Safe catchment area for bulks Bulk-handling by containers and silos generates lost material on the underground. Using collecting-trays will take care for safety and cleanness in work areas. By position the container on a platform the lost material get in a safe catchment area. Optical check of fill-level is possible. ARICON collecting-trays surface is 1260 x 1260 mm wiith flat base (type WRL) or forklift-tunnel (type WRP) delivering in 3 heighs: 515 mmm, 690 mmm and 860 mm. Highly rugged and impact resistant. For indoor and outdoor applications. Secure storage of hazardous chemicals. ARICON is expert in Polyethylen Containers for industrial use by plant-engeneering and storage.

Schenck Process is pleased to announce the acquisition of the bulk material handling assets of the TEDO Company s.r.o., Czech Republic. This acquisition further strengthens the position of Schenck Process as a global supplier of solutions throughout the process industries. Founded in 1993, TEDO have profound engineering competencies within the field of bulk material handling and serve a similar customer base to Schenck Process in the cement and power industries. TEDO’s innovative range of tube conveyors, conveyors with u-shaped rubber belts and vertical bucket conveyors compliments Schenck Process’ existing range of bulk material handling applications and strengthens our position in the European market. As a result of this acquisition, TEDO’s highly experienced engineering and design team will be integrated into Schenck Process’ Czech Republic organisation, Schenck Process s.r.o., located in Prague. Schenck Process with headquarters located in Darmstadt,

Rome, Italy, 22-25 February 2009 The global provider of process equipment, ROTEX, will be present at Nitrogen & Syngas International Conference, in Rome, 22-25 February 2009 Mr. Olivier Thouvard, our Sales and Marketing Director, along with Mr. Frank Spanknebel, our Market Development Manager will give a presentation on 24th February, entitled “ROTEX INVOLVEMENT IN FERTILIZER / UREA PROCESSING”. Rotex has a wealth of experience and knowlege within the fertiliser industry. Our speakers will convey their expertise on the following subjects: 1.Different screening applications 2.How to achieve high feed capacity ? 3.How to achieve high efficiency ? 4.How to combine both (efficiency and capacity) to achieve higher performance on UREA? 5.Market Development 6.Conclusion Rotex screeners range provide solution to a wide range of fertilizer / urea screening applications and provide High screening Performance, “Increasing Product Yield”. With international participation of speakers and

Het Pand - Ghent University, 26-27 / 02 / 2009 The global provider of process equipment, ROTEX, will be present at Aquaculture Feed Extrusion, Nutrition, & Feed Management Conference, in Ghent, Belgium, 26-27 February 2009 Mr. Freddy Holle, our Sales Engineer Benelux, will give a presentation on Friday 27th February, entitled “Proper Screening Allows Good Nutritional Quality Feed, Optimizes Production, and Reduces Losses”. Sourcing this presentation in the very wide experience ROTEX has in this delicate sector of animal feed, Mr. Holle will develop all the aspects of screening animal feed, underlining the effects different types of screening might have from a quality and productivity point of view. Also, Mr Holle will present the latest developments and the newest machines Rotex has for an improved screening, for a better final product quality and a higher productivity. With international participation of speakers and visitors and with very well known sponsors, the “8th PRACTICAL SHORT COURSE:

Helica worm blades are manufactured in a cold massive forming process and guarantee reliable, long-term operation in a multitude of areas. They are especially suited for processing granular, pulverised, pasty, liquid or inhomogeneous materials. They can therefore be applied in all kinds of fields: Mechanical engineering Chemical and pharmaceutical industry Food industry Synthetics industry Recycling management Environmental technology Road construction, agriculture and forestry machine manufacturing etc.

