News items February 2007

S+S provides comprehensive solutions for bulk materials inspection S+S Separation and Sorting Technology is inviting visitors to POWTECH 2007 (Hall 7, Stand 7-420) to take a closer look at its range of IFS compliant, "Hygienic Design” metal separators which specifically designed for handling bulk materials in the food industry. Metal separators from the same RAPID 5000 range have recently been installed throughout the new production facility of Austrian flavourings and additives manufacturer Almi by the engineering company Johann Daxner GmbH. S+S` RAPID 5000 metal separators detect and remove magnetic and non-magnetic metal contaminants from free-falling bulk materials. Contaminants are removed by means of a fast-reacting reject flap (“Quick Flap System”) with minimal loss of good material. The circular design of the reject mechanism manufactured from stainless steel eliminates sharp edges and crevices, preventing product build-up and blockages in the pipeline, even with non free-flowing bulk materials, thereby avoiding

Process Microwave Moisture Measuring Device MOIST T is a microwave based transmission sensor system for contactless moisture detection on floating and planar moving webs. Special fields of application for the sensor system are contactless moisture measurements of building materials, mineral fibrous insulating material and bulk goods. Moisture detection of grains and of agricultural materials can be special fields of application, too as well as the conceivable usage for the food industry. Customer specific calibrations and adaptions can be manufactured for new applications and materials. The microwave probe system is a smart measuring system with an on board microcontroller. It is used in combination with the control unit MOIST CONTROL 100. Transmitter and receiver of MOIST T are mounted with a special clamp and will be protected by a special dielectric cover. The MOIST T process sensor system provides a material specific moisture range from 0 to 50% (wet base) at a material thickness of 500 mm. It measures

with a sensational price performance ratio UWT is now offering a completely revised VN 4000 series from the reknowned Vibranivo® product line. An improved manufacturing process ensures that the series will be available on the market place at a very attractive price whilst still offering UWT proven quality. Certification for hazardous areas (dust) comply with European and US standards. The extension, the fork and the process connection of the VN4020 are cast in stainless steel in one piece. The VN4020 model with its compact design and short fork is particularly suitable for installations where there is limited space (e.g. in down pipes). The VN4030 is available with a tube extension of up to 4 metres, according to the specific customer requirements. Through optimisation of the vibrating behaviour of the VN4000 series, the chance of a material build-up between the forks has been further diminished. The vibration sensors have been designed for a wide range of applications in many types of fine or large

RETSCH present their new product generation for neutral-to-analysis size reduction and particle characterization of solids at this year’s POWTECH in Nuremberg: • The optical particle measurement system CAMSIZER® for the precise and efficient particle analysis with increased resolution in the micron range • The Planetary Ball Mill PM 400 with stronger performance and comfortable 1-button operation • The Mortar Grinder RM 200, the high-tech successor of the classic “Retsch Mill” • The Vibratory Disc Mill RS 200 which guarantees reproducible results with optimized grinding performance • The hydraulic Pellet Press PP 200 with a pressure of 40 tons • And the new Rapid Dryer TG 200 which dries the sample material without localized overheating and provides a loose, thoroughly mixed product. The instruments were not only completely redesigned. Proven components of other mills, such as the 1-button operation with graphic display have now also

Booth on powtech 2007 from 27-29.03.2007 in Nürnberg visit us on the POWTECH of 27. - to 29.03.2007 in Nürnberg booth 7 / 553 Experience the live new products of the OPDWIN MATRIX! Topic: Optimization of the business and production processes for weighing and Dosing plants/ costs lowers - productivity increase! Modernizations or new installations! With 4 decades PROCEDURE AND CONTROL KNOW - How and YOUR KNOWLEDGE together the optimal parameters define. And then? Arrange the modules from the OPDWIN MATRIX low-priced for your requirements! Interest? http://www.opdenhoff.de/Pyramide/index.htm Further information and inquiries to fair tickets find you on our Internet sides. Further product groups from the OPDWIN MATRIX: OPDWIN© video http://www.opdenhoff.de/HTMLen/bewegtebilder.htm OPDSpeedUp© http://www.opdenhoff.de/HTMLen/bewegtebilder.htm OPDWIN Control© http://www.opdenhoff.de/HTMLen/control.htm OPDWIN Visu© http://www.opdwin.de/HTMLen/prozess.htm

A recent upgrade at the Obourg (Belgium) facility of Holcim, one of the world’s leading cement producers, has seen the production plant move to an automated laboratory for the routine analysis of cement composition and particle size. The system of choice for particle characterization was the Insitec ALISS from Malvern Instruments, which is now installed and is delivering routine process analysis with negligible manual input. The instrument was purchased by Holcim France Benelux1 as part of an agreement with Malvern to supply two Insitec ALISS systems for use at sites in Belgium and six Insitec on-line systems for facilities in France. At Holcim’s Obourg plant, all aspects of particle size measurement are fully automated. At the heart of the automated laboratory is a robot which receives both clinker and cement samples, prepares them for analysis and transports them to the appropriate analyzer. The Insitec ALISS requires no sample preparation so the robot simply

