Bag Filling Stations onder 12 Silos The group AVT has recently delivered a 10T wheel transporter to a German customer. The transporter will move 3 Bag Filling Stations under 12 Silos. This transporter is again a nice example of a transport system which is completely designed and produced `in house`. The wheel transporter consists of a quality steel tubular frame realized in two parts for easy shipment and which includes a series of supporting plates for connecting the machinery on the top. The transporter features some nice 4 heavy duty swivel wheels (retractable during the bags filling phase), 4 compact traction wheels (2 mounted in X end 2 in Y direction for omnidirectional movements) with ‘AC’ drive motors and proportional speed via frequency inverters, radio control, telescopic electrical box (for easy accessibility) and removable pneumatic box, 4x end-stops and flash lights to each corner of the transporter.

The Dutch Agro-Industrial Group "Royal Cosun" is currently building a pilot plant for developing processes for getting the most out of their raw materials and by-products. Cosun Food Technology Centre (CFTC), has approached Lindor specifically for mixing and drying of their products after the processing of their by-products. For these products the mixing and even more importantly the drying, should be conducted in a controlled manner without any side effects. The bio refining process Cosun wants to extract as much as possible from the crops they use. In the pilot plant the crop will be completely taken apart in several stages for conversion into valuable and useful new products. All kinds of materials originating from the cells will be converted to products used in the food, animal feed and chemical industries. The remaining bio mass will be used to generate "green energy". Cosun"s objective is to make the most of their crops in an economical

Since years Essegi is one of the leading companies concerning big flat foil machines. The F1300 Motion was launched during the latest Ipack Ima fair in Milan. This new machine is especially fast with a speed of 1800 bags per hour for 50 liters or 25 kg bags. This machine runs continuously through servo controlled horizontal sealing bars. The main charecteristics of all Essegi machines such as solid, easy in use and maintenance and high flexibility can of course also be found on this machine. Brand: Essegi Type: F1300 Motion Packing: flat foil Speed: 1800 bags per hour (30/minute) Controll: B&R The F1300 Motion is suitable for the packing of all kinds of products such as compost, salt, fertilizers, sands and gravel, ...
