News items July 2011

Busch has significantly extended its series of dry-running Mink claw vacuum pumps. To achieve this, vacuum modules were designed that achieve suction capacity of up to 900 cubic metres per hour and more through the combination of several Mink claw vacuum pumps. These Mink MP vacuum modules were designed for operations which require high suction volumes, dry compression and high availability. Thanks to their modular construction, Mink vacuum systems can be excellently adapted to changing process conditions by altering the number or size of the Mink claw vacuum pumps in operation. Mink claw vacuum modules work extremely economically thanks to their non-contact compression principle. Because the moving parts in the compression chamber do not come into contact with one another, the vacuum pump operates 100% wear-free. Operating fluids such as oil or water for cooling or lubrication are not needed in the compression chamber. For the operator, this means almost no maintenance

Club Tester measures the quality artificial grass In the Netherlands people live by the thought that measuring is the key to knowing. This grew from the wish to keep everything under control. Numbers don’t lie, so we measure everything. Even in the most popular sport in the Netherlands (and the world): football (soccer), voices are rising to take all variables in hand an rule out the factor of luck as far as possible. In this standardisation of circumstances is the solution, starting by making the field artificial grass instead of the unreliable natural grass. When this grass then is measured in quality and other parameters, a “standard” field is on it’s way. This now is made possible by Deltec, in close corporation with Armac! The number of football fields with artificial grass is steadily growing, but is still a precious commodity for most clubs as well as community or public sport providers. Of course, grass needs a lot of attention as well, but also artificial grass only is optimised when installation

Dialight DuroSite Low Bay The Dialight LED Low Bay lighting fixtures DurositeTM were specifically designed to replace conventional lighting in a wide variety of applications, both indoors and outdoors. The compact weight, shape, and the many mounting options, makes this fixture ideal for use in parking lots, garages, cold storage and other applications with mounting heights up to 6 meters. All Dialight industrial lighting is designed to meet the most demanding specifications, with a maximum energy saving, low maintenance and superior light quality.

Screws are accurately positioned on the screwdriver Expansion of range with 1.2 l bowl and mini-device with piezo technology One of the main issues related to automated assembly of components is the precise feeding of the assembly components. Regardless of whether you are assembling extremely small screws or larger hexagon nuts – their availability on time and accurately positioned for the assembly process determines the productivity of a system. 30 years of experience in feeding technology for automatic feeding of screws, rivets, bolts, nuts, washers, O-rings, symmetrical and non-symmetrical components, form the basis for new developments guaranteeing nothing but the highest precision and reliability. Valuable additions to the wide assortment of feeding technology, tailormade to customer requirements, are to be introduced by the automation expert DEPRAG SCHULZ GMBH u. CO. at this year’s MOTEK fair in Stuttgart. The “6” Series program of vibratory bowl feeders for handheld screwdrivers will now be extended

Chinese delegation of the Chongqing Steel Group visited UWT in mid-July High-ranking managers of the Chongqing Steel Group of China together with the managing director of our company in Shanghai were guests of UWT from11th to 17th July. The Chongqing Steel Group is one of the major steel companies in China and is part of the clientele of UWT for years. On Monday afternoon just when the Chinese delegation arrived in Betzigau the gentlemen were welcomed with alphorn music in front of the UWT-building. After the welcome a detailed guided tour through the company followed. The next day items of the agenda were project meetings regarding expansion of the facilities in China and various product presentations. And to show the visitors a little the beautiful Allgäu trips to the Alpsee and the obligatory visit to the castle Neuschwanstein followed. Furthermore the delegation visited the house of Bavarian economy in Munich, where they could enjoy - after an excellent presentation on the German-Chinese economic relations - an original Bavarian

Tried-and-tested milling technology? Expect more! It pays off to go beyond what others think possible – that’s been our motto all along. Tried-and-tested by NOLL means: like no other we synergize our practical experience in powder processing and systems engineering with technological ingenuity and spirit of invention. This is how we develop the most economical solutions in fine particle technology, ahead of time and competition. NOLL continually puts knowledge gained from practice into practice, giving you and your products new momentum to set quality standards in your market. By the way: July 1, 2011 marks 20 years since engineer Ulf Noll started his own company. It’s in our nature to celebrate this anniversary by presenting NOLL and our developments in a familiar yet surprisingly innovative appearance. Come and have a look at POWTECH trade show in Nuremberg, 10-13 October 2011, where we look forward to welcoming you at our stand.

