News items April 2010

LFR flexible connectors Our new LFR conector is a flexible connection that includes a tri-clamp coupling. Pressing SS316 ferrules onto the sleeve makes the entire connection air-tight and creates a smooth flow profile. For the first time the high quality of the tri-clamp coupling and the high quality of our flexible connectors can be combined to a hygenic, dust- and airtight connection. All standard tri-clamp sizes are possible, starting at Ø 56 mm. - ISO - DIN - BS (British Standard) - ASME BPE However, deviating tri-clamp sizes can often also be assembled. You can choose from a wide variety of flexible materials. Almost all types of rubbers and plastics are possible. As is our latest flexible transparent antistatic foodgrade Poly Urethane film. There are many different options for ATEX, food grade and chemical applications.

Filcoflex & ATEX Antistatic Poly Urethane flexible connectors. There has long been a demand for antistatic flexible connectors wich are approved for contact with food. There were already plastics and rubbers sorts available with these properties, but never without a some disadvantages. These materials were often very stiff, dark or not permanently antistatic in a dry environment. Also, the transparent colour of poly urethane could not be combined with antistatic properties. Filcoflex B.V. and Euromanchetten & Compenatoren B.V. have long been looking for a material in which these requirements can best be provided, without the disadvantages. And in 2010 we are glad to introduce two different PU films wich both can provide the following: - Permanent Antistatic in a dry environment - Transparent - Suitable for food contact - Great flexibility - Great abrasive resistance - Great durability - A very high elongation and tear resistance - Able to handle any size and shape due

As of today April 26, the new Filcoflex website is online. You can see our whole new style. And in Solids Processing youll find our latest add, also in a completely new look. You will see that our program is quite extensive, and that you can find much more information than in the past. At the end of the year, the online ordering system wil be available We hope these resources will provide you with convenience.

More than 400 exhibitors and an outstanding scientific program The countdown is running – on June 1st, AchemAsia 2010 will open its doors in Beijing’s CNCC China National Convention Center. More than 400 exhibitors have already registered for the leading exhibition congress for the process industries in Asia, making it one of the biggest events in the series so far. Besides the exhibition which offers exhibitors and visitors the opportunity to discuss the latest challenges and solutions in the process industries, the outstanding scientific program provides information on the current thoughts and developments in chemical engineering, environmental protection and biotechnology right from the opening day. After the Opening Ceremony, Mr. Cao Xianghong, Chairman of CIESC, will give a plenary lecture on “Thoughts on the countermeasures to realize sustainable development of refining and petrochemical industry in China”. The second plenary lecture of the day is given by Dr. H. J. Wernicke, Chairman of DECHEMA and Vice Chairman

Miniaturisation: New generation of machines delivers top processing reliability The tide of ever smaller, ever lighter electronics cannot be stopped. Whether a mobile phone on your wrist or an electronic controller for the petrol saving start-stop-system in vehicles, the demand on engineers is always the same: Maximised potential in electronics for minimum weight and size. In all areas of industry the answer is miniaturisation. This creates another challenging task for automation experts, since every day in industrial production millions of screws are assembled and of course even the tiniest of screws must be analysed for the utmost processing reliability. Screw joints are again in vogue and screwdriving technology is currently experiencing a striking upturn. In times of shortage of resources and environmentalism, system designers must stay abreast of new demands: devices should be repairable and recyclable. Although reworking is almost impossible with other joining technologies such as gluing and laser welding, this is just one of the advantages

Flow-through regulation Tubing clamps can regulate or stop the flow through of tubings that carry fluids or gases. Step-less flow regulation: The knurled screw allows very fine stepless flow control. The flow can also be shut off completely and that also with already existing hose connections. Stop-it metal is extremely heat resistant and robust due to the materials steel and aluminum. The hose clamp is available in four different sizes up to a maximum hose diameter of 30 mm.

The new SPTD plug diverter has a single straight pipe and will be available in sizes from 150 mm (6”) up to 400 mm (16”). The straight pipe diverter is very suitable for applications in the food, pet food, plastics and petrochemical industries. DMN-Westinghouse will introduce the new SPTD on their stands at the Powtech in Nuremberg (H9-114) and the PTXi/Powdershow in Chicago (stand 1228). The design of the SPTD plug diverter conforms to all current legislation regarding safety in the workplace. Consequently there are no moving parts on the outside. The new SPTD has been designed to be user friendly, pressure shock resistant and with standard static seals suitable for pressures up to 3 bar g. All sizes are optionally available with inflatable seals. The DMN-Westinghouse sptd has been specially designed to route powders and pellets with minimum degradation in pneumatic conveying systems. A smooth passage of product is guaranteed by precision machining,

