News items February 2013

High quality materials, a long lifespan despite operating in adverse environmental conditions, efficient cleaning: these valves provide long-term help in meeting legal requirements for the protection of the environment. For many years, technologies for the after treatment of exhaust gases have been used in commercial vehicles to reduce emissions of nitrogen oxides and other particles. Buschjost, with their well-engineered valves, have played a considerable role in these complex developments right from the very beginning. As a longtime supplier of exhaust gas purification systems with their production site located in Germany, Buschjost is now also concentrating on dealing with the special requirements in the area of large diesel engines. Technical modifications to the worldwide tried and tested filter valves have made it possible for them to be deployed in exhaust gas purification systems, despite the extremely aggressive environmental conditions typically found there.

Buschjost is now offering a particularly compact filter cleaning system with a modular design that can be adapted to customer requirements. The high quality system solution meets all current guidelines and removes the need for customers to build expensive tanks. The fact is, filter systems around the world must be constantly improved. For this reason, Buschjost is adding to its 6" flex-on® filter cleaning system by also offering a 3" version for identical application ranges. This tank system is modular, flexible and designed for the smallest filter systems. It allows customers to easily stay abreast of increasing environmental demands. The compact filter cleaning systems is based on a tank measuring a maximum of 2,000 mm in length with a diameter of 75 mm. Manufactured from aluminium alloy, the smooth surface allows impurities and dust deposits to be removed extremely easily. And unlike steel tanks, the high quality material cannot corrode. But there

Whether Siberia or Malaysia: Buschjost filter valves are a reliable option even in extreme temperatures. Other technical benefits include durability, very short opening and closing times and high pressure impulse/pressure surge. This guarantees efficient cleaning in all situations and saves the end user money by using considerably less compressed air. At the heart of the robust filter valves is a one-piece plastic diaphragm. Where up to now two separate standard diaphragms were required for temperature ranges from -40 to +85 °C and temperatures between -10 to +140 °C, a high-performance polymer now covers the whole spectrum from -45 bis +140 °C. This offers plant manufacturers a higher level of safety and increases the service life of individual valves. All requirements for efficient cleaning can now be covered worldwide with a single diaphragm. Plastic diaphragms have a significantly longer working life compared to standard fabric diaphragms. The diaphragm

DEPRAG enhances its range of grinding motors for deburring systems What do metal castings, products made from composite materials, and brake disc blanks have in common? When all of the above items are machined, any sharp edges, burrs, fraying or chips produced during the manufacturing process need to have the edges smoothed and chips removed in a deburring process. Anywhere cutting processes such as turning, milling, drilling or thread-cutting are involved, the manufacturing process will almost always also include a deburring stage on the workpiece. This guarantees the quality of the component to comply with technical specifications. Automated deburring systems in which robots undertake many of the tasks such as milling, polishing and grinding, are becoming the norm throughout the industry. Automated processes are coming to the fore in foundries too. The job of cleaning the raw castings - an expensive and time-consuming job - is increasingly being carried out as part of the automated production process. The practice can also be observed

IMechE Bulk solids handling 2014: technology and development for the 21st century IMechE Bulk solids handling 2014: technology and development for the 21st century Conference | 26-27 February 2014 Chennai, India Call for papers now open Following on from the successful IMechE Bulk India 2011 conference, this two day event will provide attendees with an opportunity to learn about the latest technology used to handle medium to heavy bulk materials such as mined ores, stone and coal. Get an overview of the latest equipment and best practices used within the minerals handling industry. Enhance your knowledge and stay ahead in this competitive market. Technical presentations will cover: • Wagon loading & unloading • Port equipment (ship loading and unloading) • Storage and yard equipment (stacking and reclaiming) • Conveying and transportation • Crushing, screening & washing • Control & monitoring of bulk systems • Operating and maintenance If you would like to present at this event please submit a one page abstract

March 19-21 at the Exhibition Centre in Nuremberg, Germany: Hall 5, Stand 143. You’ll find surprising innovations in mechanical fine particle technology at our stand; for applications from A to Z, whether additives, pigments, waxes or zeolites. A particular focus is our special processing in the micron and nano range – e.g. customized coating solutions, cryogenic grinding, selective milling processes and much more. You find us in Hall 5, Stand 143. Individual consulting and personal commitment are our trademark. We would like to plan enough time at the stand for your particular questions and wishes. Please call +49-8234-96615-0 and arrange an appointment with us. We look forward to your visit! By the way: for those who cannot meet NOLL at the European Coatings Show – the POWTECH Trade Fair, also in Nuremberg, April 23–25, 2013, provides you a second chance!

