News items November 2010

Fike was recently awarded the best paper at the 8th International Symposium on Hazards, Prevention, and Mitigation of Industrial Explosions (ISHPMIE) held at Keio University, Yokohama, Japan from September 5-10, 2010. “The Role of Turbulence in Explosion Protection Design” was a joint effort between Fike and Ineris (France), and was one out of two papers presented by Jef Snoeys, Fike’s Manager of Explosion Protection Technology. The Fourteenth International Colloquium on Dust Explosions and the Ninth Colloquium on Gas, Vapor, Liquid and Hybrid Explosions, jointly form the ISHPMIE.

S+S Magbox MXP inline magnet also available in high-temperature version Magbox MXP inline magnets primarily are used in (already existing) pipelines where they thoroughly separate fine and very fine ferrous metal contaminations from powdery and grainy bulk materials. They are integrated in the pipelines by way of flat flanges, Jacob connections, or customer-specific connections. The sturdy stainless steel construction (1.4301) provides highest corrosion and wear resistance. The MAGBOX MXP inline magnet as a standard is equipped with two neodymium magnet grids that are positioned in staggered arrangement one above the other to achieve a maximum level of separation. Stephan Treml, Product Management S+S Magnet Systems, about this inline magnet: `In the reengineering of the Magbox inline magnet we attached greatest importance to quality. The modern, functional design and manufacture are 100 percent S+S made in Germany. The design with lateral guide frames inclusive of ergonomic handles allows easy, well-balanced and safe handling. Like a protective

Intelligent dust bag mops up virtually all dust during vacuuming Uncompromising processing quality through stable assembly system processes Nagging sneezing and coughing after getting up in the morning, teary eyes, running nose or headaches can be an indication of an allergy to the droppings of house dust mites. According to experts, about 3.5 million people in Germany suffer from this form of allergy. With a portion of 25%, this allergy occupies rank two on the list of allergic respiratory diseases, close on the heels of hay fever. The house dust mite, which is inevitably found in every household, is the main instigator. It thrives in the humid, warm climate of rooms and therefore feels especially at home in mattresses, bed linen, carpets and upholstery. But it is not the mites themselves that cause illness, but their droppings, which disintegrate into smallest particles, which are raised into the ambient air and then end up in the inhaled air. Therefore effective management of house dust is indispensable for affected allergy

Oscillating sieve mills in heavy duty construction Ricola’s instant herbal teas are very popular with consumers. In order for the teas to be able to unfold their full soothing effect consistently, they are produced with the help of a special method that ensures a consistently high fraction of active ingredients and flavors. Part of this method involves milling processes with the MF series of oscillating sieve mills from Frewitt. The oscillating sieve mills of the MF series were originally developed for the gentle milling of heat sensitive products in the pharmaceutical industry. Later these mills acquired a permanent place in the food production industry as well. Depending on the respective application, the user can select between 27 and 400 rotor oscillations per minute. This operating principle gives rise to numerous advantages: The milling process generates only a minimal amount of heat. The result of this gentle process is products with a very uniform grain size distribution and minimal fine particle fraction.

January 25 - 27, 2011; Gericke, Regensdorf, Switzerland How about beginning the New Year successfully by attending our one-day seminar “Powder handling and processing” at our Head Office in Regensdorf (Switzerland)? We offer you an interesting programme of events with the latest information and trends in connection with pneumatic conveying systems, mixing plants, feeding technology and much more. As a special highlight we’re going to present a speech of Tim Freeman, COO of Freeman Technology (UK), with the topic „The nature of powders – understanding and measuring powder flowability“. The presentation of our Test Centre by means of various trials using our machines is also a highlight which makes up an essential part of the seminar and offers you the opportunity to watch these in person. Ensure you get a place on this free seminar by enroling in good time. Use the link below to send an email before 11.01.2011. We look forward to seeing you there. January 25 - 27, 2011 Regensdorf - Zürich (CH)

Faster and more versatile “The new generation of Fischbein-Saxon sealers SH 1000 combines the latest in PID temperature-control technology, an innovative direct-drive system, improved airflow design, with a high efficiency heat transfer system. The result is a sealer that is faster and can accommodate thicker bags. Product changeovers are easily managed through user-friendly controls that include a variable speed (VFD) direct drive system and an electric, variable height pedestal that easily adjusts the sealing height to handle a variety of bag sizes. Our SH 1000 produces neat, attractive bag closures even more efficiently and reliably,” said Fischbein President Michael Siddons. “With its durable, hygienic, stainless steel housing and easy speed adjustment, the SH 1000 confirms Fischbein-Saxon’s supremacy in hot-air sealer technology which does not require sealing band replacement and simplifies maintenance. The result is increased productivity for our valued customers in the food,

