News items February 2010

The microwave barrier VEGAMIP 61 is especially designed for the requirements and special needs of the bulk solids industry. Since the microwave barrier measures contactlessly, VEGAMIP has no direct contact with the medium. This is advantageous particularly for abrasive products or very high temperatures. In such cases VEGAMIP 61 can simply measure from the outside through a microwave-permeable window, for example, of ceramic or plastic. Also in the area of liquid level detection or object detection, the microwave barrier offers many advantages over other measuring principles. The microwave barrier consists of a VEGAMIP T61 transmitter and one or several VEGAMIP R61 receivers. The receiver measures the attenuation of the received microwave signal and generates a switching signal from it. VEGAMIP can be used as a maximum or minimum sensor. Its switching delay can be set between 0.1 and 20 s. VEGAMIP 61 is fully integrated in VEGA`s plics concept and offers all

Feeding particularly low feed rates when hygiene is a central issue presents challenges of its own during production. This situation mostly arises when cost-intensive products are being handled or when small amounts of ingredients already have a decisive influence on the final product. The new DIW-PE-GZD200 „Small Scale Feeder“ with its innovative details has been specially designed for the requirements of minor ingredient addition. The modern weighing system ensures highly accurate feeding results in connection with the twin-screw GZD 200 Loss-in-Weight Feeder. The GZD200 Hygienic Feeder comes with specially polished surfaces, machined sealing grooves and is suitable for quick and easy disassembly and easy cleaning. This device corresponds to the requirements of the food and pharmaceutical industries on account of its modular design. The feeder is suitable for feed rates ranging from 0.2 l/h – 10 l/h. The mass flow is virtually pulsation free. Conveying of

Gericke’s Multiflux® mixer GMS creates with its 2 horizontal, overlapping mixing rotors a fluidized bed. As a mixing process is based on the exchange of the particles in a volume by convection, this principle is very efficient for the energy-saving and product respecting mixing. The GMS mixer is known as long-lasting and reliable process equipment. In order to complete its existing range, Gericke has made a redesign of the GMS Multiflux mixer that responds to the increasing demand for hygienic execution in the food and pharmaceutical industry. The new model is called GMS C. C stands for cantilevered and refers to the 2 shafts that are cantilevered, offering many advantages. Not only the number of sealing is divided by 2. Due to the construction, the front side of the mixer can be opened entirely. In the high end version, named the GMS ECD, the operator can even pull out the complete drive and mixing shafts out of the body. Large lateral doors offer an easy access

A lightning strike can put a vehicle scale out of service in an instant. Lightning damage can be very costly, requiring the replacement of unprotected electronic equipment. Even if a warranty covers repair costs, you still face the cost of the business you lose every day that your scale is not operating. METTLER TOLEDO provides complete protection against lightning damage. The StrikeShield™ protection system is designed to be the main line of defense for your entire vehicle scale system: load cells, cables, and terminals. The average lightning strike is approximately 30,000 amperes. The POWERCELL PDX load cell system has been proven in independent testing to survive multiple lightning strikes up to 80,000 amperes. That`s more than twice the destructive power of the average lightning strike. No other scale manufacturer has had its system as thoroughly tested by independent laboratories. Back in 1988, METTLER TOLEDO introduced the POWERCELL load cell, the first

Metal separators provide tool and machinery protection for injection moulders For a world leading manufacturer of injection moulders, quality is of highest importance. When problems occurred in the production process, caused my metal particles within plastic granulate, the company decided to install magnetic separators. S+S Separation and Sorting Technol-ogy provided ten SAFEMAG magnet systems for a test phase. The test results were excellent and by now over 1000 injection moulders are equipped with magnet systems. The magnet systems developed by S+S can be installed directly at the material feeder of injection moulders, below the metering unit. They work as a “last chance controller” to ensure metal is separated at the last possible stage. An important advantage of this type of installation is that only one magnet system per machine is needed. The injection moulder required a flat design to ensure that the magnet system could be installed in existing machines. Reconstruction of the pipelines above the machines would have been both