Confusion at coupling stations belongs to the past With the MOLOScode-System MOLLET has developed a solution that makes an incorrect connection of flexible and rigid pipelines impossible. Each pipeline gets its own name and thus avoids mistakes caused by human error in case of connecting and re-routing of connections, increases the production safety and reduces the accident risk. At the pipeline interfaces electronically coded coupling systems with RFID technology are used that give the process control the information which hose is connected to which pipe. Thus secures a safe distinction of product- and rinsing-connections and detects any hose connection with the wrong process medium. As soon as the process control detects a wrong or missing connection, the corresponding valve will be shut off immediately and diagnose tools will inform about this mistake. With MOLOScode you easily keep an overview even for crossed and intertwined hoses. The control of contamination of hoses or of maintenance periods are comfortable

3D-Animation to the process The Wurster process is one of the key methods of applying active ingredients or functional layers to particles. The high reliability and efficiency of this method have made it a mainstay of process technology. Glatt has created an illustrative 3D animation of our patented Wurster process for interested experts and laymen alike. Particles are coated in order to change their surface properties and by this means the behavior of the particles: stability in storage, hygroscopicity, free flowing property, surface structure, solubility, appearance, taste, odor Glatt offers different processes for the coating of different particles. This equipment choise allows the customer to choose specific levels of coating quality. The coating liquid can be a solution, suspension or melt. In all processes the coating liquid is sprayed onto the particles. Low viscosity and small droplets are required to ensure even spreading of the coating liquid on the surface of the particles. The

J-Tec designed a multifunctional mixing installation taking the EHEDG guidelines into account. This vertically build blending line does not need any pneumatic transport and works fully gravitational. Another advantage is that the discharging, mixing, sieving, dosing and bag filling activities can take place on a small surface (ca. 2,5x3x10 wxdxh), meaning that this J-Tec solution fits almost everywhere. On the top floor big bags® can be discharged using an easy controllable hoist. Thanks to a J-Tec discharge unit, equipped with an hygienic and 100 % dust free discharging clamp, your big bags® can be emptied in a clean and optimal way. (J-Tec hygienic dirt valve is optional) We’ve engineered a bag and liquid discharging unit in combination with the big bag® discharging unit. The liquid system allows us to add Max. 5% of warm/cold/ viscous or less viscous fluids into the mixer in a homogeneous way without the possibility of clot agglomeration. The raw materials

FRITSCH Laser Particle Sizers: Simple. Flexible. Reliable. Worldwide the Laser Particle Sizers ANALYSETTE 22 ensure precise determination of particle size distributions, by Static Laser Scattering – in production and quality control as well as in research and development. Benefit from their decisive advantages: extremely simple operation, short analysis times and consistently reproducible and reliable results. NEW: Small Volume Wet Dispersion Unit Ideal for measurements in organic solvents or if only minimal sample quantities are available. The Small Volume Wet Dispersion Unit is suitable for all kinds of dispersion liquids and needs less than 50 ml liquid for the whole measuring circuit. Automatic measurement, rinsing and analysis are guaranteed. - Strong 100 watt (!) ultrasonic power, controllable - Automatic Rinsing for fast cleaning - Liquid circulation system without dead space - All functions are SOP-controlled Choose according to your needs! The NEW Small Volume Wet Dispersion Unit can be combined with

