News items December 2010

Robust, Accurate, Versatile Sensocon, Inc., a leading manufacturer of pressure, air velocity, and flow products announces the release of the new Series A4 Differential Pressure Controller. The Series A4 is ideal for pressure, velocity, and flow applications and includes 2 SPDT relays and a simple programming menu that allows full configuration of variables such as setpoints, dead band, engineering units, flow coefficient, duct size, and many more. Programming can be done on the easy to read OLED display which will also display units of measure, setpoints, or other users defined variables during normal operation. The Series A4 is also available with a 4-20 mA output that can be digitally scaled to meet each unique application. The standard accuracy of the Series A4 is 1% with optional 0.5% and 0.25% available for most full scale ranges from 125 Pa to 12,5 kPa. Other standard features include a universal power supply that accepts any voltage from 24 to 240 VAC or VDC and Opti-Link™ communications

Sensocon, Inc., a leading manufacturer of differential pressure, air velocity, and flow products announces the new Series 251 Wet/Wet Differential Pressure Transmitter. The Series 251 Wet/Wet Differential Pressure Transmitter can be used to measure positive, negative, and differential pressure of compatible liquids and gasses. The primary advantage of the Series 251 is that it utilizes a double diaphragm sensor technology that outperforms traditional dual sensor products in accuracy, reliability, and static operating pressure. With the double diaphragm sensor technology the Series 251 offers 0.25% accuracy and static operating pressures up to 3500 kPa at measuring ranges as low as 0-35 kPa. The Series 251 features 316 stainless steel construction and is designed to meet NEMA 4X (IP 65) standards. The transmitter also offers exceptional field flexibility with a 5:1 turn down and comes standard with a certificate of calibration. The Series 251 Wet/Wet Differential

Process reliability starts with the selection of tools Basic information regarding screw assembly technology In the domain of technology, screw joints are the most frequently used method for joining components and, in many cases, to separate them again. Screws can be tightened and loosened again without damaging the connected components in most applications. In today"s environmentally aware times, people have come to understand the value of the materials contained in defunct consumer goods. The edict is "prudent reuse of resources". If we consider recycling demands alone, it can be argued that screwed connections have their undeniable place in modern assembly processes. One can only effectively disassemble an item for targeted re-use if it was screwed together. The screw assembly process gives the impression of being a very simple task, but in the assembly process it is encumbered with many potential pitfalls. From the moment the screw is seated, the assembled components behave like a single part. It

Since 1 July 2010 Alex Vlemmings is employed at KSE Process Technology BV as Director Sales & Marketing. He has 20 years experience in the field of Sales, Product Management and Project Management, gained at the largest international manufacturer of meat processing machines. Selling machines and projects and delivering these succesfully is a known matter for him. Alex is a specialist in introducing structures and process improvements and knows exactly what the fast and accurate Alfra dosing and weighing machines mean to the customers.

New at TechnoPharm: CleanRoomCongress and Cleanroom Village TechnoPharm 2011 now places a focus on cleanrooms, which are essential parts of all pharmaceutical processes. In addition to the Cleanroom Village already announced, the honorary sponsor of TechnoPharm, the International Association for Pharmaceutical Technology (APV), and CONCEPT HEIDELBERG – Europe’s leading training and information service provider in the field of pharmaceutical quality assurance and drug safety – are organizing the official CleanRoomCongress. The long version of this press release is available at www.technopharm.de/press

Connection Systems Flexiduct The British firm Connection Systems has appointed Acuradmin (Oud-Vossemeer-NL) as its Benelux distributor. Connection Systems is part of the Terriva Group and specialises in the development and production of new concepts and systems for flexible pipe-connectors. Connection System’s Flexiduct product line consists of a complete range of lightweight flexible silicone connectors to make the joining of similar or different sized pipes simple. The ends are moulded to replace the gasket used in standard quick couplings. For non-flanged pipes the Flexiduct can be attached using a standard band clamp. The ducts will compensate for reasonable levels of misalignment in all planes. The convolutions allow the joint to be made with minimum effort and absorbs vibrations. Due to their flexibility the ducts are ideal for feeding transportation systems, vibrating sieves and applications where quick connection/release of tubes is required. 2 types of Flexiducts are available:

SIL function test for guided microwave and radar without the need for dismounting or physically cont A new testing method is now available for the TDR sensors VEGAFLEX (guided microwave) and the radar sensors VEGAPULS. It allows the `recurring function test` for SIL applications to be carried out without influencing the ongoing process. Safety instrumented systems (SIS) that operate in `low demand mode` require regular function checks. The safety indices of the components (sensor, logic and actuator) determine the inspection interval. As a rule, the sensor must be dismounted or contacted by the medium in order to verify the function in such applications. This is a procedure which usually cannot be carried out during ongoing production. Moreover, this way of testing is usually very cost-intensive and filling a process vessel up to the overfill alarm level to verify the sensor function also involves risks. The function test via keystroke on the vibrating level switches VEGASWING, VEGAVIB and VEGAWAVE is already well known. A test cycle is started by simply pressing

Malta Enterprise Promotes Investment in Malta Malta’s promotion in the German market continued on 10th November with a business workshop in Munich organised by Malta Enterprise with the support of the German Chamber of Commerce and the Embassy of Malta in Germany. The workshop focused on the opportunities that Malta can offer as a business location, even for SMEs, and was attended by over 40 participants from a wide variety of sectors. The benefits of investing in Malta and the success that has already been achieved by German companies who have already set up their operations in the country were highlighted by Malta Enterprise’s representative in Germany and the Ambassador of Malta to Germany. Also information regarding the fiscal and tax environment in Malta were given by the Munich Chamber of Commerce and by Ernst & Young. In his presentation Uwe Niekrawietz, managing partner of UWT, inspired the workshop participants with helpful information at first hand. Since the establishment of the subsidiary Adpro-Instruments

LUM-User Meeting on 17 March 2011 The 2nd Workshop Dispersion Analysis, organized by LUM, is addressed to users of LUM instruments as well as to interested newcomers. The direct and accelerated stability analysis of emulsions and suspensions and the comprehensive characterization of particle properties and interactions play an important role in product development, process optimization and quality control. Speakers from different industries and from research institutions discuss their experiences, methods and problem solutions for their applications. Strategies and results based on the use of LUMiSizer, LUMiFuge and LUMiReader, applying the patented STEP-technology, are in focus of the talks. The international workshop is held in English language. Venue: LUM GmbH Justus-von-Liebig-Strasse 3 12489 Berlin Germany Phone: +49-30-6780 6030 Fax: +49-30-6780 6058 http://www.lum-gmbh.com info@lum-gmbh.de

ATHEX`s range of certified static earthing clamps can now be specified with a new Grounding Station. The Grounding Station provides an identifiable location for equipment or plant items that require earthing protection from the hazards of static electricity. Up to two Newson Gale static earthing clamps can be connected to the Grounding Station which is, itself, connected to the site earth. If more than two items of plant equipment require static earthing protection, multiple Grounding Stations can be interconnected to provide a secure and reliable path to earth. Made from stainless steel the stations can be mounted in operating environments ranging from clean rooms to corrosive atmospheres. The Grounding Station also provides operators with an ideal location to stow the earthing clamps when they are not in use.

ChargePoint Technology have released their latest test data, which has validated the entry level ChargePoint valve with an assured containment performance of less than 5µg/m³, demonstrating an improvement in the integrity of the innovative containment valve technology. The basic principle of the ChargePoint valve is to minimize the exposure of airborne particles to the operator and production environment whilst transferring potent ingredients from one piece of process equipment to another. This is achieved by creating a barrier between the product and the operator by means of a closed transfer system, through the use of unique split butterfly valve technology. Testing was carried out by an independent third party, SafeBridge Consultants Inc., during a series of typical controlled powder transfers. The tests were conducted in line with the ISPE Good Practice Guide: Assessing the Particulate Containment Performance of Pharmaceutical Equipment. Each transfer

Save freight and storage costs up to 25 % By analysing case studies in 2010 Boxon found out that optimised Big-Bags FIBC can reduce the costs for freight and storage up to 25%. This saving is a benefit not just for the user filling it but also for the end-user who realises cost savings for receiving and checking less packaging units. Further the saving of packaging material is an important target of the environmental policy at Boxon. For questions or consulting requests please contact you Sales representative at Boxon.