Feeding and discharging technology: new developments and product line cross section Being one of the traditional POWTECH participants, Brabender Technologie KG of Duisburg, Germany, are once again exhibiting their latest developments and a representative cross-section of their comprehensive product line for powder and bulk solids metering and discharging. Visitors from all bulk solids processing industries will find an ample variety of interesting state of the art feeding and discharging systems, for instance ● The Brabender FlexWall®Plus Feeder in classic design featuring single and twin screws ● The Brabender DualTray Feeder with mass flow metering unit for damageable or lumpy ingredients ● The Brabender field bus system for multiple feeder installations with touch screen operating panel ● The Brabender JetFilter filtering exhaust air streams displaced during metering feeder refilling ● The Brabender bulk bag unloader "BagMaster" featuring a unique massage ring mechanism ● The Brabender bin activator

In response to the increasing demand for cost effective isolation solutions created by new directives, codes, and standards, Fike is excited to announce the expansion of its explosion isolation product offering. In addition to Fike’s fast acting mechanical slide gate valve and the chemical barrier system, Fike now offers a pneumatically operated explosion isolation pinch valve. The Fike Explosion Isolation Pinch Valve (EIPV), used in conjunction with other Fike explosion protection system components, provides a cost-effective solution to prevent deflagration propagation through interconnecting pipes or conveying lines to additional process equipment or operating locations. The EIPV System uses a heavy duty food grade elastomeric sleeve, high-speed solenoid valves, pneumatic accumulator; high and low pressure alarm switches, and shut off/bleed/manual operation valves. The features of the Fike product include: • Provides a mechanical obstruction to explosion

ProJet smart, the new compact filter of Intensiv-Filter, is introduced first on the POWTECH. The internationally established POWTECH offers the ideal platform for a product presentation, because no comparable fair offers such a concentrated range of mechanical processing technologies. Intensiv-Filter uses the exhibition as an occasion to introduce the small brother of the process filter class "ProJet mega®", which was introduced in 2008 also on the POWTECH. The filters of the new - inexpensive and easily available – type series bear the name „ProJet smart“ and are suitable for many ranges of application with volume flows of about 20,000 m ³/h. Compact filters of the design ProJet smart are especially compact bag filters with integrated fan, silencer and accompanying cleaning control system. The function of the filters is based on the jet pulse principle. The filters are cleaned by means of the highly efficient Intensive-Filter injector system with "ideal nozzle". The fully automatic cleaning system is part of the scope. The ProJet

Hygienic-Design according EHEDG - Guidelines The solids Rotary valve Type SRVS has been advanced by S.S.T.-Schüttguttechnik GmbH to Hygienic Design. It is easy to dismantle and easy to clean and has been planned acc. HACCP and EHEDG -guidelines, suitable for food stuffs, with extensible rotar and optional check guide rails. All rotary valves of this series comply already with the new machinery directive 2000/42/EC, which has been effective since 29.12.2009. Within the required risk evaluation also have been considered the microbiological, physical and chemical demands. The GMP- / FDA-requirements and the DIN EN 1672-2 are fulfilled with measures as: in contact with product polished (interior), ground, surface quality acc. required Ra-value, all sealings without any cracks, optionally electropolished, free of dead spots. Where total freedom of cracks and dead spots is not possible, it has been paid attention to easy dismantling and cleaning. The solids Rotary valve Type SRVS is also suitable for the use under

Discover new Markets at Filtech 2011 FILTECH is the largest special interest Event world-wide devoted entirely to filtration and separation technology. FILTECH is a must for all those concerned with designing, improving, purchasing, selling or researching filtration and separation equipment and services. At FILTECH more than 200 Exhibitors will feature the latest innovations and up-to-date filtration and separation technology on 7,400 sq m exhibition space. For many years now FILTECH registered substantial growth (2009: 42% more Exhibitors / 25,5 % more visitors) and enables the event to reaffirm its claim as the leading meeting place for mechanical separation systems and, to an increasing extent, for associated measurement and analysis systems. The Conference topics are fundamentals, equipment and strategies to “Solid-Liquid-Separation“ by filtration and sedimentation as well as “Air and Gas Cleaning“ by filtration, settling, electrostatic precipitation, scrubbing and "Membrane Separation Technology".