In 2004 VEGA Grieshaber introduced VEGAPULS 68, the first radar sensor specially developed for level measurement of bulk solids. With a measuring range up to 70 m and wide temperature and pressure ranges (200 °C and 40 bar), it represented a real novelty in level measurement of bulk solids and has since established itself very well on the market. To close the remaining gap of standard applications with smaller measuring ranges and lower process demands, an additional instrument version, VEGAPULS 67, will be introduced at POWTECH 2007. The new VEGAPULS 67 finds application in areas where, for reasons of economy, ultrasonic instruments or capacitive probes were used until now. A new, innovative antenna system of plastic makes it possible to offer VEGAPULS 67 at a considerably lower price. Yet the tried-and-true pulse radar technology, with its high signal sensitivity and echo evaluation specially optimised for bulk solids, remains the heart of the instrument. The

VEGAVIB and VEGAWAVE are vibrating level switches for level detection of bulk solids. VEGAVIB operates with a vibrating rod, VEGAWAVE with a tuning fork. The central component of both sensors is the piezo-driven vibrating element. This measuring technique does not require adjustment with medium and offers comprehensive fault monitoring up to SIL 2 (according to IEC 61508). These sensors are also available for dust Ex areas of zone 20. With its tuning fork, VEGAWAVE is the ideal solution for applications in powdery media and bulk solids of small grain size. Its robust configuration also allows applications as minimum level detection in heavy bulk solids such as cement or flour. Even in case of buildup, the VEGAWAVE sensors demonstrate their advantages over the vibrating rod. VEGAWAVE works in bulk solids from a density of 0.008 g/cm³ (8 g/l). VEGAVIB, on the other hand, is perfect for applications in large-grained substances due to the vibrating rod that

Small iron parts damage the rollers during the production process A problem in the domain of carbon black processing was a good reason for Goudsmit Magnetic Systems BV, which is established in Waalre, to develop a new design of the rotating clean-flow magnet. The leading company in the Netherlands in the field of carbon black processing wanted to separate the pearl-shaped carbon black stream from iron parts. The company outlined three problem situations which could not be solved by using a normal clean-flow magnet. The renewed design provided a solution. This design can be seen in the Powtech 2007 in Nürnberg (hall 9, booth 316). Situation Carbon black is a very dry product which is not flowing well and it is used in sealing and insulation materials as well as in car tires. Naturally iron parts in the seals are not wanted and must be removed. A few problems arise when using a normal clean-flow magnet. The pellets stuck to the bars or pulverised on the bars, which was due to the height of fall. For quality control purposes it

PTS technology Based on the PTS-Technology the Batchmixer (patent pending) was developed by Dec to mix active substances in a self-contained system. This system allows contamination free and product friendly mixing (no rotating mechanical parts) in batch mode under inert conditions. This offers the possibility to mix hygroscopic, oxygen sensitive or explosive powders. Various powders can be mixed with large differences in mixing ratio (1/10.000) at a low mixing time. A high ratio of no-load to full-load can be realized (High turn down ratio < 10% - 100%). The Batchmixer is practically maintenance free and can be cleaned in place (CIP). This technology is able to be integrated easily into all kinds of production lines, because powders are transferred, mixed and discharged in an automatic and closed way. Visit us at Powtech, hall 9, booth 425.

Drum Containment System An innovative technology for emptying drums Dec developed the innovative DCS Inverter (patent pending), based on the DCS-Technology (Drum Containment System, patented). The DCS is the perfect solution for contamination free evacuation of drums of various sizes equipped with double inliners. It provides optimal protection of the operator and product at high containment-levels (<1g/m3). The DCS Inverter is the innovative development of the DCS system and offers a lot of advantages. The outstanding innovation compared to the DCS is the possibility of inverting the drum. This development allows faster emptying of the drums (higher throughput) and saves a lot of time. Lumpy and agglomerated materials can be discharged easily due to a lump breaker integrated in the suction hopper. The DCS Inverter works together in combination with the PTS (Powder Transfer System). The drums are emptied by means of inverting the drum and the powder in turn transferred by

