News items January 2011

Quality management begins with the selection of the stationary screwdriver. EC motor or compressed air screwdriver? What determines the type of drive? The achievement of zero defect production has the highest priority in industrial assembly. Time and again we hear of product recalls due to defective screw joints. The associated material damage and loss of brand image is the dread of every industry. And when it relates to safety-relevant components such as in the automotive industry then the manufactures make every conceivable effort to ensure maximum process reliability throughout the installation process. The selection of the correct tightening tool for industrial mass production is the cornerstone in creating a high quality fault free production system. A threaded fastener is intended to clamp components together so that external forces cannot cause them to come apart and the parts essentially behave like a single unit. The designer calculates how high the applied clamping force must be so that the screwed or bolted component can withstand

The worldwide operating German company WIESE Förderelemente GmbH will exhibit their improved range of Pendulum Bucket Conveyors (P) and Continuous Bucket Conveyors (SEB), which are designed to convey powders, granules and bulk materials gently in minimal space horizontally and vertically, especially in the chemical, confectionary and food industry. The conveying good is resting undestroyed in the buckets during transport. The main advantage is the unique rubber chain, which is stretch, link and grease free, has increased “up-time”, meets food standards, has no metal-to-metal abrasion and a noise level below 60dbA. Detailed solutions according easy to clean or conveying good safety are Wiese’s standards. For example it is possible to deliver magnetic detectable bucket materials or open frame designs made from tubular profiles including quick release covers. Furthermore various bucket sizes and shapes are available like special surfaces for better discharging

Pendulum Buckets made from magnetic detectable Plastic Detectable Conveyor Buckets made from food approved magnetic detectable polypropylene WIESE is doing a lot of research on new materials for the product touching conveyor buckets securing the conveyed goods. Most of the pendulum bucket conveyors are delivered into the cosmetic, food or confectionary industry. For this reason product safety of the conveyed goods is one of the main issues besides easy cleaning. It is important to be able detecting possible particles being chipped of the buckets which could fall into the product. In former days mostly colours were used to solve this task. WIESE has developed as the first and only company worldwide a polypropylene material which is magnetic and food approved also. Six months lasting test runs at German food manufacturers showed a great success. For test reasons small particles, smaller then diameter 5mm, were placed inside the packages

The sealing unit for agitators and mixers With its patented sealing unit PS-ProSet® Garlock has technically advanced and standardized its existing and continually successful PS cartridge. The PS-ProSet® is a suitable alternative to a mechanical seal and packing and turns the weakest link in the production process into a real success factor. This advanced unit can help cut costs due to downtimes in the production process, caused for example by agitators and mixers. In addition, fast reaction times and reduced delivery times are guaranteed by its standardization. This solution makes it possible to meet the increasing requirements of industrial applications with regard to safety, maximum productivity and reduced downtimes successfully. Practice Plus • Can be used for pressure and vacuum • Suitable for high circumferential speeds • Temperature range up to +260 °C • Excellent chemical resistance to different media • FDA conformity allows it to be used in the food and pharmaceutical industry •

Sensocon, Inc., a leading manufacturer of differential pressure, air velocity, and flow products, announces the newly optimized design of its Sensocon™ brand Series S2000 Differential Pressure Gauges. Since their initial market introduction, the Sensocon™ brand Series S2000 Differential Pressure Gauge is a reliable Differential Pressure Gauge based on time proven principles for low differential pressure measurement. The newly optimized Sensocon™ brand Series S2000 Differential Pressure Gauge now has additional advantages. Based on third party testing to date, the Sensocon™ Series S2000 Differential Pressure Gauge has been proven to be RoHS compliant and to conform to CE. Sensocon, Inc., has also extended the warranty for the new Sensocon™ brand Series S2000 Differential Pressure Gauges to 2 years based on the new optimization and a history of quality and reliability. To mark the new optimization of the Sensocon™ brand Series S2000 Differential

Ravindra Vithal Phadke takes over the management By January 14, 2011, Ravindra Vithal Phadke took over the management of Intensiv-Ffilter India Pvt. Ltd. He follows Rammesh Rathi who deceased suddenly and unexpectedly in the end of 2010. „With Ravindra Vithal Phadke we could win a very experienced and high motivated expert from the dust removal branch who together with our entire team will define the path for a furthermore successful future of Intensiv-Filter India “, underlines Thomas Blüggel, managing partner of Intensiv-Filter. The 51-year-old Ravindra Vithal Phadke was employed by Rieco Industries Ltd since 1997. During his occupational years with Rieco, last as a general manager, he was responsible for various national and international projects and the expansion of the business activity.

