News items November 2009

Realtime EtherCAT Master in successful use The control systems of the company Hundegger Maschinenbau GmbH are based on EtherCAT. Their first choice is the real-time master from Kithara Software, holding the role as a specialist for real-time control solutions again. More and more industrial enterprises rebuild their control technology and change their conventional field bus systems into innovative real-time Ethernet solutions like for example EtherCAT. For that, Kithara Software supplies essential function libaries for Windows-based PCs to realize time-critical applications. Developers benefit from a lean, demand-oriented programming and have full control over it. The real-time libraries from Kithara Software allow highly precise timers with several kilohertz and real-time Ethernet communication over selected Fast and Gigabit Ethernet network controllers. Using the preemptive multi-tasking, the EtherCAT master utilizes the highest system priority and thereby works in high precision. For this reason the

No Metal: Amazing air motors made from ceramic Developed for MRI (Magnetic Resonance Imaging) No Metal: Amazing air motors made from ceramic Generating growth and expanding market leadership with brand new concepts It is a company’s manpower which makes it more successful than its competitors, the decisive ambitious factor which results in constant development and realisation of new and innovative ideas. Highly motivated employees who provide a combination of creativity and knowledge make all the difference. Growth and expansion of a market position begins with a key person driving the ideas factory within the company. Germany’s machine industry is extremely competitive. It is a race to bag the contract as companies compete to provide the most suitable solution, quickly and flexibly, designed to fit the customer’s application and all at a great value price. Medium sized businesses such as DEPRAG SCHULZ GMBH & CO. rely on the inventiveness and expertise of their engineers. The internationally renowned

Pure ABS, PS and PP from electronic waste hamos GmbH Recycling- und Separationstechnik supplies a newly developed complete system for recovery of high grade, pure plastics from mixtures of plastics that are difficult to separate: clean ABS, PS and PP fractions can be produced in high purity with the hamos KRS recycling plant. Large quantities of mixed plastics arise when recycling electronic waste (WEEE) or automotive shredder residue (ASR). The materials contained here, such as ABS, PS and PP for example, are so heavily contaminated by other plastics, wood, elastomers and metals that further processing is not possible without additional treatment. The hamos KRS recycling system separates out pure plastics from WEEE or pre-treated ASR fractions. The equipment runs entirely automatically und has been designed for three-shift operation. The processing method of the hamos KRS system is so flexible that the most widely different mixtures of plastics can be separated. The previously broken up mixture of

Thai UWT partner organises very successful seminar for level measuring instrumentation In October 2009 our distributor from Thailand R.J.C. Associates Company Ltd. organised a most successful seminar about level measurement in bulk solids. Primary responsibility held the R.J.C. management with Mr. Prasit Chatcharith and Mr. Agsorn Rachanis. Markus Schalk, international Sales Manager at UWT, gave his lecture in front of top-class decision makers and engineers from different branches of industry such as animal feed, cement, glass, synthetics, building materials, etc. The numerous representatives from a variety of branches learned everything about level limit measurement with Rotonivo 3000 and Vibranivo 2000 as well as about the continuous UWT level measurement systems like Nivobob and Nivowave. During the full day event many descriptive examples for instrumentation applications were given and the participants could see for themselves the high quality and precision of UWT products by examining sample sensors. Last year a comparable event at our

Rotating Pipe Powder Sampler Sampling is done with a single rotating movement of max. 120°. In a fixed guide tube rotates a high polished internal tube. During sampling the inlets of the two pipes lay on top of each other. The sample freely drops out by gravity. The whole way of discharge the powder keeps moving on nad the product will protected from mechanical stress and grounding. An additional advantage is that the sampler has large free cross-sections for discharge. The quantity of sample collected can be varied as a function of the speed of the rotating movement. The system can automated for representative proportional sampling for a long period of time. The process connections and the construction materials will designed according to customer wishes.

powder sampler If samples for the analysis of cornsizedistribution are required, it is not enough to take a controlled section from the solid stream. In order to get a convincing evaluation of the overall product, we recommend to capture the complete product stream and to take a representative cross cut. Our cross cut sampler for verticle gravity chutes is well suited for this type of sample taking. Increments of powder or lumps of solids are taken out and delivered by gravity to a sample bottle or fall into a chute. When activated a cutter pivots through the full product stream, sweeping 90° arc, collecting a true cross-section sample. The cutter inlet is shaped so that all particles from any part of the cross-section have the same probability of being sampled independent of speed of movement. The collected sample quantity can be varied in proportion to the speed of the movement. In order to take samples proportionally over a longer period of time the cross-cut sampler can also be fully automated.

