News items April 2007

Safe liquid transfer - wherever I will! The battery-powered universal pump, AkkuPump from Bürkle, now with even simpler handling, is in-tended for applications in which small amounts of liquid are to be filled off. Safe, strength-saving, rapid and accurate dosage – even into small containers with narrow openings. It is quiet-running and the pumping capacity can be set steplessly from a few drops up to 10 liters per minute. Full concentration on the container means that liquids can be safely and comfortably filled off without any effort. The lightweight turns the scales at only 990 g which means that it is well-balanced and not top-heavy like conventional barrel pumps. The AkkuPump parts coming into contact with the medium are made from polypropylene and Hastelloy C, both of which are outstanding materials with a very good chemical resistance. This is why the Akku-Pump can be used with a wide range of liquids, in-cluding such aggressive media as acids, alkalis and cleansing agents without any problems. The

Collect samples instead of time-consuming cleaning - with the disposable samplers from Bürkle In many applications rapid and absolutely con-tamination-free sampling is essential. In such cases the disposable DispoSampler is the right tool for the job. The qualitatively correct cleaning of a sampler is very difficult, which means that it is very time-consuming and therefore expensive. The clean-ing procedure is normally also complicated, particularly with greasy, strongly adhesive or toxic substances. For such problems Bürkle GmbH, supplier of the widest range of manual samplers in Europe, can offer suitable solutions. The disposable DispoSamplers from Bürkle are made from environmentally-compatible PE or PP and can be recycled without any problems. Indi-vidually packed in plastic film under dust-free clean room conditions, they are always absolutely clean and ready for immediate use. There are five different types: for liquids, bulk goods and viscous media. The disposable sam-plers are available in 2 different lengths and have a diameter of 25mm. On

With compressed air through thick and thin Previously bulk goods with a high density could only be sampled by applying great force while taking a long time. The pneumatic sledge hammer of the PowerSampler makes taking such samples child’s play, even from baked sample material at a depth of up to 3 m. It buries itself, just like a compressed air sledge hammer, deep in the sample. The sample continually flows through the patented chamber lock at the end of the lance while it is being driven in. When the target has been reached the chamber closure seals the collection tube automatically. The collection lance can be removed from the pneu-matic drive unit with a single action. The field of application for the PowerSampler is with cement and wet sand as well as flour, plastic granules or other loose bulk goods. Ideal for silo vehicles, mix-ing containers, big-bags in the building materials, chemical, drugs and food and semi-luxury industries. Depending on the sampling depth the collection lance can be

The Blow Thru Sieve™ has been designed and certified for use in pneumatic conveying lines, enabling processors to screen and transport material simultaneously. Its development has come about as a result of a need to check-screen powder during dilute-phase positive pressure pneumatic conveying. The Blow Thru Sieve ensures that ingredients coming in or final products leaving a plant are free from contamination. By combining screening and transportation the sieve eliminates double handling, increasing efficiency. Its unique design allows the sieve to achieve phenomenal throughput rates, enabling processors to screen material as they load or unload tankers or silos without slowing the process.

Screen Frames with pre-tensioned sieve cloth and screens with hook strips Quality of sieving material, screen analysis, type of screen as well as conditions and aims of working process are decisive for the choice of the suitable screen lining. For more than 100 years THE HAVER SCREENING GROUP has been producing tailor-made screen linings for every common screen type: • from woven wire screens, self-cleaning harp screens, perforated plates up to rubber screens and polyurethane systems • single or multiple layer screens with hook strips for end or side tensioning, reinforced by polyurethane strips or PE supporting elements (optional), protection of longitudinal sides in different executions (optional) • screen frames with pre-tensioned sieve cloth for round or rectangular screens - frames made of steel or stainless steel profiles • tensioning service, i.e. re-screening of used or damaged frames up to a diameter of 2,650 mm or a dimension of 2,650 x 3,100 mm for rectangular frames. The quality of a screen lining does not only