For dry, wet and paste-like goods amixon® is presenting a new generation of vacuum mixer dryers with its AMT series. Machines within the AMT series differ from previous models because of their conical floor form. This floor offers the decisive advantage that complete and automatic self-emptying is achieved with free-flowing material. A further benefit is that even mixing is also achieved in the cone. This is the result of a patented, helical ribbon mixing tool, which creates three-dimensional movement of the goods to be mixed. The goods move upwards at the periphery, while they are moved downwards again in the centre. Not only the mixer itself, but also the helical ribbon, mixing arms and mixing shaft are completely heated. Drying is extremely fast, gentle and even. The tank is vacuum- and pressure proof, which means that pressure-dependent reactions can also be managed. For example, an inert carrier gas can be used for subsequent drying. The AMT mixer dryer reactor is suitable for drying powders,

Gravimetric metering feeders for the food industry Great demands on hygiene in the food industry do not only require easy cleanability of machines applied but also involve a wide range of additional measures to prevent contamination with microbiological, chemical and physiological contaminants. Equipment suppliers must make sure to comply with hygienic design principles. For the field of bulk ingredient metering Brabender Technologie has therefore developed the "Brabender Food Line" in close cooperation with leading food companies, resulting in an array of metering feeders strictly complying with all relevant standards, guidelines and recommendations for the food industry (DIN EN 1672-2, EHEDG, FDA, etc.). On the one hand, special attention was given to technical solutions allowing particularly quick and easy cleaning. On the other hand, however, the development especially focused on preventive measures to avoid contaminations, for instance plain stainless steel surfaces, non-porous and ground welding seams

Optimised cost-performance ratio, high reliability, quick installation Today content measurement in smaller silos for building materials or within the feed and grain industries are still determined manually what is viable especially for frequent measurement cycles. The results are often estimated and not accurate at all. The new electromechanical plumb bob Nivobob 4000 was designed by the experts at UWT GmbH Level Control to fit those applications where price is the decisive factor. An aiming flange offers the option to install the instrument directly on the silo roof without any special mounting socket and can then cover ranges up to 30 meters. Two versions are available: a model with rope for dry products and one with tape for adhesive products. The latter provides an automatic tape cleaning system which protects the interior of the instrument from material pollution. To avoid contamination of the electronics, it is completely separated from the mechanical chamber. The instruments are available for power supply with 230 V or 115 V

R400 Series - R423 Standalone Stainless Steel The R423 previously available in a panel mount version is now available in a standalone stainless enclosure. • Rated to IP66 it is dust and water resistant • All Stainless Steel (304/1.4301) • Easy access to rear of indicator and cabling when back cover removed • Compatible with all R400 series modules • High impact polycarbonate lens to protect the LCD from knock • Easily accessed tilt adjustment with positive locking Multiple mounting options using a single stand: • Desk/Wall/Post • Cut outs - key hole, Rinstrum standard post mounting and cable routing hole Available for all R400 application software: • K401 General Weighing • K402 Multi-product • K404 Truck Weighing • K410 Filling • K411 Batching • K481 Summing

Wirelessly configuring and monitoring scales from "a safe distance" Weighing and feeding can be a very elaborate, time-consuming and costly process. Configuration, monitoring and maintenance work are significant factors depending on the raw materials to be processed and the system properties. In some cases, scale controls used in tough environments incur high maintenance and repair costs. Ten years ago Schenck Process took its first major step towards improving cost/benefit ratios with specially designed mechatronic weighfeeders. These feature mechanics and electronics in a shared sturdy unit which makes them particularly robust, durable, easy to maintain and highly interoperable as various interfaces allow them to be linked to virtually any automation system. EasyServe. The name says it all The EasyServe service program can be used to conveniently install, configure and monitor the weighfeeders using a laptop. And thanks to new Bluetooth wireless modules, this process went wireless two years ago. A process requiring

Optical Particle Analysis with the new CAMSIZER XT from Retsch Technology The quality control of fine powders can be substantially improved with the new CAMSIZER XT: More precise and faster analysis of particle size and particle shape helps to improve the product quality, reduce rejects and save labor costs, energy and raw materials. The design of the Camsizer XT is based on the well-proven optical particle measurement system Camsizer but is optimized for finer samples. Not only the improved optical resolution but also new options for material feeding allow for an extended application range. Fine particles tend to agglomerate which makes it difficult to record the properties of a single particle. Therefore, it is important to have various possibilities of feeding the sample to the analysis area to be able to find for each material the optimum between the desired dispersion of the agglomerates and the undesired destruction of the individual particle. The CAMSIZER XT offers flexible solutions, from the free fall mode, which is the most gentle

