News items March 2011

What happens if a load cell is damaged during production? The process may be shut down, material may be wasted and costs may increase. The TraxEMT software detects failure in an early stage or enables the process to continue despite a failure. What happens if a damaged load cell is detected during production? Is the process shut down?,Is material wasted? Are costs increased? Or, even worse, what happens if a damaged load cell has not been detected? A broken or damaged load cell can be impossible to detect or predict. Only once batches start appearing out of specification or the weighing results appears unstable do you get an idea that there might be a problem. Then you need to call out a service technician to identify and repair or replace the broken load cell. This can result in lost production time and disappointed customers. This is where TraxEMT™ can help. With its predictive failure analysis and Run Flat system failure recovery embedded technology

Innovative research project by DEPRAG sends a signal: Generating electricity from small amounts of process gas Time is pressing. Global temperatures have been rising unrelentingly for 30 years. Experts expect 2010 to set a new temperature record, since weather records began. The continued growth in the number of extreme natural disasters speaks clearly. At the climate summit in Cancun, the world community took a small step forward and officially set a limit for global warming to a maximum of two degrees Celsius. In the European Union, there are efforts under way to reduce emissions of the climate killer CO2 by 2020 not just by 20 percent, but by 30 percent, and to make this a binding target. Research and industry are called upon to draw up and implement innovative climate protection projects. There are a variety of different approaches. Many industrial processes release and waste surplus energy. The recovery of untapped energy potential is therefore a crucial part of the fight against global warming. An ambitious

Certification of UWT products for the Belorussian market As part of the governmental certification of the UWT products for the Belorussian market the audit commission visited the headquarters of UWT in Betzigau from 21st to 25th March. The goal of the metrological certification is the registration of the UWT products Nivobob and Nivowave in the State Register of Measurement Technology of the Republic of Belarus. During the visit numerous tests and examinations have been conducted with these units. The test results showed that the UWT products Nivobob and Nivowave meet all Belorussian standards and therefore there is no further obstacle to the registration. "UWT belongs to the few companies in Europe showing a perfect organization, a thorough preparation and excellent final results. Regarding product quality, business organization and quality assurance UWT is even exemplary"- so the chairman of the Commission.

Alternatif for a Plugtype of Flaptype wissel Quantum® 2 Way WYE Line Dilute phase pneumatic conveying Positive air and material shut off to off leg Handles non abrasive to moderately abrasive powders, granulars, or pellets Vertical or horizontal valve application May be used as diverter or converger May be used with pressure or vacuum system Modifications available for a variety of environments

Wear resistant cone valve for dense phase pneumatic conveying of abrasive materials The biggest advantages of dense phase pneumatic conveying systems compared to dilute phase systems are that slow conveying speeds, large conveying distances, high solids loadings and thus high capacities are possible. With minimizing the speed for example the effect of wear and attrition can be reduced to a large extent. However, for dense phase systems a higher pressure gradient must be available and therefore it is vital to have a pressure tight conveying system without any leakage. One of the most critical parts when using a pressure vessel for abrasive materials is the inlet valve. The sealing membrane of a butterfly valve for example can be worn out quickly leading to leakage air which can disturb or completely stop the conveying process. Gericke offers now an improved cone valve (type K5 and K6) which is especially suited for applications with abrasive materials, high pressures and high temperatures. The valve shows excellent wear resistance for abrasive bulk

With the IND560fill you can configure filling and blending applications efficiently, without complex and costly programming. The InSite™ software tool makes real time viewing and online or offline configuration easy. It even allows you to simply copy configurations from one terminal to the next. The IND560x is designed for the global market because it is approved to local standards such as ATEX (EU), FM (USA & Canada) and NEPSI (China). Weigh Quickly The IND560x excels in controlling filling and dosing applications. It performs a target update rate of 50 Hz. This means once a set point is reached you can trigger a process control in only 20 ms. Choose between an analog or digital scale interface, to deliver precise, repeatable measurements from milligrams to tons, in manual, semi-automatic or fully automatic operations The IND560x is ideally suited for manual weighing applications. The SmartTrac™ graphic display provides operators with unmistakable weighing