Delivery of several dedusting units to russian steelwork After in summer 2010 Infastaub carried out successfully an order for the equipment with dust removal filters at the russian steelworks Novolipetsk, a great order for the equipment of a Russian steelwork has been awarded once more to Infastaub in December, 2010: The Nizhnetagilskij Metallurgicheskij combine (NTMK) in the region of Swerdlowsk orders through our Russian partner SovPlym seven dust removal installations for volume flow from 6,000 to 24,000 m3/h. The order comprises different types of the type series AJN with different filter areas and volume flows and will be delivered between end of february and mid of March. The filters are used in the treatment processes for coal and coke before the supply to the blast furnaces. Because of the danger of a dust explosion they are designed pressure shock resistant. A sensor for residual dust supervises the proper function. With this order the positive development of the filter business with Russia is confirmed after

Weigh Feeder for Siemens PLC easYcont was developed as a standard package to realize the functionalties of Weigh Feeder, Belt Scales, LIW Feeder especially within the Siemens S7(R), PCS7(R), WinCC (R), WinCC flexible (R) und OPC environment. Therefor all Siwarex Controller can be used, according to specifications. With the development of easYcont, useful function for a stable and accurate operation were implemented, like manual or automatic test weight functions, belt influence and tare, belt slip and a lot more. Prefeeder, additional drives, vibrators and control loops can be implemented optionally.

can be used to read up to 64 weighing systems VWO’s multi channel wireless weighing systems RCB5000, is designed for a reliable transmission of all types of weighing systems over distances up to 3000 m in industrial environment, it is enabling a significant reduction in all types of control and measurement cables between units and the PLC/automatic controller and between units themselves. The receiver part of RCB5000 systems can be used to read up to 64 weighing systems. Principle The basic RCB5000 weighing system includes a transmitter unit and a receiver unit for up to 200m. The radio units can communicate in unidirectional or bi-directional mode using a single frequency (technology based on a transceiver). The transmission systems use a technology based on our extensive experience in this field (+/- 15 years), i.e. tried and tested in industrial applications such as steel works and foundries and in an environment where the electromagnetic interference may be very strong. They operate either in the

S+S has comprehensive know-how in the production of explosion-protected equipment From physics lessons everyone knows the impressive effects a single ignition spark has when it causes finely pulverised flour to explode in a vessel. Stephan Treml, S+S Product Manager for Magnet Systems: "Just imagine the devastating destruction a reaction that is many thousand times stronger might cause in an industrial plant. And explosions may not only be caused by flour dust or by highly flammable gases, under certain circumstances even products such as metal powder, sugar, herbs, wood chips, and pharmaceutical ingredients may show a very strong reaction. Even plastic powder, which generally has no reputation of being highly flammable, according to information of German property insurance companies causes 14 percent of dust explosions." Since 1 July 2003 equipment and protective systems for use in potentially explosive atmospheres must therefore comply with directive 94/9/EC (ATEX 95). One of the most essential changes of this directive was the separate

with RETSCH"s sieve shaker AS 450 control Particle analysis of large quantities of bulk goods is usually done by vibratory sieving. In most vibratory sieve shakers in the market the sieve stack is mounted on springs which oscillate vertically. However, to evenly distribute the material over the entire sieve surface, the so called 3D vibratory sieving as it is used in the AS 450 control is the most suitable method. This is characterized by a circular motion superimposing the vertical throwing motion so that the sample material is moved over the whole sieve. The video illustrates the advantages of the three-dimensional sieving motion and of the CET technology patented by RETSCH in comparison to conventional sieve shakers.

