News items May 2010

Vibrations occur above all in production plants and can generate many different types of horizontal and vertical oscillations in a large variety of frequency ranges caused by the drives of the integrated machines. The metering result is influenced decisively by the vibration severity measured in the form of acceleration of the vibrations. “How well do the weigh feeders compensate defined intensities of vibration?” Research carried out by the University of Applied Sciences Constance showed that an acceleration of vibration of up to 0.5 m/s² did not affect the metering accuracy of the Gericke hybrid weighing technology. It emerged that, especially mechanical damping plays an important role when improving on metering accuracy. Tests made it clear that the reduction of transference of vibrations to the system (as a whole) was not achievable by using heavy weights nor were rubber feet suitable as vibration dampers for significant reduction of the effects of the vibrations.

The volumetric and gravimetric Gericke feeders, with their high feeding accuracy, robust construction and modular design, rank among the highest-quality feeders on the market. In the case of volumetric feeders, feed rate is normally not regulated continuously, but should remain constant if there is no change in bulk density. A precondition for this is constant filling of the metering organ. Feeding of the bulk material, when using the GDU610, is carried out by means of a metering helix or metering screw. Here at Gericke, we attach a great deal of importance to the linear course of the feed rate in connection with the development of a volumetric feeder. The feed rate depends on the volume transported per time unit. Precise volumetric metering is also an important precondition for high gravimetric accuracy. The new all-purpose GDU610 feeder with complete emptying covers a feed rate range from 340 l/h to 36.000 l/h. The feeder can be used in connection with products

Dinnissen Process Technology introduce Hygienic Compact Containment system. This concept was developed especially for environments in which it is necessary, for reasons of hygiene, explosion hazard or the emission of toxic and/or sensitizing substances , to work very hygienically, safely and efficiently. This concept combines the quick and thorough cleaning of production processes with an extremely effective containment of even the finest particles. The ability to quickly and thoroughly clean production processes is becoming increasingly crucial, as more and more producers choose to invest in a single process line for the production of several products. This is based on its compact design and the fact that all the process equipment is quickly and easily accessible. This is also why Dinnissen fits its mixing and grinding installations with oversized inspection hatches and easily removable mixing shafts. As a result, all the interior parts of the machines are optimally

Insulating Coating Mascoat Products, the world leader in insulation coating materials, is proud to announce the formation of a new European location headquartered in the Waalwijk, The Netherlands. This operation will be fully staffed Mascoat entity and responsible for European Sales and Support to provide the best in customer service and satisfaction. `Having an office in Europe is going to be a great asset to our clients in the Netherlands and EU region. With Mascoat an entire staff located in the Holland, we can achieve farther reach and greater growth in Europe conventional distribution models. Since our clients base is diverse from the marine and industrial side, we felt that a full support facility was needed. Our staff is well trained and are experts in the marine and industrial environments, so our support us better than ever”, said George More, president of Mascoat Products. The fully staffed location opened in early February 2010 and has a large of stock of Delta T Industrial

Projet smart®, the new compact filter of Intensiv-Filter attracted keen interest on the POWTECH The course of the trade fair POWTECH 2010 has underlined the upward trend in the German machine and plant manufacturing. Also Intensiv-Filter presented itself successfully for the POWTECH 2010. The raised investment readiness was considerably perceptible on the exhibition stand and in the conversations. As a new innovation the ProJet smart® was issued, the new with ProTex energy savings filter media equipped compact filters. With the objective of process optimisation, reduction in costs and economic efficiency the dust removal specialist has developed an optimised compact filter which is tailored to respective applications. Equipped with fitted fan and silencer as well as accompanying cleaning control system, these new compact filters are the quickly available and inexpensive dust removal solution. The ProJet smart® is conceived as a compact filter with dust collection hopper or bunker filter with optional bypass flap modular design. It is based on four filter

The AJP 224, the new silo vent filter in rectangular construction method of Infastaub, attracted act The POWTECH 2010 has underlined the upward trend in the German machine construction and investment construction. Also Infastaub presented itself successfully for the POWTECH 2010. The raised investment readiness was considerably perceptible on the exhibition stand and in the conversations. Thus one registered this year 40 % more visitors than during the last POWTECH 2008. As a new innovation the cartridge filters AJP 224 was issued, the new silo vent filter in rectangular design. With the objective of process optimisation, reduction in costs and economic efficiency the dust removal specialist has developed a new silo filter. The experiences of the proven silo filter INFA-JETRON type AJB 800 are included into the product development. Equipped with the strengths and advantages of the AJB as well as the shaker filter INFA-MAT AM 204, the new silo vent filter AJP 224 admits versatile uses by the standardization. In case of a new filter investment the connection flanges

Hand scoop with extra robust design for versatile use, especially suitable for foodstuffs. Seamlessly fixed handle without crevices or undercuts. Smooth, mirror polished surface. Compliant with EC regulations for foodstuffs. Do you have any questions? Just ask our sales team. For more information see: www.buerkle.de/en/shop/_foodscoop.html

