News items June 2013

UWT is the new Siemens solution partner for SITRANS LR 560 SITRANS LR 560 is a FMCW radar level transmitter for continuous monitoring of solids The robust stainless steel construction makes the LR560 extremely suitable for all kinds of industrial applications. The unit operates at a high frequency of 78 GHz thus achieving a very small beam angle which eliminates any signal interference at the flange but allows optimum reflection of the bulk solids material. The flange can be adjusted to ensure a perfect positioning of the LR560, ie the angle of the beam can be set to a specific point, for example the outlet of the silo. The lens antenna is highly resistant to material deposits and offers a self-clean function for extremely sticky solids using an air flush connection. The Local display interface (LDI) allows programming and diagnostics on-site making the installation and operation of the unit as easy as child’s play. Advantages Radar • 4° beam angle • Measuring range up to 100m • High measurement precision •

TDR, also known as guided Microwave or guided Radar) and offers an excellent alternative to conventional level measurements. The NGM enables precise and reliable continuous level measurement and point level detection in almost all liquids and bulk materials. This innovative device has almost no installation restrictions - it can be mounted in small tanks, tall and narrow nozzles and it measures precisely even with difficult tank geometries or close to interfering structures. NGM uses TDR Technology: low-energy, high frequency electromagnetic impulses, generated by the sensor´s circuitry, are propagated along the probe which is immersed in the liquid to be measured. When these impulses hit the surface of the liquid, part of the impulse energy is reflected back up the probe to the circuitry which then calculates the fluid level from the time difference between the impulses sent and the impulses reflected. The sensor can output the analysed level as a continuous measurement

SMC has unveiled a new guided cylinder to complement its MGP Series that is filling a gap in the market for a wide guided cylinder that can handle large work pieces. The MGPW has been designed with improved plate rotation torque that is three times larger than the standard MGP Series. This has been achieved by doubling the size of the guide pitch and re-positioning the guide components, which have also led to improvements in the non-rotating accuracy of the plate. Although similar in weight to the MGP, the MGPW has 170% more volume by using anodised aluminium and optimising the dimensions of various components. Easy to set-up and mount, therefore reducing labour costs, the MGPW can be used with two colour D-M9*W indication solid state auto switches or alternative round auto switches which can be fitted directly, removing the need for attaching brackets onto two surfaces of the cylinder. Specially designed to transfer large work pieces and those with eccentric

Great power-weight ratio while also delivering high revolution rates in continuous operation What happens when the power from your drive unit simply isn’t enough? When the motor for your robot-controlled plant has to supply maximum power yet has to be physically very small? When it has to produce very high revolution speeds, yet be fit for continuous operation? The automatic processes used to manufacture today’s modern materials place heavy demands on the equipment that drives them. Plant engineers often anguish over the choice of motor to carry out the job. Technical journalist and editor Trixy Schmidt talked to two prominent plant engineers to find out more. During the interview the Managing Director of DEPRAG, Dr. Rolf Pfeiffer, and air motors product manager, Dagmar Dübbelde, provided an intriguing answer: in some applications, a pneumatically driven turbine, with its excellent power-weight ratio, is the ideal solution to the problem of motor selection. Trixy Schmidt: If I am a plant engineer in search of the ideal motor for my application I basically

UWT and Siemens - a strong partnership UWT GmbH from Betzigau was chosen by Siemens as the first Solution Partner in Bavaria for process instrumentation specifically designed for level control. UWT is known as the leading expert of ingeniously simply level control. During their 35years in the bulk solids business they have delighted customers all around the world with their custom-specific solutions and the easy handling, reliability and longevity of their products. The UWT product portfolio includes paddle switches (Rotonivo®), vibration forks (Vibranivo®), capacitive sensors (Capanivo®), Lot measuring sytems (Nivobob®), ultrasound sensors (Nivowave®) as well as visualisation systems (Nivotec®). In addition to these long established and reliable products the UWT product range is expanded to include the Siemens Radar SITRANS LR560. Siemens is the worldwide market leader when it comes to innovative products, technologies and solutions and has once again set new standards with its Radar SITRANS

1,600 bags/hr with 25-50 Kg wpp bags Bag filling has been taken to a new level with the Starpack® range of bagging machines. The Starpack® pedigree is well known around the world and Concetti are pleased to announce the very latest ultra high-speed machine, capable of handling up to 1,600 bags/hr with 25-50 Kg woven-pp bags and a choice of closure systems. Handling woven-PP, paper and plastic bags the robust design incorporates Concetti’s automatic format change to combine speed with flexibility allowing different bag formats to be handled and changed at the touch of a button. A large capacity two-position motorised bag magazine offers users long runs and means excellent productivity. The unit is particularly aimed at Starpack®’s traditional industries such as fertiliser, salt, seeds where strength and durability are paramount.