Process control engineering specialized for the production of animal feed and grain processing Complete automation solutions for the animal feed production industry is one of the central competence areas of ProLeiT AG with headquarters in Herzogenaurach, Germany. As a complete provider of PCS, batch and MES solutions, ProLeiT so guarantees not only the horizontal integration, from the arrival of the raw material through to the delivery of the finished product, but also the vertical integration, from the actuator/sensor through to the ERP system. ProLeiT presents with a concrete example an automation solution for the mixed feed industry based on Plant Batch iT as recipe control system. This exhibit covers the complete process chain with raw material acceptance, storage, proportioning, mixing and processing of the feed, and the packaging and loading. The materials management covers the goods acceptance, the storage management of the raw materials, the process materials and the operating materials, the declaration of the finished products, the picking and

Schenck Process is extending its core competency in the 500 g/hr to 150 kg/hr range. The PureFeed® AP auger feeder satisfies the stringent requirements of hygienic design. The feed system is suitable for gravimetric or volumetric feeding of powders and granulates. It is used in the pharmaceuticals, nutraceuticals and cosmetics industries for the feeding of mills, mixers, extruders and compounders. Given the external non-intrusive agitation of its flexible feed hopper, the PureFeed® AP discharges the product gently, ensuring optimum bulk material flow. The penetration depth and frequency of the external agitation can be conveniently set to product specific requirements. The auger feeder is available in various geometries which can be easily adjusted to the application and also handle challenging feeding tasks. Pulsation can be reduced at low delivery rates thanks to the innovative “Wire Helix” auger geometry (patent pending). Feed hoppers of various sizes

Schenck Process is breaking into new ground in applications for feeding very small volumes of bulk material. Its latest feed system, PureFeed® DP, is particularly well suited to continuous, gravimetric feeding of tiny volumes of powder with manual refills. The innovative technology deployed in the PureFeed® DP allows for high-accuracy feeding of small volumes from between 20 g/hr to 2 kg/hr using a speed-controlled, ceramic feed disc which rotates at the base of a cylindrical hopper and acts as the discharge mechanism. This disc separates the material supply from the outlet opening, avoids uncontrolled outflow and prevents the bulk material which is already contained within the feeder from compacting. The moving parts operate at low levels of interfering force. The pulsation-free feed principle and the wide adjustment range allow for precise, gravimetric feeding, especially of tiny volumes, without the discharge mechanism having to be replaced. A patent for

One of the most innovative products presented at Powtech and TechnoPharm 2007 in Nürnberg came from Schenck Process. This was the decision of the panel of jurors from Process magazine and its sister publication Schüttgut, who presented the Innovation Award for the first time at this event. 50 companies nominated their latest products for the award, five of which were chosen to receive the honour from the two trade journals for chemical and pharmaceutical engineering. To convince the jury the winning products not only had to be innovative but cost-effective for the user. Schenck Process won the special award in the Apparatus Construction and Process Components category for its PureFeed® DP system. This feed system is particularly suitable for the continuous gravimetric feeding of very small quantities of powder. The system allows for precise feeding of small volumes while also offering user-friendly maintenance, cleaning and disassembly. The awards were

This simple and easy to use sieve removes contamination from your powders. It improves the quality of your final products and safeguards your reputation. The Mini Sifter is perfect for sieving small batches of products in all industries e.g. bakeries, laboratories, start up companies and pilot plants. It improves the quality of your products, just fit a mesh size suitable for your powder and it will remove any oversized contamination. Simply unlock two clamps to release the product contact parts that can be cleaned in less than 5 minutes. This eliminates the risk of cross contamination between batches. The unit can be simply transported for use in different areas by one person. Very quiet operation, typically less than 65 dBA.

Dispersing and wet fine grinding in small scale with the new DYNO-MILL RESEARCH LAB WAB succeeded in developing of a new small agitator bead mill with the new DYNO-MILL RESEARCH LAB which permits - to disperse and to grind liquid and viscous products down to the nano range - to produce small product batch sizes > 100ml in a continuous or in a circulation process - to grind products metal-free with the ceramic execution made of zirconia / silicon carbide - to dismantle the complete, closed grinding unit and to clean and to sterilize it separately - to use smallest grinding media size from 0.05 - 1.0mm Even in the early stages of the product development it is possible with this new DYNO-MILL RESEARCH LAB to receive a clear statement about the achievements of product quality i.e. particle size distribution, grain size, viscosity etc.

