News items May 2008

Optical Ex signal devices are found widely in explosion-endangered areas, whether in refineries, filling plants, joineries, grain mills or in the chemical and petrochemical industry. This has motivated WERMA to add three new and high light intensity Ex signal beacons 738, 782 and 784 to its existing range. Ex double flash beacon 738 has a high flash intensity of 15ws attained by the triggering of two flashes in succession. The new Ex rotating mirror beacon has a long life duration with its low wear wheel and disc drive. Ex revolving beacon 784 has an op-timised effect with the light bundling achieved by the 3 Fresnel lenses. The new Ex beacons 738, 783 and 784 are suitable for use in gas and dust explosion-endangered areas (zone 1 and 2, zone 21 and 22). They have a pressure-resistant metal casing with termi-nal connection “e” and are striking in their modern design and high light intensity. The high quality housing with IP 66 enables indoor and outdoor

Audible Ex-signal devices in a range of applications Whether in refineries, filling stations, joiner’s workshops, flour mills or in the chemical and petrochemical industries – today audible Ex-signal devices find a range of applications in explosion protected areas. For this reason WERMA signal technology has added the loud Ex-multi-tone sounder 714 to its existing product range. Deployment in zones 0, 1 and 2 The new Ex-multi-tone sounder from WERMA is designed for the de-ployment in explosive gas or vapour atmospheres. It signals dangers and disturbances in the zones 0, 1 and 2 and is constructed in accor-dance with the high degree of protection IP 65. The compact Ex-multi-tone sounder has a diameter of 93 mm and a height of 103 mm. The intrinsically safe product also stands out with its modern design. International signal tones for the widest possible range of applications The Ex-multi-tone sounder 714 provides 26 different tones and fre-quencies for

New online program for automatic selection of the optimum bulk ingredient metering feeder A program for automatic selection of the optimum gravimetric or volumetric bulk ingredient metering feeder for a specific purpose has been published on the world wide web by Brabender Technologie KG, one of the leading global feeder suppliers. After the user has entered the relevant basic data of his application in the program, the `FeederScout` determines the optimum metering feeder best suited to the particular requirement in due consideration of both technical appropriateness and cost-efficiency. The `FeederScout` has been made possible by months of work spent by an expert team of process engineers, technicians and computer programmers from Brabender, all of them having been in the bulk ingredient feeding business for decades. Profound specialist knowledge and an extensive database keeping a record of almost 15,000 feeding trials with thousands of bulk ingredients formed the basis of this unique program, which can give even the most experienced process engineers

The VPFlowScope wordt nu aangeboden met een aanzienlijk groter temperatuur bereik. Het is nu mogelijk om bij een perslucht- of gastemperatuur tot 100°C te meten. Hierdoor is de VPFlowScope is voor nog meer situaties inzetbaar. De VPFlowScope meet massaflow, druk en temperatuur tegelijk. Het display geeft real-time informatie over alle drie de parameters. Tevens bevat de VPFlowScope een ingebouwde data logger waarop u 500.000 data punten kunt opslaan over een bepaalde periode. Met de software kunt u metingen real-time volgen, data verwerken en uitprinten.

Jeco Plastic Products designer and manufacturer of plastic pallets and containers for the worldwide printing, manufacturing and logistics industries since 1973—recently solved an unusual material handling problem for a manufacturer of over-the-road trailers. The manufacturer must move large, heavy panels, which must be kept flat. Jeco designed and manufactured a pallet measuring 117 by 54 inches, with forklift access from all sides. The rotationally molded pallet has eight steel reinforcement bars, and is capable of bearing a 36,500 lb static load and a 24,500 lb dynamic load. Discussing the unusual product, Jeco CEO Craig Carson commented: “Few plastic molders have the design capability, oven size, or molding experience necessary to manufacture a pallet such as this. The unique design provides rigidity seldom seen in a plastic structure of this size, and the pallet, with its quarter-inch thick walls, has impact resistance which far exceeds that usually available. The pallet is manufactured

Design based on construction of M-TDV mulitport diverter Contrary to the M-TDV multi-port with electric drive, both the new 2- and 3-TDV are activated using a pneumatic actuator, which is more cost effective. This gives a very compact design to both diverters and by using an additional line cylinder on the 3-TDV very accurate positioning is achieved. The uniquely designed seal that has already been proven on the M-TDV is also being used on the new 2- and 3-TDV. This seal is made from EPDM and is very easy to fit and clean, and being inflatable guarantees absolutely tight sealing in the conveying line up to 3 bar g. The whole range of tube diverters (2-, 3- and M-TDV) are of a sanitary design and have stainless steel AISI 316 product contact parts. The swan neck pipe connecting the inlet to outlets is designed to give minimum product degradation in every conveying direction. All conveying lines that are not in use are also sealed at the diverter outlet. This ensures that there is no air or product leakage from destinations

EUROMIX 3000 CC Euromix 3000 CC The new flagship amongst mobile mixing plant from SBM Mineral Processing Since 1998 SBM has been building the tried and tested mixing plant of the Euromix series. Several million tons of concrete and references from all over the world bear testimony to the reliability of this highly mobile mixing equipment. The successful product range – starting with the mobile containerised EUROMIX 1000 with a capacity of 60 cubic metres/hour, through the classic EUROMIX 2000 with 100 cubic metres/hour up to the EUROMIX 3000 with130 cubic metres/hour – has been extended with the introduction of the EUROMIX 3000 CC with a capacity of 200 cubic metres/hour. A multitude of innovations makes these machines the best-equipped mixing plant in the world. With SBM, meeting the requirements of the EN 206 norm can be taken for granted. This wheeled version with such compact dimensions makes these machines suitable for transporting by road as a semi-trailer. Typical

remax MAXI 12 With SBM, mobile and powerful – the remax MAXI 12 The new engineering concept for tracked crushing and screening equipment from SBM Mineral Processing, first introduced to the public at Bauma 2007, has in the meantime proved itself with many of our customers. (Pic. 1 In operation in Denmark) During development much importance was attached to typically SBM characteristics. The remax series is so convincing due to:  Maximum productivity – through minimising the non-productive activities (e.g. set-up times) and optimising the tried and tested SBM components which are decisive in the overall performance (e.g. the impact crusher).  Outstanding mobility – the dimensions of the equipment have been optimised for ease of transport. For example, the return belt for oversize stays on the plant for transport but the screening unit can be removed for transport if required.  Modular concept – the remax ECO (plant without a screening