A change of direction towards "intelligent workstations" can pay off A change of direction towards `intelligent workstations` can pay off. Back on the road to success with flexibility and process reliability. Combining manual and automated assembly processes. The manufacturing industry is in an unprecedented recession. Due to the economic crisis large systems in many production halls are standing still, or working at low capacity. The only way to reach positive results in assembly processes is to quickly adjust to varying production rates. Manufacturing specialists still lack medium term planning certainty; sales forecasts are inaccurate and remain speculative. Flexibility is the right strategy to pursue. In assembly engineering this leads to an increased demand for `intelligent workstations` that make a combination of manual and automated assembly possible. Quick adjustment to unexpected rises in unit numbers is usually dealt with through additional manpower. Tried and tested system modules, combined with a system that has high

Refurbished genuine equipment in perfect condition Investing in high-tech metering feeders and a limited budget are not necessarily a contradiction. Used equipment is often an alternative. However, those looking around in the free market often rightly wonder how they can make sure to get good quality and dependable performance. The solution: completely overhauled original metering feeders directly from the manufacturer! Brabender Technologie KG, one of the world"s leading manufacturers of gravimetric and volumetric powder and bulk solids metering feeders, has a well-assorted stock of used metering feeders and feed control systems including - particularly attractive - demonstration units and exhibition equipment. All items have been thoroughly refurbished and tested and are in perfect condition. Everyone interested can contact the company by phone or e-mail to get information about current stock items and their respective performance data. The contact data are found on the website of Brabender Technologie "www.brabender-

The Rinstrum Bluetooth accessories use the serial port profile (SPP) to provide a short range RS232 to Bluetooth wireless connection. The devices are self discovering and no setup is required at the host device. They are compatible with all Rinstrum indicators and remote displays that support serial communications (RS232). Bluetooth Accessory Options: • M0200 cable replacement master end - used with M0201 cable replacement slave device. • M0202 Multi-roaming master device (used with M0203) • M0203 Multi-roaming slave device - can be used with M0202 or any other BT SPP master such as a PC, smart phone or PDA Application Scenarios: Cable replacement – in this case the indicator (master) is equipped with a M0200 and the remote display or console (slave) equipped with a M0201. Multi-roaming - where one master device may connect to different slave devices depending on which is in range. In this case the M0202 is used at the master and the M0203 in the

Further product development of worm geared motors as a result of specific customer requests In one case, the long-standing customer Rhein-Nadel Automation provided the impetus for a meaningful further product development. In a special case, a bunker conveyor is used to stock up work pieces with a filling volume of between 5 and 200 litres that are equipped with Ruhrgetriebe worm geared motors in a three-phase and AC design. However, the transport speed of the single stage worm gear was too high for the bunker conveyor in order to fill the work pieces into the sorting pot in a dosed manner. The Development Department managed to find a worm geared motor in stock that could be adjusted to match the particular needs of the customer. The power of the motor already matched the requirements, but the structural design and the output shaft had to be modified. Thus, the Ruhrgetriebe engineers developed prototypes within a very short period of time: A double stage worm geared motor as an attachment version complete with flange (B14) and hollow shaft for direct

Main characters of process engineering met in Nuremberg from April 27th to 29th The Powtech taking place annually in Nuremberg offered more than only one eyecatcher for the visitors of our exhibition. On the one hand, we presented UWT on an entirely new created exhibition stand. A great amount of visitors used our 63 m² presenting area and enjoyed transparency in product presentation as well as straight lines, shapes and plain colours. On the other hand, we showcased our astonishing and latest innovation in the UWT product portfolio: our world champion "Bobino". "Bobino" is based on our Nivobob and was developed and created for applications in the building material-, animal feed- and grain industry. Through the introduction of this electro-mechanical lot system we are able to set another milestone in UWT"s success stories. Bobino shines at a fabulous value for money and offers UWT opportunities to set high standards in the above mentioned markets. Moreover, we are able to strengthen our position and establish ourself

Hygienic and airtight flexible connectors The Sure Fit Line is a new series of highly innovative flexible connectors. Sure Fit Line products are very easily mounted with a quick connect clampring. This creates an air- and powder-tight seal with a very smooth surface and profile on the inside. This makes these connectors verry suitable for CIP cleaning. The air- and dust-tight connection of these flexible connectors keeps your work environment neat and clean. This can significantly save on your cleaning costs, and can keeps your factory nice and clean. The product loss is greatly reduced this way, wich also improves efficiency. The smooth flow profile and the air- and dust-tight properties of these flexible connectors elliminates all product build ups. Hygiene is thereby greatly improved. It’s verry easy to clean because there are no corners, edges, crevices or openings that you can’t reach during cleaning. This makes these flexible connectors ideal in CIP cleaning. The flexible connectors are

Rub-Block with a PT100 sensor The Rub-Block RB200DN with a PT100 temperature sensor is designed to report the misalignment of a conveyor or elevator belt. The advantage of the Rub-Block is the fact that it will send a continuous output signal to the PLC. The Rub-Block emits a permanent life standby signal. If such a signal is absent, this must be investigated and if required the PT100 sensor must be replaced. As long as the Rub-Block emits a standby signal, it will also emit an emergency contact signal caused by its temperature rising, as soon as a belt touches it. Off-tracking belts running into the side of conveyor equipment will cause friction, which may cause damage to the belt, and may generate heat, fire, or a dust explosion. The Rub-Block is very easy to install, it will be fitted on both sides of a conveyor or elevator belt. Once the belt off-tracks and runs onto the brass plate of the Rub-Block, it will create friction and the temperature of the Rub-Block brass plate increases.