Berthold Technologies is introducing a new densitometer, based on the non-contacting gamma transmission technology. The SmartSeries LB 414 detector measures density, concentration and solids content online and on all kind of slurries and liquids. Beside the high level of accuracy and repeatability, the easy way of detector handling is a major advantage of SmartSeries. The local user interface with display and the software - focusing on the main functions make calibration and operation of the HART device very easy. Alternatively an infrared remote control can be used to parameterize the detector. SmartSeries detectors are characterized by a high mechanical robustness, verified by the Fraunhofer Institute. They are cost-efficient and can be used for many years without the need of maintenance and re-calibrations. More about our new density detector SmartSeries LB 414 on our BERTHOLD website

News for Material Handling doubrava is known for quality, reliability and technology, know-how and innovation. We permanently work on the development and improvement of our products. The determinating factor are the needs of the market, which are often groundbreaking for evolutionary steps. The input of our customers are essential for development, so a close cooperation and communications is aimed and lived. The specific requirements of our customers are considered from the beginning and integrated into new or improved products. Referring to these conditions also the GBW 100 was developed. Based on the previous types and sizes of bucket elevators doubrava designed the GBW 100, the "MINI" under the bucket elevators. The aim was to develop a small, compact bucket elevator, which is optimized for low flow rates (<2m³/h), such as needed for vertical conveying of incorrect materials, but which is still affordable. The advantage of this bucket elevator is obvious. The abrasion compared

to italian pharma group AVT Europe has produced and delivered two identical transport systems for a pharmaceutical group in Italy. This transporter on air cushions with a lightweight chassis has a maxium capacity of 4 tons and will be deployed in a clean room environment. The application consists to exchange the position of various mixing tanks. The transporter frame as well as certain parts are made out of stainless steel 316L.

Martens eko b.v. in Venray, Netherlands is manufacturer of wooden pellets for the industry and individual users. This company will do significant investments and Holtrop & Jansma is proud that it has been awarded with this contract. This contract consists of two big silo’s for the storage of raw material as well as unloading facilities or raw material as well as all necessary transportations systems for the feeding and retrieving of the material.

POWTECH remains Number 1 in the international powder and bulk solids processing industry 724 exhibitors from 27 countries invited the powder and bulk industry to the POWTECH trade show in the Nuremberg Exhibition Center – and 16,805 trade visitors from 83 countries came to see the world’s leading trade show for mechanical processing and the parallel show TechnoPharm. The high quality of talks was praised, as was the strong international involvement in the events. Every third exhibition visitor and every third exhibitor travelled to Nuremberg from abroad. “A stable number of exhibitors, a very good response from the visitors, and a large international showing demonstrates how important our trade shows are for the international powder and bulk solids processing industry,” says Willy Viethen, Director Exhibitions for the organizer NürnbergMesse. The trade show duo for process plant and equipment is a permanent feature for Europe’s chemical, pharmaceutical, food and building material industries. The leading exhibiting nations after Germany were

A success story of the founder and General Manager Wolfgang Hageleit Founded in 1983, this company has been growing continuously and belongs today with its subsidiary Filsa that has been successful in level measurement industry for more than 50 years to one of the world”s leading suppliers of equipment for safe handling of bulk solids. Wolfgang Hageleit is the creative mind and founder of MOLLET Füllstandtechnik GmbH. With much commitment and experience he and his employees focused on sales and development of level measurement devices for bulk solids at the beginning. At a later date he started his own production of these units. A lot of small and great innovations that he pushed forward have contributed to continuous growth of the enterprise. The decisive factor for this success was that all innovations have been developed to the marketing stage and really satisfied customer requirements. Thus a enhancing product portfolio has been developed that includes today for example a wide range of different rotary paddle level indicators,

