News items February 2012

A powerhouse in the drainpipe - and supplier of green electricity Four applications demonstrate powerful versatility of air motors. Dagmar Dübbelde, from drive specialists DEPRAG SCHULZ GMBH u. CO., described the air motor as a “universal genius”, and gave four impromptu and exciting examples of how such motors are deployed. As a compact power pack, it helps a cutting robot to battle its way through the muck inside the drainpipe. The air motor adds enormous power to a truly amazing transporter device. As an ATEX-compliant brake motor for potentially explosive areas its job here is to optimise a barrel emptying system. As an innovative GET turbine generator its energy recovery credentials are extremely “green”; it even generates power from small amounts of process gas. Temperatures globally have been rising inexorably for 30 years now. Researchers and industrialists have struggled to counter the effects of climate change with innovative products and processes. At its test laboratory DEPRAG is producing the prototype of

HAVER CPA 2-1 online Time is also money in bulk material industries. The response time to manufacturing errors has to be minimised as much as possible. Haver & Boecker has developed a HAVER CPA system for online measurement of dry and free-falling bulk material in a measuring range from 34 µm to 25 mm. It is called HAVER CPA 2-1 ONLINE. The HAVER CPA 2-1 ONLINE is resistant against negative surrounding conditions such as heat, dust and wetness. An integrated cooling cycle system ensures a proven operation even at high temperature operation. An ‘AIR KNIFE’ cleans camera and lighting array of dust deposits regularly with an air blast. An absorbent minimises the formation of condensation at high air humidity. Procedure: The HAVER CPA 2-1 ONLINE is ready for continuous measurement. It is connected with a downpipe sampler, which takes samples without any interruption of production. The sampler and CPA device can be activated manually or by a programmable controller with interchangeable

About us Geroldinger bring complexe powder and bulk secure and precisly from and to your process. Since 40 years we have experience in handling complex powders und bulk materials. We are spezialised in storing, conveying, dosing and discharging of complex bulk materials. The 12.000 m² company site houses planning and design departments for mechatronically organised engineering, a laboratory for bulk-solids analysis and a modern, generous technical department for performing practice-oriented experiments. Almost the whole range is produced by us ex works in four large production halls with an assembly tower for silos up to 28m. In our process technology department we have more than 1.500 different bulk-solid-examples and therefore a wide range of experience and Know-How. Our export-rate is approx. 75%.

Miscanthus, wood chips, dust and powder Geroldinger sees the pelletization of biomass fuels as a waste of energy, therefore first flow experiments were carried out with the the biomass "miscanthus". The technological challenge of this product is the low bulk density of only 140kg/m³. Based on the laboratory results the silo and heating system of our plant was produced. The annual heat requirement of 1500 hours at full load by 150kW involves the heating of all operational buildings (warehouse and office areas) and the peak loads caused by the paint shop. The heating system consists of a standard industrial combustion boiler, a self-made 25,000 liters of hot water storage for providing the energy for the peak heat load, a housed intake pit (equipped with a dedusting unit) and four screw-conveyors (500mm diameter) to ensure a rapid take over of materials from suppliers. The resulting combustion is almost pure ash from the boiler transported pneumatically into a silo. The 650m ³ concrete silo,

Special metering feeders for the food industry Brabender Technologie KG, one of the world`s leading suppliers of gravimetric metering feeders, are presenting a selection from their special dry ingredient metering feeders for the food industry at this year`s Anuga FoodTech exhibition in Cologne, Germany. The product line has been developed in close cooperation with leading food companies in strict compliance with all relevant standards, guidelines and directives for the food industry (DIN EN 1672-2, EHEDG, FDA, etc.). Beside easy cleanability, particular importance was attached to preventive measures to avoid contamination by microbiological, chemical and physiological contaminants. As a result, design features include plain stainless steel surfaces, non-porous and ground welding seams without joints, no cavities or hollow spaces, radial edges and corners, FDA approved materials for ingredient contact parts and gaskets, plus a vast variety of further details. All metering feeders are hygienic design variants

H-Tec from Heteren, The Netherlands has curently started with the delivery and service of all kind of weighing equipment.

Working at home with IQsafeLink While implementing IQsafeLink in various circumstances in industrial automation, we unexpectedly came to extra usage of this safest solution of remote take-over of machine and process controls. Together with the easy IQsafeLink-tool (the application that runs on PC’s and laptops and actually grants access to the machines that are equipped with an IQsafeLink), the clever box also can connect from anywhere to a company network or server. In a time that sees a growing popularity in working from home, there are several solutions. If it however is one that needs a safe connection between home and the office, than IQsafeLink is the way! The concept is simple: the companies network or server is equipped with a IQsafeLinkand employees that work from home install the IQsafeLink-tool on their home PC or laptop. Now they are able to safely remote access their “office place” and work at a distance as if they were sitting on the chair behind their desk. Home – office solutions

New animation on-line To inform our customers on a better way about the advanced technology that our earth control systems are using, a new animation is placed online.