Vertical Helix-Dryer for Dietary supplements For a big manufacturer of dietary supplements in Germany a dryer-project has just been realized, which once more was a real challenge to the flexibility and modifiability of drying technologies. In this case there was a process of evaporating, in which the product in dependency of the inner pressure of the vessel has been brought to its boiling temperature. By applying of vacuum in the AVA-Dryer the product temperature is adjusted exactly according to the vapour pressure graph of the liquid component, which is to be vaporized. Through this an especially efficient and gentle drying is reached. The heat input is effected over the heated outer vessel wall, in which the heating medium is circulating. For rising of the drying capacity and to avoid caking the main shaft of the dryer as well as the whole helix can be heated over a rotary connection. The mixing procedure bases on a counter flow of product within the vessel. The AVA-Helix conveys the product continuously along

with the air jet sieving machine AS 200 jet The new air jet sieve AS 200 jet is particularly suitable for low density materials with particle sizes in the lower micron range. It is used with 203 mm (8’’) sieves of 10 microns mesh size or more. An industrial vacuum cleaner generates a jet of air which disperses the particles on the sieve through a slotted nozzle. The material which passes the sieve is transported to the vacuum cleaner or to a cyclone for recovery. The procedure is very gentle on the material, the average sieving time only takes 2-3 minutes. A special feature of the AS 200 jet is the Open Mesh Function which helps to greatly reduce the number of near-mesh particles. This provides optimum separation efficiency and also excellent reproducibility. Operation of the sieving machine is very simple. The Quick Start Mode allows to start the sieving process without previous programming. Benefits at a glance: • Gentle sieving with short sieving times • Reproducible results due to Open Mesh

pressure shock resistant and flame propagation proof as protection system acc. ATEX Dusts, processed in the industry, become more and more fine. In case of flammable dusts, together with air an ignitable mixture develops. With an ignition source, as sparks or hot surfaces for example, there will be an explosion. For the preventing of the expansion of blast waves and/or sparks or flames rotary valves in pressure shock resistant and flame propagation proof design are an approved solution, especially as they complete conveying- and dosing tasks. They are installed in front of pneumatic conveying, in front of and behind mills and hoppers as well as for the safety-related separation of single installation sections. solids – rotary valve Type SRVP was developed by S.S.T.-Schüttguttechnik for the use under Ex-requirements, pressure shock resistant and flame propagation proof. The dimensioning and design of the rotor, especially of the gap between rotor and housing has been constructed that way that the sparks, which approach with high velocity in

for long duration checking For process applications that require earthing for more than 6 hours per day, there is a brand-new mains supply designed on 230V or 110V to power the monitoring circuit of each indicator station. The IECEx / ATEX certified Universal Power Supply can provide continuous power for up to 10 GRP monitoring-indicator stations simultaneously. The monitoring-indicator stations can be mounted in Zone 1/21 hazardous areas with the IS power supply located in a Zone 2/22 area or local Safe Area. Benefits: - provides monitored earthing of up to 10 items of plant equipment at risk of static charge accumulation. - Provides option of bonding equipment for processes that last 6 hours or longer, including processes that require continuous static earthing. - Highly visible LED mounted in indicator station ensuring operators know when low resistance connection is achieved with potentially charged equipment. - Tungsten carbide tips bite through product deposits, vessel/drum

The refined concept of the ElevatorEX® II for bucket elevators, drag conveyors and transportation systems distinguishes itself by combining a variety of different proven features. Critical components on the elevators foot and head are protected by maintenance-free relief devices such as Q-Box II or bursting discs; Infrared detectors sense possible ingress of flame into the elevator shafts, feed openings or discharge chutes. Extinguishing barriers are activated within milliseconds at precise fixed points. Plant downtime is minimized while maximizing protection of the conveyer from disastrous dust explosion consequences with the minimum of investment. The ElevatorEX® II is the only globally certified protection system for conveyor systems.