New series industrial basic vacs Mod. T22 is a mobile Industrial vac for liquid&solid materials. Its available with a 100L or 50L capacity bin as well as with a Gravity Unload system (GU) for disposal Bag. The variants with HEPA filter, with M Class primary filter or with cyclone plate already mounted are available as well. Thanks to its high performances, mod. T22 is the ideal industrial 3ph vac for the general cleaning in all kind of industry. It can run for many hours without requiring maintenance thanks to its very silent and reliable side channel blower. The lower position of the blower gives it a great stability even when moving on rough floors. An handle runs all around the machine allowing to pull or push it from a working place to another one. A L class filter is fitted on mod. T22 as standard but an M filter version is available as well when fine dust have to be removed. Furthermore the manual filter shaker guarantees a perfect efficiency of the filtration. A version with a HEPA filter

RETSCH"s Vibratory Disc Mill RS 200 For the rapid size reduction to analytical fineness of hard, brittle and tough materials, the new Retsch Vibratory Disc Mill RS 200 is the product of choice. The new model grinds samples such as minerals, cement, concrete, soils and also electronic scrap not only extremely fast but also with excellent reproducibility. The new features include: • Optimized drive kinematics: the main directional movement of the drive train is secured in a plane which prevents the jar from gyrating or tumbling. This leads not only to increased reproducibility but also to an extremely quick formation of the movement pattern inside the jar and thus to very short grinding times. • New operating concept: All grinding parameters can be set via one single button, the current settings can be read off a graphics display. For the RS 200 up to 10 parameter combinations can be stored. • Improved grinding sets: the grinding set geometry was further optimized to increase the energy input

row filter of the type CombiJet as well as a filtering installation type ProJet mega® for Aurubis Intensiv-Filter supplies Aurubis, the largest copper producer in Europe and the world leader in copper recycling, a row filter of the type CombiJet as well as another filtering installation type ProJet mega®. The bag filters are employed for the dust removal of a new storage building for slag with various breakers, conveyor and sieve and for the dedusting of an auxiliary hood. The CombiJet bag filter is laid out for a volume flow of 80,000 m³/h n.c. at room temperature. The newly developed filter media with the name ProTex PES come into operation. With regard to environmental protection ProTex energy savings filter media are the economic alternative to filter media with laminated membrane surface and, be-sides, substantially more robustly. The bag length amounts to 4.5 m and the filter surface about 1,200 m². The JetBus Controller® controls the online cleaning of six filter chambers. In May 2011, the assembly works start which will be concluded with commissioning

Career in dedusting Infastaub registers a steady and healthy development since decades. Also in the economically difficult environment of the crisis months we have succeeded in growing solidly and future-oriented. Among the rest, a lmilestone of the last months is the new silo vent filter in rectangular design. So that we also are in future successfully in the market, we strengthen our departments of technology and sales. Become a part of our team and apply for the offered positions.

Morphologi G3 now offers wet and dry particle characterization The introduction of a new large volume wet cell extends the range of sample types that can be analyzed with the award-winning Morphologi G3 automated particle characterization system from Malvern Instruments. Equipped with the new wet cell accessory the Morphologi G3 measures size, shape and intensity of particles for a wide range of wet dispersions and emulsions. This adds to the system’s existing capabilities which include the analysis of dry powders and characterization of foreign particulate material on filters. Liquid suspensions often present major challenges for analysis using conventional microscopy instrumentation since it is possible to measure only limited sample volumes under a cover slip. Obtaining statistically relevant quantitative data is therefore problematic. With its 2 ml interior volume and large scan area, the new wet cell overcomes these limitations. Furthermore it is magnetically clamped together to prevent sample evaporation during analysis

Feeder-mounted electronic modules ISC-CM plus and ISC-FC plus For economical reasons plant operators in bulk ingredient processing industries demand maximum process automation also covering the gravimetric loss-in-weight or weigh-belt feeders used. To meet the requirement, suppliers of automation systems (PLC, automation software) offer integral feeder control functions within their system-wide control solutions. Functional guarantees, however, do well cover all control operations but not the performance of the gravimetric metering feeders with their complex interaction of metering, weighing, control and regulation functions. Understandably enough, feeder suppliers refuse to guarantee failure-free feeder performance unless proprietary control technology is used. Hence, it is the plant operator who bears the risk. As a solution, Brabender Technologie now offer a newly developed successor generation to their fully digital control and regulation modules ISC (Intelligent Signal Conditioner) under their new designations ISC-CM plus

