News items July 2010

Seven sequences with 99 respective screwdriving programs realizable Flexibility and functionality, and high process reliability with low investment costs, these are the industry’s demands to master the control tasks in screwdriving and assembly technologies, which are becoming increasingly complex. With the introduction of their new function control fc20 for pneumatic and electric screwdrivers at the AUTOMATICA in Munich this year, DEPRAG SCHULZ GMBH & Co. has succeeded in satisfying these demands. The automation specialists combined all their expertise in the further development of the fc10 control. The new fc20 impresses with its extensive user-friendliness, its high flexibility and the numerous possibilities of individual screwdriving process configuration. With the introduction of the fc20, DEPRAG is staying true to its company policy – Improving what has proven successful and setting standards through innovation. The new function control fc20 was developed for use in combination with DEPRAG pneumatic screwdrivers: MICROMAT®-F,

From the 19th of July 2010 our distributor for Holland Inrato International has moved into a new office. As a result of the expanding range of products in machinery safety and vehicle safety products the current location didn’t meet the requirements anymore. With this new office and storage Inrato International trusts to improve their service and performance level. All phone and fax numbers remain the same.

MAHLE unites all advantages in one system: conical quick-lock cartridge with rotating wing With a combination of a conical dust filter cartridge, quick-lock attachment, and rotating wing, MAHLE Industriefiltration has created a unique system that leads to much higher efficiencies in dust collectors. The innovative combi-system is based on the well-established conical filter cartridge. This cartridge is combined with a conical rotating wing, which achieves uniform and effective filter cleaning, and, due to the quick-lock system, the smallest possible size of the raw gas chamber. The improved cleaning behavior relative to cylindrical filter cartridges, as well as more effective flow ratios, lead to up to 30 % greater efficiency. The lower flow velocity in the raw gas chamber reduces the entrainment velocity and simultaneously improves dust sedimentation. This means that “re-intake” of light particles is minimized with this patented system. Another plus—the patented Quick-Lock cartridge: This cartridge allows quick and easy installation with

ATEX-conform pressure surge protected small dust collector for single station extraction MAHLE Industriefiltration presents a small dust collector with pressure surge protection for dust filtration, using a conical cartridge. MAHLE Industriefiltration has extensive experience in applications for separating easily combustible chemicals and metallic dusts, and offers a range of ATEX devices that can even be used with high volume flow rates: - Product separation during pneumatic transport - Dust collectors for central extraction systems - Fine dust removal using fluidized bed and spray dryers - Filters for packaging systems as well as weighing and dosing systems - Filters for mills, sifters, and screening plants -Mixers and bunker-top filters In accordance with EN 14400, MAHLE Industriefiltration builds pressure surge protected dust collectors with relief valve or rupture disk, for easily combustible dusts below 3mJ. This European standard defines the design of the container with regard to explosion burst strength. The corresponding test

Superior design for light, fine dust particles MAHLE star-pleated dust filter cartridges are used to separate ultrafine particles from the air. Dust-laden air passes through the fixed, upright filter cartridge, flowing from the outside to the inside, and escapes through the open end cap at the top. Efforts to optimize the filter cartridge for improved flow and rigidity have resulted in a conical cartridge design. With the exceptionally quiet MAHLE multi-jet nozzle, filter cartridges can be cleaned much more efficiently than with conventional nozzles. A superior cleaning performance compared to cylindrical filter cartridges and more efficient flow ratios result in up to 30% greater capacity in dust collectors. Advantages of conical filter cartridges over cylindrical cartridges: - Up to 30% higher volume flows/performance density owing to optimal flow ratios - More compact filter units as a result - Better efficient cleaning (less interior volume compared to cylindrical cartridge) - Superior dust sedimentation

MAHLE cleaning system for installation in a wide range of dust filtration systems MAHLE Industriefiltration has developed a compact cleaning system that features effective cleaning at low operating costs and maintenance requirements. The system, consisting of a cleaning unit, controller, cartridge, pressure tank, and maintenance unit includes all the components needed to guarantee direct, uncomplicated installation. Cleaning unit Cleaning can be performed using either the multijet nozzle or the rotating wing. The optimized multijet nozzle allows highly efficient cleaning with low compressed-air consumption, while the patented rotating wing allows gentle cleaning of cartridges, which significantly increases their service life. Controller The installed controller (controlled by time or differential pressure) further contributes to improved cleaning performance and longer filter service life. Conical cartridges A superior cleaning performance compared to cylindrical filter cartridges and more efficient flow ratios result in up to

