News items July 2008

M4501 Compared to previous memory printers we recently developed a perfect solution for collecting, recording and archiving data which have to be collected under ‘legal for trade’ liability. Our M4501 data storage device joins our legal for trade weighing indicator R420-K402 to a non legal for trade user software. Just mount it at the back of the indicator. In this manner weighing results can be saved in a ‘legal for trade’ storage device. Thus guarantees that data may not be manipulated and the application can always be identified. Typical applications: • Truck Scales • Dosing Systems • Onboard Weighing • Filling Processes Specifications: General: Data Storage (DSD) Module Power Supply: Internal Indicators: 5 Annunciators Led’s Memory Capacity: 6 Mbytes Flash Memory Record-Format: - Transaction based (records are not stored in files but as read-only transaction records

R320-K302 R320-K302 Ring Network Enhancement connects up to 31 instruments in a network. Benefits: - Connects up to 31 x R320 into a ring network - no loss of backward compatibility - Simple setup with the R300 Viewer - Uses only one communication port on the master computer - Saves on communications cabling - Ideal for process control applications

Fast weighing results under almost any installation conditions Now the weighing and metrology experts at Sartorius have expanded the Combics family to include the high-resolution CH Series of industrial scales, with weighing capacities from 16 to 300 kg. Built with monolithic weigh cells, these new models have weighing platforms that deliver a resolution of up to 340,000 digits. For example, a scale with a capacity of 34 kg has a readability of 0.1 g. With short stabilization times, low sensitivity to vibration and electronically compensated preload without reduction of the weighing capacity, this series guarantees fast weighing results under almost any installation conditions. Moreover, the built-in motorized calibration weight makes the scale ideal for integration in GMP/GLP certified production processes. It provides fast and reliable weight values even under conditions that require dust and water protection up to the levels of IP65 or IP67. Just like other members of the Combics family, CH components are easy to configure

A beautiful balancing act as Synchronous Lifter One of the world’s most advanced heavy lifting systems has been deployed in Australia to maximise safety and precision during maintenance of a huge dredger at the largest coal mine in the Southern Hemisphere. The successful lifting and balancing of its huge superstructure illustrates the versatility of the Synchronous Lift system for major industrial and civil engineering tasks, including manufactured structures, buildings, bridges, oil platforms, ships, turbines, generators, mills, mining equipment and heavy but delicate computerised/electrical equipment.The Synchronous Lifting technology chosen for the task of hoisting Dredger 16’s superstructure to inspect and refurbish the giant machine’s slewing ball race uses digital synchronisation control accurate to within a 1 millimetre between leading and lagging lifting points. The Synchronous Lifting system was an eight-point model that can be used with multiple cylinders ranging from 10-1000 tonnes capacity each.

integrated Ethernet TCP-IP The in-line Brix-meter / Refractometer / Dry Solids meter model PR-23-A is 3A sanitary certified. It is a compact process measuring instrument and very suitable for the continuous and in-line measuement of % Dry Solids, or Brix. Mounting is feasable in process pipes diameters from DN10 to DN80. Very suitable for all aplications in food industry en biochem industry, specially there where in-line QA/QC contributes to improving produc qualtity and the reduction of production costs.

robust in-line process meter Model TC007 Turbidimeter is an industrial, robust, in-line process turbidity meter designed for a variety of different process applcations and this turbidimeter meets ISO7027. Industrial FiberOptic Cable Glasvezelkable is apllied as interface from the TC007 analyzer the sample flowthrough cell and back. This is an important benefit allowing you minimum maintenance en high reliability over a long period of time. the measuring range is 1 - 10.000 NTU/FTU. The laser-LED-lightsource has a very long life time.