The Netherlands - The single point load cell B6F from Zemic has been awarded the OIML R60 C3 approval for ”legal-for-trade” applications. The NMI in the Netherlands have examined and tested the B6F and concluded that an approval with a Y-value of 12.000 for standard C3 is applicable. Approved capacities from 500 kg to 2.000 kg are available. Features This load cell has a robust construction and is made of 17-4-PH stainless steel. The B6F has an IP67 protection class. For an explosive environment an Atex-certificate is optional for this load cell. Applications The B6F load cells are ideal for the following applications: • Conveyor scales • Hopper and tank weighing systems • Platform scales • Belt scales • Onboard weighing systems The maximum platform size for this single point load cell for the capacity 500kg is 600 x 800 mm and for the capacities 750 to 2000kg the maximum size is 1200 x 1200mm.

by DeltaNu RAPID.ID™ is a palm-sized, lightweight Raman spectrometer that performs non-destructive identification of chemicals and materials in real time, whenever, wherever testing is needed. RAPID.ID is easy to learn and use, making it the ideal system for non-technical personnel. By eliminating the expense and wait time associated with sending samples to a laboratory for testing, RAPID.ID is also the cost-effective choice. By comparing the Raman spectra of a sample against that of the chemicals and materials stored in its reference library, RAPID.ID collects and identifies the make-up of samples and results appear in seconds on its highly visible LED display. RAPID.ID connects via USB to a PC for further sample analysis. RAPID.ID is used for QA/QC applications in the chemicals, consumer products, medical devices, pharmaceuticals and plastics industries.

The new version CSA IF includes a lot of interesting news and advantages For 25 years PAYPER has been manufacturing is CSA brand of open mouth bag placers. More than 450 installations later, PAYPER is considered one of the leading global manufacturer. Today we launch the new version CSA IF which includes a lot of interesting news and advantages: Cabin concept design including the whole process in one single frame from filling to bag evacuation once is closed. Several lateral doors allow full access inside the machine. All closing systems (Stitching, sealing, ..) are integrated within the cabin. A continuously hold-the-bag powered design make the complete process very reliable as it never releases the bag since is evacuated. Cabin is modular making it as longer as we need depending on how many stations compose the system. Optimum protection against pollution. Contamination of the product is impossible from the empty bags placing through the closing of the filled bags. Low level noise in the operator area. Cost saving for

FFS bagging station form-fill-seal the bags from a plastic roll. During this year 2010, PAYPER has been chosen to solve specific problems for corrosive products using FFS technology, positioning itself as a leading supplier of tubular winding machines for aggressive products. We would like to highlight four specific projects for their characteristics and distinct issues, but with one common denominator: The demand for results. The pressure given in recent years upon FFS applications has allowed new solutions for projects with some degree of difficulty, both by the characteristics of bagging products as environmental conditions of the facilities. ASSAC L10 bagging machine in its version for "difficult" product like corrosive, hygroscopic and sticky, had solved problems found in different production plants as ADUBOS DEIBA (Manufacturer of fertilizers in Portugal) where the variety of particle sizes required a versatile machine and, in turn, fully conceived to withstand the extreme aggressiveness of bagged product. TALLERES

Payper pfg-10 air packer Despite the recent world crisis, the building industry is still very active in some world areas. Due to our world wide network of customers, we have got many orders in the last times to supply bagging machines for new plants producing dry mortar and building chemicals. Many well known international customers, as SIKA, BASF, PAREX or WEBER-SAINT GOBAIN, have ordered us new machines for their projects in Middle East, South Asia and Latinamerica. New regional manufacturers as KARBETON in Turkey or BCIC in Saudi Arabia are also expanding to produce building materials, and we have also got important bagging machinery orders from them. Finally, PAYPER is regularly supplying bagging machines to the most relevant international companies that built turn – key dry mortar plants, as M-TEC from Germany or LAHTI from Finland. All these companies have ordered our air packer model PFG10, one of the world references to bag bulk dry powders in paper bags. The PFG10

