News items December 2013

Make savings of over 30% using a turbine grinder with high quality abrasives Grinding as a geometrically undetermined machining process is widely employed, whether processing moulds or removing sprues in foundries, in machinery, tool or jig construction, in industrial steel construction or the automobile industry. Abrasives are used to process the surfaces of widely varied materials such as metal, wood or plastics or used to separate materials. Every grinding process is based on two components, whether manual or used in stationary applications, the grinder and the abrasive, and they must be carefully matched to obtain an optimal end result. Dr. Michal Hubálek, Head of Development at DEPRAG CZ a.s. and responsible for the pneumatic tool product area DEPRAG INDUSTRIAL gives us the inside story and reveals that it is this balance in particular which is indispensable for efficient and ergonomic processing within industry. When this balance is right, it can mean enormous savings in time and costs for many applications. “Our customer, a

Two years ago J-Tec opened its Asian headquarter in Bangkok, Thailand, and the investment is paying off. An exquisite example proving our success in Asia is a recent project we’ve realized for a well-known producer of cacao products. This client asked us to engineer and build a complete blending line in a production facility in Samutprakan, Thailand, near to Bangkok. J-Tec provided an innovative solution for their process challenges and got the project. The blending line mainly consists out of 4 different levels. On the upper level several receiving hoppers (on weighing cells, with integrated filters) are fed by different pneumatic conveying lines. •We’ve connected the first line to an existing dosing premix installation for the transportation of one specific premix. This line will be foreseen of product by additionally installed screw conveyors. In order to install these conveyors we needed to lift up the complete existing structure. •The second

9700 x 435 mm - s/s 316 - Atex Vertical screw conveyor, Klinkenberg, ss 316, centre-to-centre distance 9700 mm, 435 mm diameter, pitch 350 mm, shaft 324 mm, screw welded at both sides, 9.5 kW Bauer drive, 160 rpm, ATEX Product no.: 24.55A2353 Visit our website for a complete overview of our used machinery in stock. Surplus Select is partner for the fluids and solids processing industry in CSR/re-use.

“Measure twice – cut once” is a famous proverb describing the value of correct measurement. On its own, measuring is just a start; the values must be available and remain available. The first requirement is achieved by the display on the instrument. For the second requirement, PENKO has now enhanced its instruments with an internal memory which should store the weight information of the past 7 years for any typical production usage. When fully loaded a FIFO (first in, first out) procedure applies in batches of approximately 6% of the contents. The individual weighing information contains at a minimum the time, date, weight and identification. Depending on the application, additional information, up to an entire e-mark protocol, is available as an option. The importance is that the memory resides inside the instrument and its contents can be recalled, printed or transmitted to a supervisory system. This feature is important for applications such as continuous (beltweighers)

Inline measurement of residual oil content in compressed air According to ISO 8573-5: 2010 all hydrocarbons with 6 or more carbon atoms per molecule in compressed air need to be measured. The RCS Oil monitor is capable of measuring the residual oil with a minimum detection limit of 0,001mg/Nm3. The RCS Oil monitor is easy to install and optionally it is possible to expand the measurement range to CO2, CO, O2 and other possibilities up to ISO 8573-1. Because residual oil is an important measurement for the end quality of your produced product it is therefore the ideal monitor to install and monitor your compressed air quality. The complete set is delivered including a sample take-off point, a measurement system and a monitor system, providing you with a 4..20mA output or a RS485 digital link. The system only needs 230VAC, 50HZ power supply to start your measurement.

POWTECH looks forward to welcoming powder and bulk solids experts from all over the world The Exhibition Centre Nuremberg invites the industry to POWTECH again from 30 September to 2 October 2014. The 2013 event once again consolidated its position as World-Leading Trade Fair for Processing, Analysis and Handling of Powder and Bulk Solids. Every third exhibition visitor and every third exhibitor travelled to Nürnberg from abroad. Eight per cent more visitors is also a clear indication of the great response from all branches of industry. The initial figures for 2014 are promising as well. “POWTECH registered its best result so far in 2013 and this positive trend is continuing: We have already received more applications than at the same time before the last event,” reports Willy Viethen, Director Exhibitions POWTECH at NürnbergMesse. “Exhibitors who would like to be there in 2014 should contact us now to stake their claims to the desired stand positions.” Over 700 exhibitors from more than 20 countries are expected at POWTECH 2014. This makes