Universal for all sensor types and brands Do you want full visualisation of silo content & status of all silos on any PC on the LAN? The ICS22 webserver system gives full accesss to all Silos on any PC an the LAN! for new installation and extentions of exisitng silos independent of sensor brand and type of sensor (radar, microwave, silot, weighing system min max sensors) are attached. No application licence required,due to browser technology linked via ethernet to the server. alarm indication by email or SMS reporting. Level history is available for any silo attached. Useful for VMI services or remote readout of silo level over distances. Easy to install even extention of the webserver to existing silo monitoring systems is reasonable!

At the POWTECH 2010 trade fair S+S focuses on metal separators of the Rapid series At the POWTECH 2010 in Nuremberg (hall 7, stand 7-667) S+S Separation and Sorting Technology GmbH of Schönberg presents the highly sophisticated metal separators of the Rapid series that separate magnetic and non-magnetic metal particles (steel, stainless steel, aluminium, ...) from free-falling bulk materials. By the way: The Rapid series, which was introduced on the market in 1980, formed the basis for the leading position S+S today has in the field of industrial metal separation. In the year 2010 S+S celebrates 30 years of experience in the metal separa-tion of bulk materials. The new, extremely compact Rapid 8000 metal separator is designed for high throughput rates with nominal widths starting from 200 mm. It can be universally used for the inspection of a wide range of products covering powdery, fibrous, and chunky products. The completely new reject mechanism of the Rapid 8000 metal separator reliably prevents any jamming of coarse-grained and badly pourable

VPVision With the VPVision system, VPInstruments offers the complete solution for cost allocation of compressed air. With just one touch VPVision shows real-time data providing direct insight in the compressed air consumption in your entire plant. VPVision is an essential monitoring tool for an easy way of saving energy and thereby saving money. VPVision consists of a central touch screen and is equipped for 8 connections mass flow meter; our VPFlowmate and/or VPFlowScope. VPVision can even be expanded up to 16 flow meter connections. On the touch screen you can see the actual consumption and the accumulated costs per division of your plant, presented in a comprehensible overview. VPVision logs all your flow data for further analysis and report. Because of the built-in Ethernet interface, you can view VPVision from every PC in your network; making it easy to keep an eye on your energy consumption. With the VPVision system you have a complete solution to monitor your compressed

New trends on the scientific congress in Nuremberg LUM GmbH, Berlin, Germany, presents new scientific results from the comprehensive characterization of dispersions and particles during two talks and in 8 posters on the 6th World Congress on Particle Technology (WCPT6) in Nuremberg from 26 – 29 April 2010. LUM GmbH is market leader in innovative instruments for direct and fast stability analysis and particle characterization of dispersions. Using LUM’s extremely powerful measurement instrumentation demixing processes in dispersions can be analysed in a rapid, efficient and reliable way, a comprehensive characterization of dispersions is provided. Besides the provision of innovative measurement instrumentation LUM supports the development of the subject area of „Basics and Applications of Dispersions“. Recent scientific results, partly obtained together with national and international co-operation partners, are presented to the international audience on WCPT6. The focus of the contributions is on the direct

Dispersion stability, particle size & more - POWTECH 6-114 L.U.M. GmbH welcomes all visitors to present innovations for dispersion analysis & particle characterization. During POWTECH besides L.U.M. products also new instruments for particle shape analysis and flowability of powders are presented. Non-spherical reference particles complete the presented highlights. The new Demixing Tester LUMiCheck® (L.U.M. GmbH) is your first step in dispersion analysis. This instrument is especially designed for the quality assurance lab. It is used for the uncomplicated, comparative stability analysis & particle characterization of dispersions in their original state (without sample preparation or dilution). The fast quantitative comparison of different samples and the qualitative characterization of demixing behaviour, flocculation, sediment formation and stability make LUMiCheck the instrument of choice for the measurement of beverages and food, construction material, fuel and lubricants, and generally speaking for a large variety of

