News items June 2009

Blowpipe Fast and Reliable Fastening for Bag Filters Now, bag filter maintenance is easier and faster by using MikroPul’s patented MikroFix® blowpipe fastening system. MikroPul – one of the leading suppliers of industrial dust collection equipment – established decades ago an efficient cleaning system, which has since been further developed and became standard in many different applications. The MikroPul Pulse-Jet Technology, invented over 50 years ago, releases dust effectively and reliably from the filter bag surface using short high-pressure back-pulses of compressed air from the clean side of the bag. Clamps instead of Screws The MikroFix® fastening uses „click-on“ clamps which quickly connect the blowpipes reliably to housing flanges. Dismantling does not require any tools, as the clamps only need to be pulled off. Swivel nuts, screws or other connecting parts are eliminated. Access to filter bags and cages is considerably simplified. User benefits The use of the MikroFix® fastenings is safe

Automated sampler for powders and granules The proven automated sampler PowderProof has a new drive assembly. The sampler for powders and granules can now be used with a rechargeable battery drive as well as with a pneumatic drive. This may be especially useful if there is a compressed air connection at the sampling site. The PowderProof operated with compressed air can be used in areas where electrical equipment is not allowed.

Prevention from abrasion- and dust development Product buffering and safety filling with the filling telescope. Prevention from abrasion- and dust development by the further and arrange formed rough- through fine-grained products they are - fragile - wear sensitive - spraying - explosion hazard being, must be do special measures to prevention from break, abrasion dust seized. In many technical processes, were are rough- through fine-grained bulk materials will processed, there step a unintentional corn on to crushing. It is necessary very often to limit the crushing as far as possible (drop in sales revenue). Through a special regulated filled technique , the sparing filling could will be guaranteed : Operational areas: * Non food and food area * tabletting, granulated * briquette or domain of applicability * explosion hazard spray * emission limit * noise development .

The OPDENHOFF Technologie GmbH has successfully established a quality management to DIN EN ISO 9001:2008. The certificate was drawn by the TÜV Rheinland after the certification audit in March 2009. Why ISO 9001 to the OPDENHOFF Technologie GmbH? Consistent quality assurance is a central instrument of the corporate strategy with the uppermost priority of the OPDENHOFF Technologie GmbH. The ISO 9001–certification is an important step to guarantee the customer a optimum product quality by a constant adaptation to the current technical development. The quality management system accompanies all relevant operational processes, analyzes them to optimisation possibilities and documents them comprehensible and transparent. What was certified ? The quality management is certified for the scope Planning, development ans realisation of complete system solutions for continuos and discontinous processes. IT solutions, automation solutions and control solutions

Simple Setup * Filling * Negativ Batching The R400 series has been expanded to include the K410 software for single material filling applications. Batching specifications: * 100 Recipes (Products) * 3 set batching stages - Fill, Dump and Pulse * 1 Material * 3 Speed Fill * Fill correction using jogging or in-flight * Dump to time or weight * Negativ batching - Supported by setting the fill direction which defines if the weight is increasing or decreasing while batching * Batch suspend - A suspend function key can be set that will pause the batch and adjust the tare weight when resuming the batch * Timer based multiple batching Ideal for dosing and bag or silo filling as well as filling applications using negativ batching, e.g. dischcarge from a silo into a truck. With its large two line display using logical prompts, its dedicated and programmable function keys and the tailored printing of custom record, docket and reports printout the R400 indicators are highly operator friendly.

ROTEX`s success at ACHEMA 2009 ROTEX, the global leader in the development and supply of screening equipment and technology for the process industries is pleased to announce that their attendence at ACHEMA 2009, exhibition and conference, was a great success. Our many visitors had the opportunity to see the famous ROTEX gyratory movement in action and to test our new panel system on our new APEX™ machine, but also to see and try a ROTEX screener and a working Mineral Separator model. The quality and number of the projects and the contacts made from ACHEMA proved to be one of the most professional and useful exhibitions ROTEX EUROPE attended this year. We would like to use this opportunity to thank all our visitors and partners for making this exhibition a huge success for everybody : customers and Rotex.