Masterflex AG starts 2012 with the development of an innovative new hose series for the field of PU suction and blower hoses, which, due to its accreditation of the DIN 5510-2 standard, is especially suitable for applications in railed vehicles. The new Master-PUR L/H MHR se hoses made from special polyurethane can be applied for ventilation in railed vehicles, as drainage hoses for rainwater and condensation from air-conditioning systems, as well as suction and blower hoses for conveying abrasive solids in railed vehicles. Its special characteristics, such as its flammability resistance acc. to DIN 5510-2 and its microbe and hydrolysis resistance, sets this hose range apart from its competitors and makes it highly versatile for a wide range of applications. All Master-PUR MHR se hose types have been tested acc. to the DIN 54837:2007 standard with the classification DIN 5510-2:2009 and achieved the flammability class S-4, the smoke development class SR-2, as

On Oct. 25, 2011 the OHIM (Office for Harmonization in the Internal Market – Trade marks and designs) has registered AVA Europe-wide for numerous products, applications and services as a brand name. We are proud to use the brand AVA in future together with the ‘R’ as the registering mark for a legal protected brand.

Since February AVA is present on the international important social network portals Facebook, Xing and LinkedIn. Visit us and communicate with us!

Sophisticated inspection solutions for all product types and processing stages At Anuga Foodtec 2012 which takes place in Cologne from 27- 30 March, S+S Separation and Sorting Technology GmbH will be exhibiting magnet systems, metal detectors/separators, and X-ray scanners at our stand D010 in hall 5.2. Particular emphasis will be given to the completely new VARICON+ metal detection system featuring the C-Scan GHF detection coil, and the RAYCON product inspection system with high-resolution imaging and enhanced detection. All the new S+S systems on show have been developed further with enhanced hygienic design features. The VARICON+ metal detection system can be specified in two versions, either with the standard GLS detection coil, or with the new C-Scan GHF detection coil, offering three frequencies and enhanced detection capability as standard. The detection coil design guarantees highest metal sensitivity throughout the whole inspection area. The C-Scan GHF detection head features improved hygienic design with a sloped top and totally

The filter company Infastaub has again received orders from Russia Nine BKF bulk loading systems made of stainless steel with integrated filters will be supplied to RusVinyl in Nizhny Novgorod. The filters will ensure a dust free loading of plastic granules from silos into railway wagons. Date of delivery will be this summer. In 2011 Infastaub has already delivered seven dust removal devices for volume flows from 6,000 to 24,000 m3/h to Nizhnetagilskij Metallurgicheskij combine (NTMK) in the region of Swerdlowsk. The filters are employed in the conditioning processes for coal and coke before the inlet to the blast furnaces. They are designed pressure shock resistant because of the danger of a dust explosion. A residual dust sensor supervises the flawless function. This order was received from the Russian partner SovPlym. Apart from heavy industry there is an increasing demand for superior filters in the Russian food and pharmaceutical industry. Latest orders from Russia are determined for these sectors. The filters for the pharmaceutical

Gericke customers increased their bulk handling know how How can sources of bacterial contamination and sediments already be reduced to a minimum when planning a system? Which steps ensure fastest possible process from product idea to industrial mixing system? Participants at Gericke’s 2012 customer seminar received compre-hensive answers to questions like these. Just under 120 participants from 59 different compa¬nies took the opportunity to attend the customer semi¬nar held by the bulk material pioneer from Regensdorf in Switzerland. The fact that visitors came from ten different countries shows that it is worth travelling a considerable distance to participate in a seminar of this kind. Hygienic solutions – from simple coffee pots to indus¬trial plants – were presented by the guest speaker, Hans-Werner Bellin. As an expert for hygienic design, he explained the legal basic principles in Europe and using positive and negative examples. He showed how one can protect a product from unnecessary contaminants

MWS300-BW belt scale direct connection to DCS/PLS This weighing electronic for belt scales is suitable to almost all mechanical belt scales with load cell sensoric. modern interfaces like Profibus-DP and Modbus/TCP allow direct link to PLC/ PLS/ DCS systems. Stay with your mechanical belt scale and add new MWS300-BW electronic to your system, or chose belt scale mechanic independent from electronic supplier to have a powerful weighing solution. An impulse output scalable x kg/imp. is still available to fit old system requirements. Besides belt scale this hardware can fullfil also loss-in-weight and hopper scale functions.