The global provider of process equipment, ROTEX, will be present at Aquaculture Feed Extrusion, Nutrition, & Feed Management Conference, in Ghent, Belgium, 26-27 February 2009 Mr. Freddy Holle, our Sales Engineer Benelux, will give a presentation on Friday 27th February, entitled “Proper Screening Allows Good Nutritional Quality Feed, Optimizes Production, and Reduces Losses”. Sourcing this presentation in the very wide experience ROTEX has in this delicate sector of animal feed, Mr. Holle will develop all the aspects of screening animal feed, underlining the effects different types of screening might have from a quality and productivity point of view. Also, Mr Holle will present the latest developments and the newest machines Rotex has for an improved screening, for a better final product quality and a higher productivity. With international participation of speakers and visitors and with very well known sponsors, the “8th Practical short course:

KREATE goes for Draiswerke DCP Bead-mills KREATE is one of the fastest growing producers of pigment pastes for colour dispensers in Europe. For their newest production plant based in Belgium KREATE turned to Draiswerke for all of their production requirements. The first phase of the factory saw deployment of a Drais vacuum-dissolver plus two vertical bead-mills. KREATE formulates and produces pigment pastes for popular in-shop paint dispensing systems and needs to stay ahead of the lastest technological developments. KREATE therefore wanted the DCP Megaflow 12 lab/pilot-plant mill for development work on new pastes. However, this high-performance mill is no slouch in the pilot plant role either! Production volume is taken care of by the Draiswerke ACS-100 Megaflow mill with 8,5 litre high energy density milling chamber. This mill features a dynamic separation sieve which allows the use of very fine grinding media and an advanced rotor cooling system to keep product temps well below the critical treshold. Draiswerke�

Airconveyors International B.V. nearly finished their air supported conveying system as part of a ship loading installation at Nutreco’s business unit Skretting A/S Averøy in Norway which is the global number one producer of marine fish feed ! Their delivery consists of two parallel Airconveyors® type LB650 with a length of 65 meter each, including of a open steel structure (belt bridge) with a walkway down the middle. The conveyors are going to carry the end product (fish feed) from the factory crossing the existing warehouse overhead into the new quay building to load the ships. Each conveyor designed to supply 100 tonnes per hour. (equivalent to 160 m³/h). This environmental friendly air supported conveyor system runs with minimal friction and wear and is therefore very reliable, low in energy consumption and requires hardly any maintenance!

We are glad to inform you of our new cooperation with Dynamic Air Ltd. Located in the United Kingdom fabricates complete (dense phase) pneumatic conveying systems. Dynamic Air has built worldwide more than 10,000 customer-designed systems, with a high reliability, from a few (100 kg) up to over 400 tons per hour and distances exceeding 1500 m in length. The systems are complete designed, and can include all required equipment, as weighting, batching, blending, mixing, lump breaking, storage, complete electronic control and more. In the United Kingdom Dynamic AirLtd. has an complete full-scale test facility, where your new material or applications can be tested on all product properties and other test data that might be required. We gladly invite you to examine the 16 standard pneumatic conveying concepts on the internet site of Dynamic Air.

Interest of Exhibitors and Congress Participants remains strong ACHEMA 2009 from May 11th - 15th in Frankfurt am Main is still on the road to success. So far the econonomical situation has had no consequences for the leading worldwide event of the process industries. Exhibitors continue to show a high level of interest. As the most important international exhibition congress for chemical engineering and the process industries ACHEMA is the platform for new technologies and products, but also for worldwide exchange and setup of new business connections. Pumps, Compressors, Valves and Fittings make up the largest group of exhibitors. They are followed by Laboratory and Analytical Techniques, Engineering and Thermal Processes, Mechanical Processes, Instrumentation, Control and Automation Techniques and Pharmaceutical, Packaging and Storage Techniques. ACHEMA 2009 is once again the innovation forum for the process industry. Energy efficiency remains an important driver for innovation, as well for individual compo-nents as for measurement

A full flow orifice provides unrestricted conveying with no disk or ledges The Vortex VAC-Slide Gate is specifically designed to handle dry bulk solids in gravity flow or vacuum conveying systems. A full flow orifice provides unrestricted conveying of material with no disk or ledges to impede flow or cause material bridging. The VAC-Slide Gate is designed to eliminate problems associated with typical butterfly valves and knife gates, increasing production, while decreasing labor and equipment costs. * Smooth, Unobstructed Bore for Unrestricted Flow of Material * Seal Protected from Abrasion * Access Ports for In-service Seal Adjustment * Easy Installation and Maintenance Available sizes: 75mm to 150mm (3 to 6 inch) Contact the ITS office for more information.

