News items November 2022

High torque drives for rapid mixing of larger quantities. Stainless steel air motors are your best option for challenging application environments. Mixing and stirring – a science in its own right. Agitator specialists draw on decades of application experience and extensive material tests of mixing behaviour. Whether handheld or automated agitators, the correct mixing technology is decisive for the quality and workability of the material mix. For changing tasks, handheld solutions tend to be more advisable than small automatic mixers, as soon as you also take the frequency of changing and cleaning the mix inserts into account. Single / double spindle agitators In general, we differentiate between single / double spindle agitators which mix low viscosity materials well, automatic rotation mixers which are used to mix large quantities at high speed, centrally located stirrers in a revolving container or compulsory mixers where consistent quality is required. Energy-saving mixing A perfect energy-saving mixing result can only be achieved when the drive, mixer and mixing material are optimally coordinated.

Sinfimasa designed three chain conveyors for the transport of SRF. Sectorization of two fire zones was important, so one of the conveyors was equipped with firewall slide gates. Solid Recovered Fuel (SRF) is a fuel prepared from non-hazardous waste, and used for energy recovery in incineration and co-incineration plants. It consists of small fractions of waste with a high calorific value. This makes it also suitable for use in cement kiln installations. Our client is a non-hazardous waste valorisation plant, and needed to build a conveying line to deliver different types of SRF into storage boxes after shredding, separation and classification process. The required output was 150 m3/h. Transport in 3 steps To solve this need, Sinfimasa designed three chain conveyors; the first one would transport the SRF at a horizontal distance of about 10m and would elevate it to a height of 8m. The second conveyor is positioned horizontally over a distance of 4,7 m. An important function of this conveyor is to ensure the sectorization of two fire zones, so it was equipped with firewall slide gates. A third conveyor was designed and manufactured

A review of equipment and outputs used to assess the flowability of powder and granular materials which can also be used for vessel design. Prof Mike Bradley, Director of the Wolfson Centre, explains the importance of Powder Flow Technology in this short video. Please contact us for advice through consultancy or training in this area of application. A chat in the first instance will cost nothing but your time.

Understand the importance of knowing the powders and bulk materials you use and why they behave as they do. And use this to solve or avoid problems in handling. Powders and Particulates used in the processing industry can often cause major disruptions to production whether through build-up in hoppers, de-blending, uneven weights when packing or dosing, degradation, dust build-up……the problems go on. Experts at the Wolfson Centre for Bulk Solids Handling Technology have put together a series of training courses to help delegates identify potential issues before they become a major headache and advise on how to help solve or avoid the problems that may otherwise occur. Some of the courses looking in detail at different characterisation methods include: * The Measurement of the Properties and Bulk Behaviour of Particulate Materials; Jan 2023 * Undesired Deblending and Separation in Processes and Equipment; Feb 2023 * Caking and Lump Formation in Powders and Bulk Materials; May 2023 * Dust Control for Processes; June 2023 * Electrostatics in Powder Handling; Dec 2023 These courses are all delivered online in English

An overview of a bench scale evaluation method for quantifying the sensitivity of a free-flowing material (or blend) to segregation. Richard Farnish, Technical Director at the Wolfson Centre for Bulk Solids Handling Technology, explains the importance of testing materials for their segregation tendency in this short video. If segregation issues are a problem in your plant, please contact us for advice through consultancy services or training.

You are highly Welcome on the 12. ForumMIRO .... the Congress of the German Mineral Industry We will present our PrimeTracker with the built-in monitoring system, there are also many interesting topics such as: Interesting topics such as: Building raw materials - how secure is the supply? Extraction of raw materials and public Technology - innovative and sustainable Demand high - raw materials scarce Technology - future And many exhibitors with innovative new products.

The Indus NEVA system is a highly efficient method of reliably storing and transporting big bags. The Gericke/Indus big-bag pallet unloader facilitates the unloading of difficult powders. Last week Indus, together with Gericke, were present at the SOLIDS fair in Antwerp. Great talks were held and many demonstrations were given. Big bag unloader and NEVA Many people were interested in the NEVA big bag handling system developed by Indus because of its advantages: easy emptying and filling of big bags; reinforcement of the big bags and saving space in the warehouse. Gericke’s fine development can be used when bridging occurs during big bag emptying. To prevent this, the Neva can be placed with the big bag on Gericke’s Big Bag Pallet Unloader and can be completely emptied by vibration. Innovation award This innovation, mainly in the powder industry, ensures reliable storage, transport and disposal of products from Big Bags. This was also the opinion of the participants of the Innovation Tour because together with Gericke, Indus received the Innovation Award.