with digital single signal processing and coincidence correction The welas® digital is a flexible, powerful and economical light-scattering spectrometer system, which determines the particle concentration and the particle size precisely and reliably. Using fibre-optic cables, welas® sensors – equipped with measurement volumes of varying sizes – can be easily attached to the welas® digital 2000 and 3000 and exchanged at will. These sensors make possible a reliable measurement in the concentration range from <1 P/cm3 to 10E6 P/cm3. The sensors are available for measurements in gases as well as in liquids. Temperature range sensors: from -90 °C to +70 °C (standard), optional up to 250°C; (higher upon request) Pressure range sensors: optional up to 10 bar overpressure (higher upon request) The welas® digital is based on the light-scattering analysis of the individual particle. In the new welas® digital, the particular advantages of the well-known and internationally proven welas® system are combined with a new and

Micro-Polar II (LB 567) is the new moisture measurement system from BERTHOLD TECHNOLOGIES, specifically developed for the measurement of bulk materials. It provides online monitoring on conveyor belts or chutes and can be easily installed at existing plants. The Microwave based measurement operates completely non-contacting. The components are not exposed to any wear and tear as the emitting antenna is mounted below and the receiving antenna is mounted above the conveyor belt. Therefore no maintenance is required. The measurement provides very representative measuring results by the penetration of all material layers. Due to technical improvements in frequency and frequency range, new opportunities have become available for applications, which had been restricted in terms of bulk density or particle size. Using the new system, even high bulk layers can be penetrated due to the increased dynamics. The multi-frequency technology used by Berthold Technologies ensures

Parallel event: the World Congress on Particle Technology Suppliers and production specialists from all over the world meet to discuss the latest innovations at POWTECH 2010 from 27-29 April 2010. Next year’s POWTECH will again prove its top position as Trade Fair for Mechanical Processing Technologies and Instrumentation. No other exhibition in the world offers such a combination of concentrated themes and a large number of international exhibitors and trade visitors. At the last event in 2008, 707 companies – including 209 international exhibitors from 26 countries – presented their products to more than 15,000 trade visitors. WCPT6, the World Congress on Particle Technology sponsored by PARTEC, takes place parallel to POWTECH next year, starting a day earlier on 26 April. WCPT6: news from particle technology The World Congress on Particle Technology (WCPT), supported by the PARTEC Congress, takes place next year for the second time parallel to the POWTECH/TechnoPharm duo. This world congress will concentrate and

Attractive supporting programme taking shape TechnoPharm takes place in the Exhibition Centre Nuremberg from 27-29 April 2010. This exhibition is the expert information forum for cleanroom technology, analysis and packaging technology for the production of pharmaceuticals, food, cosmetics, dietary products and health foods in Europe. The some 300 exhibitors at the last event showed the industries the latest developments and discussed current trends with specialists from research, development, cleanroom and GMP production, and analysis. TechnoPharm takes place in combination with the international exhibition POWTECH (mechanical processing technologies and instrumentation) and parallel to WCPT6, the World Congress on Particle Technology. With its concentration on life science process technologies, TechnoPharm offers a compact information forum for all the leading manufacturers of hygiene process components and the operators of cleanroom plants. This exhibition shows the exceptionally high innovation potential

This year PAYPER will participate in different international events. Firstly, the company will be one of the speakers at BULKSOLIDS INDIA 2010 International Conference and Exhibition Storage, Handling and Processing of bulk solids and powders, to be held in that country from 3 to 5 March. In this case, the presentation will focus on `Bags, bagging bulk products & systems - A general overview of the worldwide market and technology bagging”. PAYPER has entered strongly in the Indian market after securing an important contract in 2008 and 2009 with two petrochemical companies and expects to strengthen its presence in the country in future projects. Furthermore, PAYPER will also be present at POWTECH 2010 the International Exhibition for Mechanical and Process Technologies, to be held in Nuremberg (Germany) from 27 to 29 April. The participation will be carried out in cooperation with its German representative, the company SSB Wägetechnik; and both of them will take the opportunity to show their latest technology for the bagging
