News items August 2013

The proven rotating vane level switches model NIR-9 from KOBOLD are also available with an ATEX- compliant version with immediate effect. This means that the devices can also be used in dust hazardous areas (zone 21/22) for level monitoring of bulk goods e.g. in chemical, forage and food industry or plastics processing. A synchronous motor drives a shaft at which a rotating vane is fastened at the lower end. When this rotating vane is decelerated or stopped by bulk solid, the engine moves over the pivoted gear from one end position to the other and thereby switches two micro switches, one shutting down the engine and the other providing an alert signal for display of limit level. When the level decreases, rotating vanes are released again and the motor is pulled into its primary position by the force of a spring. Thereby the motor is switched on again and working contact is switched back. The mechanical connection is via flange or screw connection without any problem.

Solving the problem of fluctuating production rates and short life cycles Old heating pumps are secret power guzzlers. Few people think about these hidden “service providers” when seeking to save on electricity. Even with oil and gas heating systems, electric pumps ensure that hot water circulates from the boiler to the radiators and the hot water points. Many old pumps operate round the clock, even if no water is being heated or drawn off. On the other hand, modern, intelligent heating pumps only switch on when they are needed. That represents an energy saving of up to 70 percent. The new generation of pumps - known as ultra-efficient pumps (energy efficiency class A) - uses 400 - 700 kilowatt hours less energy. So it is not just consumers’ electricity bills that go down, but experts calculate that 240 kilograms less of climate-harming CO² per year is released into the atmosphere. Incentive programs have therefore been set up, with the aim of hastening the change to improved pumping technology. New EU directives also aim to ensure

What you don`t know about sampling systems could Swagelok Nederland is organizing: The Process Analyzer Sampling System training from December 2 - 6 2013 in Amsterdam. Learn to avoid costly errors with comprehensive hands-on Process Analyzer Sampling System Training. You will learn to: diagnose sample transport problems, calculate and optimize sample transport lag for liquids and gases, read and create sampling systems schematics, design and build a sampling system and enough other interesting topics. Tony Waters, Industrial Expert and Consultant with more than 45 years of experience with process analyzers and sampling systems, will present this 5-days English intensive training in Amsterdam. This training is suitable for engineers who are working with process and analyzer systems and want to increase their knowledge. This will result in working with this new knowledge and techniques in their own work environment.

In the category "company with 50-249 employees" UWT is awarded first place in the regional Great Place to Work ® competition "Best Employer in the Allgäu region 2013” in the category "companies with 50-249 employees" and positioned themselves as one of the winners of the regional and regional-cross-industry Great Place to Work® competition. This was announced on August the 12th by the Great Place to Work® Institute Germany. Awarded were companies from of all industry sectors and size categories, who represent - from the employees‘ point of view - a trustworthy, respectful and attractive workplace culture. As valuation basis an anonymous survey was carried out where employees were asked to answer question on topics such as trust, identification, team spirit, career development, pay, promotion of health and work-life balance. Furthermore the quality of the personnel management and leadership methods of the company were assessed. Top ratings from the employee survey 91% of employees state:

Come and see the UWT level control experts in Hall No. 2, Booth B2 The Powder & Bulk Solids India Exhibition & Conference is the one stop event for materials handling and processing and UWT – experts of level control in the bulk solids markets – are looking forward to seeing you there. Powder & Bulks Solids India is the Indian event for mechanical Processing Technologies and Bulk Solids Handling Technologies. The exhibition with accompanying conference is the high quality get-together for process technicians, process engineers, production managers and scientists. At the exhibition, manufacturers and suppliers of mechanical processing and material handling technologies are showcasing all kinds of solutions for • conveying • transporting • storing • size reduction • screening • mixing • granulation for powder, granules and bulk solids Basic processing technologies for powder and bulk material, plant engineering, processing components and other products related to the chemical, food, cement, mining and ports