XPT-C with flow through cell, XPT-P with probe XPT-C: particle suspension is pumped through the flow-through cell on the outside of the unit - either directly from process or from a sample. XPT-P: the probe is measuring directly in process. The integrated CCD camera continuously takes images which are analysed in real time and results displayed and saved. Different systems – one software: The XPT software is used for all types of XPT units for automatic online image acquisition, particle size and shape analysis, trend display, storage of analysis methods, automatic saving of images depending on predefined criteria and process integration (external start/stop of measurements, analog and digital outputs). Special Applications: + Particles, droplets or bubbles in liquid + Measurement of particle size, shape, count/concentration and shape + High pressure / high temperature possible + Cutting oil online quality control + Counting product beads into vials + Detection of micrometer particles in highly

The Powder Characterization Instrument With the REVOLUTION Powder Analyzer you can determine your powder`s process behavior in a simulated process environment. You can perform all of these performance behavior tests: Flowability, Granulation, Caking and Fluidization with one simple to use PowderAnalyzer - The REVOLUTION. The working principle: The REVOLUTION Powder Analyzer has a rotating drum that measures the flow properties of granular and fluidized materials. The operator fills the rotating drum with 125 cc of powder. A stepper motor rotates the drum at a set rate. A digital camera takes digital images of the powder during the rotation process. The images are automatically analysed and various parameters representing the powder`s quality and process ability are calculated. The user can perform the following three types of analysis: Flowability, Granulation, Caking and Fluidization. 3 application examples: * Dairy creamer must pour smoothly and consistently from its packaging. The dairy

Microwave-Level Guard MOIST xLEVEL is an intelligent microwave sensing head for level monitoring in process. The microwave technique the device is based on has many advantages when compared to other customary methods of level metering. A high field range and the big sensing distance are only two representing advantages MOIST xLEVEL provides. According to the microwave technique being used, the probe works highly sensitive. In addition to the advantages described above the probe will not be influenced by dust or foam. The sensor is a smart sensor. MOIST xLEVEL is a compact and robust sensing head predominantly used for controlling levels in solids and bulk goods, where high penetration depths are desired. As a consequence the probe can be used in applications capacitive sensors cannot cope with in terms of reliable switching. An optimisation of the switchpoint is possible on-site due to the serial interface that allows the probe to get programmed within the field. MOIST xLEVEL is mounted

This year Kramer & Duyvis will be present at the Empack exhibition, Brabanthallen Den Bosch The Netherlands. April 4 and 5 2007. There shall be showed the Sefix conveyor with double drive. The Sefix conveyor is a unique modular transport system. The system exists from aluminium profiles with low friction plastic covers where plastic Sefix links slide across. The unique characteristic of the, complete patented, SefixConveyor is that the Sefix links are pushing operated. This in contrast to a chain where the links pull each other. Therefore there is no chance on break and strengths which can be transmitted a lot of times higher than standard chain conveyors. You will find the SefixConveyor at Stand No. D7007. Our product specialist are happy to welcome you.

Rotex Europe conference participation The global provider of process equipment, ROTEX, will be present at Nitrogen & Syngas International Conference, in Bahrain, between 25-28 Feb 2007. Mr. Mike Birt, our Product Manager, will give a presentation on 28th February, at 11.35h, entitled “Meeting the demands and challenges of screening on the World’s largest Urea Processing Plants”. As it is significantly involved in the fertilizer industry and has many solutions for the screening process in this sector, Rotex , through its Product Manager, will develop some very important issues in Urea Processing with particular attention to be given to: • Granulator Extraction System – to control material discharge to optimise flow and bed depth within the granulator for optimum performance. Equipment supply flapper valve, electro-magnetic feeder and safety screen. • Feed/Screen System -using a feeder distribution arrangement with Rotex Screeners for the accurate separation of Urea Granules • Rotex

Ten silo`s of 640 m3 each for rent in Terneuzen The ( concrete) silo`s are located on the quai in the harbour of Terneuzen, and are suitable for storage of powders like cement, kaolin, fly ash etc. The silo`s can be filled directly by a self-unloading barge or with TPT`s pneumatic loading / unloading installation, while product discharge can go via bulktrucks. Please contact TPT fot futher information.

Dust accumulation and work regulations concerning explosion safety and cleaning on the work floor often present a major challenge for companies. Last year a world player in the petrochemical industry was confronted with these issues, and started looking for a solution that could be implemented as a central vacuum cleaning system, as well as a pneumatic conveying system for the removal of residue from several storage facilities. J-TEC analyzed the problem and found the solution within its own standard production supply. The central vacuum cleaning unit was designed with J-TEC’s standard separator in mind. This separator was then equipped with all the required safety precautions, in accordance with Atex guidelines. The product to be conveyed has a minimum ignition energy of 1 millijoule. The installation enables the operator to do the vacuum cleaning at different points in an area with several polyolefin compound production lines. This cleaning process takes place