The GRAF company based at Teningen has recently commissioned a coextrusion blow-moulding machine manufacturing products for rainwater use with a volume of up to 3000 l. The Graf company has a large product range all about water management and is the greatest German manufacturer of rainwater containers. The multilayer containers are produced in one single production step and side products of each finished part are tops and tails with a unit weight of more than 20 kg, the weight of the purgings can be many times higher. A Herbold granulator of the SMS series recycles these tops and tails, still warm, next to the line where they are produced. Herbold Meckesheim GmbH is the manufacturer of this turn-key customised grinding plant. A characteristic feature of this plant is the little power input needed for the size-reduction of these viscoplastic high-molecular PE tops and tails – this was in the end run the decisive criterion for GRAF to decide in favour of the Herbold

For the transport of raw limestone, AUMUND Fördertechnik of Rheinberg supplies five LOUISE troughed chain conveyors with a conveying capacity of 270 t/h to the Herrlingen plant of Märker Kalk GmbH. The troughed chain conveyors from AUMUND are used in the new limestone screening operation. Three conveyors will distribute the material (low-burnt material and kiln cakings) to the corresponding silos. Another two are destined for the discharge from the silos. The set of machines to be supplied is complemented by three chain bucket elevators with center distances in the range of 13.5 to 43 m and conveying capacities of 50 to 350 t/h. The LOUISE troughed chain conveyor has proven its worth as reliable solution above all for the transport of difficult bulk materials such as limestone, gypsum or filter dust. The dust-proof components (standard parts) are also available in gas-tight, pressure-tight and water-proof construction. The main fields of application for

Extensive range of weighing and electronics components METTLER TOLEDO is a leading manufacturer of weighing components for constructors of instruments, machines, systems and equipment. The comprehensive range of weighing cells covers everything between 120g and 300t, with the smallest readout accuracy being 0.01mg. The range of electronics covers complete weighing terminals for fitting in control panels, as well as components available for fitting in DIN rails in switch cabinets. Depending on the version, the electronics can be integrated in superordinate controls using analog or serial interfaces, Profibus DP, Profinet IO, Ethernet IP, Modbus, DeviceNet or ControlNet The extensive range is presented clearly in the 180 pages of the new catalogue, which also features drawings and installation instructions. Order the latest catalogue through the link on our company page (click the link below:)

Patented wear protection improves economic efficiency Master-PROTECT tube bends not only feature a PU lining but have a special, patented internal geometry. The lining acts as a protection to the actual tube wall and prevents early wear. The most distinctive feature, however, is the reinforced lining at the very point of the bend that is subject to the greatest mechanical loads. The inclined PU portion provides a relatively smooth material flow around the bend, ensuring particles hit the lining instead of damaging the tube wall. The risk of clogging is reduced since clogging does not occur at the narrowest point of the bend but at the slowest flow rate. The new design ensures improved material flow and reduced pressure drop. At the same time, material build-up and caking is decreased since the tube bend has no offsets or edges upon which material could accumulate. The innovative product features a lightweight, compact design and provides significantly lower noise operation than any conventional models. By now, Master-PROTECT

The new Challenge under Windows CAN in real-time A continuously accelerating data exchange demands better methods for data processing from developers. Thanks to the Windows extension »RealTime Suite« by Kithara Software there is a real-time solution for CAN. While using CAN-boards for example by Peak, IXXAT or EMS Dr. Wünsche, a safe and fast data exchange as well as a quick reaction to external events are demanded. At this point the usual Windows drivers fail, they are only usable from within the execution context and do not support real-time. The new real-time CAN module by Kithara completes the Windows extensions and realizes a lot of automation solutions which require real-time compliant CAN connection. The function library is used by developers who require a time critical handling with CAN messages for example machine builder and computer control companies. At present boards with 1, 2 and 4 port/channels are supported. CAN messages are stored in the cache during the process of sending and receiving

Vortex Valves for a long term solution You can download the new procuct cataloque from the ITS website