Induvac offers industrial, energy savin multiplex vacuum solutions utilizing VFD(variable frequency Induvac b.v. introduces the Ecoseal oil sealed ring systems with variable frequency drive, which are reliable for tough industrial applications such as tank cleaning, woodworking, glass manufacturing, plastic thermoforming, printing and envelope manufacturing, biogas installations etc. Consisting of two, three or four simplex liquid ring systems, Induvac advanced design combines benefits of the Ecoseal oil sealed liquid ring vacuum pumps with VFD motor speed control. They are micro-processor controlled and offer substantial energy savings by automatically adjusting pump speed to match varying vacuum demand. This also eliminates frequent stop-starts and results in more stable vacuum levels. Liquid ring pumps have only one moving part resulting in high reliability, a cooler and quieter operation, lower maintenance costs and increased up-time. The alternation program is based on actual run time hours assuring balanced usage on pumps. Induvac’s Ecoseal VFD

10. July 2008 Less than three years after the first sod was turned for UWT’s four storey office block, there is more building news on the horizon. On 10 July, the next sod was turned to overcome the acute lack of space; this time for a combined production and office building with three levels. UWT’s agents, customers and not to forget the employees have advanced the success and growth of the company so that the current “new” office building was no longer sufficient for the requirements of the growing enterprise. The new ecologically compatible building will be constructed using local raw materials and will offer an effective floor space of 2,600 square metres over three storeys. Built according to the passive energy (ultra low energy) standards, it is expected that energy requirements will be far exceeded! Pellet heating and a ventilation system with a heat recovery ventilation system and a solar energy system will supply the necessary energy to be self sufficient. The

TELSCHIG with interesting solutions on BRAU Beviale 2008 From November 12th to 14th TELSCHIG Verfahrenstechnik GmbH will be exhibitor on BRAU Beviale in Nuremberg. As part of this important international trade fair for investment goods, TELSCHIG will present a great product range around Automatic Bag Emptying. The BRAU Beviale, with over 1,400 national and international exhibitors and about 34,000 trade visitors is one of the largest exhibitions for the beverage industry. Especially when it comes to the choice of beverage raw materials, new technologies, logistics and marketing ideas, the BRAU Beviale has a key position. Visit us in hall 7.

FT-13 process indicator is approved according new European MID regulations. The FT-13 is an accurate and multifunctional weighing indicator usable for several weighing processes as filling or emptying of powders, fluids and gasses. Just change the parameters to get the filling or dosing application as you wishes. This weighing processor is automating the whole process. By getting the “Certificate of EU Type Examination” for this instrument, automated filling processes can be controlled as well in an approved way. The multiple available interfaces are offering an outstanding fundament for creating a weighing and control system. The Flintec FT-13 offers; • 7 pre-programmed filling and dosing modes, for example; Filling of Big Bags and Barrels, Loss in Weight, Discontinues Totalizing, etc. • Weighing functions MID approved up to 10.000 increments • High internal resolution, display up to 60 000 counts, up to 400 values/s • Real-time clock • Numeric keys • Communication ports like ETHERNET, MODbus and PROFI-BUS are available

DFT truck scales, the fifth generation The experience gained from the DFT variant of the truck scales of which, more than 2,700 have been sold throughout Europe to date, can be seen in the fifth generation’s optimised concept. For example, the entire truck scales are pre-fabricated out of high-quality precast concrete parts of the C45/55 strength class. When combined with the robust, zero-maintenance RTN ring torsion load cells and suitable elastomer mount elements or the new low-cost VDW load cell, we supply a complete model that can be installed in just one day. Depending on the length of the scales, they may be supplied in a pit version as a one- or two-part weighbridge with foundation bed, or as an above-ground version, in the following standard designs. With a single weighbridge in sizes: 8m, 10m, 12m. With two weighbridges in sizes: 16m, 18m, 20m, 24m, 25m. Special sizes can be supplied in various versions. The benefits at a glance: · Pit or above-ground version made from precast concrete

Low-cost VDW load cell and DFT truck scales For many years, the RTN load cell used in Schenck Process’ truck scales has been a reliable guarantee for high quality standards. And now, the new low-cost VDW load cell for the latest generation of DFT truck scales offers customers even more alternatives. Schenck Process sells truck scales of various designs all over the globe. Depending on where they are used, both technical standards and local competition may vary. The truck scale solutions deployed reflect these variations. Until now the only common denominator has been the robust, durable RTN load cell. But markets around the world are changing. Economic requirements are changing at an ever increasing speed. Demand for simpler, lower cost and electromechanical scale solutions is growing all the time. And Schenck Process has come up with the new high-quality, self-centring VDW pressure load cell for this very reason. Many of its details are based on the experiences gleaned from the long-established RTN load