Accurate volume measuring in large silos, open bins and warehouses To have a high accurate inventory control system, Rembe GmbH , European distributor for APM 3D volume scanner systems, introduces the Multi Scanner System. The system is special for silos diameter from 5 mtr up to 50 mtr .For the first time, the finance manager, plant manager and inventory control manager, can base their decisions on accurately measured data rather the estimated figures. The ROI is short because of the high acuracy compared with a 1 point level measuring system.The Model MVL, visualisation feature provides early warning of build-up loads and bridges that radomly form over time enabling immediate response to maintenance problems. The software provides real-time data about the product being stored: volume, weight, historical logs, maximum/minimum levels. The common applications : sugar, grain, coal, cement, flyash, plastiscs, animal feed, pet food and many more. Rembe is also producer of high accurate flow meters & belt scales and European distributor

The Invitation Flyer to ACHEMA 2012 is now available for download. It gives a cmpact overview on the exhibiton profile, the set-up of the exhibition halls, exhibition opportunities, the extensive congress program and the various services around the global summit of the process industries. The interest in the 30th World Exhibition congress on Chemical Engineering, Environmental Protection and Biotechnology is remarkably high. In view of the latest global economic turmoils exchange and information on new technologies is essential for the process industreis. With almost 4,000 exhibitors and 175,000 visitors, ACHEMA offers an unmatched overview. The special show focusses on "innovative Energy Carriers and Storage" and deals with innovative concepts for enery storage for applications from renewable energy generation to e-mobility.

New Sensors for abrasive or adhesive materials Special sensors for special products. We develop new sensors: One with titan surface for abrasive products and the other teflon-coated for products which are adhesivein the production like wood fiber or wood chips

On the basis of pure polyethylene Tridelta Siperm has developed a new material with high conductivity; Siperm HP antistatic. This new, black material has the positive properties of the white material Siperm HP, the distribution of the pores is homogenous, the surface extremely smooth, it is extremely well weldable and it is officially approved to be food-safe. The surface resistivity of the new antistatic Siperm HP material is below 106 ohm and therefore it can be designated as electrically conducting. Especially for construction companies for bulk handling plants this newly developed, antistatic material may be of interest.

Tridelta Siperm has developed a two-layered porous material. Compared to our standard qualities, which show a homogeneous pore structure in the cross-section, the new material consists of two layers with different pore sizes. The sinter bridges which are formed between the two layers in the sintering process prevent that the layers loosen from each other when the material is cleaned with compressed air. In use the smoother side is facing the product in order to either achieve a maximum filter efficiency or – in the sphere of fluidization – to avoid the infiltration of the bulk into the fluidization unit. The product-averted side consists of a rougher, more permeable layer in order to hold the pressure drop as low as can.

Fine-grained bulk materials such as colouring pigments, manganese dioxide, soot, cement, coal dust, various ceramic powders, powders for the food industry, pesticides and many other materials are very difficult to handle. They have a very large bulk volume, i.e. a very low bulk density, and produce large amounts of dust when transferred. In these cases compaction of powders is aimed at. Such fine-grained bulk materials can be compacted down to 20% of their bulk volume using vacuum compaction rollers made from SIPERM-materials. The highly porous SIPERM-material used for covering the compaction rollers is available in sheet form and can be welded to create larger units and adapted by rolling to the radius of the rollerbody. This can either be done by the customer himself or by Tridelta Siperm GmbH.