Our foundation 31 years ago and more about our company history How it all began... On 22.11.1991 exactly 31 years ago our SSB Wägetechnik GmbH, at that time still under the name SSB Steuerungsbau GbR (Lebrato und Partner) was founded. On the photo the letterhead with the company headquarters at that time. For more pictures from the old days click the link under more info.

Our SSB Wägetechnik video is now online. Together with the creative agency Realdot we have created our own corporate film. Learn who we are, what we can do, what makes us tick and what our values and demands are. You can find it on our website or on our YouTube channel. Take a look.

The LAS 5000XD cross-duct laser gas analyzer offers fast response time, robustness and is calibration free. for measuring an extensive range of parameters such as NH3 + H2O, HF, CO + CO2, O2, HCl + H2O, CO2 + H2O, etc. The new TDLS (Tunable Diode Laser Spectroscopy) LAS 5000XD gas analyzer comes in various models for measuring an extensive range of parameters such as NH3 + H2O, HF, CO + CO2, O2, HCl + H2O, CO2 + H2O, etc. It has been designed to offer robustness, fast response time (1 s) and high accuracy measurement in harsh environments. The analyzer is calibration free, doesn’t require a sampling system and provides a large and dynamic measurement range from ppm to %. It offers real-time communication between receiver and transmitter units and an embedded web server. In addition, the LAS 5000 XD includes a specific feature for managing outside path interference. Indeed, thanks to ClearPath, interference of relative humidity, O2 or CO2 is removed from the purging areas. This guarantees high accuracy measurement of H2O, O2 and CO2. As a consequence, N2 and dry air purge are not needed. Operator’s benefits include low maintenance, process optimization and reduced total

A long tradition at the Allgäu-region. The leaders of the subsidiaries around the world meet each other. , , , , , , , , , , , , , ,

MoistTech is debuting their Food Grade Sanitary Valve Connection that allows for the instant measurement of moisture through a pipeline for pneumatically conveyed materials. Requiring an instant method of moisture detection during the manufacturing process is very common in the food industry, but what about when it comes to applications such as condiments, chocolate, soft cheese, sauces and more? MoistTech is debuting their Food Grade Sanitary Valve Connection that allows for the instant measurement of moisture through a pipeline for pneumatically conveyed materials. This provides users with a non-destructive way to have instant moisture measurements directly on the production line without time consuming traditional laboratory methods. The Food Grade Sanitary Valve Connection is designed to be adapted to the process pipeline conveyed material, allowing the material to flow directly against the NIR detector without wasting or contaminating the product. * Monitor: Process optimization and monitoring creates increased efficiency & less waste * Adjust: Operational personnel are able to make crucial, immediate adjustments * Improve:

On 29 and 30 March 2023, Messe Dortmund will once again be dedicated to solids handling, pumps & valves and recycling. After their debut as a third event, the Solids, Recycling Technology and Pumps & Valves trade fairs will once again show the way to a more sustainable future next spring. Visitors and exhibitors alike will benefit from the synergies of the three trade fairs, especially in the areas of mechanical recycling, sorting and digitalisation. ”Against the backdrop of increasing raw material scarcity, greater environmental impact and rising energy costs, the pressure on industries remains high. The call for sustainable, more recycling-oriented and energy-efficient products is getting louder and companies are challenged to quickly lay the foundations for this,” says Anna Lena Sandmann, Head of Events Solids, Recycling Technology and Pumps & Valves Dortmund from organiser Easyfairs Deutschland GmbH, explaining the current situation in the industries. In addition to sustainable product design and energy-saving processes, recycling plays an important role. Decision-makers are

Mixing and grinding intelligently combined: Hosokawa Alpine convinces with many years of know-how for integrated solutions for preparing cell culture media Preparing cell cultures involves a process in which cells are grown under well controlled conditions. In basic medical and biological research, processes such as metabolism and cell division can be studied in this way. This provides scientists with crucial insight in the search for vaccines, therapies and cures. Furthermore, in today’s biologicals production cells are used to produce new and innovative pharmaceuticals. It’s most important that these cells generate high-quality drug in a validated process constantly. The foundation for optimising cell activity and growth curves lies in creating the ideal breeding environment – and therefore in the recipe and correct formulation of ingredients for the culture medium. The quality of the culture medium is strongly determined by the particle size and the homogeneous dispersion of the ingredients in dry powder. Over the past 20 years, Hosokawa Alpine has specialized in an integrated process that meets the demanding

This project aims to significantly increase the presence of UWT equipment in Switzerland. We are looking for distribution partners. For the expansion and systematic development of the market in Switzerland, we are looking for distribution partners on the one hand and plant manufacturers and large end customers on the other. * Business partner brokerage This project aims to significantly increase the presence of UWT equipment in Switzerland and to establish a long-term partnership with a Swiss company. This project was funded by the European Regional Development Fund. This Fund aims to strengthen economic, social and territorial cohesion in the European Union.