An outstanding employer As a result of a study conducted by CRF, Schenck Process has been awarded the `Top employer for engineers 2008` seal in Germany alongside 24 other well-known companies. Here are five good reasons why: ·Internationality – with 25 sites around the world, Schenck Process gives its staff the opportunity to deploy their know-how around the globe. ·Open company structure – we give our staff room to develop their own careers – they can for example switch from a technical position to a management career path. ·Flexible working hours model – staff have time accounts to which overtime is credited and can then be changed into time off. We have no core working hours, which means that staff are relatively free to determine their working hours with their team. ·Prospects for the future – whether they are looking for a work placement, apprenticeship or first job after graduating, Schenck Process offers young people the ideal springboard for their career. We

Dust free filling no longer a problem! Thanks to it’s special construction the VSF filling system developed by Vollenda enables a dust free bag filling which is very important especially in the pharmaceutical- and food industry. The fully automatic VSF by VOLLENDA is most suitable for the bagging of free flowing up to critical flowing products in open bags at a filling range from 5...up to 25 kg. Based on an new security -/ and design concept the filling process takes place in a completely closed double-compartment housing. To increase the reliability and to reduce the efforts for cleaning and maintenance to a minimum, the system components as drives, tubing etc. are mounted out of the process area in an intermediate compartment. Pre-prepared open bags are put in a stock in staples or in a slide-in stock. Then the bags are released automatically and placed and clamped on the dust free clamp BK-AS. Due to the pneumatic bag clamp BK-AS it is possible to realize a completely dust free bag filling

REA-JET HR The REA-JET HR is a high-resolution printing system which uses the proven HP TIJ (Thermal Ink Jet) technology. The key characteristics of the REA-JET HR are a safe and intuitive operation, genuine IP 64-durability, a modular design, maintenance free operation and ease of installation. All these characteristics lead to a very high working reliability and guarantee the user a high level of plant availability unique in it´s class, thereby the system can be amortized in the shortest time. The REA-JET HR supports a print height of up to two cartridges with 12,7mm for each cartridge. The high-contrast, full-colour GUI display with a diagonal size of 14,4 cm (5.7 inch) makes for safe operation due to its high brightness and clear visibility. A central element for the input and operation of the REA-JET HR is an industrially suited jog dial. Additionally a numeric keyboard, various special keys and five menu-dependent function keys are available.

Analytical Sieve Shaker AS 300 control The AS 300 control is ideally suitable for the rapid and reliable sieve analysis of sample amounts up to 6 kilograms in one working run. As it is particularly designed for test sieves with a diameter of 305 mm (12’’), the average sieving times can be greatly reduced compared to sieve shakers which are laid out for smaller sieves. Repetitive operations can be greatly simplified with the possibility to store up to 9 parameter combinations. One of the unique features of the AS 300 control is the possibility to eliminate potential influences of error by different sieving frequencies, load or age of the instrument via automatic adjustment of the amplitude. This feature allows for the worldwide reproducibility of the sieve analysis! The AS 300 control can also be used for wet sieving. The benefits of the AS 300 control at a glance: · Sieving with 3D effect · Measuring range 36 µm to 40 mm · 9 parameter combinations can be stored · Short sieving times · Low

REA FL Laser With the REA FL Laser, REA Elektronik extends the product offer within the range of laser marking with a diode-pumped fiber laser marking system. This is available as 12W and 20W version. The pulsed laser system works with a wavelength of 1065nm and offers an alternative to maintenance-intensive and bulky Nd:YAG and Vanadate (Nd:YVO) systems. Sample applications of the REA fiber laser marking systems include among other things: • Engraving and annealing metals, • Colour inscription of untreated and with additives transferred plastics, • Day and night design, • Laser transfer foils, • Coated substrates. With a focus diameter of less than 30µm the highest marking resolutions can be achieved. Character heights of under 150µm are possible. Unlike with the lamp and diode-pumped Nd:YAG systems by selecting the REA FL Laser you can expect a life span (MTTF) of 400.000h, with no regular maintenance required. Beside simple and automated texts,

