News items July 2012

The new HR rotary valve comes with a wide range of specification options with easy manual handling functionality, achieved with sturdy linear rail configuration and tapered rotor geometry. Value engineered the HR includes a patented adjustment arrangement which enables precision and secure rotor adjustment and setting. The new rotary valve enables safe manual handling in an easy, flexible and economic solution. Fast and simple removal of rotor The design also takes advantage of Rota Val’s proven tapered rotor configuration, with the rotor shaft having been tailored to suit purpose-made seals, which ensure reliable extraction and insertion. Just one spanner is required for simple rotor removal. The basic specification of the HR rotary valve is suited for most production processes, being easily configured with several options. • Direct or chain drive • Drop or blow through options • Sizes 125 mm to 300 mm • ATEX option • Polished internal

Authorized service partners cover now entire NAFTA zone and France Berlin, 31.07.2012: The annual international service training took place at LUM Berlin-Adlershof headquarters from 16-20 July. In parallel to the continuing education of the distributors in applications and sales, here the fundamentals are established for the fast and qualified technical on-site support around the world. The increasing use of dispersion and stability analysers in cosmetic, food and pharmaceutical industries comes along with an increasing integration of LUMiSizer and LUMiFuge in the quality assurance systems there. This involves required instrument qualifications (IQ/OQ/PQ), as precondition for their work under GMP guidelines. Successfully passing the training course now a staff member of the Mexican partner is authorized to perform LUM instrument qualifications on-site. Now also fast technical service is provided in the entire NAFTA zone, by the own subsidiary LUM Corporation in the USA and Canada and by Conceptos é Instrumentos for Mexico. With

FLEX-4ch, now approved in accordance with EU directives. There are several applications needing the monitoring/control of more than one weigher. Frequently such systems possess complete or partially combined sequences. Examples are: *fast multihead filling machines. *bulk loading systems. *on board truck weighing with the calculation of the load per axle. *in motion weighing of railway vehicles. *control of garbage, discharged into the truck. Until now such instrumentation existed out of a number of instruments. With today’s technology PENKO succeeded in combining four instruments to one compact unit. Moreover apart of the weigher this instrument possesses complete, ultrafast controlling facilities and a full colour operator terminal. What more do you wish? The specifications are self-convincing: *operation with a TFT touch panel, full colour, high resolution and the choice out of different screens, by example dependent of the function and/or the weigher. *four fast weighing indicators, each 1600 conversions/s,

Focusing on high quality stainless steel drives What do tasty shish kebabs, weather-proof paints and varnishes, delicious fruit juice drinks and newsprint have in common? At first glance, very little. But if we take a look at how they are made, we see the question in a different light. The manufacturing processes of all four of these products utilise stainless steel air vane motors. These high quality drives are the number one choice when high torques are required in confined spaces, or where strict hygiene rules apply in the food processing and medical technology sectors. When deployed in aggressive environments - even under water - the stainless steel drive proves indestructible. Airmotors specialist DEPRAG, in Germany, is presenting the most comprehensive international range of stainless steel vanemotors. The airmotors are designed using the latest sophisticated technology and they receive highly specific finishing treatment at the company’s own hardening shop, thus ensuring that they are the very best drive

Successful company foundation in India We are very proud that the UWT group has the following new member: UWT Level Control India Pvt. Ltd. The last months we founded a new subsidiary in New Delhi, India with the support of a consulting firm named Maier + Vidorno. This is the first market entry in one of the main industrial areas in India. We are sure we will expand in more regions in this promising country the next years. We are happy to welcome our new employees and colleagues Mr. Rahul Kumar Singh Rathore who started as Regional Sales Manager, and our Area Sales Manager, Mr. Roopesh Menon. We wish both gentlemen a good start, great success in their new job challenges, a lot of fun in the UWT team and a fruitful and successful cooperation in future. (image left: Uwe Niekrawietz, Rahul Kumar Singh Rathore, Roopesh Menon)

The new EN1114-1 Class C European Standard in support of the implementation of the Machinery directive 2006/42/EC has been released on October 2011 and addresses the safety requirements for plastic and rubber extrusion machines. This novel standardisation document addresses the need for overpressure protection of extrusion unit barrel. As a result of the high level of reliability and simple installation the use of bursting disc devices is recommended. The use of bursting discs avoids the required use of sophisticated and safety-system certified pressure sensing systems and therefore results in lowest cost of ownership for these critical pieces of production equipment used in today’s plastics and rubber manufacturing industries. As a renowned producer of Extruder Rupture Disc devices since more than 60 decades Fike offers a wide range of standard solutions to this industry application, with of-the-shelf solutions for most used applications. For specific non-standard

New sales engineer in action since May We cordially welcome Kevin Walter to our team. Born in 1985 Kevin Walter is a new member of the UWT sales team since May this year. He likes to spend his leisure time in nature with biking and rock climbing. The certified engineer collected sales experience the last one and a half years at M-Net and will enrich the UWT-team as a sales engineer after intensive training. Kevin Walter will technically support the sales office and sales force, will take over the technical development of comprehensive projects (measurement, visualization, installation, commissioning) and will conduct technical trainings for employees and partners of UWT. He also will assist in customer meetings and product presentations and carry out the service and commissioning of the UWT units for our customers. We are pleased that from now on another competent partner for technical questions will be available for all employees, customers, distribution partners and subsidiaries of UWT.