Cooler for TPU`s (thermoplastic polyurethanes) The company Dimple-t has recently delivered a new cooler to a German manufacturer of TPU`s (thermoplastic polyurethanes). Dimple-t Bulk Solids Cooler designs and supplies the so-called technology for the heating and cooling of `free-flowing` bulk solids. The Dimple-t Bulk Flow heat exchangers have conquered a unique place since early 1990 in the powder and bulk industry. It is one of the most important innovations in the field of heat treatment of bulk goods. The main reasons are: • compact construction • No cooling air so no air filtration • No odor emissions • Low operating costs • Extremely low maintenance The Dimple-t Bulk Solids Coolers are built in the Netherlands and tailored to each application.

Bladel, December 4, 2013 – KSE Process Technology launches special system for filling storage silos fully automatically. It uses containers, which results in low contamination transport. The ALFRA Silo Filling Unit (SFU) automatically fills a complete silo-deck using transport containers. The ALFRA SFU consists of a movable shuttle which moves both from left to right as from the back to the front in order to position above the right silo and to directly discharge into the right silo. Each container can transport up to 5,000 liters of raw materials or finished product. A Lid Lifter is one of the possibilities. This automatically takes the lid of the desired silo so the container can directly discharge into the silo. Also effective dust extraction and diverting retour air is also possible with this ingenious system. The ALFRA SFU is part of the Automatic Container Transport system. A proven technology for low contamination transport, using containers. It is

International standardisation of logistic processes VAS® the IT-Logistics solution of the Axians has recently won an international bid of the renown CEMEX Company. As a multinational enterprise in the building materials industry, CEMEX will use VAS® on the basis of a tailor-made template solution that is connected to the central ERP system and likewise will be rolled out to several CEMEX plants starting in Germany. The key reason for choosing VAS® has been the ability to cover all requirements towards an IT-Logistics solution, that have been described in the detailed systems specification provided by CEMEX. The very good reputation of VAS® as a market proven IT solution has been another crucial factor in favour of Axians. Following its development more than two decades ago, VAS® has been implemented in more than 160 plants across different industries worldwide. At CEMEX the implementation of a VAS® workshop is currently being prepared. As Mr. Claus Jordan, the Director of Business Development of Axians Industrial

Beltweighers are automatic devices, meant for the control, the regulation and totalising of continuous flows of bulk material. Frequently a part of the belt conveyor is weighed, giving the load per meter of the belt conveyor (m/l). A length measuring device establishes the displacement (l). Multiplying both values (l x m/l = m) gives the mass of the bulk material, transported over the weigher. Simultaneously the belt speed, the displacement per unit of time (l/t), is measured. This way the mass flow (m/l x l/t = m/t) can be calculated. During production the new instrument offers you a lot of information, such as the: 1. Total transported mass (m). 2. Mass flow (m/s). 3. Belt speed (l/t). 4. Load on the belt (m/l). Apart of presenting this information it is possible to switch off or control the supply of the belt conveyor. So the mass flow can be regulated and a pre-set amount of bulk material can be delivered. The instrument has 3 inputs, 4 outputs and

VEGABAR series 80 - fast track to the right pressure transmitter VEGA has completely re-engineered their VEGABAR pressure transmitter family as well simplifying them down to just three innovative model ranges. This means it is now much easier for the user to choose their perfect instrument from this full-range supplier of pressure technology. These three transmitter variants can solve practically any process pressure application. VEGABAR 82 is the all-rounder, with its ceramic measuring cell, which covers 60 to 70 % of all applications. If high temperature and chemical resistance is required, the VEGABAR 81 with a chemical seal assembly is the first choice. While VEGABAR 83 with its metallic measuring cell is recommended for very high pressures. The versatile VEGABAR 82 can cover the majority of all applications in the process industry. It features the proprietary, oil-free, high abrasion and overload resistant ceramic-capacitive CERTEC® measuring cell, and it boasts some new and extraordinary innovations. For example its sensitivity