SSB Wägetechnik GmbH looks back on more than 30 years of experience in the field of bagging, control and weighing technology, always close to the customer, with a strong team behind every project. SSB Innovation by Tradition. Company milestones of SSB Wägetechnik GmbH On 22.11. we have our foundation day. A lot has happened since the foundation and we have grown and developed steadily: New employees, new building and expansion and modernization of the headquarters, innovations and expansion of services and portfolio. Take a look here at our chronicle with the individual milestones and which steps we have taken together with our customers, partners and employees. Be curious about further progress and stations in our history and the release of the new corporate film.

A conveyor belt tracker with an integrated predictive monitoring system. At the same time, the misalignment of the conveyor belt is continuously monitored and automatically corrected. Everything OK. at the conveyor belt? In the future, the user will be able to answer this question simply and comprehensively without having to inspect the conveyor system on site. This is made possible by a belt conveyor tracker with integrated sensors, which ScrapeTec - a specialist in optimizing bulk material conveyor systems - developed and presented for the first time at bauma. Basis: The conveyor belt tracker for detecting belt misalignment The basis of the system is the ”PrimeTracker” belt tracker, which detects and automatically compensates for belt misalignment (image 1). Even slight misalignment is immediately recognized due to the non-uniform forces that then act on the roller. The cylinder body then pivots automatically in such a way that the belt is guided back to the centre. This works equally with minor and severe misalignment. In contrast to similar systems, the tracker can move completely freely in a 360 degrees radius during operation and

Plant manufacturer and process expert Glatt uses pre-engineering to put investment decisions on a firm basis and enables its customers to bring forward sub-projects. ”Successful pre-engineering is the mental anticipation of all project contingencies - and it’s done before investment decisions are made.” No expensive surprises. Clifford Schäfersküpper, Glatt Ingenieurtechnik, uses practical examples to explain what is important in pre-engineering. To stay ahead in the race for successful new product launches, the concept phase is crucial. Plant manufacturer and process expert Glatt uses pre-engineering to put investment decisions on a firm basis and enables its customers to bring forward sub-projects. Preparing to make an investment decision can bring beads of sweat to the foreheads of R&D experts, product developers and founders alike. Often, they lack an overview of the project’s scope and details, and have to assess both risks regarding future operations and the profitability of possible alternatives. Read the full article to learn about * The early concept phase * Consumption and connected values * A preliminary

PerMix makes mixer cleaning easy with our EZ-Clean series mixers. Eliminate confined space entry to clean the mixers with our EZ-Clean series mixers PerMix makes mixer cleaning easy with our EZ-Clean series mixers. Eliminate confined space entry to clean the mixers with our EZ-Clean series mixers. Our EZ-Clean series mixers are engineered to allow production teams to quickly access both horizontal and vertical mixers quickly & easily with no tools needed to clean the interior of the mixers. Come see the PerMix difference.

The new Sesotec showroom in Varedo MB, Viale Brianza 25, in the Milan area, provides space for metal detectors, metal separators and X-ray systems that can be used by customers in the plastics, food and recycling industries. Milan, November 2022 Sesotec GmbH from Schönberg in Lower Bavaria officially opened its new showroom near Milan on 06 October 2022. Representatives from the parent company - CEO Joachim Schulz and Regional Sales Manager West Franziska Lechner - were on site to ceremoniously inaugurate the showroom together with local management, customers and partners. Italian market Joachim Schulz expressed his gratitude for the trust placed in Sesotec: ”The successful cooperation over the past years confirms that we have taken the right path by opening a showroom in Italy. We have already opened a branch in Milan in 2021 and since July the Sesotec website has also been available in Italian. The concept of providing all-round support to customers on site has proved to be an excellent one. The great importance that the Italian market has for Sesotec is also reflected in the current investment in the showroom. This is an important milestone for us and our further growth in Italy.” Sesotec

