News items June 2005

To avoid streamers and for abrassive products Pelletron to Unveil Revolutionary New and patented Pellbow™ Pelletron, the Lancaster, PA-based bulk material handling company, will showcase a unique and patented conveying pipeline elbow that is tradenamed the Pellbow™. It is especially designed to minimize damage caused when solid particles are injected into a high velocity conveying system — the higher the velocity, the more dust and streamers are formed in elbows. Design Principle: The Pelletron design creates a streamlined pocket shape by enlarging the bend at the incoming point in order to produce a soft layer of pellets just before they impact the angular target zone. The resulting soft layer of pellets will deflect incoming pellets toward the outlet, thus minimizing product degradation and air pressure resistance. Advantages of the new Pellbow design include: Elimination of streamers; reduction of dust; handling of abrasive products and the gentle changing of direction in the piping system.

Dust and streamer removal in one machine Pelletron Introduces Redesigned DeDuster With 30 000 kg/h Capacity Pelletron Corporation, the pioneer in DeDusting technology, has redesigned its Pelletron P-600 DeDuster, a dust and streamer contaminant removal system designed for large applications in plastics manufacturing and other chemical industries. The new P-600 has the capacity to dedust up to 30 000 kg of material per hour and complete the max size series of DeDusters. The new P-600 features a split design, which creates a low profile for easier retrofitting in limited headroom application facilities. The split design means the P-600 has four, larger air wash decks, two patented Venturi chambers, and two patented flux field generators. The dual Venturi chambers and larger air-wash decks provide more precise control of the airflow, allowing for a wider variation of flow rates, resulting in quicker, more efficient DeDusting. Design principle: In the split design of the P-600, dust and streamer contaminated

with Horn and Multi-tone Siren WERMA is to extend the successful product group 420 by the addition of signal combinations. An optical as well as an extremely loud audible signal can now be combined neatly using a diameter of only 90mm. The signals can be triggered variably i.e. both the light and the audible ele-ment can activated in whatever sequence necessary, or simultaneously. In addition to the proven base mounting bracket mounting is also available. The base will be in an attractive grey. The optical signal component is available as LED perma-nent light or as a flashing light. The audible component is available as a buzzer, a multi-tone siren or a horn. The buzzer has a continuous or pulse tone. The multi-tone siren is adjustable in eight tones, and the volume can be ad-justed continuously up to 100dB. The horn version is a high-tech product and has a life du-ration of up to 50,000 hours, 10 times higher than that of a conventional horn. The volume can be adjusted likewise.

The Austrian plant engineering and construction company AMMAG is specialised on spray granulation / coating and bulk material handling (conveying, silos, big bags, dosing and weighing). Own test plants in lab and pilot scale are used to test all process steps and to develop new products together with the customers. Toll manufacturing of these joint developments is possible, too. AMMAG has developed and constructed a novel laborscale spraygranulator A-WT 25. Air supply/-heating station and process-modul are designed in sparate units. Favorable design and a well elaborated plant concept, makes the A-WT 25 multi-purpose and in conformity with ATEX. The granulator can be operated in top - or bottom spray mode with different positions for the nozzels. An up-to-date control- and visualization system and changeable granulation-baskets for different batch-sizes give additional advantages to the user. Thus, first feasibility studies and small productions in the field

Hammermill with hygienic design The hammermill MFH-6 from Frewitt allows crushing and milling of hard, crystalline or fibrous products in the pharmaceutical and chemical industry. The hygienic design of the housing prevents product accumulations and permits a fast and simple access for cleaning the processing area, The absolutely tight design of the dosing equipment with paddle wheel ensures a dust -free processing of the products. Depending on the product the rotor can be reversed easily on the hammer side (impact side) or on the knife side (cutting side). The rotor drive is ensured by a single bearing so that the product is heated to a minimum during the sizing process, and the large front door ensures a quick disassembly of the sieve and the rotor and permits simple access for cleaning the processing area. The hammermill further fulfils the guideline of ATEX 94/9/EC.

The winning product: WERMA Signal Tower deSIGN 42 WERMA has extended the successful signal tower program with the launch of the new LED signal tower in an attractive stainless steel de-sign. The signal towers deSIGN 42 are examples of state of the art technology. These compact LED signal towers enable two or three defined states to be displayed while using only on signal device. When no signal is active, the tower appears “cool“ with its clear, transparent domes. Upon activation of the signal colour appears to be breathed in to the tower. The signal tower deSIGN 42 has a life duration of up to 50,000 hours and a very low current consumption, making it both economical and maintenance. The low starting current of well under 500mA enables triggering via PLC.