Laboratory mill with autofill system for LN2 For size reduction of sample materials which cannot be processed at room temperature, RETSCH’s CryoMill is the ideal choice. An integrated cooling system ensures that the grinding jar is continually cooled with liquid nitrogen before and during the grinding process. Thus the sample is embrittled and volatile components are preserved. An Autofill System provides liquid nitrogen in the required amount so that the user never gets into direct contact with the LN2 which makes operating the mill particularly safe. The new CryoMill achieves considerably improved grind sizes thanks to the increased oscillating frequency of 30 Hz. Another new feature is the possibility to store up to 9 SOPs. Further improvements include a reinforced housing, optimized liquid nitrogen duct and new accessories such as an adapter for 6 reaction vials and a 10 ml grinding jar. The mill can also be operated without cooling which makes it suitable for a vast range of applications. NEW: • Oscillating

AVA mixer-driers are perfectly suited for processing cellulose powder (HPMC). HPMC is used, for instance, as a thickening agent in the food industry, as a humectant in the pharmaceutics industry, or as a bonding agent in the tobacco industry. In a mechanically produced fluid bed and by using centrifugal processing, the cellulose powder is mixed with additives within a very short time, then heated, dried, and cooled off. During this process, the solution water and isopropyl are vaporized. The final humidity amounts to < 3% and the final product will be conveyed to further processing at T< 35°C. The shovels in the mixer are positioned in such way that they fulfill both tasks of mixing and conveying towards the discharge in the middle of the mixer. Please do not hesitate to contact us for references.

Square and rectangular wire mesh cloth The standard is already cutting edge. Haver & Boecker stocks a wide range of standard wire mesh as to ISO 14 315 and ISO 9044, which therefore allows customers to find the right mesh for the job at hand. Square mesh wire cloth. Whenever precise cut sizes for loose materials are required or whenever long particles need to be screened, it is essential to use rectangular opening mesh. For processing coarser loose materials, the type of weaving determines the screening behaviour. Wire mesh pre-crimped on both sides, e.g. DOKA weave and DOKA mesh, causes good rotation of the screened material because of its rough three-dimensional surface. The material has much greater chances of falling through the mesh openings and thus leading to successful screening. Moreover, the fine particles are brought to the screen surface more quickly, which accelerates the entire screening process. The faster the fine particles are screened out, the more screen area is left for screening

For specific static earthing applications A new single pole connector is now available to specify for the static earthing of fixed plant equipment that is regularly cleaned and maintained or requires regular movement around the plant. These new connectors from Newson Gale ensure perfect fast and permanent connection to the earth to drain static charges, and are the perfect addition to the Earth-Rite MULTIPOINT ground control unit.

EHEDG certifies rotary valve to EL class I The youngest member of our CIP product family is the ZFD-CIP blow-through valve. It was recently approved by the EHEDG and awarded the EL class I certificate. The interior and exterior surfaces of the rotary valve are extremely smooth. All corners and edges were designed with a large radius to achieve the best possible cleaning results. Surfaces in contact with the product are polished with a surface roughness of <0.8 µm to prevent even the slightest product residues and contamination by microbial growth. The valve is made of stainless steel type 1.4404/AISI 316L. During fully-automatic wet cleaning the rotary valve remains closed, saving time and money. To ensure that all fluids are fully removed from the interior during drying, we use special seals on the ZFD-CIP blow-through valve which are flush with the front and prevent capillary action. The EHEDG has tested this end-to-end hygienic design during several practical trials. The ZFD-CIP was approved with the

Metso HiSafe Systems At the end of 2012 Metso was launching several new products in the Metso Product Range. HSE (Health, Safety and Environment) is very important for us so we invest in possible solutions that are complementary with our conveying solutions. We develop safety solutions for conveyors and we reinforce solutions for dust That`s why we launch the next products: - Metso HiSafe Systems - Metso Belt Turning Systems - Metso Loading Systems - Metso Sealing Systems Metso HiSafe Systems Focus on safety around the conveyor, nip/pinch protection for moving parts, elimination of risks, no moving parts, preventing serious accidents - Metso HiSafe Roller Guard - Metso HiSafe Roller Guard Return - Metso HiSafe Head Pulley Guard (HPG) - Metso HiSafe Tail Pulley Guard (TPG) with a Rock Deflector Metso Belt Turning System (Used to keep both sides of the belt clean and to keep more grip on the drums) Metso Loading Systems - Metso Glide Block - Metso Chain Cradle -