High reliability in feeding, less rejections. Higher demands of product quality in the chemicals, detergents, food and plastics industries needs higher dosing accuracy. Besides the accuracy of loadcell and feedcontroller as well as a proper selection of feedertype, the final accuracy also rely on a proper ventilation and refilling of the feeder. Deaeration while feeding of powders by using filtercandle or filterhose leads to blockage after a short time. The air escapes through inlet and outlet of the feeder resulting in a delay of refilltime and an uncontrolled blow-out at the outlet leading to rejection of production by an inaccurate dosing, unreliable production and various errors. Based on more than 50 years experience in developing, manufacturing, installation and service, Brabender Technologie KG developed the JetFilter, an improved self-cleaning system for venting of gravimetric feeders. The JetFilter works as dust collector for particles larger than 5ìm and is mounted on the feeder. Compressed air

World`s first hermetic direct driven dairy separator. Suitable for all dairy customers with high capacity production, the Tetra Centri AirTight Eco separator reduces energy consumption of an overall separation system by up to 35% compared to conventional paring disc separators and doubles production time between major services compared to belt driven separators. Said Lars Jacobsson, Managing Director, Tetra Pak Processing Components: “This new generation separator is a further development in our proven Tetra Centri AirTight range of separators. Using a number of breakthrough innovations to deliver higher operational efficiency and lower environmental impact than ever before, the Tetra Centri AirTight Eco separator will enable our customers to cut costs and meet the growing environmental demands on their operations.” The new Tetra Centri AirTight Eco separator introduces three innovations: the eDrive system, the eMotion system and the eCon control system. Unique to the TetraCentri AirTight range of separators

Fast Bulk Robot with integrated sieve Van Aarsen’s latest development, a X-Y bulk robot with integrated sieve was commissioned in December 2009 in the new bulk out-loading facility of the Boerenbond Deurne in Oirschot, The Netherlands. This newest version of the Van Aarsen bulk robot was designed completely in 3D to optimize the design and the production process. To enable high speed bulk out-loading, the bulk robot is equipped with frequency controlled individual drives for all 8 wheels. In combination with the sturdy construction of the drive frame, this allows the bulk robot to accelerate and de-accelerate rapidly to a speed of 1.25 m/s. The accurate positioning of the bulk robot is achieved by means of laser distance measuring systems. The signals from the laser systems are processed in an integrated PLC control system that is compatible with the factory process control system. Safety features include collision protection, end of track detection, various safety switches and a work platform at

Unique 3 sieves automatic screen exchange system For their GD Hammer Mill Van Aarsen developed an automatic screen exchange system for 3 screens. The system is already operational in 2 feed mills and demand is constantly increasing. The system consists of a cassette unit with 3 slots to hold the screens, a motorised insertion system and control system. The screens are stored in a cassette system that is suspended above the hammer mill. This construction enables: • The surface area required for the hammer mill to remain the same • Easy access, ergonomic working conditions • Use of simple straight screen plates • No extra tools • Sieve exchange during operation • CE protected cassettes • Cassettes to be moved aside when opening the hammer mill doors The screen is suspended in a cassette slot by means of a lever with pneumatic cylinder. During insertion the lever pushes the screen down into the mechanism. The insertion mechanism consists of two sets of motor driven wheels that place the screen

On 29 March 2010, ERIKS bv acquired Kubra Plastics in Nuenen, the Netherlands, part of MCB International bv, Valkenswaard. The activities of Kubra comprise the marketing, sale and customising of products and services in the field of plastics technology. In 2009, Kubra realised sales of approx. € 4.5 million. Kubra supplies its products directly to the industry. As a part of ERIKS bv, Kubra will continue to serve its customers independently. Both Kubra’s and ERIKS’ customers will benefit from the joint plastics assortment, the product and application know-how, the product development and the logistics services. With the acquisition of Kubra, ERIKS strengthens its market position in the core activity industrial plastics in particularly the South Netherlands and is in an even better position to offer its customers an integrated service package of technical plastics (industrial plastic semi-finished products, machined products and injection moulded parts).

ERIKS bv has reached an agreement in principle to acquire Alfa Techniek bv in Almere, the Netherlands. Alfa Techniek is part of MRC Transmark and holds a strong position in the development and the supply of innovative products of rubber technology, sealing technology and connectors in de Dutch and European markets. The company supplies its products directly to the machine and equipment construction and realises sales of € 9 million (of which 70% in the Netherlands and the remaining part in the rest of Europe) with approximately 14 employees. By acquiring Alfa Techniek, ERIKS strengthens its position in the field of technical rubber and sealing technology. For many international machine and equipment constructors, Alfa Techniek acts as partner in development and as supplier. The co-engineering and sourcing know-how is an enhancement for ERIKS. Moreover, the European customers of Alfa Techniek are an excellent basis for ERIKS’ strategy to expand its activities in