New RETSCH Sieve Shaker AS 450 for sieve loads up to 20 kg With the analytical sieve shaker AS 450 RETSCH have designed their first siever for 400 mm and 450 mm sieves which operates with a three-dimensional sieving motion. It can be used for dry and wet sieving. The optimized electromagnetic drive allows for an amplitude up to 2.2 mm which renders the separation process much more effective than with other sieve shakers of this type. Reproducibility plays an important role: The amplitude - which is independent of the sieve load - is continually adjusted. The three-dimensional sieving motion lets the sample material move equally over the complete sieving surface. This results in high load capacity, extremely smooth operation and short sieving times with high separation efficiency. When it comes to operating comfort, the AS 450 meets all the requirements of a modern laboratory. All parameters such as amplitude, time and interval are digitally set, displayed and controlled. It is possible to store up to 9 parameter combinations

On Wednesday 14.January 2009 one of the world largest PET bottle recycling plant for food grade flakes has been opened at Spartanburg, South Carolina, USA. The operation is a joint venture of URRC and Coca Cola named NURRC and will process 50.000 tons / year (output) of PET bottles at its final stage. This plant is not only a significant environmental benefit but with 100 newly created jobs also an advantage for the local community. NURRC uses the latest state of the art technology in processing post consumer PET bottles into food grade flakes. The selected equipment supplier for the size reduction part is Herbold Meckesheim GmbH from Germany with a total of 6 units of its new series of forced feeding granulators. This new granulator series type SB offers key features of today’s demand for reliable, energy saving and highly productive recycling machinery. The bottles in the granulator storage hopper are evenly and horizontally fed into the cutting chamber with the

With reduced margins it is time to cut costs. For the section “size-reduction/washing/ separation/drying HERBOLD MECKESHEIM has been developing quite a number of substantial improvements that we are now going to present: - for granulators: cutting knives with exchangeable stellite-tipped plates (see Figure 1). This problem is well-know to every operator of granulators: Cutting knives for granulators are worn out and therefore tool steel that was expensive when it was bought is usually put on the scrap heap. The new solution using exchangeable stellite-tipped knives puts an end to this: Not only is the consumption of valuable, high-alloyed steel reduced to a minimum, but also the lifetime of these knives is many times higher. - for abrasive materials: pipe bends with wear plates with post-consumer plastic waste or glass-fibre reinforced plastics a high wear and tear is well known, as well in the suction units. For highly

Busch has launched a completely revamped new generation of rotary vane vacuum pumps in the R 5 series. Three pump sizes with a suction capacity of 10, 16 or 21 cubic metres per hour produce an ultimate pressure of 0.5, 1 or 20 hPa (mbar), depending on the version. All sizes and versions offer stable performance characteristics, i.e. a high suction capacity is guaranteed even in the working pressure range. Thanks to their extremely compact design, these vacuum pumps are suitable for an installation in very confined spaces. A standard non-return valve in the suction pipe prevents ventilation of the recipient if the vacuum pump is turned off. The new R 5 rotary vane vacuum pumps are each driven by directly flanged standard motors. The main fields of application are the plastics industry, vacuum packing machines, food processing machines, transportation and lifting devices. Busch R 5 rotary vane vacuum pumps are available with a large range of volume flow rates from

Kemutec Powder Technologies announces the installation of a high specification package for GSK. GSK had several requirements for the package to fulfil, central of which was to accommodate a multi-product process train. This was achieved by designing in quick change operating parameters, equipment speeds, type of grinding media and sieve and screen type. The package consists of two RB100 screw feeders, which lead into two KEK Under-Driven Cone Mills. These in turn feed into two KEK Centrifugal Sifters. Mobile and sliding support mechanisms were developed to allow a milling or sieving operation to be added or removed from the process quickly and easily. The sifters are mounted on moveable structures, as GSK required them to be interchangeable with two existing flat-deck machines. Impressively, all machines used in the package are manufactured in C22 Hastelloy, thus accommodating the corrosive nature of materials and cleaning fluids. All of the machines were pressure

Touch computer for Weighingsystem and other aplications. The Bosche company from Damme will show on the exhibition Embedded World (from 3. - 5. March in Nürnberg) the new Industrial PC. These Panel PC is designed for aplications in difficult industrial environments. It provides a stable weatherproof extruded aluminum case in pleasing Design. The HMI 15 is an all-in-one-industry PC with a high-resolution touch screen. The fanless system has a solid state disc and allows for the operation even under vibrations. Because of the completely enclosed aluminum case is the infiltration of dust and other foreign objects prevented. This assures maximum protection against moisture, dust, and rough usage. Info: Jarmila Bosche, 05491/976911, info@bosche.eu, www.bosche.eu.