Dinnissen introduces new functionality The Pegasus® Vacuum Coater is a valuable and flexible tool for every company involved in the production of granular and extruded products in compliance with modern requirements. It allows producers in the feed and food sector to create a vacuum environment within their production process, which in turn enables them to effectively deal with a wide range of challenges. Dinnissen is now introducing a new application for the vacuum coater on the market: “drying a wide range of ingredients at low temperatures.” The advantage of this novel drying process is that it ensures complete retention of taste, colour, vitamins, minerals and enzymes. Until now, the Pegasus® Vacuum Coater has been used primarily to add essential substances - including aromas, oils, vitamins, minerals and enzymes - to granules and extruded products. The Pegasus® Vacuum Coater makes it possible to add the precise amount of powder or liquid required, after which the added substances are drawn

Uninterrupted spraying, even over your head Spraying over your head is not possible with standard spray bottles. As soon as the suction tube is no longer immersed in liquid, you can"t spray any more. No so with our overhead spray bottle Turn"n"Spray. It features a special technology that allows you to spray from any position. That means you can spray practically and conveniently from any direction and reach hard-to-access places easily and without straining. The high-quality, refillable quality spray bottle can be used again and again. For more information see: www.buerkle.de/shop/_turn-39-n-39-spray-spray-bottle.html

The vertical conveying of bulk solids with conventional machines like belt bucket elevator or belt conveyor with corrugated side walls can become a hard resolvable problem very often. That is why DOUBRAVA engineered the new TWIN BELT CONVEYOR. This twin belt conveyor has one big advantage that also at the conveying process with adhesive, wet bulk solids the material can be released from the belt during dropping a 100%. Furthermore the belt can be cleaned like conventional conveyors using wiper systems like it is usual on the market. The belt guide has no limits too: a change from the horizontal to the diagonal or vertical and also the craning conveying road are no problems. Bevor dropping the conveying road can cross over any long horizontal without problems again.

with Retsch"s Air Jet Sieve AS 200 jet The new Air Jet Sieve AS 200 jet is particularly suitable for sieve cuts of powdered materials which require efficient dispersion and desagglomeration. An industrial vacuum cleaner generates a jet of air which disperses the particles on the sieve through a slotted nozzle. The material which passes the sieve is transported to the vacuum cleaner or to a cyclone for recovery. The option to store up to 10 SOPs and the automatic vacuum regulator (accessory) guarantees reproducible and meaningful results. Innovative features such as the Open Mesh function, the selection of the nozzle speed as well as optional use of standard 2" high test sieves perfects the new air jet technology. The procedure is very gentle on the material, the average sieving time only takes 2-3 minutes. Benefits: • Gentle sieving with short sieving times • Reproducible results due to Open Mesh Function • Suitable for 203 mm (8 ‘’) test sieves • Automatic vacuum regulation

App and mobile sites available for the first time from mid July The exhibiting companies are always the heart of an informative exhibition. Over 1,000 exhibitors from all over the world are expected again in Nürnberg from 11–13 October 2011 to present products and services from the segments of mechanical processing technologies, instrumentation and life science technologies in the six halls of POWTECH and TechnoPharm. The exhibitions are supplemented with a particularly extensive supporting programme: from explosion protection and hygienic design to Cleanroom Village and sustainable packaging solutions. In order to keep track of things before the exhibitions, NürnbergMesse now offers a brand-new service with app and mobile sites to help mobile terminal users to ideally prepare for their visit to Nürnberg on the move. All press articles, more detailed information and photos are available at: www.POWTECH.de/press and/or www.TechnoPharm.de/press