Fike announces the availability of a combined EHEDG and 3-A approval for the Sani-V/A and Sani-VS/A explosion vents. This makes the Fike explosion protection system unique in the world: never before such a combined approval has been achieved. The patented integral gasket design applied exclusively to this Fike product makes this new explosion panel preferred for all challenging applications in the food, bio-chemical and pharmaceutical industries where dust explosions can occur. The optimized venting efficiency, combined with the light-weight construction and full aseptic design features, provides a fully ATEX-compliant solution with minimal concerns regarding contamination related risks.

Barely one year after the takeover of the Holcim subsidiary in Venezuela by the state, investments are made to ensure the proper functioning of the system in the South American plant: The responsible managers placed with AUMUND Fördertechnik GmbH the order for one heavy-duty apron feeder with arched plates (2000/150/25+25) of type BPB-S-K and for two spillage conveyors for the limestone transport. This order for AUMUND means the medium term replacement of a still operating apron feeder with arched plates by the new machine that will be designed for a conveying capacity of 1050 t/h. The heavy-duty apron feeders are preferably installed underneath tipping points and transport uncrushed raw materials. The preferred materials to be conveyed on this feeder are uncrushed limestone of more than 1,000mm edge length, gypsum and other raw materials extracted from quarries. AUMUND apron feeders with arched plates can also be used to discharge moist and sticky materials such

Helical spiral mixers with a cylindrical mixing chamber have been around for about 30 years. This type of mixer is equipped with a centrally-mounted mixing shaft to which radial blade-like arms are mounted. These bear a helical spring that is adapted to the diameter of the mixing chamber. The mixture is screwed upwards at the perimeter and flows downwards in the centre of the mixing chamber. The market at that time demanded large mixers with lot sizes up to 12 m³, extremely short mixing times and a particularly gentle treatment of the mixture, especially in order to retain agglomerate structures that result, for example, from spray drying, without damage. In particular, it had to be possible to mix baby food with first-class solubility, good sinking behaviour and ideal dispersibility, ready to pack. Extremely high mixture requirements demanded a precision mixer. This was created by fusing two vertical single-shaft mixers to form a twin-shaft mixer. Precision

Already in 2008, Intensiv-Filter received the complete contract for the supply, installation and commissioning of a bag filter of the type "ProJet mega®" for one of the largest cement plants in Northern Europe. Client was the Cementa AB, a subsidiary of HeidelbergCement. The plant is located in the city Slite on the Swedish island of Gotland. After only six months of construction, the new and within the HeidelbergCement Group largest bag filter for the dust removal from the rotary kiln line 8, was successfully put into operation in early November. The initial startup was carried out by the Chairman of the Board of HeidelbergCement. In addition to the filter - designed for a volume flow of approximately 1.2 million m³/h - Intensiv-Filter was responsible for the pipes, the dust transport system, fan, steel works and the entire assembly. The pre-assembled steel components and ducts were transported by authorized and escorted heavy and specialized transport

Traditionally, the province Groningen has always been an area of grain cultivation. The cooperation Agrifirm receives, stores, dries and cleans the grain for her members. This happens in different establishments among which is Delfzijl. Over the years the capacity of the drier became insufficient. We supplied two new driers with strainers with a capacity of 25 tons/hour, a couple of chain conveyors and readjusted the existing installation. Long before the harvesting of the grain everything was installed and fully functional. Although the nice summer made sure the new equipment hasn’t seen a lot of action yet.

Configure your best solution Benzlers has provided a tool to make the selection of drives, gearboxes, spindles and Sala. It will be a lot easier now to get detailed information of these kind of products. You can download 2D / 3D drawings and technical details. More info: Benzlers main office at Venlo

for air-based quick, efficient and hygienic cleaning of mixing systems Dinnissen Process Technology has developed the fully automatic air-based Dry Cleaning in Place concept. The new method allows companies to clean their mixing and transport systems quickly, efficiently and hygienically. Weighing bunkers, mixers and storage bunkers are blow-cleaned, removing 99.9% of any residual materials. The system is especially suitable for companies in the feed, food and chemical industries. It allows them to benefit by reducing labour costs, minimizing downtime when switching from one product to another, preventing the loss of raw materials, and eliminating clumping, sticking/caking (contamination) and growth of microorganisms. Fully automatic cleaning system based on dry air Companies that wish to clean their mixing system after a product switch often do so manually using traditional cleaning techniques such as water, cleaning agents, and knocking or sweeping away residual materials. This is very labour-intensive and not always effective enough.

We believe that innovation is the key to surviving any crisis. That is why we keep investing in new equipment. Such as our new CNC plasma cutting machine, that can handle plates up to 30 mm thickness and a pressbrake, which supplies a pressure of 1.800 kN.