On-site assembly of Prorunner mk1 and mk5 Qimarox has made the installation of vertical conveyors faster, easier and cheaper. Thanks to the modular design of the Prorunner mk1 and mk5 it is possible to transport the machine in parts and to assemble it on location. This leads to lower transport costs and prevents all kinds of measures being necessary in order to place fully assembled product elevators in the correct place on location. System integrators can optionally take care of assembly themselves. A fully assembled product elevator takes up a lot more space than all its loose parts together. This means that delivery in parts entails much lower transport costs than the transport of a fully assembled machine. This also means that less space is needed on site to install the machine in the right place. All parts fit through any door and no heavy equipment for unloading and erecting the machine is needed. Shorter delivery time An additional advantage of delivery in parts is the shorter delivery time, since

The new DTM Collection contains functional enhancements for TDR sensors of the VEGAFLEX 80 series, eg Profibus and HART SIL. Functional enhancements for adjustment of other sensors as well as signal conditioning instruments have also been added. All VEGA DTMs available in this version have been checked and released for operation under Microsoft® Windows XP, Vista and Windows 7 as well as Windows 8. This also applies to the included version of the adjustment software PACTware 4.1 SP3. All DTMs for adjustment of VEGA sensors and signal conditioning instruments are available in DTM Collection 05/2013. The DTMs describe the functionality of the hardware and allow complete adjustment. All VEGA DTMs have been developed according to the FDT/DTM Style Guide. The new DTMs of course supersede the older DTMs of the same series. Compatibility across all instrument versions is ensured. This means that the user can adjust all instrument generations entirely with the latest release

RETSCH has further perfected the compact bench top model of the jaw crusher series. The new BB 50 offers many features which ensure efficient and convenient usage. The speed can be set between 550 and 950 min-1 to allow for perfect adaptation to sample requirements. Another advantage is the so-called zero-point adjustment which helps to compensate for wear of the breaking jaws. Operating the BB 50 is simple and safe. The large hopper facilitates material feed, the capacity of the collecting receptacle has been doubled. The fold-back hopper can be easily removed without using tools, just like the crusher arm. The breaking jaws can be replaced by the user as well. The space-saving unit fits on any laboratory bench and crushes smaller sample volumes with a feed size of up to 40 mm to a final fineness of approximately 0.5 mm, depending on material properties. There is no other instrument in the market to achieve this in a single operation! Breaking jaws and wearing plates

A.B.S. receives large order from a leading manufacturer of plastic packaging from St. Petersburg In the last months several road trains have left the yard of A.B.S. Silo- und Förderanlagen GmbH in Osterburken, their destination: St. Petersburg in Russia. There are the company headquarters and production site of Mir Upakovki, a leading Russian manufacturer of plastic packaging. Mir Upakovki has ordered a large number of tailor-made, flexible silos from A.B.S. which are used to store plastic granulates. The plastics specialist produces an extensive range of packaging and containers for the food, pharmaceutical and chemical, cosmetic and perfume industry as well as other important industries. According to Mir Upakovki, they made their decision for flexible silos by A.B.S., based on the fact that they offer a high storage capacity on only a small storage space as well as low transportation costs and are easy to install. Other important reasons for the decision of the Russian manufacturer were the ability to store various plastic materials for example polypropylene,

Optical particle analysis with CAMSIZER XT Retsch Technology’s CAMSIZER XT determines particle size and particle shape with the help of Dynamic Image Analysis.The analyzer extends the application range of the well-proven CAMSIZER towards smaller particle sizes and agglomerating materials. Many new customers in Germany and other countries are using the CAMSIZER XT for applications from a wide range of areas such as construction materials, food or pharmaceutical products. The possibility to analyze not only the particle size (in a range from 1 µm to 3 mm) but also the particle shape is perceived as an important benefit. The various convenient dispersion options allow for perfect adaptation of the analyzer to the user’s requirements. The new CAMSIZER XT is characterized by: Precision • Dynamic Image Analysis with wide measuring range from 1 µm to 3 mm • Simultaneous determination of particle size and particle shape • Sensitive detection of oversized and undersized particles Efficiency •