ScrapeTec presented its innovative dust protection solutions for conveyor technology and the world’s first E-PrimeTracker. The whole world wants to know: ScrapeTec with a new product at bauma 2022 The world’s leading trade fair for construction machinery, building material machines, mining machines, construction vehicles and construction equipment has invited for the 33rd time. And the worldwide professional world came. Also to the booth of ScrapeTec GmbH. The interest in dust protection solutions was high, also in the new E-PrimeTracker. After the success at the POWTECH in Nuremberg in September with over 150 contacts and numerous inquiries, the bauma in Munich followed. For seven days, numerous visitors from the professional world from all over the world were at the ScrapeTec booth, which is part of a joint booth of the Ministry of Economics, Industry, Climate Protection and Energy of the State of North Rhine-Westphalia. Here 10 companies presented the mining competence under the national flag. The inflow at ScrapeTec was also the result of the great response to the LinkedIn activities

Vibration decoupling machine mountings at Eurotier and Energy Decentral. The trade fair season 2022 is slowly coming to an end and will once again offer a highlight with the trade fair duo Eurotier and Energy Decentral in the coming week. RG+ Schwingungstechnik will be represented in Hanover with its range of stainless-steel vibration dampers. At Energy Decentral, the exhibition for decentralized energy supply, the focus is primarily on the storage of exhaust gas aftertreatment components, as well as complete CHP modules. Silencers, heat exchangers or catalytic converters are supported by means of compression-tension elements with integrated damping pads. For CHP modules, spring isolators are a very good option for decoupling. At Eurotier, it is mainly air classifiers, screens, mixers or even tank systems that can be successfully decoupled with special machine feet. What unites all applications is the successful extension of service life of the stored components, which is achieved using decoupling elements. We are pleased to advise

ULT has developed a dedicated version of the LAS 800 extraction system free of ignition sources to increase explosion and fire protection during laser dust extraction. The all-new LAS 800 Ex was specially designed because ever finer combustible dusts are produced in laser processing due to higher input energies or shorter laser pulses. Therefore, the explosive potential increases with the degree of fineness in the dust. The ignition source-free device is an externally tested and confirmed solution that safely extracts the finest laser dusts at relatively low investment costs, utilizing H14 HEPA to ensure a separation degree of over 99.995%. Both the suitability for extracting explosive dusts (at the IBExU Institute for Safety Technology, Freiberg/Germany) and the filtration efficiency of the filters (at the Institute for Ventilation and Refrigeration Technology ILK, Dresden/Germany) were assessed. The ignition source-free design of the device ensures that the potential for explosions is eliminated when the LAS 800 Ex is used as intended, and expensive structural explosion protection can therefore be dispensed with. The LAS 800

A lot of applause for NOLL Processing Technology’s latest innovation, the ultra-compact laboratory system 1050. Another big winner: extraordinary energy saver DemiNo®, NOLL’s exclusive impact jet mill. For the first time since the young generation has taken the helm at the fine particle technology specialist, the NOLL team and its new Managing Director Bettina Noll welcomed visitors at POWTECH. Their stand offered a relaxing experience in sunny »forest bathing« design and, of course, unique innovations to discover. Visitors turn to NOLL because they are looking for extraordinary engineering solutions for a very specific challenge, explain Sales Director Christian Vochazer and Technical Director Gerd Stiegler: “Solutions they wouldn’t find anywhere else. Our talks with clients focus e.g. on particular target fineness, sustainability, multifunction…we are partners in the exquisite dry processing of polymers, metallurgy, minerals, pigments and foodstuffs.” An inspiring ambience which Senior and company founder Ulf Noll wouldn’t have missed for anything. Flying in from Venice, he, too, joined the team at POWTECH’s most beautiful stand…from sunlight into

Trade fair for professional animal farming and livestock management. EuroTier is the international trade fair for professional animal farming and livestock management. We look forward to meet you there and discuss the possibilities of our feed and (waste)water storage solutions. In the agricultural sector, Polem is has been Europe’s market leader in the bulk storage of cattle feed and chemical fertiliser for many years. This is because Polem manufactures a wide range of high-quality feed silos, chemical fertiliser silos and liquid feed tanks using fibre-glass reinforced plastic. Thanks to its proven quality, this corrosion-free, near-indestructible material guarantees a long life span.