Adpro-Instruments Ltd, a subsidiary of the German firm UWT GmbH producing highly specialised indicators for bulk goods, are supporting Junior Achievement Young Enterprise Malta with the Adpro Excellence in Quality Award together with a sponsorship. Uwe Niekrawietz, managing director of Adpro-Instruments Ltd, and Emidio Friggieri, general manager of Adpro-Instruments said this sponsorship mirrors Adpro-Instruments" commitment to improving quality. Mr Niekrawietz said: "Quality is an important concept within our company and we firmly believe in the importance of involving young people and introducing them to the concepts of quality management." Mr Friggieri pointed out that Young Enterprise bridges the gap between academic education and real business life. "Throughout my long involvement with Junior Achievement Young Enterprise I have seen many participants reaching a high level of quality in setting up the company, drafting a business plan

The twin-shaft Pegasus® Mixer has established its reputation as a veritable workhorse in the product range supplied by Dinnissen Process Technology. Dinnissen is a specialist in precisely mixing and dosing raw ingredients in quantities ranging from very small to very large as well as doing so in accordance with very strict hygienic requirements with the help of the Pegasus® Mixer. Dinnissen is now introducing a new line of Sustainable Pegasus® Mixers which make energy savings of up to 60% possible for mixing processes. In doing so, Dinnissen is responding to client demand for process technology which is sustainable and economical. The Pegasus® Mixer is an accurate and efficient mixer which is fitted with a twin-shaft mixing mechanism rotating in the opposite direction. As a result, a unique fluidized zone is created during the mixing process which lies at the heart of the entire mixing concept. The twin-shaft mixing mechanism throws the raw ingredient particles

This system enables the final packaging of an API in a contained (< 1 µg/m3) and GMP manner without the requirement of a clean room around the filling area. The system is designed in a way that the contamination of the powder from outside atmosphere or the exposure of the operator is at all times prevented. The discharge of the filter dryer (or other process equipment) is carried out by the PTS Feeder which is installed on load cells. The system allows transferring and dosing powder accurately and directly into drums. All the dosing procedure is fully automatic. The powder is directly sucked out of a dryer and transferred online through a conical mill. The product is filled into a continuous liner installed into a compact glove box (DCS Drum Containment System). The system comprises an inlet and an outlet HEPA filter. The DCS glove box itself can be set under positive or negative pressure according to process requirements. The drums are brought under

RETSCH"s new SM 300 RETSCH have extended their range of cutting mills by a new model which combines powerful size reduction with very easy handling. The new cutting mill SM 300 can be perfectly adapted to many different – and also difficult - size reduction tasks thanks to the variable speed from 700 to 3,000 rpm. The powerful 3 kW drive with additional flywheel mass and a high torque ensure excellent grinding results so that even heterogeneous sample mixtures are no longer a problem! Another advantage of the SM 300 is the easy access to the grinding chamber for cleaning: the housing is simply folded back and the push-fit rotor can be removed without tools. This only takes a few seconds. The cutting mill SM 300 can be equipped with a wide range of accessories, among them a cyclone-suction-combination. Benefits at a glance: • Powerful size reduction thanks to 3 kW drive with additional flywheel mass • Perfect adaptation to application requirements by variable speed from 700

Rotating Sample Reducer The sample reducer produces small but representative sample quantities of solids and suspensions and is combined with high-accuracy analytical measuring instruments. It is used in research, development and process monitoring laboratories. Rotating sample reducers combine three dividing methods in one unit and provide the best possible sample reducing available today. The sample is fed to a dividing cone that emulates the process of quartering and coning. The sample material on its surface is accelerated outwards by rotation and is divided through guide channels into up to 30 individual samples. The individual samples are collected in 250 ml and 500 ml glass screw-top bottles which can be easily and reliably secured by means of a quick-release clamp. The rotation and number of dividing channels enable variable dividing conditions to be achieved up to 3,000 dividing steps per minute. This means that each sample consists of a very large number of individual samples