Two JFI Group subsidiaries Two industrial companies belonging to JF INVESTMENT Group, RPA Process and HASLER INTERNATIONAL, will introduce their respective range of products at the SOLIDS ANTWERP 2013 fair (Booth B1030). This event is the result of a successful synergy between two entities which have constantly joined their forces in order to offer integrated mixing, weighing and measuring solutions. RPA Process, renowned supplier for vacuum filtration solutions, boosts its mixing range Well known in the industrial filtration market since 1880 through brands such as Filtres Philippe®, Aoustin® and Filtres Vernay®, RPA Process is also very active in the mixing field as the company can rely on the experience acquired by Malaxeurs Guittard® since 1948. Today, more than ever, RPA Process wants to push its mixing activity to the front. It is with this aim that the company will attend Solids Antwerp 2013. RPA Process will notably exhibit the UCP™ (Ultimate Continuous Processor), a unique

The LB 444 Fracking / Cementing density measurement system is designed to measure fracking proppants and cement in both high and low pressure lines. Designed for the most punishing environments and high pressure conditions, the LB444 system combined with ruggedized detector technology and the most robust shieldings can be used with confidence in Hydraulic Fracturing applications. Although the standard process value provided by means of the LB 444’s 4-20 mA output is the density of the fracking/cementing mud, if requested an additional module can provide further output units such as PPA, KGsA and others. With far lower source sizes, better performance due to scintillation based technology and superior customer service, the LB 444 system is the answer to your fracking/cementing density measurement requirements. And it’s proven too, with hundreds of systems currently in operation.

The non-contacting, radiometric level measurement system provides extreme, non-intrusive and critical measuring technology in the cement making process with a high degree of accuracy and stability. This requires an accurate measurement of clinker compared with a superior product quality and cost savings.

here available! Please visit our homepage: www.Berthold.com/density_meter Our Products for Density Measurement: Density Measurement LB 444 Density Measurement with Uni-Probe LB 491 Density Measurement with SENSseries LB 480 Inline Density Meter LB 379

The new moisture analyzer Micro-Polar Moist LB 568 from Berthold Technologies has proven successful in several applications. Amongst them: the online moisture measurement of coking coal. Although conventional microwave systems normally failed on this application, the new moisture measurement system showed excellent accuracy and stability. Besides the moisture value, the analyzer can also provide the bulk density of the coal, which leads to an improved charging of the coke chambers, achieving significant cost savings of several thousand Euros per month. In addition the analyzer is easy to handle and requires virtually no maintenance.

Three of the shelf models PENKO starts the New Year with the roll out of a complete range of state of the art instruments for check weighing. The range is available in three off-the-shelf, ready to use versions. All you need to do is to select the one relevant to your applications: • Category X: determining the package mass; this is useful when determining the weight in price calculations • Category Y: determining and comparing the weight within defined tolerances allowing you to choose between one or two automatic removal of packages from the process line. Either based on insufficiently filled packages i.e. volume, or to light or to heavy packages, i.e. weight. • Dynamic weighing means that the weight determined is in motion as it moves along the process line or, Static weighing, where the package is stationary during the weighing process. Due to the high internal resolution and the tremendous measuring speed, all three above options offer supreme weighing accuracy. You can select

Soliqa Engineering B.V. [Ltd.] in Nijkerk is an independent engineering firm, which focuses exclusively on SOLids and LIQuids processes. We guarantee specialists with ample experience and reliable knowledge of this subject. We assist numerous companies, especially in the food, chemical, pet food, and pharmaceutical industry. Our clientele also includes general engineering firms and consultancies. Our activities are subdivided into three product groups: - Engineering services - Architecture - Process optimization