The C5 is the universal one-pot machine that combines an entire development lab in one. One machine - many options. Don’t make your lab unnecessarily full and expensive with a variety of lab machines. The C5 is the universal one-pot machine that combines an entire development lab in one. Due to the unique mixing principle, all process operations such as mixing, deagglomerating, dispersing, granulating, coating, kneading, and drying and many more are possible with a single machine. Effective cleaning Thanks to optimized accessibility, smooth surfaces and selected components, the C5 can be cleaned effectively and reproducibly. Ergonomic and quick handling The product contacted components (mixing tools, seals, scrapers, mixing vessels) can be assembled and disassembled in the twinkling of an eye. Extra flexible Simple change of mixing tools and parameter adaption allows flexible variation of different production and preparation techniques. Technical features * Effective volume: 1.6 to 5.0 liters * One-piece welded mixing tool, selectable in various geometries,

On 16 and 17 November 2022, Klinkenberg will be at the fair with its new representation, TAMAR Innovative Sealing Technology. Krommenie-based Klinkenberg Zaanstad B.V. is expanding its cooperation with ”TAMAR Innovative Sealing Technology” from Israel. TAMAR is for Klinkenberg the partner that is unbeatable on sealing technology of rotary equipment. As a result of the close and good cooperation, Klinkenberg together with TAMAR has decided to take on the representation of TAMAR seals for the Benelux.

A new product in the big bag crusher range of JH. It has proven to be a very successful alternative between the mobile crusher and the fully automatic crusher. The content of big bags can become hard for many reasons. In that case, it is not possible to empty the big bag in a normal way, because the lumps are too big. By crushing the content, the large lumps are reduced to a workable size. Scope of the installation * crusher arms * frame at height * removable shield * radio remote control for the forklift driver * hydraulic unit * the entire frame can be easily moved with a forklift Operation The big bag crusher semi-automatic can be operated as following: a big bag hang with its loops on a forklift and is loaded into the crusher form the top. The crushing usually starts from the top and moves its way down to 4 to 5 places distributed over the height of the bag, the forklift thus lowers the big bag downwards. A crush movement of the big bag crusher lasts approximately 10 seconds. This cycle may be repeated after rotating the big bag 90 degrees , this ensures that all large chunks in the big bags are broken. Hydraulic

A customer project from SSB A customer project from SSB: * Compact, mobile PVC bagging plant for silo farm. * A major technical challenge for the Vestolit/Evonik silo farm in Marl. * 3-spout bagging system for filling valve bags with E-PVC. * With ultrasonic welding and dust extraction. Our customer is extremely satisfied with this installation.Would you also like information and comprehensive advice on your projects and our service?

How do you modernise your operations? Drive efficiencies by optimising data exchange and delivering real-time actionable insights. Discover Brady’s Intelligent Manufacturing Solutions Like nearly everything in today’s world, manufacturing operations are going through a radical transformation. By implementing modern methods of identification —such as advanced barcoding & labelling technologies, RFID, machine connectivity, and business system integration – organisations are now unlocking a level of visibility into their operations that has only recently become possible. So what is the visibility you need to revolutionise your operations: * Real-time information – know what’s happening when it’s happening - and why * Operational flexibility – adjust quickly to changing production needs * Seamless productivity – manage assets and inventory holistically and scale on demand * Customised solutions – easily customise data exchanges and workflows Real-time information Real-time information and insights to optimise any production facility. When it comes to efficiency, productivity and cost savings, real time is the real deal.

The 40th MOTEK exhibition opened its doors in Stuttgart over the 4th to the 7th October 2022. The 40th MOTEK exhibition opened its doors in Stuttgart over the 4th to the 7th October 2022. Throngs of customers from Germany and abroad were greeted with a top-class programme encompassing all the hot topics from production and assembly automation. DEPRAG, the screwdriving technology and automation specialists, also put on quite a show. Visitors were treated to a wide range of product innovations - in particular, screwdriving and automation applications in combination with robotics. The motto “#screwbotics – automation excellence by DEPRAG” underlines their expertise in this sector. Light, flexible and smart products, optimally prepared for connection to lightweight robots and cobots. The DEPRAG screwdriver function modules are amongst the most suited machines for this task. In addition to their standard versions, the collection has been expanded. The E-SFM (screwdriver function module with electronic stroke) facilitates a flexible response to complex

The expectations of Siloanlagen Achberg were clearly exceeded at this year’s K trade fair in Düsseldorf. The new stand concept and the exhibited products were extremely well received by the expert audience. Even after the first three days of the exhibition, the manufacturer from southern Germany saw initial positive signs. Demand from existing customers in the mechanical and plant engineering industries, as well as from interested parties worldwide, was considerably higher than expected. “We are extremely pleased with the outcome from the exhibition”, said Gerd Maass, company founder and managing director of Siloanlagen Achberg. Mobile mixing container is well received The prototype of the new mixing container from Achberg was very well received by the specialist audience. “There have already been several enquiries about the mixing container”, said a spokesperson from the company’s sales department. The market launch is earmarked for 2023. In addition, the coupling table with connected pipe system as well as the various containers and components for pipe systems caught the attention of visitors. New stand concept strengthens the ACHBERG® brand The company