Problems are often experienced when handling powdery and fined-grained bulk materials, such as flour, cement, pigments or fine plastic powders. Storage, mixing and discharge are difficult because these fine-grained powders do not flow freely. They tend to agglomerate and form bridges or tunnels around the silo outlet and, therefore, can only be removed effectively using some sort of discharge aid. A highly efficient solution to these problems are pneumatic Siperm-aeration components. They are supplied complete with all the necessary hardware (seal, washer, nut) and can also be retrofitted into existing systems. The SIPERM-R spots have a diameter of 100 mm. The pads are available as standard in sizes of 125 x 250 mm and 125 x 500 mm. Of course we also manufacture pads in special sizes.

Storage, mixing and discharge of bulk materials with average particle sizes of less than 0.1 mm frequently causes problems because these bulk materials do not flow freely and therefore are almost impossible to discharge. They tend to agglomerate and form bridges and tunnels, particularly around the silo outlet, thereby obstructing the free flow of the material out of the storage vessel. A proven solution to such problems is the fluidization of the bulk materials using custom-made aeration bottoms, cones or inserts which we manufacture to your specifications. Dry, dust-free air is injected to reduce the friction and cohesive forces of the bulk material, producing a continuous flow of material out of the vessel. Air supply pressure and velocity of air must be set at such a rate that the contents of the silo are evenly loosened. When fitting-out large silo areas with aerations units, it is advantageous to divide them into sectors which can be aerated interchangeably.

Problems are often experienced when handling powdery and fined-grained bulk materials, such as flour, cement, pigments or fine plastic powders. Storage, mixing and discharge are difficult because these fine-grained powders do not flow freely. They tend to agglomerate and form bridges or tunnels around the silo outlet and, therefore, can only be removed effectively using some sort of discharge aid. A highly efficient solution to these problems are pneumatic Siperm-aeration components. They are supplied complete with all the necessary hardware (seal, washer, nut) and can also be retrofitted into existing systems. Ready-to-install aeration pads are supplied complete with all the necessary hardware (seal, washer, nut). They are ideally suited for installation at those sites where access is limited or difficult. The pads are available as standard in sizes of 125 x 250 mm and 125 x 500 mm. Of course we also manufacture pads in special sizes.

Storage, mixing and discharge of bulk materials with average particle sizes of less than 0.1 mm frequently causes problems because these bulk materials do not flow freely and therefore are almost impossible to discharge. They tend to agglomerate and form bridges and tunnels, particularly around the silo outlet, thereby obstructing the free flow of the material out of the storage vessel. A proven solution to such problems is the fluidization of the bulk materials using custom-made aeration bottoms, cones or inserts which we manufacture to your specifications. Dry, dust-free air is injected to reduce the friction and cohesive forces of the bulk material, producing a continuous flow of material out of the vessel. Air supply pressure and velocity of air must be set at such a rate that the contents of the silo are evenly loosened. When fitting-out large silo areas with aerations units, it is advantageous to divide them into sectors which can be aerated interchangeably.

We Make the Most of Your Powder Processing. Naturally, NOLL will be part of the European Coatings Show in Nuremberg, Germany. This year this leading exhibition for the international coating and paint industry will take place March 29 – 31. New exciting developments await you at our stand. One of the innovations we are presenting is our impact jet mill DemiNo® 3125. With all-ceramic design, it is the specialist for metal-free powder processing up to Mohs hardness 7. Visit us: You’ll be convinced of the outstanding NOLL know-how. You’ve got the processing challenge, and we the engineering expertise! However specific your processing application may be – we know what the optimum technological solution can look like. Personal consulting, all-inclusive development and a technical realisation ahead of its time. Our address this year at the European Coatings Show is Hall 9, Stand 351. One way or another, we’re easy to find. Just head straight for the beach, to the most relaxing atmosphere and best

We are the specialists for your processing units in the field of liquid and powder in the pharmaceutical, biotechnological, alimentary and chemical industry. Due to our experience we are able to install and to connect stocking silos, to transport, convey and mix the powder and the liquids towards and between your processing units. Finally we can offer you a high precise dosing for the packing in bags/drums or for the dosing of the product into your equipment. All of this in a GMP and/or ATEX environment and/or under high containment with a self-provided electrical control including a visualisation according to the latest standard. The key to your processing units…. …. JetSolutions SA, your specialist in units!