Technical and intercultural exchange at Berlin-Adlershof headquarters in February LUM GmbH, market leader in innovative instruments to analyse dispersions, welcomes its world-wide partners now to the 13th international technical and intercultural exchange at Berlin-Adlershof headquarters from 27-29 February. Here, the fundamentals are established for the LUM growth during the next years. “We have managed to increase the turnover in 2011 by approximately 24 %, compared to 2010. Now in 2012, we are working hard for further growth and we are optimistic despite alternating forecasts for the international business development. The export plays an important role for LUM. The formula for success of our own US subsidiary and of our Japanese partner Nihon Rufuto, Co., Ltd. must be transferred to other countries. For further use of the positive aspects of globalization, for competent and fast support of local business units of multi-national companies and world-wide research networks, we regularly qualify our distributors“, explains Prof. Lerche, Managing

Product safety for food, biotechnology or similar applications Apart from the legal requirements in particular the EHEDG guidelines provide valuable directions and specifications for the hygienic and aseptic design of equipment, systems and complex production facilities. These have also to be considered for a hygienic conception of production processes for solid product forms. As a system provider of equipment for solids process engineering and an active member of the EHEDG-subgroup "dry material handling" Glatt Ingenieurtechnik Weimar makes its contribution to the development of guidelines in this field. Results from many years of experiences are considered in the relevant documents. To be able to produce under hygienic conditions a HACCP concept is developed together with the customer. Various requirements resulting from this concept have to be considered. Glatt Ingenieurtechnik has many years of experiences in this field. Several production facilities with specific hygienic and cleaning requirements have already been

with RETSCH”s Vibratory Disc Mill RS 200 For the rapid size reduction to analytical fineness of hard, brittle and tough materials, the new Retsch Vibratory Disc Mill RS 200 is the product of choice. The new model grinds samples such as minerals, cement, concrete, soils and also electronic scrap not only extremely fast but also with excellent reproducibility. The new features include: • Optimized drive kinematics: The main directional movement of the drive train is secured in a plane which prevents the jar from gyrating or tumbling. This leads not only to increased reproducibility but also to an extremely quick formation of the movement pattern inside the jar and thus to very short grinding times. • New operating concept: All grinding parameters can be set via one single button, the current settings can be read off a graphics display. For the RS 200 up to 10 parameter combinations can be stored. • Improved grinding sets: The grinding set geometry was further optimized to increase the

Haver RPT The sample reducer HAVER RPT produces small but representative sample quantities of solids and suspensions and is combined with high-accuracy analytical measuring instruments. It is used in research, development and process monitoring laboratories. Rotating sample reducers combine three dividing methods in one unit and provide the best possible sample reducing available today. The sample is fed to a dividing cone that emulates the process of quartering and coning. The sample material on its surface is accelerated outwards by rotation and is divided through guide channels into up to 30 individual samples. The individual samples are collected in 250 ml and 500 ml glass screw-top bottles which can be easily and reliably secured by means of a quick-release clamp. The rotation and number of dividing channels enable variable dividing conditions to be achieved up to 3,000 dividing steps per minute. This means that each sample consists of a very large number of individual

Bladel February 8th. 2012 – In the fourth quarter of 2011 KSE received a fazed order for the bulk out loading process of Perfect Companion Group (PCG) in Thailand. This order includes both, ALFRA dosing slide platform, The ALFRA Bulkweigher, frame for movable blenders and the PROMASst automation software. The process The ordered parts are intended for filling the hoppers. First, the exact composition of the various pet food grains of PCG is dosed by the ALFRA dosing slide platform. The exact composition goes through the platform to the movable ALFRA bulk weigher. Then the pet food goes to the blenders, where it will be mixed on moving and it will be loaded in the hopper. Then out of the hopper it will be packed in the packaging line. December 2011 PCG preferred the PROMASst automation software of KSE. The automation will take care of enough finished product to the packaging line to run continuously. “The transport to Thailand was quite a challenge, because

Bladel, 27 January 2012 – KSE Process Technology B.V. has bundled her years of experience in the PremixMineral into an analysis tool. This tool can be used for the ideal design of a factory, taking account into all current and future variables and all disciplines. Analysis First, with the participation of the different disciplines in a business, all variables are mapped. The Executive Board, the production manager, the nutritionists and the quality managers provide their input to make a good analysis. The amount of raw materials, ingredients, the percentages required in recipes, the size of batches, the production hours (per day and per year), the supply of raw materials, etc., are all mapped. Since each recipe is company specific, absolute confidentiality is guaranteed. Output of the analysis The tool processes all data for an accurate view of all design parameters; for example the capacity of dosing and weighing systems, the number of silos, the contents