The 30th ACHEMA in 2012 will once more be the leading international meeting place for experts and de ACHEMA is already arousing intense interest on the part of exhibitors. The addition of the two-storey Hall 11 to the Frankfurt exhibition grounds has provided a welcome opportunity to showcase the individual exhibition groups better than ever before. Furthermore the western part of the exhibition grounds in particular benefits from the newly created entrance at Hall 11. The distribution of the exhibition groups in the halls has been dramatically reorganized in order to cater better for their individual needs. This chiefly affects the exhibition groups Instrumentation, Control and Automation Techniques and Pumps, Compressors, Valves and Fittings which have been allocated far larger areas than hitherto. Laboratory and Analytical Techniques, Pharmaceutical, Packaging and Storage Techniques and also Mechanical Processes will similarly find the reorganization to their advantage. "At first sight the hall allocation resembles a gigantic chess game", explains

Sieve mills in CIP design with no dead spaces In fine milling, product accumulates in and on corners, edges, recesses, and shaft bushings. The only way to dislodge these residues is by using large amounts of cleansers. These factors were taken into account in the design of the ConiWitt conical sieve mill. The ConiWitt is also now available in CIP design. Where solid residues are effectively bonded and removed due to optimized surfaces. The most important goal in the designing of the ConiWitt was a shape free of dead spaces. In order to achieve this goal, Frewitt opted for the monoblock design. The milling head consists of a monoblock with high quality surfaces (most of which are perpendicular) and a rounded drive and driveshaft. All metal contact surfaces of the CIP model are sealed off from the milling chamber with O-rings. The transitions between the rotor and the shaft, the conical sieve and the bevel gear, and the conical sieve insert and the housing are hermetically sealed. The seals do not interfere with

New concept eliminates infeed hopper Automatic hopper scales are still the most common intake and production scales for cereals, flour and fertilizer. Especially for poor flowing products there are nearly no alternatives to measure the production rate or the consumption of raw material. The new CSE hopper scale offers a concept, that eliminates the disadvantage of a hopper scale by the use of two parallel weighing hoppers. A pneumatic controlled switch feeder guides the product ialternative into two weighing hoppers. After filling the hopper the net amount of material is added to the total flow rate. The discharge system ensures, that the hoppers are completely emptied. Due to pneumatic operatation the scale has a very low energy consumption.

Markus Rinderspacher, leader of the SPD in the Bavarian parliament, visited UWT on 20th December. During the visit he was particularly interested in business and employment policy. On the one hand he was positive impressed by the worldwide business relationships of UWT and on the other hand by the company"s philosophy to employ professionals over 50 years. During his conversation with the UWT leadership the SPD politician was confirmed that this strategy has proven in the past to be very valuable. The experiences which older people contribute to the company were and will always be a corporate benefit.

ISO 14001 certification and new building Designing, manufacturing and installing automatic lubrication systems is the essence of the business of TrustLube. Their lubrication systems enable to reduce the amount of lubricant needed. Environmental responsibility and sustainability are very important to TrustLube. In December 2010 the certification body Det Norske Veritas (DNV) concluded that TrustLube has implemented their environmental management system successfully. They received their certificate for ISO 14001:2004 on December 27th. With this certification they wish to show and guarantee their structural focus on the environment in their business operation. They wish to control and try to improve their performance levels in the area of the environment. TrustLube managed to achieve four certifications within 2 years: ISO 9001, OHSAS 18001, SCC Petrochemical and ISO 14001. At the same time TrustLube is looking forward to moving to Oud Gastel. On the business area Borchwerf II they are developing a

Flexible hoses with system If a medium-carrying link must be movable and easy to extend or replace, hoses and not rigid pipes are the practical choice for that link. If heat losses in the carried medium must be prevented, a combination of hose and electric heating is the ideal solution. This combination is offered by the novel templine heated-hose system from Masterflex AG. The electric heating’s novel design yields significant savings in energy consumption. The templine heated-hose system is notable for having several heat conductors, arranged in a spiral round the medium-carrying hose and secured in stable textile braiding. Consequently, a uniform “heat envelope” is formed all round the medium-carrying hose during use. The temperature differences over the whole length of the hose are extremely slight. With templine heated-hose systems, “hot spots”, i.e. temperature peaks due to uneven heat distribution constituting a hazard particularly in areas where there is a risk of explosion,

Capacitive level switch CLS-53N& For limit level sensing of bulk-solid, fragmental and extruded materials •Detection of various types bulk-solid materials (pellets, wooden chips, granulates, cereals, sand, etc.) in various metal and plastic hoppers, containers, and silos •Simple sensitivity setting by means of magnetic pen •Two-wire connection directly to the contactor or relay circuit •Wide range of supply voltage (20 to 250V AC/DC)

Our courses aim to provide delegates with the knowledge to identify bulk solids handling problems and to teach them the techniques to overcome them. For details on the range of courses available, please go to our website: use the external link below.