The LMC-F-0050-1 is an opto-electronic level measuring module for industrial application like tank level measurement. The module operates on basis of non-contact comparative phase measurement with amplitude modulation. The laser diode (cw operation) has a divergence of 0.6 mrad for measurement with pinpoint accuracy. The measured result is available on the RS 232 / RS 422 data interface. Optional also Profibus, Canopen, Ethernet or WLan Interface are available. A digital switching output (second as option), an analogue 4..20mA output and optional a Profibus output is also available. The sensor alignment can be easily achieved with the help of the red pilot laser. The Measuring range is on any natural surface between 0,2 to 30m, for 30 to 100m it depends on the surface reflectivity coefficient.

SWECO, the worldwide producer of separators for dry and wet products, invites you to visit its booth at : Easy Fairs SOLIDS (Antwerpen, Belgium) on 5-7/06/2007: Hall 4, Stand N° 4411 PulPaper (Helsinki, Finland) on 5-7/06/2007: Hall 6 Stand N° b21 Industrial Maintenance (Rotterdam, The Netherlands) on 5-7/06/2007: Stand N° 538 Polagra-Tech (Poznán, Poland) on 15-19/09/2007. Ouest Agro (Angers, France) on 02-04/10/2007. FoodPharmaTech (Herning, Denmark) on 13-15/11/2007: Hall J, Stand N° 7206 Pollutec (Paris, France) on 27-30/11/2007. We will exhibit namely our new Gyramax Gyratory Sifter. It maximizes productivity, provides maximum vibration control, and enables maximum recovery of clean, acceptable product. The GyraMax™ is specially designed for high capacity dry screening up to 6,6 M² of screen area per deck, it provides up to 5 decks of separation, high temperature applications are possible up to 120°C.

Free subscription for professional visitors On 18 and 19th of April 2007, the first edition of easyFairs FLUIDS takes place in the Ahoy Rotterdam. easyFairs FLUIDS is a two-day professional trade show for the handling, processing and storage of fluids and gases. The trade show covers pumps, gaskets/seals, filters, valves, pipes, tubes, hoses and fittings, drives, controls and frequency converters, fluids and vacuum technology, filtration and separation, quality control and test equipment and process technology. About 90 companies will present their products and services. An overview of the exhibitor list, the floorplan, exhibitor news and an overview of the learnShops programme, can be found on the website. learnShops are case studies, presented by an exhibitor together with its customer about the challenges in the industry and the ways to solve these. The show is for professionals only, and is collocated with easyFairs INDUSTRIE & MILIEU, the platform for environmental equipment and techniques. Subscription

Are you looking for new equipment and systems for your plant? Visit victam international 2007 and you will probably find the solution. 250 of the world’s leading companies that supply the animal feed, aquafeed, petfood, flour milling and grain processing industries as well as biomass pelleting technology will be exhibiting at this important trade show. To register FREE as a visitor, conference information, hotel & travel details, opening hours, and a full exhibitor list, see more info.

Inductive Positioning System F110 allows more flexibility The inductive Positioning System F110 makes modern palletizers more flexible and better prepared for the future. Thanks to the contact-free operation of the Positioning System F110, readjusting the palletizers to new packages now only takes a fraction of the time needed before. Due to the monitoring of the whole traverse path, every packaging format or stack pattern can be adjusted and new formats can be easily accommodated in the future. Palletizers constantly have to adapt to new kinds of package forms, sizes and patterns, with ever-higher processing speeds. Increasingly, pallets have to cope with different package layers, requiring high machine flexibility. When changing to a new packaging format, the sidesliders on a palletizer have to be readjusted to ensure the layers are centered correctly on the pallet. Previously, the hydraulic cylinders of the side-sliders had to be adjusted with the help of magnetic cylinder sensors and often only a limited number