Manfred Borkowsky from the regional office south retires By 1st of July, 2012 Manfred Borkowsky went into retirement and said goodbye after more than 33 years of service at Infastaub. The sales professional began his career with Infastaub in 1978. In his responsibility lay the regional sales office south. „During his time with Infastaub, Manfred Borkowsky has brought the sales in South Germany and the adjoining neighbouring states forward and continuously developed it. We wish him all the best for his future and thank him for his engagement and the long-standing trusting and successful cooperation“, says Berthold Geppert, General Manager Infastaub. With Andreas Müns an experienced and competent successor could be found for Manfred Borkowsky. The 49-year-old graduated engineer disposes of long-standing sales and project experience in the dust removal branch which he has acquired from DCE (Donaldson Torit) and Dantherm-Filtration. The change in staff, already announced November last year, has already been implemented

As proof of the pressure shock resistance the DEKRAM executed two explosion testings of a pocket filter type AJN 1/603 SL on behalf of the INFASTAUB GmbH. The film is shown on YouTube: http://www.youtube.com/user/InfastaubEntstaubung/

A 3D-visualisation is the perfect solution to represent details, processes, operations and reactions within a filtering installation. The complex processes of a dust removal process using a bag filter are communicated in 3D-visualisation easily and clearly understandably. The functions and process steps of the dust removal are clearly shown in the 3D-visualisation. A bag filter of the series ProJet mega is shown. The technology contained in it, e.g., the cleaning using the coanda injector, the particle flow in the raw gas duct and clean gas duct and the dust discharge are explained in detail. Everything on dust removal with a bag filter revolves here: http://www.youtube.com/user/IntensivFilter

Dual measurement System PelletScan PelletScan is the solution for the automated moisture- and simultaneous bulk density measurement in pellets Adherence to the norm EN 14961 At the “Industrieforum Pellets” in Stuttgart in October 2009 it was announced that the new “EN 14961” becomes effective at the beginning of 2010 and thereby replaces national regulations. The certificate “ENplus” is an important seal of quality for pellets. By strict guidelines carefully examined pellets alone receive this titling. For the client this means: - failure-free operating of the pellet heating - low residual moisture, results in a high heating - value with accordingly low emissions - consistent length of the pellets and very little dust content By the use of the new norm, the market becomes more accessible for the consumer and products from different manufacturers can be compared more easily. The manufacturers of quality pellets are therefore required to monitor the product’s quality in order to

Dec"s simple and cost-effective transferring and dosing solution The DosiValve has been especially designed to avoid typical flow and accuracy problems when using standard rotating or vibration valves as it allows for precise dosing even when handling difficult products. The DosiValve works, either through gravity charging for normal charging and discharging applications (drums, big bags, containers, silo, hoppers, etc.) or active powder charging, in combination with the PTS – Powder Transfer System* for longer distances in a safe and contained manner. The pneumatically actuated piston opens and closes according to set parameters. By varying the frequency of opening and travel of the piston, the speed, weight and precision are controlled.Highly accurate dosing can be achieved (+/- 1 g). With the optional integrated fluidization cone, even difficult products such as sticky or wet powders can be easily controlled. The absence of rotating parts allows for easy cleaning and sterilization (CIP/SIP). The DosiValve is a cost-effective,

Exact 3D-Bunker Measurement with continuous inventory By means of the LASE CEWS BV Module-Application it is possible to operate exact 3-dimensional bunkerprofile- and bunkervolume measurements while doing a continuous inventory simultaneously. Indirect methods of measurement or at worst just only estimations belong to the past now. Depending on the bunker-size, one or more 3D-laserscanners are installed above the bunker or box for the realization. A 3-dimensional image of the whole bunker will be developed now. Out of the obtained data the LASE CEWS application software calculates the profile and the volume of the bunker or box precisely. The software analyses the raw data by dividing the bunker or box volume into fields compared to a chessboard. By this information the process control system automatically realizes the feeding and removal flow of the material. In conclusion you profit from following benefits: o Accurate volume information of the volume & profile in m³ o Profile information of the storage

the economic hose clamp, British type Nestinox has added new hose clamps in the assortment. These hose clamps have special edges which avoid cutting into the material. Slots are squeezed into the strap instead of perforated. This way the inside of the clamp will be smooth for a perfect connection to the hose. All parts are completely stainless steel 304. The hose clamps are available in various dimensions, qualities and types. Nestinox can also deliver the well-known JCS `Hi-Grip` and `High-Torque` hose clamps. These heavy duty hose clamps are of a very high quality and have Lloyd`s Register approval for marine, offshore and industrial use.