ideal for wet and dry grinding, mechanical alloying and activation FRITSCH Planetary Mills classic line are the most effective laboratory mills for rapid loss-free ultra fine grinding down to colloidal fineness of hard to soft materials dry or in suspension. In addition to Comminution, you can also use them for mixing and homogenising of emulsions and pastes or for mechanical alloying and activation in materials research. Your advantages with FRITSCH Planetary Mills classic line - Fast grinding to below 1 μm - Up to 800 rpm - Safe clamping of the bowls with the Safe-Lock-System - Simple, ergonomic handling and easy cleaning - Grinding bowls and balls in 8 different materials to suit all needs and avoidance of contamination through abrasion – maximum protection against undesired contamination of the samples - Consistent reproducibility - Long, reliable service life even under continuous, heavy duty usage Ideal for Comminution of samples with a maximum feed particle size of up to 10 mm and a sample quantity of 0.5

or the first time ACHEMA 2015 is training the spotlight on three major themes: Process Analytical Te It goes without saying that other areas, from laboratory and analytical techniques to packaging machinery, from pumps, valves and fittings to the complete range of process engineering through to plant engineering and construction, will also come into their own. "By selecting three focal themes, we are doing justice to the immense spectrum of ACHEMA, while spotlighting developments that will radically transform the process industry", explains Dr. Thomas Scheuring, CEO of DECHEMA Ausstellungs-GmbH. Practically all areas of the process industry are affected by these focal themes. Process Analytical Technology (PAT) covers far more than "only" real-time measurement. PAT provides input for process optimisation and automation, without which the fundamental changes in process control, such as QBD (Quality by Design), would not be possible. Industrial Water Engineering is yet another topic at the top of the agenda worldwide. Whether it be zero

RUHRGETRIEBE celebrates its anniversary The specialist for worm geared motors from the Ruhr area looks back with pride on its company history and celebrates its sound business success. While it is above all the reliability, flexibility and competence of RUHRGETRIEBE that the customers value, Bernd Gildemeyer, the managing director, attributes the long-term success primarily to the extremely short delivery periods, which is an important selling point in the sector. In urgent cases, delivery of gears and motors can be carried out within only 24 hours. Due to its sustained service quality, RUHREGETRIEBE was last year selected as the best supplier by a renowned machinery manufacturer. The specialist for worm geared motors from the Ruhr area looks back with pride on its company history and celebrates its sound business success. However it is not just appreciation from outside that makes up a significant part of the corporate culture of the Mülheim company but also that from within. The liberal management

HAVER screening machines DMS and UMD. With more than 75 years of experience in the screening machine manufacture, mineral processing technology is not only a valuable part of the Haver & Boecker company history but also one of the technical cornerstones of the company. To this day, the name NIAGARA stands for quality, robustness, and performance. Three sites in Germany, Canada, and Brazil collaborated to form the Haver & Tyler Alliance for the sector of mineral processing technology. Haver & Tyler designs, produces, and provides support for premium stateof-the-art technologies in the field of screening, washing, and pelletising. For screening small production volumes and small single batches and for applications on laboratory and pilot plant scale, Haver & Boecker Wire Weaving Division offers two sleek screening machines. Both machines are available in one- and two-deck design. The HAVER DMS and the HAVER UMD are suitable for a large variety of bulk materials such as sand, gravel, ore, or coal, as

Zweibrücken, Germany (16 October 2013) – A new grinding system from Pallmann enables energy-efficient recycling of vulcanized rubber waste back into fine powder for direct reuse in rubber processing. A key feature of the Karakal is its ability to devulcanize the rubber as it pulverizes it, so that it can be used in place of virgin material. Karakal is a type of twin-roll mill that has been designed specifically for recycling waste from production of technical parts, as well as waste arising from retreading truck tyres. It accepts material that has been pre-cut to a particle size of 4 mm or less, and which is fed to it continuously by a series of screws positioned along the gap between the rollers. Pallmann has applied for several patents on technology incorporated into the equipment. “There is quite a lot of waste produced in the rubber processing sector, and we wanted to develop a cost-effective process that would enable it to be recycled back into production,”