Belgian bin producer SCE, Silo Construction & Engineering, has built a new bulk station for animal feed producer ATR in Husum, Germany. Since its establishment in 1988, the company produces and assembles modular square bins in all parts of the world. SCE offers both smooth wall panels as corrugated wall panels. Arp, Thordsen, Rautenberg GmbH & Co. KG - ATR for short - with about 650 employees from out of 5 production facilities, provides and advises 15,000 farmers, grain dealers and corn mills in Denmark, Schleswig-Holstein and Mecklenburg-Western Pomerania as well as northern Lower Saxony, Brandenburg and Saxony. Such a prominent firm holds quality, competence and punctuality as of paramount importance. ATR recognized these values at SCE and trusted them with the commission of building their new bulk station. The bulk station consists of 2 load tracks and has a volume of 870 m³ distributed over 72 smooth wall cells. The delivery includes engineering, the

4B’s adjustable depth bearing (ADB) temperature sensors have been designed to allow the depth of the probe to be adjustable depending on the application. The ADB series are available with three standard probe lengths of 2, 4 or 8 inches (50, 100 and 200mm), and screw directly into a bearing housing through the existing grease zerk thread. There is no need to remove the sensor for bearing lubrication since each sensor is fitted with its own grease zerk. The ADB series have NTC type thermistors which allow for continuous temperature monitoring, and they can be connected to a PLC or to a hazard monitoring system, such as 4B’s T500 Hotbus Elite or Watchdog Elite. The ADB Series of bearing temperature sensors have been approved for use in hazardous areas according to ATEX, CSA and IECEx. 4B Braime Elevator Components is a leading supplier of level controls, intelligent sensors and safety control systems that prevent costly downtime and minimize the risk of explosion

Rotary Level Indicator 4B Braime have launched a new type of rotary level indicator, the RLI “Shaker”. A rotary paddle switch,to detect high / low levels of bulk granular solids in bins, tanks and silos, the RLI "Shaker" can also be used to detect plug conditions in spouts, where long life and failsafe detection is required. Utilizing a unique stepper motor drive, the RLI “Shaker” rotates clockwise, then counter-clockwise and then shakes to shed any excess material build up. If the paddle rotation is impeded at any time by the bulk material then the electronic circuit provides a signal for level indication or control. The RLI “Shaker” uses fewer mechanical parts compared with standard rotary level indicators. No gearbox or clutch is required as the stepper motor drive is directly coupled to the output shaft and is practically indestructible and cannot be damaged by forced or backwards rotation. Also, an adjustable torque control allows one unit to cover many different

Our customer, Chongqing Steel, one of the biggest steel manufacturers in China was looking for a reliable content measurement system even in the extremely rough and harsh environment of steel plant applications such as coal, lime stone, iron ore etc.. The particular challenge was to guarantee reliable measurement and ensure easy operational set-up. Previous other technologies failed in the application or would have caused very high maintenance costs (e.g. regular cleaning intervals). The NB3200 measuring system gives added values such us tape version for low maintenance as well as an integrated tape cleaner for the dusty atmospheres. The NB3 assured next to low maintenance & reliable measurement a very long life time on a very difficult application. In total 90 pieces of our NB3200 were installed in the different applications.

Static earthing Our new generation earth control systems can now be ordered completely installed in a cabinet. The new generation earthing systems of ATHEX are developed following the newest technologies, with newly developed ground monitoring electronics and a new operator interface. The modern and robust universally approved IIC explosion proof enclosure make it possible using these systems in high explosive ATEX environments zone 1 IIC T6.

for grinding of soft to hard-tough samples, fibrous materials as well as plastics. Typical fields of application: waste recovery and waste disposal, garbage (non metallic), computer and electronic scrap, batteries, wood, plants, bones, horn, compacted sewage sludge, plastic profiles, rolling hides, rubber, leather, cardboard, coal The PULVERISETTE 25 is an extremely powerful cutting mill, which can also be used for pre-crushing. Different configurations enable an optimal adjustment of the system to the application. The casing can be opened by a central shutter with one hand. For easy cleaning and changing of the sieve cassette the casing top and the cover can be opened and the cover is additionally removable. Technical Data Power Cutting Mill PULVERISETTE 25 max. feed particle size: 120 x 85 mm Throughput: up to 85 kg/h Sieve inserts: 1 – 10 mm