High resolution particle analysis down to 10 microns - with modular dispersion Laboratory unit for particle size and shape analysis in the measuring range from 10 µm up to 4 mm. The HAVER CPA 2-1 HR (High Resolution) has been specially designed for particle size and shape analysis of fine material down to 10 µm. The development of this high resolution photo- optical particle analyser, meets the expectations of many users who measure even the finest material such as powder. The HAVER CPA 2-1 HR is equipped with the newest HAVER CPA software, enabling easy installation, user-friendly menu navigation and clear display of results. Due to the use of a GigE-camera the HAVER CPA 2-1 HR can also be operated using a notebook computer with an USB interface. Thanks to the HAVER REAL TIME function in combination with the single-camera technology, the HAVER CPA 2-1 HR can also be utilized as a particle counting device. Haver & Boecker has developed a completely new modular dispersion technology for a uniform transportation of finest material

Highest mixing homogeneity and the hygienic design characterize the continuous mixers GCM made by Gericke. The series has now been further improved by the models type GCM ECB. With the latest design it is possible to extract the drive and the mixer housing for easy access. The mixer has 3 operation positions: - 1 Mixing position - 2 Cleaning positions The GCM 800 ECB and 1200 ECB are equipped with a cantilevered shaft and a shaft seal which can be dismantled completely in a very simple way. In the hygienic version, the parts in contact with the product are polished. The mixer has no hollow bodies where residue can build up. The experiences made with the mixers during the operation have been incorporated in the design of this latest model. For the user it means a remarkable improvement in regard of accessibility to all components and excellent cleanability of the mixer. The GCM mixer is suitable for the operation in ATEX zones. Optionally the mixer can be

The Disposing Association EGK (established a laser-measurement system for volulume determination Corresponding to the expansion of their wate bunker the disposing association EGK from Krefeld (Germany) its management board wanted to establish a measurement system which can provide continuous data of the bunker filling level. After a critical analysis with the task EGK decided for a laser supported measuring system from the company LASE by following reasons: 1. Its laser technology is field-tested, robust and low-maintenance 2. By its high accuracy the system can be used for an inventory 3. The modular software concept allows the future integration of new functions 2D-Laser Measuring Systems by the LASE company A 2D-laser scanner is attached to the portal of the crane and the data from the laser scanner is supplied to a LASE Control Unit (LCU). A 2-dimensional profile of the bunker is built up by the laser scanner and in connection with the position of the crane a three-dimensional profile of the bunker will be generated. The bunker is divided

We have the pleasure to provide our customers with a new approval for our load cell model B6N for OIML C3 (3000d) low profile applications. The B6N gives multiple- and multi range possibilities. (Z=6000). The stainless steel single point is fully compatible with the aluminium load cell model L6N and is suitable for platforms up to 400x400mm. The B6N has standard a 6-wire 1m cable but can be changed upon request. PTB has certified the B6N load cell and filed under Test report D09-10.10 and the OIML certificate is filed under number R60/2000-DE1-10.04. Zemic has already obtained the ATEX certificate for the B6N load cell. For more information please contact Zemic Europe!

Alternative for traditional flapper and rotating tunnel style diverters The Vortex 2-way Wye Line Diverter offers positive sealing in both vacuum and pressure conveying systems. The scissor material shearing action allows the valve to be reliably diverted on a stream of material when required. The Wye Line is bi-directional and may be used as a diverter or a converger. The Vortex Wye line diverter provides a number of advantages over traditional flapper and rotating tunnel style diverters and eliminates trouble spots inherent in these diverters, available in 50 to 300mm pipe or tube. The wye line diverter provides good sealing, low installation weight and fast in-line maintenance. Use of durable seal material make the Wye Line Diverter an excellent choice for high cycle applications. Adapting the diverter to meet system requirements is possible due to a large selection of actuators, position indication switches, flanges, and tube stubs. The Quantum Series also offers a wide variety of modifications to accommodate high or low temperatures,