please contact directly by phone or e-mail Mr. Krings, +49 (0) 22 36 - 39 90-18, or Engineer Mrs. Knaack, +49 (0) 22 36 - 39 90-28

according the Ploughshare priciple from Lödige GmbH Eskens Benelux BV introduces the Easy Clean Lödige mixer, as the name suggests, is easy to clean and especially as suitable where hygiene is important. The mixing principle is based on the well-known horizontal Lödige ploughshare mixer, however, the fixed drum has other dimensions and therefore the mixer is more narrow and higher. This allows to apply one large hatch at the front (inspection and cleaning) and one large hatch on the bottom (discharge of product) of the mixing drum. The mixer dissolves almost completely and is easily accessible for additional cleaning or inspection. In fact, the benefits of the horizontal and vertical principle are being combined. The mixer can be applied to batches of between 110 and 2000 liters (depending on the type), and is especially suitable for mixing dry materials and dry mixes. Tests can be done on a 400 liter model at Lödige in Paderborn (DE). For more information please contact Eskens Benelux BV and ask for Jack Winder.

Comsol, Inc., a leading global provider of engineering simulation software, today announced the release of COMSOL Multiphysics® 4.4, the latest version of its powerful platform for the modeling and simulation of electrical, mechanical, fluid, and chemical applications. New COMSOL Desktop Interface for Windows® Offers Enhanced User Experience A ribbon design has been introduced to the COMSOL Desktop® environment, when run on Windows® platforms, to provide easier navigation and an enhanced user experience. By grouping commands and displaying them as needed, the ribbon makes it easier to find and use the tools available to let you get your work done faster. The COMSOL Desktop brings several additional workflow improvements, such as a one-click select feature that enables faster selections in the graphics window. Using this feature, users can now hover over a boundary or domain to highlight it, and then select it with a single click. Another noteworthy feature

With our steadily increasing number of load cell models (over 60 families) and OIML approvals, it is our duty to keep our customers informed, therefore we would like to inform you about 3 new OIML Approvals: BM8H Stainless steel IP68 shear beam load cel Hermetically sealed Suitable for hopper, platform and pallet scales High accuracy Current calibrated (sc‐option) OIML certificate for full capacity range: 500 kg - 5t L6P Low profile, parallel beam construction Anodized aluminum alloy IP65 sealed Easy installation OIML certificate for capacities: 22kg, 45kg, 100kg L6P1 Low profile Anodized aluminum alloy IP65 OIML certificate for capacity: 7.5kg

The 2013 Nobel Peace Prize was awarded to the Organization for the Prohibition of Chemical Weapons (OPCW), for its efforts in safely dismantling one class of destructive weaponry. In order to do their jobs safely, the OPCW requires the most reliable equipment. That’s why it purchased six sets of mobile scales from Penko several years ago, including three standing and three hanging constructions that have various capacities. The dependable gear is the right size to be transported by truck or by plane, and stands up to the harsh conditions where the OPCW works. So, in a small way, Penko has helped the mission of the Nobel-winning organization.

7 new dealers for PENKO Penko Engineering, Ede, the Netherlands, sees exports markets as being the primary source of future growth for the company. In recent months it has appointed no fewer than seven new distributors around the world, namely: Beijing Avenue International Trade Co. Ltd, Beijing (China); Goldbell Weigh Systems Pte Ltd (Singapore); Interprocess, Warsaw (Poland); Maxpac bvba, Temse (Belgium); Maxwell Industries Srl, Crema (Italy); Process Automation Ltd, Dhaka (Bangladesh); and Scanvaegt AB, Gӧteborg (Sweden). Each of these enterprises welcomes the opportunity to serve its local customers with high-grade instrumentation.

2014 Calendar out now These courses cover solids handling issues for the food and drink industry, chemicals, minerals, aggregates, renewable energy, recycling, pet foods, pharmaceuticals - in fact, any industry where powders and bulk solids are processed. The range of courses covers pneumatic conveying, storage and discharge, general and specific materials handling, dust explosions as well as the deblending of materials - so there is something to suit all situations. Some include practical sessions in our laboratories. Discounts apply for multiple bookings.