ETI selected Royal Dahlman in an open tender process, in which the world’s most advanced and innovative gasification technologies competed for a partially funded design and project development phase. ETI will select the winning design after 10 months, resulting in the realization of the plant. ETI selected the three most interesting technology proposals based upon: • Full integration of waste segregation, gasification, gas clean up and power generation. • Typical UK waste as fuel. • Technology that is commercially viable at 5 to 20 MWe scale. • Robust operability. • An overall net electric efficiency >25% . The plant design is based upon MILENA gasification and OLGA gas cleaning (tar removal) technology. Both are patented inventions of ECN, further developed in close cooperation with Royal Dahlman. The combination of MILENA and OLGA produces a clean gas with a high methane content. It’s high energy value allows for efficient utilization of the

SMC has developed a ‘fitting’ solution for a textile industry customer, thanks to its new air amplifier, that is small in size but has delivered big benefits by reducing energy consumption by a fifth. The ZH20-X185 air amplifier, from SMC’s Energy Saving and Vacuum range, uses compressed air technology for suction and blowing and it has proved to be an effective and cost efficient alternative to traditional electric hoovers and fans. Ideal for processes requiring the removal or suction of small particles or gases, the ZH20-X185 has been certified as the best solution and an alternative to electric hoovers. In this instance, SMC’s customer needed to suction the fabric leftovers when operating an ultrasonic fabric cutting machine. The hoover not only used 3.75 Kw of electricity but also proved to be a bulky and noisy solution that required a great deal of maintenance due to its moving parts. SMC specialists were quick to see the benefits that the air amplifier

FLOWROX Innovativ Hose Pump FLOWROX peristaltic pumps have proven their suitability for a wide range of industries andapplications. Designed for industrial pumping, the LPP-T pump is ideal for slurries with high solid content, abrasive, corrosive, viscous and crystallizing media. Size range: LPP-T25, LPP-T32, LPP-T40, LPP-T50,LPP-T65, LPP-T80, LPP-T100 Flow capacity: Up to 100 m3/h• Maximum operating pressure: 10 bar Standard drive unit: Helical bevel geared motor Auxiliaries: Pressure transmitter, revolution detector,hose leakage detector, connectorhoses Frequency inverters The pump can also be equipped with a parallel shaftgeared motor

In order to overcome production issues, Steinert Elektromagnetbau GmbH, Cologne Germany, has designed the ingenious XSS ® X-Ray sorting plant. Thanks to this manufacturing plant the quarried valuable Tungsten Concentrate of the Wolfram Camp mine may be separated from the gangue, which provides for up to 85% (!) of the production flow. The centre of the entire system is the section where by means of X-ray beams and highly sensitive cameras the desired material within the ore is detected. During the development of the plant Steinert GmbH called in the help of Fiktech B.V. to find a feasible solution to protect the X-Ray section against extreme Australian production conditions; large temperature differences and negative influences of dust and moisture. Fiktech engineered for this purpose a dedicated system based on the use of AFECO Vortex Coolers in order to keep the housing of the X-Ray section at a slight overpressure, along with cooling the electronics and preventing

The SmartSeries LB 414 is a radiometric detector for density, concentration and solids content measurements, combining both -detector and evaluation in one single unit. SmartSeries LB 414 densitometers can be applied on all liquids and slurries. Beside the high level of accuracy and repeatability, the easy way of detector handling is a major advantage of this density gauge. The local user interface with display and the software -focusing on the main functions make calibration and operation of the HART device very easy. Parametrization can be carried out directly at the detectors push button or using a HART communicator, via PC or infrared remote control. SmartSeries has been designed for the harshest of process conditions and is best suited for standard density measurements in non-hazardous, non-explosive environments but tough industries like mining, cement or pulp & paper industry. Its outstanding mechanical stability and robustness is verified by the Fraunhofer

BEUMER delivers 16 belt conveyors to Brazilian mining group - Largest order for conveying systems Vale Malaysia Minerals Sdn Bhd (VMM), a subsidiary of Brazilian mining group Vale SA headquartered in Rio de Janeiro, has awarded the BEUMER Group an order to supply 16 overland conveyors. For the specialist intralogistics company, this is the largest order in the conveying and loading systems product segment in the company’s history. Vale intends to set up an iron ore distribution centre in Teluk Rubiah, Manjung District, in Perak. At the facility, iron ore will arrive from Brazil and then be blended and shipped to the customers throughout the Asia-pacific region. Vale wants to use the BEUMER troughed belt conveyors off the Malaysian coast, in the Strait of Malacca, for transporting iron ore from very large ore carriers (VLOC) to smaller vessels in a specially designed port and storage facility. This around 100 Mio. US$ order for the BEUMER Group is the largest in the conveying and loading technology segment of the company. Construction work is already in full