Holcim ph: We save time that we use better for our customers Axians IAS was commissioned by Holcim Philippines to introduce VAS, the dispatch and logistics solution for cement and lime Industry, in the four cement plants and one terminal in the Philippines. With this project, Holcim Philippines, the leading cement company in the Philippines, makes another significant step in the journey of continuous improvement of business operations through automation and integration. “With automated truck weighing process, we will be able to spend more time in value-adding processes and spend more time with our customers and business partners,” said Holcim Philippines Logistics Head Rey Cervera. The VAS® solution delivers seamless integration of logistical processes and their respective data with Holcim’s core IT system. This will lead to increased stability, reliability and efficiency of daily business operations in the logistics area of the plants. Furthermore will the improved integration and automation enable the logistics personnel

Fluid bed system effectively combines granulation and coating The L. B. Bohle Maschinen + Verfahren GmbH product range of proven fluid bed systems extends from the smallest Bohle Fluid Bed System BFS 3 through to the “flag ship“ BFS 480. At this year’s ACHEMA, the granulation and coating specialists will be presenting the further development of the “bestseller” in the medium range – the BFS 240. Like the small and big systems of the BFS series, the optimised granulation and drying system offer numerous advantages and various options in pharmaceutical production. Thanks to the tangential spray system, the BFS 240 is a highly efficient machine. In addition to highly efficient drying, the system is equipped with eight tangential spray nozzles and is suitable for granulation and pellet-coating. This decisive advantage eliminates the need of retrofitting the system when changing from granulation to coating. Through the tangential-spray technology, this new processing design is much more robust than traditional Wurster

Stronger. Faster. Better! The new, completely modified FRITSCH Vibrating Cup Mill PULVERISETTE 9 offers many practical advantages in all areas in which hard, brittle and fibrous material must be ground extremely quick down to analytical fineness. The Vibrating Cup Mill is indispensable for all areas in which hard, brittle and fibrous materials must be ground extremely quick down to analytical fineness. And ideal for fast sample preparation, such as in the areas of spectroscopy preparation, ore and geology laboratories, mining and metallurgy, ceramics industry, agriculture and environmental science, infrared and x-ray fluorescence analysis. Now with increased grinding power and a completely new drive concept, even safer and easier to tension the grinding set, especially quiet, simple to operate and quick to clean. For perfect, loss-free grinding results in shortest times! Easy working No similar mill offers a more convenient operation: The working position is ergonomically optimised; the

The two Swiss companies Gerteis and Gericke present a fully developed solution for the continuous tablet manufacturing. The companies combine their market proofed feeding, mixing and dry granulation equipment to a complete continuous manufacturing module. Gericke and Gerteis present a new solution for the continuous mixing of powder and dry granulation for upstream tablet production. The various possibilities of Gericke and Gerteis devices enable processing of almost all pharmaceutical powders, including those which are difficult to handle. This gives the pharmaceutical industry an attractive opportunity for a highly flexible production with very low production cost per tablet. The module of Gerteis and Gericke is supplied as a complete solution. Powder transport unit and tablet press may be integrated. Thus, the engineering effort in designing a new production line is simplified further. The advantage of this "one stop shopping" lies in shortened planning

Extremely high mixing quality for micro components, short mixing time and very easy cleaning process. These three features characterise the new revised type series of Gericke GMS mixer. This is Gericke’s answer to the needs of the food, pharmaceutical and chemical industries where hygiene demands have become more and more stringent and product quality is of utmost importance. GMS stands for Gericke Multiflux® mixer. In the Version GMS C The mixing tools are cantilevered. Thanks to this feature, the front of the mixer can be opened up completely for cleaning purposes. The Gericke GMS C mixers is the only twin rotor mixer available on the market with this feature. Easy to clean In the case of the GMS ECD version (Extractable Cantilevered Drive) the whole drive unit, including mixing rotors, can be extracted from the body. Large side doors for cleaning also facilitate cleaning of the inside of the body. The cantilevered construction means that the number of seals

H-Tec Weegtechniek bv H-Tec from Heteren is delivering the complete line of Baxtran pallet truck scales. Several capacities, from 500 kg until 2000 kg. there is a approved version and a model in stainless steel.

The design and planning areas are characterized by specific requirements in many ways. To meet the complex problems of our customers, doubrava decided for the implementation of 3D CAD. The planning accuracy and quality is increased many times over and offered its customers an even better service. The egineers are realizing the assemblies and components using the latest 3D software. The new system, coupled to a database, thus enables a more precise response to customer needs. Initially 12 employees were familiarized in an one week training with the new working tool. To consolidate the knowledge acquired, the employees will be supported another 2 weeks by the supplier in “daily business”. Another service for the customer is to be able to print the on computer generated 3D models in cooperation with the higher technical school Vöcklabruck. The 3D plotting technology makes it possible.