Chemowerk GmbH is one of the leading companies for the tank and container construction sector and for the production of specific moulded parts from fibre reinforced composites. Within the scope of building a highly modern, new production plant for PE storage tanks and large containers, the company selected with respect to the dosing logistics the solution offered by A.B.S. Silo und Förderanlagen GmbH. The fact that A.B.S. could offer a complete turnkey solution from one source for the raw materials logistics upstream of the production process was crucial for this selection. A total of six flexible transport bins were delivered together with discharge aids, three dosing stations and three weigh bridges including the complete measurement and automation technology. Flexibility combined with high dosing accuracy was of crucial importance to Chemowerk GmbH when choosing this solution since the production of individual pieces frequently requires variable mixtures and dosing

for sale at Surplus Select Homogenizer, GEA Niro Saovi, Ariete NS3006L, 2 stages, sanitary execution, max. viscosity 10,000 cP, max. working pressure 1,000 bar, max. flow rate 120 L/h, max. product temp. 90 degree Celsius, suitable for CIP and SIP, Monoblock VHP compression head, ceramic plungers, 32,6 operating hours, technical data in English available, manual in Dutch, has been used in a pilot plant in the food industry

Berthold Technologies announces the availability of the new electromagnetic mould level system ECcast. ECcast measures the level of molten metal reliably and extremely precisely, and is not affected by casting powder or slag. Used as a stand-alone system ECcast doesn’t require a radioactive source. However it can be also used together with the radiometric measurement system GAMMAcast to combine the advantages of both technologies: larger measuring range, automatic start-up, redundancy and determination of powder thickness. Operation of the ECcast measurement system is carried out using the proven castXpert evaluation unit. Existing casters can be easily retrofitted. Find more information on our BERTHOLD product page ECcast mould level measurement system.

ECcast - Berthold`s electromagnetic measurement system - measures the mould level reliably and extremely accurately, and is not affected by casting powder or slag. ECcast can be used as a stand-alone system or for even higher process reliability it can be combined with the radiometric GAMMAcast systems. System characteristics •Best accuracy •High resolution <0.1 mm •Quick response time •Not affected by casting powder or slag •No radioactive source required •Easy retrofit of existing casters Measuring Principle A coil inside the sensor generates an electromagnetic field, penetrating deep into the mould. As a result eddy currents are induced in the top layer of the molten metal. These eddy currents in turn generate a counteracting electromagnetic field – its strength being proportional to the distance between sensor and molten metal inside the mould. In this way the mould level can be determined very precisely and irrespective of casting powder

The radiometric mould level measurement is maintenance-free and applicable for different mould types. Successful applications can also be found in Beam Blank and Round casters. Although working under extreme temperatures and harsh environmental conditions, the measurement has proven to be reliable for many years of operation. System characteristics •Highest reliability •Virtually unlimited measuring range •Very robust •Applicable for all mould types •Easy calibration •Minimum source activity due to high-sensitive detectors •Maintenance-free •Constantly high accuracy over the whole measurement range Measuring Principle Gamma radiation is attenuated as it passes through the mould. This attenuation is measured by a detector. The extent to which the radiation is attenuated depends on the mould level. The higher the level of molten metal in the mould, the less radiation will reach the detector. In this manner, the mould level can be reliably

Bomatech located at Wijk en Aalburg, the Netherlands has constructed a double shaft paddle mixer wherewith rests easily can removed by product change or cleaning operations. Fore this purpose the manufacturer has created wide wing doors into the trough so access to the shafts and paddles at the inside of the machine is simple. It’s also an advantage that no special construction is necessary for per example to separate the inner works from the mixer body. This means that the required floor area for placing the machine stays reduced to a minimum. Of coarse the mixer has bomb doors and also the trough corners are chamfered to stimulate total discharge by unloading. For adding liquids it’s also possible to install dosing systems on client specifications. The paddle mixer is available in the sizes of 2000 and 4000 litres and can be delivered in mild steel as well stainless steel. For international trading the company and PRES International are co-operating so the

The type NVI level monitors especially designed for use in powdery to fine-grained and granular bulk solids work on the vibrating fork principle and are practically free of maintenance and abrasion. The devices are particularly durable due to the lack of moving parts. The formation of deposits is mostly impossible because of its single rod shape. The rod is self-cleaning in principle as the vibrations shake off the medium from the rod. A mechanical system is brought into resonance by an electronic circuit. When a medium covers the probe, this vibration is muffled. This change in the resonant frequency is converted into a switching signal by an electronic system. The evaluation electronics are well protected within the robust aluminium connection housing with protection class IP 67. It registers the change in vibration and displays this on an LED display. An additional relay output is used to transmit signals. Depending on the material density, settings for the operation