Many innovative products, especially new antistatic hose types acc. to the guidelines of TRBS 2153 Masterflex AG, Gelsenkirchen - November 2009 Masterflex AG Gelsenkirchen, one of the leading manufacturer of high quality and innovative hoses and connecting systems has released a new product survey brochure "Hoses and Connecting Systems". It contains many innovative products next to the basic range of products for various fields of application. The brochure contents especially plenty of new antistatic hose types acc. to the guidelines of TRBS 2153. The brochure is clearly laid out and comprehends the most fundamental information about each product from the wide product range of Masterflex AG. The simple structuring allows a quick search for the adequate product. Detailed technical information are published in the online web catalogue www.masterflex.de/com < products. The product survey brochure is available for free and can be ordered by e-mail: vertrieb@masterflex.de

TrustLube B.V. reduces grease consumption TrustLube B.V. from Willemstad proves that ‘less’ does not always need to mean ‘less’. In fact, with TrustLube®, less is always more! Less waste, more performance. Meanwhile, renowned names in the dredging and offshore industry have been using products and services supplied by TrustLube B.V. from Willemstad. Ships contain many moving parts which all need lubrication. With traditional lubrication systems, large amounts of excessive grease end up leaking into the sea, having all sorts of detrimental consequences. TrustLube® offers an alternative. TrustLube® lubrication systems are fully hermetically sealed. They guarantee you will receive the exact dosage, at the correct location, at the desired time, using the correct quantity. Lubricant wastage is therefore a thing of the past. Also, by using a higher grade lubricant, the chance of it being flushed away by seawater is minimal. There have been proven savings of up to 70%. TrustLube B.V. has been able

Bulk ingredient feeding, weighing, discharging and flow metering Available free of charge with immediate effect is a completely revised version of the interactive information CD from Brabender Technologie (`BT Info CD`) presenting the company`s total program for bulk ingredient feeding, weighing, discharging and flow metering in an easily understandable manner and with self-explaining navigation. Displaying the medium requires an internet browser but no internet access. The BT Info CD is a `digital working manual` and contains comprehensive information on gravimetric and volumetric metering feeders, discharge aids and flow meters for bulk ingredients together with individual machinery descriptions, capacity charts, selection guides, data sheets and application examples. With respect to ease of use and navigation and regarding suitability for different browsers the new version has been substantially improved. Other than with the previous version, equipment descriptions, capacity charts of the individual models and the pertinent

Following the acquisition of Netherlands-based Penko Engineering by the global American company Electronic Theatre Controls (ETC) in 2004, ETC`s unfailing commitment to developing the Penko weighing and dosing instrumentation and measurement business, continues at full speed - even during a recession. The new two-storey building includes 3370m2 of factory space and 1280m2 of office space, surrounded by parkland in Ede, just 5 km from original home of Penko, which for the last 30 years has been in Veenendaal, central Holland. The new building represents an investment of more than 5 million Euro by the American parent company. Penko`s General Manager, Pekka Sundstedt explained, `When we started the process of looking for larger premises, some factory buildings we saw locally were either too small or did not have the facilities we needed to improve production efficiency, material handling and were therefore unable to meet our need to improve logistics and efficiency.

Masterflex AG has recently launched a brand-new "A" hose series that complies with TRBS 2153 The Masterflex AG has recently launched a brand-new “A” hose series that complies with TRBS (Technical Rule for Operational Safety) 2153. Some of the well-tried Masterflex standard hose types have met the requirements lined out in the new directive years before it came into effect. The new “A” series products such as Master-PUR L-A or some hose types for the food industry will further complement the range of applications compliant to TRBS 2153. The new technical rule which became effective in April 2009 replaces BGR 132 and introduces new criteria for wire-reinforced hoses used in potentially explosive atmosphere zones. One of the major changes induced by TRBS 2153 is the classification of bulk materials into two categories: 1. combustible bulk materials 2. non-combustible bulk materials Provisions and procedures concerning the transport of non-combustible bulk goods have basically remained the same. Yet, this is not true for the transport

During the completion of the administration period (per July 17th) J. van den Berg en Zn. Waddinxveen B.V. was acquired by Van Mourik en Zn. enabeling to continue their activities, though heavily restructured, but including all knowledge and expertise. As of September 2009 about 20 people are again at your service. We look forward to meet you at easyFairs Solids in Rotterdam, booth number 1012, November 25 and 26, 2009.

Stand 1047 ROTEX, a global leader in the development and supply of screening equipment and technology for the process industries will be exhibiting at EasyFairs Solids at Ahoy Rotterdam. It will be a pleasure to welcome you the 25th and 26th November 2009 to our stand 1047. Our screening expert, Freddy Holle, will be on hand to provide customized solutions to a wide range of processing applications and to show you our newest machine, the APEX™ screener. You will have the opportunity to see the famous ROTEX gyratory movement in action and to test our new panel system on our new APEX™ machine right there, on our stand. Visit our booth and the benefits of using Rotex machines and spare parts will become obvious. We look forward to seeing you there.
