News items January 2010

SPIDO2B Is a state of the art, user friendly batch dosing and control system complying with all the needs for the bakery- and pastry industry. Based on a unique PLC platform where process visualisation, recipe control, production planning and alarm management are all integrated in a user friendly and ergonomic way Additional to the basic dosing point control, possible extension with functions for manual or automatic minor ingredients, water dosing with temperature calculation as well as a batch follow-up system. Additional possible extension with a tracking & tracing module in accordance with the General Food Law. Disposes of real time and historical trending Can be linked with ERP, as for registration and control of the baking processes and registration of quality parameters. Available as an extremely fast PLC system with 6” or 10” touch screen with web server and serving a 100% compatible software platform. We will present SPIDO2B at EUROPAIN in Paris

Leading edge measurement technology helps to prevent product recalls Monitoring the screwdriving assembly process to detect errors sooner Product recalls are the fear of every industry. Automobile defects are especially in the public eye. An automobile recall is mandatory when stemming from an unforeseen, unavoidable and imminent threat to personal safety. When a particular vehicle type is identified as a risk, the original automobile manufacturer will initiate a “vehicle recall”. With the support of the government automobile registration authority, individual owners of the affected vehicles are identified. With this information the manufacturer can notify the owners directly to return the vehicle to their local service provider for modification. Additional to this the automobile registration authority maintains the statistics for vehicle recalls. For example: in 2008 the German “Kraftfahrtbundesamt” documented 148 cases involving 726,000 vehicles which were recalled by the manufacturer. For the past few years vehicle recall

LUM GmbH welcomes world-wide sales partners in February Berlin, 25.01.2010: L.U.M. GmbH, market leader in innovative instruments to analyse dispersions, welcomes its world-wide partners now to the 11th international technical and cultural exchange at the headquarters in Berlin-Adlershof from 23-25 February. „During the last year we have increased our international sales network by 13 % and established competent partners for LUM products in 42 countries. Hence, the local business units of our global customers as well as regional customers from industry and science are provided with a quick and competent support“, explains Prof. Lerche, Managing Director of LUM GmbH. “We especially welcome new partners from Korea, Spain and Portugal, who already successfully sold our analytical instruments within a short time after starting the partnership.” All participants will undergo an intensive training in stability analysis and particle characterization of emulsions and suspensions from different application areas, including

INFASTAUB launches the new silo vent filter in rectangular design Filtering separators are essential for silos. The INFA-JETRON silo vent filter; type AJB 800, has proven performance for this application. The "Filtration + Separation" magazine has already commended the bestseller and its performance. INFASTAUB from Bad Homburg uses the experience of the reliable AJB 800 and launches the silo vent filter, type AJP 224, in rectangular design. The construction of the newly engineered cartridge filter combines both the strengths and benefits of the AJB and of the mechanical shaking filter AM 204, which has been installed on many silos for many years. It focuses on the identical dimensions of the AM 204 and the pneumatically cleaned AJP 224. Consequently, the connecting flanges on the silos don’t have to be modified, if you want to change the filter type. This saves costs in a new investment. In addition, the standardisation allows very versatile applications. Without making alterations to the flange connections, the AM 204

Silo discharging Gottwald GmbH built up an reputation with silo discharging screws for (flat bottem) silo’s with a big storage capacity and/or heavy flowing materials as wood, biomass, meatmeal, paper etc. We can deliver systems for silo’s up to diameter 16 mtr. and are also available in stainless steel. JAVO Procestechniek installed already several systems succesfully .

Grinding with the Vibratory Micro Mill PULVERISETTE 0 Relatively new on the market are scented toys. Not only do these substances smell good, but they also possess an allergenic potential. It exists EU directive in regards to the regulation of chemical safety of toys was passed. The contained critical values are by all means questionable. Derived from this difficulty the task was drafted, to comminute a sample of a “scented toy horse” in such a manner so that a powder evolves. The scents can not be lost though. Scents are relatively slightly elusive in order to be smelled. Therefore it has to be assumed that with the amplification of the surface, a faster transition into the ambient air occurs. Therefore the substances would elude analysis. In order to avoid this to the greatest possible extend, the sample was comminuted during permanent cooling with liquid nitrogen. For this 8 x 8 mm large chunks were cut from the toys and comminuted with the Vibratory Micro Mill PULVERISETTE 0, equipped with a cryo-box,

Loesche relies on Intensiv-Filter Indonesia"s Gresik group covers approximately 80% of the local cement market. The world"s largest cement mill producer Loesche received the order for the supply of four cement mills mill for the new cement-grinding plants Tuban and Tonasa. Loesche relies for the dust removal of the mill on Intensiv-Filter and their modern bag filter installations. Loesche placed an order with Intensiv-Filter including a total of four process bag filters of the type “ProJet mega ®” as well as small filters and accessories. The process bag filters are designed for a volume flow of 690,000 m3/h and a raw gas temperature of 90-120 °C. Filter bags with a length of 8 m come into use and a filter area of about 11,000 m2. The cleaning of the “ProJet mega ®” is made in offline mode.