Dynamic weighing from fertilizers and phosphates Over the past four decades Precia-Molen has established a worldwide reputation as the leading supplier for weighing equipment for use in bulk transhipment and storage facilities. The proven concept of one basic design for multi purpose applications in intake, transhipment and out loading operations, makes the standard ABS-xl scale suitable for a wide range of dry free-flowing bulk commodities such as cereals, expellers, tapioca, soya meal and many derivatives. Special version are available for fertilizers, sugars and liquids. The standard Automatic Bulk Scales type XL are suitable for dry and free flowing bulk products with a bulk density of 0.5 – 1 t/m3. Products with lower bulk densities are also handled by the ABS and specials designs always possible on request. For products with higher bulk densities (for example fertilizers up to 1.2 t/m3) small modifications are sufficient. Precia Molen received last year a special demand from customer for weighing

Product training for the new Japanese sales partner UWT is continuing the expansion, and since December 2010 we have a new sales partner in Asia. Four employees of our new partner JMC in Japan have been here in Betzigau at the end of May for two days for an intensive product training. The gentlemen came from Osaka and Tokyo. Our Product Manager, Mr. Johannes Blochum, instructed the employees of JMC in an intensive training on the skills which are necessary for successful sales of UWT products. The training contents were a basic product training for all UWT-products, in-depth basic knowledge of the products SN/VN/NB, practical exercises on the NB (setup, change of rope/tape, PCB replacement), introduction Nivowave (startup NW, connection to PC) and applications, application examples and success stories. According to the program the evening took place in a typical cottage with Allgäu flair and Bavarian hospitality, what the Japanese guests enjoyed very much.

Distributor CNN organized a seminar in Kuala Lumpur In the beginning of May our International Sales Manager, Mr. Markus Schalk, was away on a seminar and customer tour in Malaysia. On this trip Mr. Schalk performed three half-day seminars. The first technical seminar entitled "Solid Level Measurement - Overview About The Different Technologies" took place in Dorsette Hotel in Kuala Lumpur. The organization was adopted by our distribution partner in Malaysia, CNN. Mr. Schalk explained to the participants the different products for level measurement from UWT. The group of participants consisted of decision makers in the various industries such as power plants, animal feed plants, plastic processing industry, etc. There were many relevant examples shown and discussed. Further seminars were carried out in Johor Bahru Malaysia (south) and in East Malaysia in Sarawak. The time between was used for various customer visits. Summing up we would like to say that the seminars were well attended and the feedback was very positive.

The flexible solution for problematic bulk goods Down-pipe systems often require redirecting or discharging of product fl ows to different processes. The Roweflex® 2-way diverter valve solves this problem in a particularly effective manner by using a fl exible elastomer Y-tube. Advantages of the Roweflex® 2-way diverter valve: • Absolutely dust-proof • No metal parts inside • Self-cleaning due toe fl exibility • Double seal on the switch bracket • No cross-section reduction in the product area • Available in ATEX version • FDA-compliant Y-tube part available Applications areas of the Roweflex® 2-way diverter valve in industry: • Food products • Pharmaceuticals • Carbon black and tyres • PVC processing • Toxic media • Colour pigment production • Colour pigment processing

Evolution in the design of high-efficiency agitator bead mills The design of the new DYNO-Mill ECM AP is impressive and innovative, both in operation and in technology. The main advantages for you below: • New separation system of the WAB DYNO-MILL ECM-AP Series • New design provides higher throughput and capacity, especially for highly viscous products • Less wear on contact parts • Ability to grind with bead size 0.1 mm The new ECM-AP is designed to perform single / multi-pass or circulation with a constant efficiency in both processes to achieve nano size particles. The patented DYNO®-Accelerators produce a powerful, hydraulic movement of the beads which guarantee a high and constant energy input and due to its efficient enery input the has a low energy uptake. The mill provides an improved product throughput and longer life of the screen. The ideal cooling properties allow the processing of temerature sensitive productsf, better ability to handle highly viscous products and foaming products. Besides optimizing