”It was definitely the right decision to present ourselves in Nuremberg”. Innovations in technologies and software solutions, high-level talks Schönberg, November 2022 Sesotec GmbH, one of the leading manufacturers of equipment and systems for foreign body detection, material sorting and analysis, draws a positive conclusion from its participation at Fachpack/Powtech in Nuremberg. With the topics of foreign object management, resource conservation and sustainability burning on the nails of customers from the food and packaging industries, the quality of contacts and discussions at the show was high. Due to its expertise in both the plastics and food industries, Sesotec was able to present competent contacts and high-tech products for foreign body detection at both trade shows. Main highlights: the high-end X-ray inspection system RAYCON D+ HX, the VARICON metal detection systems with latest coil technology and the Compliance Package software. ”Must have” effect with visitors ”The ”must have” effect with our customers was great, because we not only presented well-known foreign body inspection

Hardox pipe is the first choice when it comes to wear resistance and long service life under abrasive stress from the corresponding pumped media. SSAB presents itself with Hardox pipe and profiles. For the first time worldwide, the day-to-day business with Hardox pipe can now be served with currently 2 dealers in Germany. In addition, the dealers also offer processing up to ready-to-install OEM components. Hardox pipe is the first choice when it comes to wear resistance and long service life under abrasive stress from corresponding pumping media. The Swedish steel company SSAB has focused entirely on the production of quenched and tempered steels for high-strength or wear-resistant applications. The world-famous Hardox wear plate is complemented by a Hardox round bar, tube and profile range. Both companies, Gera-based MEHAG Bearbeitungs GmbH and Abraservice in Düsseldorf, are far more than just trading companies for steel. The service package ranges from cutting and processing to the production of ready-to-install components. ”We support both our trading partners and the end users by providing comprehensive

The controller retrieves the recipes from an external ERP system so that the operator no longer has to enter the recipes manually, thus avoiding typing errors. Breatec B.V. (part of BRAIN Biotech AG) develops enzymes and enzyme mixtures for flour mills, bread improver manufacturers, pasta and noodle producers and distributors. Breatec expansion Due to huge demand for natural ingredients in the form of enzymes, Breatec decided to expand production. Breatec was looking for an automated line that could dose microcomponents accurately, but above all could ensure a maximum emission standard of 0.6 mg/m³ dust load for the operator. Food ingredients such as enzymes can be harmful if inhaled frequently in too high a concentration. The new extension had to be built into the existing (limited) space. Cooperation Poeth-Breatec Breatec challenged six suppliers to set up a smart basic concept. After extensive preliminary research, Poeth Solids Processing was selected for pre-engineering to develop the concept further. ”Poeth quickly came up with inventive and practical solutions,” explains operational director Jacobus Richter

The topic of “explosion safety” is omnipresent for plant operators and OEM´s when it comes to handling or transporting combustible dusts. Despite the widespread assumption that an increased risk of explosion only exists for gases, enormous forces can also be released by explosive dust- / air mixtures. To help minimise the risk of explosions when handing combustible dusts, it is important to understand the requirements for an explosion and the respective dust safety characteristics, which are described below. The following picture shows the fire triangle and the explosion pentagon which must be taken into account. The following conditions must exist for an explosion to occur within a production facility or machine. If any one of the aforementioned prerequisites is eliminated, explosion prevention has intrinsically been practised. However, if this is not possible at all times and in all operating states, explosion hazards will still be present. In this case, it is necessary to divide any potentially explosive atmospheres into zones and systematically apply safety measures. Drying processes in

When processing anthracite coal into briquettes the moisture range is crucial for the product quality. To save time and costs, the moisture measurement process needed to be automized. Our customer is a leading manufacturer of process carbons. More than 70,000 tonnes of dry coke, anthracite, blown coal and alloying coal are produced each year for the iron, steel and electrode industries throughout Europe, as well as for other areas of application. Anthracite coal is of particularly high quality. At the beginning of the processing process, the material is in powder form, which is then processed into briquettes. In order for it to be formed into a briquette, it needs a special moisture range. If the powder is too wet, it sticks to the mould. If it is too dry, on the other hand, a briquette cannot be formed at all. To obtain the right moisture range, the moist anthracite is mixed with dry starch. The plant operator takes a sample of the material every 15 minutes to check. In order to automate and optimise this manual sampling, the customer was now looking for a measuring solution. Process data * Customer: Process carbon manufacturer * Material:

Due to the extremely cohesive properties of very specific types of powders, a challenge can arise in getting these powders to flow. For over three decades, Lindor has been manufacturing industrial mixers and processing machines for powders, granulates and bulk solids. Among the large variety of applications our powder blenders have been built for, there are a few exceptional powders that tend to cause a fuss. Due to the extremely cohesive properties of very specific types of powders, a challenge can arise in getting these powders to flow from one section of a machine into the next. We like to refer to them as ’sticky powders’, and these exceptional powders include: # Battery powder # Fine minerals # Fine ceramics # Pigments After having experienced a challenge in the powder flow from the inlet to the drum of our mixer machine, we decided to come up with an innovative improvement for these very special powders. Tackling flowability challenge For almost all powders, a special coating like Teflon within Lindor powder mixers, along with the water blasting and mirror polishing, is

Powerful comminution with variable rotational speed The FRITSCH Universal Cutting Mills PULVERISETTE 19 and PULVERISETTE 19 large ensure fast, easy comminution of a wide range of plastics/polymers as well as biological materials in small and large quantities. Its main areas of application include environment and recycling, secondary fuels/RDF in cement production, power generation and other similar contexts, as well as cannabis processing. There is a special stainless steel version for the foodstuffs and pharmaceutical sectors. The gradually variable rotational speed setting allows optimal adjustment of the cutting speed to any sample material. The well-conceived structural design of the grinding chamber ensures optimized hygienic cleaning. Overview of the main features: - Variable rotational speed from 300 – 3000 rpm or 50 – 700 rpm for optimized torque - Feed size up to 70x80 resp. 120x85 mm - Throughput up to 60/85 l/h - Variable final fineness with sieve cassettes from 0.1 – 20 mm - Tool-free maintenance

Spiral jetmills enable ultra-fine products with dry processing. The Spiral Type Jetmill of PMT-Jetmill is specialized in optimizing air streams to improve efficiencies and to minimize energy consumption. One application example is Wollastonite. The material is fed pneumatically to the spiral jetmill and runs spirally through the milling chamber. Grinding media enters the area through the milling nozzles. Grinding media is either compressed air (3.5 to 15 bar and 240°C) or superheated steam (up to 24 bar and 400°C). The air stream fluidizes the material-bed and lifts as much particles as possible into the stream. Comminution is mainly based on shearing forces which result from velocity differences. The integrated dynamic classifier is capable to run at a maximum circumferential speed of 190 m/s. As soon as the particles reach a certain fineness, they can pass the classifier to the final product. The fineness can be easily adjusted by variation of the classifier speed. One application example is Wollastonite: Sample 1: * 7700 rpm classifier speed * Particle size: d50 = 2,5 µm (after Lasergranulometer Cilas 1064L) * Particle size: d97 = 10,5 µm (after Lasergranulometer Cilas 1064L) Sample 2: *

55 years ago, TBMA, Technical Bureau for Mechanisation and Automation was founded by the father of Bart Houben, our current managing director. Mr Houben started the company by importing the English Westinghouse Derion rotary valves and supplying pneumatic conveying systems. Over the years, TBMA has developed its own line of rotary valves and the product range has been expanded with, among other things, diverter valves, loading chutes, samplers, big-bag filling and discharging installations and the Galahad bag cutting / emptying machine. Also, in 2000, TBMA Belgie was founded by Bart Houben, Wim Van Parijs and Stefan Schumann. We thank all our customers, representatives and suppliers for their continuous cooperation and trust and are looking forward to the future with confidence.

Hosokawa Alpine offers a cryogenic grinding system with the Contraplex CW II pin mill and the Pharma Cryogenic Feeder PCF. This video explains the functional principle of the plant. For some products, cryogenic grinding is necessary to ensure the highest possible product quality. Examples of this are sensitive APIs in the pharmaceutical industry or spices, whose aroma and flavour are better preserved this way. The material to be ground is first embrittled by cooling, usually with liquid nitrogen, and then ground. Hosokawa Alpine offers a cryogenic grinding system with the Contraplex CW II pin mill and the Pharma Cryogenic Feeder PCF. This video explains the functional principle of the plant.