The ChargePoint® range of containment valves have been long established as an ideal method for the safe transfer of API’s (Active Pharmaceutical Ingredients) throughout Pharmaceutical production processes. Now, with ChargePoint® DL split butterfly valve technology, the fast and secure transfer of larger quantities of ingredients in solid dose production has just become more efficient and economical. The ChargePoint® DL system has been specifically developed to meet the challenges of contained materials handling with IBC’s (Intermediate Bulk Containers). As an interface between the IBC and process equipment, the ChargePoint® DL offers the ability to safely transfer product ensuring a dust free, high containment operation when handling API’s and other formulation ingredients. The design of the DL, with patented DiscLock™ technology, also ensures that maximum yield is achieved from each transfer in a fast and repeatable manner. Sensitive product is also

AirVision is the first intelligent monitoring solution for your compressed air system. It shows the condition of your system and gives you direct insight in your compressed air consumption, 24 hours per day, 7 days per week. Furthermore AirVision gives advice on how to improve your system. The heart of the system is a central touch screen that provides an overview of the status and performance of your installation. You can see where optimisation is most rewarding, based on parameters like compressed air consumption, system pressure, dew point, air velocity, leakage and compressor performance. AirVision can be implemented for every compressed air installation. Even when a compressor control system is replaced, AirVision will continue show your measurements and energy efficiency. AirVision is intelligent, it evaluates the quality of your compressed air system and gives tips for improvement. Also AirVision generates monthly reports with an overview of the compressed

Conform ATEX zone 20 & DMT klasse St1, St2 en St3 The butterfly valves in the standard series DKZ 103 GS DN50 - 500 are flameproof against explosions of combustible gases, where their explosion behaviour does not exceed that of propane gas explosions, and flameproof against organic dusts in dust explosion classes St1 and St2, and metallic dusts in dust explosion class St3, where their explosion behaviour does not exceed that of aluminium dust explosions with a KSt value of 1000 bar x m/sec. The series DKZ 103 GS-ST3 DN50 - 200 was specially developed for metal dusts that do not exceed the explosion behaviour of aluminium dusts with a KSt value of up to 1000 bar x m/sec. Further application limits are characterised here by an explosion pressure shock resistance up to 14 bar and an ambient or product temperature of -20° to +150° C, dependent on the elastomers and components used. The series DKZ 103 GS-0.3-200°C DN50 to DN250 was designed for an ambient or product temperature of -20 to +200°C. The butterfly

ideal for rapid loss-free ultra fine grinding down to colloidal fineness The planetary mill with one working station offered by Fritsch Gmbh, Germany for fine-grinding of laboratory samples down to < 1 µm as well as for mixing, homogenising, emulsifying and alloying. With this universal mill the sample preparation and the sample analysis have again equal rights on the laboratory bench. Typical fields of application: geology, mineralogy, metallurgy, soil research, electrical industry, chemistry, ceramics industry, glass industry, nuclear research, pharmacy research. The PULVERISETTE 6 is a planetary ball mill with one grinding station and an internal unbalance compensation. Because of the high ball acceleration a significantly higher comminution rate is achieved compared with centrifugal ball mills. The comminution in closed vessels guarantees loss-free milling (including suspensions). All grinding parameters, like grinding time, interval-, break times and rotational speed are adjustable via membrane keyboard. Grinding bowls

New subsidiaries in Brazil and Russia Masterflex AG is still on the road to success. In the third quarter of 2010, Masterflex AG again significantly improved its overall economic performance as against the previous year. With the foundation of a sales company in Brazil as well as the launch of a joint venture with the Russian partner ZAO SovPlym Masterflex expands the core business activities for high-tech hoses and connecting systems. Masterflex intends to enter the Russian market for high-tech hoses and systems from the company’s head office in St. Petersburg and its seven sales offices throughout Russia. SovPlym has been active on the Russian market for more than 20 years and is a joint venture with the Swedish company PlymoVent AB, one of the leading manufacturers of suction, ventilation and filter systems. The new subsidiary located in São Paulo will serve directly the South American market. Up to now the American subsidiary Masterduct Inc. (Houston, Texas) supplied those South American

The Netherlands - The compression load cell BM14G4 from Zemic has been awarded the OIML R60 C4 approval for ”legal-for-trade” applications. The NMI in the Netherlands have examined and tested the BM14G4 and concluded that an approval with a Y-value of 8800 for standard C3 and C4 is applicable, with a Z-value of 4000. Approved capacities from 10 to 50 tons are available. For the 10 and 20 ton capacities the OIML approval is new. Features This load cell has a robust construction, is made of stainless steel, has an IP68 protection class and is hermetically sealed. This load cell has built in surge arrestors. The load cell is standard current calibrated (SC) for an easy parallel connection of 6, 8 or 12 load cells. Applications The BM14G4 load cells are ideal for the following applications: • Truck scales o concrete & steel construction o both pit and above ground • Silo’s • Train weighing The BM14G4 load cells can be used in a wide