Complete assortment stainless steel security screws Nestinox developed a complete new SECURITY leaflet which includes its range of stainless steel security screws, including hexagonal break-off nuts and pinplug hexagonal. The security screws are available in various finishes including Snake Eyes®, Torx® Pin, Phillips Pin, One Way. They are also available with various screw heads including pan head, round countersunk and flat countersunk.

independance on density and perticle size Rembe Safety & Control , introduces the newest generation in line flow meter, the C-Lever , for all kind of dry bulk products. An accuracy of < 0.25 % makes the unit on a level of high performance in every kind of industry where dynamic weighing in this range, was not possible before. Applications like wood pellets , sugar , coffebeans , grain , milk powder , granulate , flyash or cement are no problem and can be measured in a range of 50 kg/h up to 600 t/h . The new model is avaliable for high temperature applications and also in ATEX zone 20/21. For FDA/2A certification we`re in the process and we will have it very soon. The technology is based on centripetal forces and this gives a much better and accurate flow control than the Impact Flow Meters on the market. Rembe Safety & Control is producer of flow meters, flow sensors and stainless steel belt scales. Behind this Rembe is also European distributor for APM volume scanners, Bindicator level measurement

Delft Solids Solutions now offers testing the tendency of powders towards segregation Considerable efforts are often devoted to the mixing of several different species of powders (of various sizes, shapes and densities) in order to have a homogeneous mixture of the intermediate or final product. Nevertheless, a well-mixed system may segregate during handling, e.g. when discharging into a bin or big-bag, transportation in a truck or pipe-line, but this could also occur when loading the powder in e.g. a tablet press for production of pharmaceutical tablets. Surprisingly, this phenomenon is often overlooked or not adequately tackled. Prediction and quantification of this segregation phenomenon can now be executed in the Delft Solids Solutions laboratory. The fluidization segregation tendency of powders is assessed in accordance with ASTM D 6941 standard. In this segregation test, a fixed volume of a representative powder sample is fluidized and collected in different fractions. Subsequently, typical characteristics (e.g. particle size or density) of the

RETSCH ‘s new cyclone mill TWISTER is specially designed for the processing of foods and feeds for subsequent NIR analysis. The optimized form of rotor and grinding chamber generates an air jet which carries the ground sample through the integrated cyclone into the sample bottle. The air jet prevents the material from heating up, thus preserving the moisture content. The provided sieves guarantee an optimum particle size distribution so that it is not necessary to recalibrate the NIR spectrometer. The rotor speed can be adjusted in 3 steps allowing for perfect adaptation to the sample requirements. Cleaning the mill is quick and easy as the air jet effects a complete discharge of the material from the grinding chamber. This new cyclone mill in proven RETSCH quality optimizes the reproducible sample preparation to NIR analysis thus allowing for meaningful and reliable analysis results. Advantages: • Ideal for grinding feeds, grains, forage and similar

Besides the individually detachable close-it and close-itfood closure labels, our repeatedly tested and proven control seal is now also available on a continuous roller. This helps you discover whether you require only a small piece, for example for closing a small hole, or for marking a specific point. Or whether you want to repair a long crack or a large hole quickly, reliably and easily. With its extremely strong adhesive strength, close-it tape holds on the most diverse bases, where the glue effect of normal adhesive tape quickly reaches its maximum capacity. For universal use, we have kept the adhesive tape close-it tape in white with tear-off lines. It can be labelled with pemanent ink and locks gas-proof. Available in the classic close-it design, as well as close-it tape food, with a food-compatible adhesive. For more information see: www.buerkle.de/en/shop/_close-it-tape.html

