News items August 2008

simulation of discrete elements EDEMTM is the world`s first general-purpose CAE tool to use state-of-the-art discrete element modeling technology for the simulation and analysis of particle handling and manufacturing operations. With EDEM you can quickly and easily create a parameterized model of your granular solids system. CAD models of real particles can be imported to obtain an accurate representation of their shape. Add the mechanical, material and other physical properties to form your model particles. These can be stored in a library allowing you to build a collection specific to your processes. EDEM manages information about each individual particle (mass, temperature, velocity and so on) and the forces acting on it. It can also take into account the particle’s shape, rather than assuming that all particles are spherical. For post-processing, EDEM provides data analysis tools and 3D visualizations of the particle flow. EDEM`s Particle FactoryTM technology provides a unique method

Automatic Feeding of Kieselgur from Sacks into Dissolving Tanks Handling bags of kieselgur is a constant daily challenge for breweries. We provide a unified solution to automate this process. This comprises an automatic bag emptying machine to automatically open and empty the bags, with integral compacting of the emptied bags, a pneumatic conveyor to carry the Kieselgur into the dissolving tanks, and an extraction and filtering unit for the pneumatic conveyor and dust extraction for the dissolving tanks. Plant is available for this process with different performance ratings, mainly in the range of up to 120 bags per hour and up to 250 bags per hour. The bags has to be put only on a conveyor belt. This then transports the bags into the automatic bag emptying machine, and separates the packing material from the kieselgur. The packing material passes through a chute into an empty bag compactor where it is stuffed into a tubular film. The kieselgur falls through the emptying drum into the discharge hopper and flows into the

Delaere Weighing and Bulk Filling systems was created in 1851. It is only in 1985 that it decided to enter the bulk filling market. Since that day it developed itself as one of the most creative companies in the business. It generated itself a large list of references all over the word in almost all the industrial branches. Products: BIG BAG/OCTABIN/BOXES filling station OCTABIN Deployment robot Bag slitting installations dosing systems, internal transport systems, rappers,... Based on those years of experience in design, production, installation and service of industrial weighing and bulk installations it has ever had one goal : ‘being original’. Our ever quest for quality, specialization and customer’s productivity it succeeded in very large and complicated projects, as well in smaller custom made projects.   You can find us stand: 7 B024

In May 2008 RHEWUM received an order for screens for the MA´ADEN fully integrated phosphate fertilizer production operation in the Kingdom of Saudi Arabia which will be the world´s largest of this kind. In May 2008 RHEWUM received an order for Lump Screens for the MA´ADEN fully integrated phosphate fertilizer production operation in the Kingdom of Saudi Arabia which will be the world´s largest of this kind. The screens will be part of the 4.5 million t/a phosphate rock beneficiation plant at the Al-Jalamid phosphate complex in the north of the Kingdom of Saudi Arabia. The order has been placed by the EPC contractor Litwin Europe Middle East, a part of the Bateman Litwin N.V. Group. The order covers three screening machines Type WAU 195x269/1 and three feeders Type AV 1950, each screen for a capacity of 400 t/h – which means a capacity of nearly 10.000 tons per day! Delivery of the screens is foreseen for November and December 2008.

New screw vacuum pump S-VSI TWISTER Because of the contact-free operating principle of the S-VSI TWISTER there is no lubrication required in the pumping chamber. So there are no costs for the waste disposal of contaminated oil. The S-VSI range features an optimized, progressive screw pitch design synchronized by gearing. The main advantages of the S-VSI 300 TWISTER are: • Short evacuation time • Ultimate vacuum 0.1mbar • Low compression temperatures • High water vapour tolerance • Low noise level • High suction capacity • Maintenance friendly • High efficiency • Variable speed possible • Lower exhaust temperature

the revolution VELOCIS Side channel blower: the revolution There are technologies, so proficient, you are almost not able to improve. Just one example are the side channel blowers of Elmo Rietschle. Since many years they prove their reliability day in and out, work factual maintenance-free and operate more quiet than almost all other vacuum pumps and compressors. Our R&D department has created a new generation of side channel blowers, based on the know how of the market leader Elmo Rietschle and on the requirements of our customers: the Velocis G-BH2. • Reduced life cycle costs • Unrivalled reliability and robustness • Extremely quiet operation • Quality motors with voltage range in Eff 1 • High performance operated by standard machines with frequency converter (87/100 Hz) • World-wide application (UL/USA-, IEC/EN – certificated) • ATEX 94/9 EG With its significantly expanded range of performance, the technology of the side channel blowers can even

Xtreme Duty The Tapco Inc. and the European Distributor SKM Witte Löhmer GmbH in Ennepetal, Germany now offers a complete line of CC-XD ( Xtreme Duty ) elevator buckets designed for the most extreme thruput elevators. Injection moulded with 35 % more resins throughout the ENTIRE bucket - NOT JUST AT CRITICAL WEAR POINTS - guarantee very dense, long wearing surfaces. Strong, thick walls `give` and `yield` to withstand hangups and returnto their origianl shape. CC-XD fills and discharge exactly the same as the tested and proven CC-HD style. All CC-XD buckets are 100 % interchangeable with standard CC-HD buckets. The buckets are available in Nylon, Polyurethane and Polyethylene. Some of the buckets are presented from SKM Witte Löhmer GmbH at the exhibition POWTECH 2008 - Stand 5 - 238