The new vibratory sieve shaker AS 450 control accepts loads of up to 20 kg With the analytical sieve shaker AS 450 control RETSCH have designed their first siever for 400 mm and 450 mm sieves which operates with a three-dimensional sieving motion. It can be used for dry and wet sieving. The optimized electromagnetic drive allows for an amplitude up to 2.2 mm which renders the separation process much more effective than with other sieve shakers of this type. Reproducibility plays an important role: The amplitude - which is independent of the sieve load - is continually adjusted. The three-dimensional sieving motion lets the sample material move equally over the complete sieving surface. This results in high load capacity, extremely smooth operation and short sieving times with high separation efficiency. When it comes to operating comfort, the AS 450 control meets all the requirements of a modern laboratory. All parameters such as amplitude, time and interval are digitally set, displayed and controlled. It is possible to store up to 9 parameter

Vacuum conveyor for safe and gentle conveying of powders and granules With the new development of the ProClean® Conveyor, we have succeeded in making use of this knowledge and presenting our own vacuum conveyor. In particular in the pharmaceutical, food and chemical industry, the ProClean® Conveyor can prove its superiority in the safe and gentle conveyance of powders and granules. The heart of the ProClean® Conveyor is its filter head. There, the innovative and powerful ring filter system is located. It is available in different versions, features a big filter surface, is easily cleanable, long-lived, robust and enables fast dilute phase as well as safe and gentle plug conveying. The cover of the filter head is free of connections. Thus it can be opened quickly and the filter can be replaced easily and without much effort. The optional installation of a sight glass or a level indicator permits the system to be checked easily without having to open the cover. The ProClean® Conveyor sets new standards in terms of operator

The volumetric version of the gravimetric ProFlex® C feeder is a low-cost alternative to a proven Schenck Process product. It is also used to feed additives and fillers in powder, granulate or fibre form. One particularly appealing feature of the volumetric feeder is that it requires no maintenance. Its well thought-out design also makes flexible installation possible. Available in two feeder sizes and a total of three container sizes, the system fits in any available space. Up to eight feeders can be installed in a very compact space to form one complete feeder station as the augers are positioned off-centre. The position of the drive and auger can be changed at any time and they can easily be modified later on. Vertical container walls mean that optimum use is made of the space available and this also impacts positively on how the bulk material flows. The ProFlex® C feeder system is available in two discharge lengths for feed rates of up to 9500 dm3/hr. Maintenance-free

Grain Silo The new bulk storage terminal that Ultra-Brag AG operates in the Rhine port of Kleinhüningen is an impressive structure, with overall height of 83 meters, it clearly dominates the Basel port skyline. This height required a number of special measures: The structure has to be earthquake-proof, it must be resilient enough to absorb wind loads, and its immense weight must be reliably supported by its relatively small footprint of 27 by 40 meters. The concrete structure, which was built by the slip-forming method in three stages, therefore stands on a large number of piles with a thickness of up to 1.2 meters and a length of 28 meters. The bulk storage section houses 32 round storage bins plus 15 interstice bins, which hold more than 40,000 cubic meters of material. Most of the Buhler supplied equipment is installed in the headhouse of the elevator building. The core systems of the entire installation are the two 87-meter-tall belt-and-bucket elevator legs which elevate

Twin-level flat store The twin-level flat storage facility built for Ultra-Brag AG in the Auhafen port of Muttenz has a footprint of 42 by 120 meters holds a total of 27,000 cubic meters of bulk animal feeds and of 6,600 cubic meters of fertilizer. The modified design supplied by Buhler – with chain conveyors installed above the flat store roof for introducing the material into the feed storage section instead of belt conveyors inside the building – increased the customer’s total storage capacity by more than 60 percent with given building dimensions. The formulated feeds and the fertilizers are stored and handled on two completely separated building levels. The top level of the flat store is reserved for animal feeds. Its 25 compartments are filled by separate roof-top conveying systems. Fertilizer is stored on the ground floor. As the new flat store is not located on the waterside, a high-capacity, dust-free conveying system had to be constructed from the grab crane to the new shed

Three functions in one machine SWECO, the world leader in separation technology, introduces the DC Classifier, a multi-functional unit designed to dry, cool and classify all in one machine. Developed specifically for the plastic pellet industry, the DC-Classifier is perfect for any dry application requiring one, two or all three functions ... drying, cooling or classifying. The top two screens of the DC Classifier encompass the drying and cooling stages, using either positive or negative air flow to draw moisture and heat away from the particulates. The classifier can then contain either a single or double particle classifying deck where the sizing and dedusting of the material takes place. The DC Classifier was designed with modular decks for easy removal for cleaning in-between process changes when more than one material type or color is proccessed in the same machinge. The Classifier can also be designed with casters for trouble-free mobility around the lab or production facility. Dryer, Cooler,

Prescision tensioning, lower tolerances SWECO Fusion Screens are the latest in a long line of technologically advanced products from SWECO, the originator of the vibratory round separator, Supertaut-Plus-Screens, Magnum-Screens and countless other innovations. Fusion Screens habe been designed to eliminate the use of adhesive, epoxy or silicone in screen manufacturing. Instead, the mesh is "fused" directly into the patented polymer construction tension ring. The repeatability of the robot construction assures precise tensioning, lower tolerances and smaller deviations of the screens. Fusion"s unitary construction integrates the screen gasket directly into the tension ring. This design eliminates the handling and stocking of separate gaskets and provides a precision fit into the separator. this unitary design also reduces cracks and crevices, producing a more "cleanable" screen with less potential for cross contamination. And the one-time use ring is disposable, saving handling and

Following a year in which he has spoken at many different events covering aspects of powder characterization, Tim Freeman, Director of Operations for Freeman Technology, will again join academics and other industry experts for the next Mixing Consultants Inc. course. The course, which is being held in Pearl River, NY, USA from 23–25 February, covers the ‘Blending and flow of pharmaceutical powders’. The content is being delivered by: Professor Fernando Muzzio of Rutgers, The State University of New Jersey; Ralf Kretzschmar, President of Glatt Systemtechnik GmbH; Ralf Weinekötter, General Manager of Gericke AG; and Tim freeman. Programme details and registration information are available at: http://www.freemantech.co.uk/goto.php?link=10012_30001 Key elements of the course include regulatory perspectives, mixing of free-flowing materials, mixing of cohesive materials, lubrication, continuous mixing and powder flow issues. “Once again I am pleased to