Optimal for fine grinding of temperature-sensitive samples and for higher throughput! The FRITSCH Variable Speed Rotor Mill PULVERISETTE 14 grinds rapidly and effectively soft to medium-hard, brittle as well as fibrous samples. Due to its very efficient air cooling and the cyclone, even the comminution of difficult to grind samples like temperature-sensitive powder coatings and plastic samples or slightly moist materials such as herbs, leaves or teas are no problem for the PULVERISETTE 14. The efficient air routing inside the PULVERISETTE 14 and the powerful air vortex within the FRITSCH Cyclone cools the sample during grinding, reduces the thermal load of the sample, minimises clogging of the sieve rings while simultaneously increasing the throughput significantly. Also, the cleaning of the mill itself is reduced to a minimum. The air flow inside the FRITSCH Cyclone leads the ground sample directly into the screwed-on sample glass. This type of sample discharge is the most convenient, because the ground material is drawn directly into the glass

Dont miss this opportunity! On the occasion of the Solids Exhibition, we start a sales campaign with our Belt Cleaners. Within this period you will be able to buy our Belt Cleaners at a strongly reduced price. If you are already interested now and are you looking for high quality material for your conveyor installations, send us an email. Our representative for your region will contact you as soon as possible. You can of course also visit us on stand 3509 of the exhibition; different possibilities will be shown there: - ABC 70, 90 and 95 - ABC 70, 90 and 95 HD - HMS and HMS XL - T cleaner HMS and HS - Arm cleaner HMS and HS - Easy clean and one-piece pu blades - Belt brush ABC 6 - 12

VPFlowMate in-line family VPFlowMate in-line for Nitrogen and technical gases The VPFlowMate in-line series can be used for nitrogen and technical gas consumption monitoring. In many cases, technical gas is only measured at the bottle, using a pressure switch. When the bottle is empty, a new bottle is connected and no one seems to care about the costs involved. VPInstruments now offers a cost effective solution for Nitrogen, Argon, Helium, C02, Oxygen and Welding gas mixtures. The VPFlowMate has a large measurement range and on the display you can directly view the actual flow and total consumption. This makes the VPFlowMate ideal for cost allocation of technical gases. For more information, please contact us.

for a longtime and reliable operation Especially in the bulk industry, where measuring sensors are exposed to a high-abrasive environ-ment, the interest in non-contacting measurements is reasonably high. At the Schüttgut 2011, Berthold Technologies presents a moisture measurement system that works absolutely non-contacting and never requires maintenance. Micro-Polar is a Microwave measuring system, which - based on transmission technology, penetrates the whole material cross-section, thus allowing for utmost representative measuring results. Once installed and calibrated, Micro-Polar works highly accurately and reliably for many years of operation. The multi-frequency technology, utilized by Berthold Technologies, ensures a very stable measurement, eliminating the influence of reflecting surfaces. The system can be installed on both conveyor belts and chutes. Providing options to compensate for varying bulk heights and varying bulk densities, Micro-Polar achieves an outstanding measuring accuracy even

Rotonivo in high temperatures The Challenge The company Pyroforce was looking for level limit detectors to work in a reactor, which produces gas for power generation. The sensors control the feed of woodchips, which burn up in the reactor. Also the discharge of the ash should be controlled by a limit sensor. The challenges in this application are the high temperature of 600°C and the condensing hydrocarbons like tar. The Solution The feed of the woodchips will be controlled by a UWT paddle switch ROTONIVO® 6000. This full detector is installed on the top of the reactor in an angular position. Is the sensor free of woodchips, the feed screw switches on with a time delay and woodchips are filled in the reactor from a storage silo. If the level gets to the sensor the screw will be stopped. In the upper part of the reactor there are temperatures of about 600°C. The high temperature and the condensing hydrocarbons like tar are the critical elements in this process which influence the function