If the creation of ideal mixing goods is intended, most certainly all kinds of mixers on the market are able to handle the task. If furthermore a complete discharge is needed, the choice is a lot smaller. amixon® has developed a solution for those high requirements: the process is called “ComDisc”, as a short form for complete discharge. It is a new system providing a carry out of the mixing good up to 99,997% and more. The working principle: The lower mixer arm is fitted with one or more wings. During mixing the system moves into the shadow of the flow and turns to the rear. As the filling level decreases, the ComDisc® elements turn in the direction of rotation and gently scrape the mixture residues towards the outlet. The gadget does not touch the floor of the mixer. Together with the SinConvex® Technology, it is possible to reach a nearly complete discharge of the mixer. The carry out of the mixing good happens without segregation, cleaning times can be

Subsidiary Masterflex Cesko s.r.o. launches own sales activities in Czech Republic and Slovakia Masterflex AG is further expanding its international presence and, effective immediately, operates on the Czech and Slovakian market directly through its own subsidiary in Planá/Czech Republic. In the past, the subsidiary in the Czech Republic only produced vulcanised hoses from neoprene or silicon and coated glass fabric using state-of-the-art equipment. In addition to drying equipment in the plastics industry, classic applications for these hoses include automotive, aircraft and engine manufacturing. Local sales in the Czech Republic and Slovakia began at a trade fair appearance at “For Industry”, an international event showcasing the full diversity of industrial production. Dr. Andreas Bastin, CEO of Masterflex AG, says: “The step of no longer just manufacturing in the Czech Republic and Slovakia and instead offering customers the full range of the Masterflex Group locally and with greater proximity is the next systematic stage in continuing our strategy

Award for Metallic and Steel building Technology Traineecompetition in the industry branch of WKOÖ 2011. On the 30th of April 2011 our Metallic and Steel building Technology trainees of the 2nd year as an apprentice compete voluntarily with other trainees in this sector again. It took them nearly 6 hours. During this time they had to create a work piece by marking out, cutting, drilling and so on. In line with the award at the Linzer Design Center the winners were honored. From around 130 participants Doubrava trainees came in first, second and two of them in third. 1.) Patrick Humer 2.) Sebastian Seiringer 3.) Patrick Höller und Daniel Riss

Nürnber, Germany 11.-13. 10. 2011 As every year we also attend at the international Trade Fair for Mechanical Processing, Technologies and Instrumentation, better known as "Powtech", this year. We are happy to welcome our visitors in hall 6 at booth no. 250 and to inform them about our offers and news, alternatively to network our customer relationships. To create a comfortable clime for our visitors, a well arranged booth is very important. Furthermore it is a matter auf course for us to arrange for adequate information material.

Practical entry into the complex world of screwdriving technology and automation The new DEPRAG Website answers all questions about assembly technology The engineer Peter Feldmeier (Dipl.Ing. (FH)) is studying the construction plans. He looks once more at the specification of the assembly equipment for which the medium-sized engineering office IBF has secured the order for project planning and construction. For production start-up, a process-safe manual workstation will do, he thinks. Later when the volume of production increases, partially or fully automated assembly equipment will be recommended. But what he needs now is detailed information and an informed introduction to screwdriving and assembly technology. Best would be information from one source is clear, concise and understandable. He thinks that the Internet would be a good source for information. This should result in consultation with a competent equipment manufacturer. Peter Feldmeier sighs. He thinks of surfing for hours and hours in the Internet to find answers to his many questions

Optimal for comminution with minimal cleaning effort Ideal for size reduction of soft to medium-hard, tough-elastic and fibrous materials as well as for heterogeneous mixtures. They are indispensable in the areas of plastics, textiles, agriculture, forestry, environment, construction materials, chemistry and foodstuffs as well as for analytic and sample preparation for RoHS-analysis. Unmatched ease of cleaning A particularly important criterion for a Cutting Mill is the question how fast and easy it can be cleaned in daily laboratory use. Therefore we have placed particular value on the easy cleaning when we developed the FRITSCH PULVERISETTE 19. Unbeatable fast, simple and efficient cleaning! The entire grinding chamber can be opened easily in seconds and both the rotor and the sieve can simply be removed with simple motions. Only at FRITSCH Cutting Mills it is possible to lift open the entire top part of the housing as well as the door – in fact, the door can be completely removed. And that’s not