Improved design VPFlowMate in-line family Now all in-line mass flowmeters of VPInstruments are offered in a new revolutionary design! Improvements were made to the VPFlowMate in-line family in several areas, making this the ultimate device for your compressed air flow measurements. The VPFlowMate in-line now has detachable in- and outlet piping. Piping and pipe thread is often damaged during installation, or it needs a little change to fit a certain type of process connection. Now the new unique feature makes installation and service much easier. The flow path has been optimized and the temperature measurement has been greatly improved. All contributing to more accurate results of measurements. And thanks to the new design, it also looks better. The VPFlowMate in-line measures mass flow and can be used for compressed air, Nitrogen, Argon, Helium and other non-corrosive, dry gases. The VPFlowMate in-line is available in 0.5”, 1” and 2” and flow ranges are 0..30, 0..60, 0..120, 0..750 m3/hr. Now

Quick exchange of chain guides The problem is well-known: A chain causes wear on the plastic guide. Even if the wear is extremely low for Murtfeldt materials, the guides have to be exchanged from time to time. When using one-piece cage profiles, like Murtfeldt type K or CKG, the chain has to be separated and removed from the profile. Due to this problem, Murtfeldt, the Dortmund-based specialist in the the manufacturing and processing of semi-finished plastic products, has developed two new part guide rails for the roller chain sizes 16B-1 (1” x 17 mm) and 20B-1 (1 ¼ x ¾”). With them the assembly is very easy. The advantage of these new products: In future, there will be no need to remove the chain from the profile when overhauling the guides. The exchange of the chain guide is done in a quick, clean and chain protecting manner. First of all the steel backing is removed that is now offered by Murtfeldt in the two part designs C16H and C17V. As a next step, the two halves of the plastic

At the POWTECH, in hall 7, stand 679, S+S among others presents the GF 4000 metal separator The Gebrüder Leimer KG in Traunstein / Upper Bavaria is a company with a long tradition that was founded in 1919 by the brothers Carl and Josef Leimer as a bread factory with confectionery. Developed into an internationally important company by Karl Leimer, the company`s philosophy of `Quality through freshness` right from the start has been the decisive success factor. Based on the existing quality management system with integrated HACCP concept, Leimer has obtained a higher-level IFS certificate. To ensure that Leimer`s full product range is free of any metal contaminations, Leimer among others uses a metal separator of type GF 4000 made by S+S. The GF 4000 metal separator examines breadcrumbs for magnetic and non-magnetic metal particles. The products are transported by way of continuous vacuum conveyance. Contaminations are separated with a minimum loss of good material by way of the fast-acting eject flap (`quick-flap system`). The metal separator was installed

To remove ferrous contaminants Puritan Magnetics’ Suspended Belt Magnets are designed for suspension above a belt conveyor and are engineered to remove ferrous contaminants from high volume deep burdens. As product passes under the magnet, metal contaminants are drawn out of the material to the face of the magnet. This style of magnet should be installed at the discharge of the head pulley if possible. Material will be flowing more freely and can be thrown into the face of the magnet increasing the separation results over an installation that has the magnet suspended over a troughed belt. This can be supplied with a wiper arm or stripper plate to simplify cleaning. For automated continuous cleaning, a POW-R CLEAN option can be selected which incorporates a set of pulleys, belt, motor, and reducer that travels around the Suspended Belt Magnet discharging metal contaminants automatically. Suspended Belt Magnets can be installed in an in-line or cross belt configuration and are commonly used in such

With effect from August 1st 2008 Mr. L. Fleischmann takes over sales activities of RHEWUM in France Of course Mr. Dominique Lallement will still be available for our customers as a contact person ensuring the continuity of the long-term customer relationship established by RHEWUM. Simultaneously this will secure the path into a reliable and successful future for both the customers and RHEWUM. After having studied process technology in Berlin Lutz Fleischmann worked for several well-known customers in the fields of mechanical process technology. In this relation he was not only involved in sales, planning and project management, but also in the commissioning of various large-scale projects. For family reasons Lutz Fleischmann then decided to move to France after having gained several years of work experience in Germany. In France he continued his work as a customer-oriented process engineer. Thanks to his long-term and successful work experience at the interface between customers and manufacturers Lutz Fleischmann is a qualified and competent contact person for

Spark extinguishing systems have been an integral part of security concepts of preventive fire and explosion protection in the various industrial processes. The task of this technology is to detect the smallest ignition source such as sparks and glowing particles in time and to extinguish them safety by local limited extinguishing measures before these sparks and glowing particles could damage machinery or other equipment. Especially in pneumatic transport ducts is this a thousand fold proven technology to protect filter systems, silos or bins against fires or explosions. Gladly GreCon will show you during the POWTECH how simply it will be possible to protect your plant as well. If a spark will be detected a fine extinguishing efficient water mist spray will be inserted in the corresponding exhaust ducts for an adjustable extinguishing time to safety extinguish the sparks. This will certainly prevent that the spark can be the fire or explosion reason in the filter,

RETSCH presents new mills and sieve shakers Retsch, the experts in milling and particle characterization, present new product innovations at this year’s POWTECH. The versatile Mixer Mill MM 400 grinds, mixes and homogenizes two samples at the same time and can even process up to 20 samples simultaneously with adapters. This all-rounder is suitable for a great variety of materials such as ceramics, glass, soils, minerals, drugs or plastics. Thanks to the screw-top grinding jars the MM 400 can also be used for wet and cryogenic grinding. Another highlight is the Planetary Ball Mill PM 100 CM which operates in the centrifugal mode. Size reduction to the nano range is effected by friction and pressure which helps to reduce the temperature inside the grinding jar. To monitor the processes which occur during grinding, Retsch offers the new measurement system PM GrindControl which is used to document pressure and temperature inside the grinding jar. For particle size analysis Retsch presents the new sieve shaker