REA MLV-2D The REA MLV-2D is a measuring instrument which examines the print quality (ISO/IEC 15415) of 2D Data-Matrix Codes (ISO/IEC 16022). The Data-Matrix codes are used in the pharmaceutical industry, the automobile industry as well as in air- and space industries for automatic identification and individual part tracking. In particular for small packing or parts with small surface areas the Data-Matrix code is more practical than a linear barcode, in terms of storing more information in a small area. The checking possibilities can be supplemented by further criteria for the requirements in the field of image processing to get even better results then ISO/IEC 15415 demands. The REA MLV-2D has a measuring area of 54x43mm. The field of view can be made smaller in size by simply exchanging the camera module, in order to be able to measure high-resolution codes. The REA MLV-2D has built in illumination which works at an angle of illumination of 10° and 45°. It can be switched

Even finest Fe contaminations are reliably separated Alfons Greiwing GmbH is a family-run internationally operating logistics company headquar-tered in Greven in the German Münsterland. In more than 75 years Greiwing has grown from a transport service provider into a logistics specialist for complete solutions with more than 380 employees at 5 locations. When it comes to matters of quality, Greiwing is absolutely uncompromising. Work sequences and technology are permanently inspected and improved, and all the company sectors are certi-fied according to DIN EN ISO 9001:2000. At the Wesel location Greiwing specialises in bulk materials, providing high silo and hall storage facilities, handling, as well as silo and box container transshipment. Before the product – for example PE – is fed into the silos through vacuum and pressure conveyor pipes, it is examined for smallest Fe contaminations. For this application S+S supplied the PNEUMAG inline magnet. The PNEUMAG inline magnet was designed for applications in vacuum

The new look of Granulation The new generation of fluid bed systems offers many exciting, new concepts. The Bohle BFS is suitable for drying, granulation, layering and pellet/particle coating without any optional modifications. This new processing design is much more robust than traditional Wurster technology. Due to the shift from top-spray technology to tangential-spray technology, the latest design of the BFS is extremely compact and reduced in overall height. Furthermore, a self-supporting structure without additional side bearings is incorporated to enable simple access and exterior cleaning. Spray nozzles are arranged tangential to the product bed and can be exchanged during the process from the outside. The BFS includes large sight glass ports without intrusive fasteners for easy cleaning and unobstructed product visibility. The product bowl is equipped with an integrated bottom discharge valve. Using vacuum transfer, raw materials can be introduced into the bowl through the discharge

PLC systems to modernize from S5 to S7 PLC systems is possible within shortest time, by using special adapters to reuse the S5 connectors with special adaptation to S7 connectors! The adapters are available and they prevent re-cabelling of the cabinets. Only change the S5-rack by the S7-rack and connect the S5 connectors to the new PLC system -ready! We will assist you with transfering the software to S7 and create new visualisation system to have a new PLC system available in commissioning within one day in work! Send us your request!

Batch dosage Characteristics  Possible net value that can be weighed in: up to 5 kg.  Dosing performances from 0.1 up to 1.0 dm3/min can be realized.  In batch mode, weighing accuracy of up to ± 0.5 g attainable.  Dosing material hopper made of light alloy, available volume 3 dm3.  High dosing and weighing accuracy even at very small set values.  Strain gauge transducer.  Optimal tare / net ratio.  Absolute operating safety even under hardest operating conditions due to robust construction.  No recirculated air and/or aspiration troubles.  Casing closed on all sides, equipped with filling and aspiration nozzle.  Provided with shut-off valve to prevent in-flight-material. Application  Wherever the precise dosing of powdery or granule type products in compliance with the related laboratory accuracy standards - even under hardest operating conditions - is required.  Also