The Lab HM modular laboratory mixer from MIXACO is the latest innovation for use in your laboratory. The wide range of applications and easy handling make it the most flexible mixer solution for your laboratory. The MIXACO Lab HM mixer series is all about flexibility. The mixer base contains a high-performance motor that ensures the optimum peripheral speed and the corresponding torque for all sizes. A special highlight of the new MIXACO Lab HM are exchangeable vessels, which can be precisely replaced via a quick coupling system, depending on the desired batch size. 100% safety is guaranteed here. It is a high-standard­ised all-in-one solution and revolutionizes the entire laboratory work. Three vessel sizes with adapted tools make this heating lab mixer incredibly flexible. The 3-in-1 Heating Mixer for Laboratories. 5, 10 and 20 Liter Volumes Fully Automatic Heating and Mixing. Advantages MIXACO Lab HM * Flexible mixing in 3 container sizes 5, 10 and 20 liters * Laboratory mixer for all common mixing processes * Heating with total temperature control * Fully automated processes * Quick couplings for compressed air, tempering fluids, electrics * Combination

PerMix Hybrid is a Paddle Mixer & Plow Mixer all-in-one powerhouse. It allows you to switch between a paddle mixer and plow mixer with ease. This allows for the ultimate in diversity. Hybrid Paddle Mixer / Dryer The PerMix Hybrid Paddle Mixer / Dryers have the same mixing principle as our Horizontal PaddleMixers & Paddle Mixer / Dryers but add the ability for the operator to change agitation type with ease, switching from paddle to plow, or even segmented ribbon. Working Principle The PerMix Paddle Mixers consist of one electrical motor, one reduction gear, coupling, and shaft with an agitation that has paddle liked shaped attachments that collide with ingredients causing a multi-directional response that mixes products quickly. The shaft is sealed with bush & PTFE gland housing at both ends, with other options available. Materials are loaded from top side, and the discharge is located at the bottom side in the center or end, depending on production needs, either batch type or continuous. The discharge height can be adjusted as per requirement so that material gets discharged into the container below it without floating dust.

Schenck Process has finalized the previously announced sale of its Mining business (SP Mining) to the Swedish engineering group Sandvik AB. As one of the market leaders in screening, feeding, screening media and train loading solutions with a strong aftermarket business, SP Mining will not only complement Sandvik’s existing product offering but also benefit from a greater global reach. With the closing, the Mining business is to be integrated in the Stationary Crushing and Screening division of Sandvik’s Rock Processing Solutions (SRP) business area. “Sandvik AB is one of the world’s leading suppliers of equipment, services, and solutions in the area of rock and mineral processing. I am confident that SP Mining has great opportunities for future growth and furthering its potential within the new ownership structure. I would like to thank all the employees of the SP Mining business for their significant contribution to the Schenck Process Group over many years and wish them well and for continued success as part of Sandvik Rock Processing,” says Keith Cochrane, CEO of the Schenck Process Group.

Innovative recycling solutions result in high-quality recycled materials. Bezner’s recycling processes include (color) sorting, cleaning, shredding, granulating, melting and molding. Thanks to the growing demand for recycling, also the need for innovative recycling plants increases. In the years to come, waste will be a definition from the past. A significant number of recycled materials have become resources over the past decades, and the varieties continue to grow. High-quality materials Optimal recycling means selecting the ultimate installation design and applying high-quality materials, meeting your requirements. At Bezner, we have an in-house team of engineers for both mechanical and electrotechnical engineering. We are experienced in PLC programming and project management. Moreover, we have an in-house production facility. Plastic recycling machines and plants Apart from the argument of sustainability, given the oil price as a raw material for plastics, the reduced need for energy required to produce recycled plastics is another reason, economic this time, to use recyclables. The most common types of discarded plastics for a profitable

Join our one day short course to learn about the design, selection and operational issues in selecting a suitable Rotary Valve When faced with a choice of rotor and drive type, venting arrangements, bearing pattern, seal choice, clearances, cleaning features, construction materials etc, it can seem like a minefield when it comes to selecting a rotary valve. Taking place at the Wolfson Centre in Kent, UK, this one day course, delivered by expert Mike Bradley, is aimed to help delegates understand the reasons for the different options and how to select the correct specification. DMN Westinghouse have been invited to demonstrate rotary valve features, explaining what to look for during an inspection and providing general useful information to consider before purchasing such a piece of equipment. The course aims to guide delegates through the technical aspects of technology and provide an opportunity to discuss any relevant issues with the experts. It is recommended for engineers, system designers and maintenance personnel who have responsibility for sourcing, specifying and keeping