Beijings National and Olympic Stadium During construction, the crisscrossed interwoven steel roof construction of the bird’s nest roof was supported by 78 temporary steel columns. For additional stability, the huge ‘twigs’ were welded onto the supports. After completion of the bird’s nest construction the ‘twigs’ had to be cut off the support piers, before dismantling of the piers could start. Basically the disconnecting and dismantling process of the temporary supports comes down to synchronically and fully controlled lifting the structure of its supports, cutting the welds, followed by controlled and synchronized stage-lowering to allow the removal of the 50mm think leveling plates that were used during construction. Enerpac was granted the contract to perform the stage lifting and lowering of the roof. The design of the bird’s nest is based on three construction circles; an outer circle, a central circle and an inner circle. Each circle has supporting piers. For load, control and accuracy

As well as exhibiting the latest additions to the company’s extensive range of particle analysis, rheology and analytical imaging systems for materials characterization, Malvern Instruments will highlight a new consultancy service at Powtech 2007 (27-29 March 07; N&#369;rnberg, Germany). In addition, members of the Malvern team will make presentations at the associated Partec 2007 congress. In 2006, Malvern added powerful NIR (near infrared) chemical imaging technology to its Analytical Imaging portfolio of systems for materials characterization. These will make their Powtech debut in 2007, alongside the company’s established Morphologi G2 morphological imaging system. Both have particular application in pharmaceutical formulation and manufacture. A new consultancy service from Malvern has been developed to meet the requirements of the process industries, helping manufacturers to better understand and optimize particulate processing operations. It also

Laboratory Moisture Measuring Instrument MOIST xLAB is a ruggedised laboratory moisture meter on a microwave basis for reproducible offline measurements close to the production process. The portable, compact and robust instrument can be used for fast moisture measurements in solids, bulk goods and planar materials. One reading takes only one second. The measurement detects moisture at the surface and in the core of the sample. Customer specific material calibrations allow exact and reproducible measurements. MOIST xLAB is an intelligent device with an integrated microcontroller. In simple applications it can be used in a stand-alone mode. For more complex moisture measuring tasks, especially for time dependent monitoring of moisture or better documentation of measurements, the combination with the software MOIST LAB TERMINAL is recommended. Special fields of application for the device are moisture measurements in bulk goods, grains and agricultural materials as well as the conceivable usage for the food

This year, sweco will exhibit at the following Trade Fairs: 1) BIOGAS – Leipzig, Germany 31/0 - 02/02/2007 (Hall 2 Stand N° 406) 2) UKRPRODMASH – Kiev, Ukraine 13-15/02/2007 (Stand A21) 3) CFIA – Rennes, France 06-08/03/2007 (Hall 5 Stand N° F20) 4) POWTECH – Nürnberg, Germany 27-29/03/2007 (Hall 9 Stand N° 561) 5) Easy Fairs SOLIDS – Antwerpen, Belgium 5-7/06/2007 (Hall 4 – Stand N° 4411) 6) PulPaper – Helsinki, Finland 5-7/06/2007 (Hall 6 Stand N° b21) 7) POLAGRA-FOOD – Poznán, Poland 15-19/09/2007 8) OUEST AGRO – Angers, France 02-04/10/2007 9) FOODTECH SCANDINAVIA – Herning, Denmark 13-15/11/2007 10) POLLUTEC – Paris, France 27-30/11/2007

Booth #2010 Malvern Instruments, who last year extended its areas of activity by adding powerful NIR (near infrared) chemical imaging technology to its Analytical Imaging portfolio of systems for materials characterization, will launch new products at Pittcon 2007 in two key application areas. The first of these is a new addition to the company’s Near Infrared chemical imaging (NIRCI) product line, which will add additional capability in terms of speed of data acquisition and increased sensitivity. Also launched at Pittcon 2007 is a new option for Malvern’s Zetasizer Nano system. The new flow mode option enables the coupling of dynamic light scattering with size exclusion chromatography, conferring the ability to perform Absolute Size Exclusion Chromatography (ASEC). This allows protein size to be measured directly rather than relying on column calibration and means that molecular weight standards are no longer required to identify oligomeric species or

POWTECH The patented ProClean Liner Filling Head (LBK) of Hecht Anlagenbau GmbH allows the contamination-free filling of any type of containers. The product outlet and a side hand-access opening are closed towards the environment by a protective liner. For connecting a container, a liner is fixed with a rubber ring and secured with a counter ring. The operator removes the contaminated protective liners and the rubber rings of the previous filling process by using a liner tube at the hand-access opening. Upon filling the container, the liner is closed and separated underneath the counter ring with the effect that both the filled sack and the filling head are sealed against the environment. The liner tube enveloping the contaminated protective liners and rubber rings is disposed of. This filling system is working extremely well for FIBCs with inliner. The product is closed towards the environment at any time. Thus the ProClean LBK meets highest demands on human- and