Optimised filling technology with the BEUMER fillpac R The intralogistics professional BEUMER has expanded its product portfolio with the rotating filling machine BEUMER fillpac R. This machine, designed for capacities of 300 to 6,000 bags per hour, can fill all types of valve bags. The complementary bag placing technology for all common bag types rounds out the product portfolio. The weight accuracy of the bags is guaranteed by a calibratable weighing unit. Together with a special bag placer, the BEUMER fillpac R can fill even woven polypropylene bags. The three-position cylinder that regulates the coarse and fine flow is protected from dust, because it is positioned vertically and outside of the dirty area. The cylinder for bag discharging is also located in the dust-free zone above the filling spout. This solution minimises wear and tear on both cylinders and therefore ensures longer service life. BEUMER has also equipped the optimised filling machine with an automatic bag weight correcting device. This device automatically

KSE receives order via Ottevanger Milling Engineers for a considerable expansion of the bulk outloading at Aveve Veevoeding Aalter, Belgium. The expansion realizes flexibility and a more efficient throughput of the existing bulk outloading. Less waiting time for trucks, faster loading of trucks, more efficient use of stocks, less logistic handling, these are all reasons for Aveve to ask Ottevanger to expand their bulk outloading. To realize this order, Ottevanger includes systems of KSE Process Technology. From silos, finished product is transported via five movable ALFRA bulk weighers. They deliver it to seven movable ALFRA Bulk Batch Transports (BBT). The BBT’s deliver the finished product to counter bins which load the trucks. A paddle mixer is also supplied by Ottevanger. KSE will make this mixer movable and weighing. The mixer is fed with medicines by an ALFRA Micro Component Dosing system. In addition, the installation includes a dual-axis paddle mixer

High storage capacity with a low space requirement The Cologne-based company Heinrich Axmann GmbH & Co.KG is a modern, family-lead company specialising in sophisticated plastic packaging, containers and cutlery for the food sector. In line with modernisation measures, it was decided that the material supply for the production of lids should be changed to an automated silo solution instead of the previous supply using sacks, which was very personnel intensive. Compared to manual filling, it increases process security significantly. An essential requirement was that the installation should save as much space as possible, so that the driving with lift trucks on the company premises would not be hindered. It was decided to use the silos of A.B.S. Silo- und Förderanlagen GmbH in Osterburken to realise the project. The fact that the supplier"s polyester fabric Flex-Silos are tailored to the customer"s needs was crucial for this selection. Another factor was that A.B.S., due to its comprehensive competence,

Abrasion resistant and compact design The patented deflection chamber reduces turbulence and friction. This results in gentle conveying of the product, avoiding formation of angle hair and reducing pipe wear. Gericke Ellbows Type GB can be used for vacuum and positive pressure conveying as for lean and dense phase conveying.

For the production of sausages, meat and fish products as well as for numerous other foods, large amounts of most different spices are processed. Coming from distant countries and climate zones, they however also carry large amounts of micro-organisms. Amounts of several million “colony-forming units per gram” (CFU/g) are perfectly normal. Still, these spices should be as germ-free as possible when fed to industrial production processes for foods. Heating the spices over a longer period of time is not acceptable: this process would indeed eliminate the germs, however destroy or desorb fragrances and flavors as well. AVA has found the process solution to sterilize effectively, yet protecting fragrances and flavors. AVA vertical dryers of the series HVW-VT are suitable for all variants of overpressure sterilization and saturated steam sterilization. The amount of microorganisms in pepper, coriander, marjoram, onions, sweet pepper, and mixed spices has been held considerably