Maximum process reliability and highest quality A partner who assists Zollner Elektronik AG in meeting the requirements for maximum process reliability and highest quality is S+S Separation and Sorting Technology GmbH. For the inspection and purification of such industrial materials S+S provided metal separators of type GF Primus. After the installation of the metal separator, production could be continued without machine downtimes. It is only the use of metal separators that allows an economic processing of granulate mixed with regenerated material or ground material. The GF PRIMUS metal separator removes metallic contaminations from the pneumatically conveyed regenerated material. Installed directly in the pneumatic conveyor pipe of the material conveyor for the injection moulding machine, it reliably separates metallic contaminations, even such contaminations that are embedded in a granulate grain. Klaus Kandlbinder, injection moulding process planning manager at Zollner Elektronik AG, Zandt: "S+S metal

Multi- function feeder SILETTA® The bridging or ratholing in the silo can block the whole process and cause a discontinuity with high technical and financial consequences. The influences of geometry of the silo are, the silo diameter, height, angle of the hopper, pressure in the silo and wall friction. The influences trough powder are the cohesion, angle of internal friction, density and unconfined compressive strength. The vibration however, is not transferred to the powder in the silo, because a layer of powder above the louver is flowing and expanded in which case a transfer of the vibration to the powder in the silo is not possible. The vibrating bottom makes material bridges and angles of repose collapse. Triple Function: live bottom discharge equipment dozing and proportioning device shut off valve Application: Universal application for all bulk materials of up to 40 mm particle size and silos of all sizes and silos of all sizes with circulator, square or slot –shaped discharge

T wentebelt makes its entrance onto the spiral market by introducing a new spiral belt design. With the elimination of welded joints as key element this patented design holds several improvements on the existing technology regarding durability, cleanability and efficiency. The TwenteFlex™ will be presented for the first time to the general audience at the Anuga FoodTec.

With the Vortex Roller Gate valve, there is no metal on metal contact between the blade and the valve body. This feature eliminates the associated gate seizing and binding seen with other slide gate valves. The Vortex Roller Gate is an excellent choice for handling sticky material. * Dust tight material seal * Gravity and low pressure applications * Bonnet seals easily replaced while gate is in service. * 4” – 72” square or rectangular sizes * Designed specifically to handle dry material.

The Azo group introduces Zoatec GmbH, with approximately 40 employees and located on a brand new production site and with a separate technology centre in Neuenburg am Rhein (D), near Basel. Zoatec has been founded around a group of specialised and skilled engineers from the pasta and cream branche and fabricates process machines for the production of viscous products such as ketchup and mayonaise for the food industry, unguents for the pharmaceutical industry, creames for the cosmetic industry and toothpaste for the chemical industry. The synergy between Azo and Zoatec lies in the fact that during all these processes powders are mixed into the liquid process. From the Azo Nv site in Antwerp the distribution of Zoatec equipment is assured. Moreover, Azo represents the Amixon mixers exlusively, and during the fair, a sanitary mixer, proper for quick recipe exhange, will be exposed. Furthermore we would like to inform you about following innovations : -

For setting up safety systems compliant with the explosion protection requirements The PROTEXT SRB 101-Ex (one safety release) and SRB 200 (two safety release) series are suitable for use in Ex zones. There are variants with monitored reset function (trailing edge) as well as with automatic or manual reset function. All these versions have a stop 0 safety release and optionally can be supplied with cross-wire short detection. The four new safety relay modules can be used in intrinsically safe circuits in combination with, amongst others, reset buttons, emergency stop control devices, interlocking devices and safety magnet switches to the ATEX-Directive 94/9/CE. Due to the explosion category “n” to EN 60079-15, they can be used in IP 54 control cabinets in Ex zone 2 (gas).

atex New in our programm of silicon foodgrade bellows for weigthing apllications are silicon conductieve bellows. For information please contact our sales specialists.