FlowSlide meter replaces weigh feeders and hopper scales The FlowSlide Meter offers a precise and maintenance free alternative to conventionell weigh feeders and hopper scales. The FlowSlide system measures in the process. The product is guided via a curved stainless steal slide. This is causing a centripetal force, which is absolute proportional to the mass flow. Compared to conventional flow meters based on the effect of impact, the FlowSlide is nearly independent from product density and grain size. A simple factory calibration provides an accuracy within 2%. With a comparison field calibration it is possible to achive +/- 0.2 %. The Flowslide system is suitable for all free flowing solids within a density range of 0.03 and 3.0 kg/l .

Modular Signal Tower System with high protection rating IP 65 and long-life LED WERMA is extending its successful modular Signal Tower range with the addition of an attractive tower with a diameter of 70mm. The KombiSIGN 71 offers the high protection rating IP 65 for use in extreme conditions. The unique KombiSIGN features, such as the practical bayonet fixing system facilitating simple operation and modular assembly, are once again incorporated into KombiSIGN 71. As a result of these features tool free bulb changes are possible with minimum effort. KombiSIGN 71 offers the choice of two terminal elements; either an improved screwable connection or a terminal element with Cage Clamp® technology providing screw free wiring. This simple connection system is unique to WERMA and its KombiSIGN is the only signal tower on the market which offers this technology. The large degree of variety within the range of optical and audible elements available and a comprehensive array of accessories make it easy to find the right Signal Tower combination

Simpler & Faster Line Vac™ in-line pneumatic conveying Description The Line Vac™ is a simple and cost-effective solution to transport a wide range of products pneumatically. Advantages - Simple to instaal, compact, nó moving parts. - Cost effective. - Materials: Aluminium, SS 303/ 316 or “High Temp” and PVDF. - Connections ¾” – 5” flexible hose, thread or flanges. - Increases productivity. - Foodgrade. Applications - Transport of granulates, tablets, small parts. - Tensioning of fibers/ yarns. - Vacuumcleaning, filling and discharging of tanks, bigbags etc. - Plastics, chemicals/ farmaceuticals, foodproducts, chips etc.

For all types of solids that don not need Stainless Steel The Swedish company PIAB has developed a new series of vacuum conveyors, the IC33, for handling of material in the manufacturing industry. This new series creates a whole range of new possibilities of material handling. The series consists of three versions and is based on a new patented pump technology. Working environment friendly: the closed vacuum system does not only protect the material handled from external influences, but also the user from the material handled. Saves Floorspace. The compact design of the conveyor makes it possible for the user to secure floor space that otherwise would have been occupied if using more space-demanding belt- or screw conveyors. As the material is conveyed in pipes or hoses, this solution is also more flexible, according to the manufacturer. Many Fields of Application With this new product series the company can offer competitive conveying of virtually all types of materials in the shape of flakes, pellets and powder.

Sartorius system controller meets requirements of the IFS and EC Directives Manufacturers in today`s process-oriented industries, particularly in the food industry, have to meet increasingly strict safety requirements as well as obligations regarding legally regulated accountability. European Council Directives and the International Food Standard (IFS), in particular, call for 100% traceability of all stages of the production process. Sartorius has developed the new MIX-X5 weighing-system controllers specifically to meet the IFS in the food industry for manual dispensing and batching processes. These compact and easy-to-use controllers are equipped with practical and versatile features for manual batching, such as user IDs, material ID verification and report logging for all raw material batches used. Another advantage of the MIX-X5 controller is the wide range of options available for label printing and report generation. With these convenient performance features, the MIX-X5 controllers make the entire production process fully transparent.

Sartorius terminals and platforms integrate Bluetooth® for you With Bluetooth® there are no obstacles to wireless communication in the production environment, because this established technology enables cost-effective networking of mobile and stationary equipment, such as indicators and scales from the Combics series and high-resolution digital weighing platforms. Moreover, Bluetooth® has turned out to be a real money-saver, since the price of cabling – including procurement, installation and maintenance – can be as high as 15 euros per meter. Investment in a radio transmission network rapidly pays for itself, even for short distances. In addition, wireless transmission technology provides solutions that would have been unthinkable with standard cabling, for example in cleanrooms. Sartorius has products for wireless communication between indicators, scales and platforms and PCs. Bluetooth® adapters are available for connection to Combics, Factory IS and isi series industrial weighing equipment, as well as ME

New: METTLER TOLEDO IND130 Now it is possible to convert weighingsignals from loadcells of almost any construction (silos, hoppers, etc) to any PLC or PC with RS232 or Profibus or AB/RIO interface The METTLER TOLEDO IND130 gives you new possibilities