High Power Magnetic Proximity Sensor Non-contacting extended range magnetic proximity sensor, not affected by dust or material build up, used to detect moving ferrous material up to 75mm away from the sensor. The WDA sensor is designed for use with bucket elevators to detect the buckets in order to measure speed and alignment. It can also detect screw conveyor flights, and ferrous bolts when attached to non-ferrous buckets. A more specialized use of the WDA sensor is for broken/slack chain detection. The sensor is used in conjunction with a PLC or with 4B’s Watchdog™ Elite or A400 Elite control units. Two output signals are provided: one signal is a pulse output, representing each bucket detected: the second signal is a continuous output when moving buckets are detected. FEATURES ►Adjustable Sensing Range 25mm to 75 mm ►LED Indication ►Mounting Bracket Included ►½” NTP Conduit Entry ►Stainless Steel Construction ►High Temperature Version Available ►IP66

Easier to integrate, gentler and less expensive mixing concept Dinnissen Process Technology has already built an enviable reputation for delivering sophisticated solutions for mixing powders, granules and granulates. Dinnissen is launching its new Lean Mixing concept with a new and integrated transport system that can be more easily integrated and is gentler and less expensive than the pneumatic transport systems now commonly in use. The Lean Mixing concept offers a total and integrated solution for mixing powders, granules and granulates, including a highly effective and efficient system for transporting the raw ingredients as well as the finished product. This new concept allows for a totally integrated mixing and transport process without having to resort to pneumatic transport with allthe related disadvantages such as increased risk of product damage, higher energy costs, higher contamination risks, and extra handling. LeanMixing utilizes big bags in which the ingredients have to be lifted only once. Once the big bags are

Knowledge sharing, trainings and social networking are the central focus of the DSIV activities The association was founded in September 2012 and sees itself as representatives of more than 1000 companies in the German speaking countries within the bulk solids industry. The DSIV e.V. offers a knowledge and information sharing platform, trainings but also social networking. The focus is definitely on creating a communication platform for the bulk solids industry. Members are offered the following services: • Industry specific trainings and seminars • Platform to exchange information • Information & expert knowledge about the bulk solids industry A list of the current DSIV members including many well-known companies within the bulk solids industry can be accessed via the DSIV homepage.

Looking for Pioneers! Utange Project Ursula Stein from Betzigau, Board Member of the voluntary organsiation Utange, supports children in Kenia. With the slogan “Looking for Pioneers” Frau Stein’s aim was to inspire local companies to support her new project in Kenia to finance a pre-school and a small primary school on a piece of land which was given to them by a pastor. As Uwe Niekrawietz, managing director of UWT and his wife are already „godparents“of three children in Kenia - organized through the Utange project (two children sponsored privately and one through the company) they could not say „No“ to this appeal. On the picture you can see Uwe and Petra Niekrawietz handing over a cheque for 2.000.- Euro to Mrs Stein to financially support her new and exciting project. We wish Mrs Stein great success with her project!

Dinnissen Process Technology has developed an automated container tipper for emptying containers with hazardous substances inside a closed housing. Via this innovative solution, Dinnissen aims to offer process operators an optimum level of safety and the ability to empty containers without leaving any residue behind. The container tipper will be on show at the EasyFairs Solids in Rotterdam and the K-Messe in Dusseldorf. Optimum safety and stress-free operation for the operator Companies in the chemical, pharmaceutical, recycling, and petrochemical industries often process hazardous substances in drums and octabins. The process of emptying such containers is physically stressful and also hazardous due to the toxic and irritating properties of the contents. The container tipper has been specially developed to automatically tip the container and empty it safely and efficiently without leaving any residue behind. This even applies to situations in which the container

IEP Technologies, a newly formed company, has acquired the industrial explosion protection businesses of UTC Climate, Controls & Security, a unit of United Technologies Corp. These businesses, which currently go to market under the names Fenwal Explosion Protection (USA), Incom Explosionsschutz (Switzerland), Kidde Explosionsschutz (Germany) and Kidde Explosion Protection (United Kingdom), have combined under IEP Technologies to form the global leader in the industrial explosion protection industry. IEP Technologies will continue to provide the best-in-class explosion protection systems, design engineering, replacement parts, material testing, and service and support that customers around the world have come to expect from its legacy businesses. The strengths of IEP Technologies are their existing system design platforms, which are based on sophisticated computer calculation tools, thousands of full-scale explosion tests and over five decades of field experience. IEP