World`s first compressed air flow meter with direction sensitivity The VPFlowScope of VPInstruments offers direction sensitivity without the usage of extra equipment. Thanks to the patented ThermabrigdeTM sensor, measuring flow and direction is now an easy task. In the industries that use compressed air, the awareness is growing that flow measurements are key to large energy savings. In some cases however, measuring the compressed air demand is not as straightforward as it seems. In ring networks, the flow direction depends on the actual air consumption of each division and is therefore unpredictable. Also, measuring near air buffers is tricky, because without a non-return valve, the buffer can also deliver air back to the network. Measuring flow direction was already possible, using a flow direction switch and a mass flow meter combined. This used to be a quite complicated task. Now with the VPFlowScope you can measure the compressed air usage and direction with only one instrument. Measuring in e.g. ring networks becomes

Magnetic separator for conveying lines The PneuMag is a high intensity magnetic separator designed to remove ferrous and stainless steel scrapings from pneumatic conveying lines operating at up to 25m/s. It features a centrally positioned high intensity magnetic grid with quick release toggle clamps, tamper proof cover plate and totally stainless steel construction. The PneuMag is particularly suited to flour, sugar and other powder and granulate processing. It is Atex certified for zones 20 interior and 21 exterior. • High magnetic performance - 9000 Gauss • Reduces `spark` risk • 316 grade stainless steel construction • Cleaned in under 30 seconds • Tamper proof guard • Silicon rubber, metal detectable seal

DEPRAG SCHULZ GmbH & CO. has set a new standard on the market by restructuring the brand portfolio for their successful range of air motors. The company’s contemporary website presents a logically structured overview of the popular air motors. The new English product names for the air vane motor programme: Basic Line, Advanced Line, Power Line and Individual Line highlight the international role of the company as a leading supplier of air motors, automation, screwdriving technology and air tools. DEPRAG is working towards the future with 600 employees in over 40 countries. The company’s philosophy has always been to expand on achievements and set the trend for future innovations. The new layout provides customers with a clear outline of all the important information concerning DEPRAG’s various motor lines. The sophisticated visual features optimise navigation through the wide range of uses and clearly explain which air motors are particularly suitable for which

Monitoring system for bucket elevators and conveyors The latest NTC Watchdog Elite now incorporates continuous bearing temperature monitoring as well as fixed trip point monitoring. The system uses solid state NTC sensors or PTC sensors, allowing the user to set a temperature trip point and to monitor actual bearing temperatures in real time. Continuous temperature reading outputs can be monitored in any combination of up to 6 bearings, gearboxes, or machine surfaces. As with our previous Watchdog Elite control units, you will also be able to monitor belt speed, belt and head pulley alignment, and plug condition on a single bucket elevator or belt conveyor. The LCD screen displays machine status (available in 4 different languages) and a super-bright LED display shows belt speed. It is easy to calibrate and setup using a simple front-panel touch button interface. The system includes alarm and shutdown contacts, RS485 output, and an optional PLC interface. Cert: ATEX/ IECEx Zones 21 & 22, & CSA Indication of

unlocks new possibilities, which otherwise would not be possible Available only with FRITSCH Cutting Mills: The patented FRITSCH sample exhauster with Cyclone separator with its based on negative pressure powerful vacuum function, ensures a simple feeding, fast throughput and a good cooling, effectively prevents sample material from escaping during feeding and unlocks up new possibilities in the processing of heterogeneous mixtures of materials, like for example derived fuels in the cement industry. Also this is only possible with FRITSCH Cutting Mills: While you are still tightening the screws on other mills, your FRITSCH Cutting Mill is already clean. Because the entire grinding chamber can be opened completely and all grinding parts can be removed for cleaning in just a few seconds without tools – unbeatable fast, simple and efficient! This makes the FRITSCH Cutting Mills the ideal, time-saving assistants in the comminution of soft to medium-hard as well as fibrous or also tough materials. They are indispensable in
