This method covers fluctuations much more effectively than the zeta potential As the first supplier ever, FRITSCH has now developed a way to measure the pH value of the dispersion liquid almost directly in the measuring unit. The new pH sensor is installed as a module in the dispersion bath and connected to the Laser Particle Sizer. It continuously measures the pH value during the measurement and automatically transfers the determined values to the software for documentation. This method covers fluctuations much more effectively than the zeta potential and offers many advantages, especially in the area of research and development. The pH value is much broader, especially with measurements in the field of nano-suspensions. Its monitoring provides valuable information about how and when a chemically inert material, for example, reacts to alkalis, depending on the environment. If the curve is unstable and varies during measurement, the pH value helps with stabilization and interpretation. The pH measurement process now introduced by FRITSCH

Now combinable with high-performance Cyclone separator The Disk Mill PULVERISETTE 13 premium line grinds hard-brittle to medium-hard solids down to 0,05 mm fineness. It is especially safe due to the automatic locking of collecting vessel and grinding chamber. And thanks to the simple motor-driven grinding gap adjustment with digital gap display and the presentation of all parameters on the well-designed display absolutely convenient to operate. - High throughput of up to 150 kg/h with extra powerful motor - Fast, residue-free cleaning due to Clean Design with smooth inner surfaces of the grinding chamber and removable funnel - Longer service life of the grinding disks due to simple change of the rotational direction (clockwise/counter-clockwise) - Grindings disks are available in 4 different materials for optimal adaptation to your sample material - Dust-free grinding due to the connection of a dust exhaust system – directly controlled via the instrument Ideal for medium particle sizes in the areas of mining

Powerful comminution with variable rotational speed The FRITSCH Universal Cutting Mills PULVERISETTE 19 and PULVERISETTE 19 large ensure fast, easy comminution of a wide range of plastics/polymers as well as biological materials in small and large quantities. Its main areas of application include environment and recycling, secondary fuels/RDF in cement production, power generation and other similar contexts, as well as cannabis processing. There is a special stainless steel version for the foodstuffs and pharmaceutical sectors. The gradually variable rotational speed setting allows optimal adjustment of the cutting speed to any sample material. The well-conceived structural design of the grinding chamber ensures optimized hygienic cleaning. Overview of the main features: - Variable rotational speed from 300 – 3000 rpm or 50 – 700 rpm for optimized torque - Feed size up to 70x80 resp. 120x85 mm - Throughput up to 60/85 l/h - Variable final fineness with sieve cassettes from 0.1 – 20 mm - Tool-free maintenance

As a pioneer in the industry, we have poured 35 years of experience in particle sizing technology into the new FRITSCH Technology Centre for Particle Sizing, combining it with the latest high-end technology. Covering an area of 240 qm on three floors, the new building at the FRITSCH headquarters in Idar-Oberstein/Germany offers plenty of room for the entire FRITSCH particle sizing team, bringing together development and application technology. Here, in the Robert Fritsch Tower, all new technical developments in the field of particle sizing with and without lasers will be created in future; application tests are carried out and the optimal parameters for your specific measurement tasks are determined in individual test measurements. Ideas for new, innovative instruments and modules are developed on the top floor of the tower, constantly improving and expanding the range of FRITSCH Particle Sizers. One floor below, theory is put to the practical test in the application technology department. When setting up our new technology centre for particle sizing, we also modernized and extended our fully equipped training laboratory. Here we bring particle measurement technology

New modules for Particle Size Measurement down to the nano-range Laser Particle Sizer ANALYSETTE 22 NeXT The FRITSCH A-22 NeXT Nano is your Laser Particle Sizer, when it comes to the highest accuracy and sensitivity even with the smallest particles - with an extra wide measuring range from 0.01 to 3800 μm. And as Micro version an economy alternative for a smaller measuring range from 0.5 to 1500 μm. Both are designed with just one laser and a number of patented features for maximum durability with minimum maintenance. All FRITSCH Laser Particle Sizers ANALYSETTE 22 NeXT are developed according to a smart, modular concept. You only buy what you really need and you can flexibly grow with your sizing tasks. The modules * NEW: Module Dry dispersion unit; It’s height-adjustable funnel and a stirrer made of stainless steel ensure optimum sample feeding adapted to the respective sample material. * Module Wet dispersion unit; Fast, uniform distribution of the sample material thanks to the powerful centrifugal pump with adjustable

FRITSCH A-22 NeXT Nano Laser Particle Sizer: highest accuracy and sensitivity; Now with new modules like dry dispersion unit and much more The FRITSCH A-22 NeXT Nano is your Laser Particle Sizer, when it comes to the highest accuracy and sensitivity even with the smallest particles - with an extra wide measuring range from 0.01 to 3800 μm. And as Micro version an economy alternative for a smaller measuring range from 0.5 to 1500 μm. Both are designed with just one laser and a number of patented features for maximum durability with minimum maintenance. Installation is easy via plug and play, thorough cleaning without tools with just few simple steps. And the high-performance software – delivered free of charge – offers unique options for evaluation and documentation and meets the requirements of 21 CFR Part 11. Overview of the main features: - Two different measuring ranges - perfectly equipped for all measuring tasks - Ultra-fast measuring times of less than a minute - Especially quick rinsing – four times faster than usual - Wear-free and low-maintenance - one professional maintenance

The FRITSCH Mini Cutting Mill PULVERISETTE 29 is the ideal laboratory mill if you regularly grind small sample quantities of materials such as grain, seeds or even plastics and other materials with a low specific density. The Mini Cutting Mill PULVERISETTE 19 is inexpensive, compact and space-saving, completely uncomplicated to use and can be cleaned contamination-free in a few simple steps. Particularly powerful: different rotors with 4 cutting edges and fixed knives enable up to 48,000 cutting processes per minute. Overview of the main features: - Variable rotational speed from 500 – 6000 rpm for optimal cutting speed - Feed size up to 13 mm diameter, volume up to 100 ml - Variable final fineness with sieve inserts from 1 – 6 mm - Grinding chamber completely made of 316L stainless steel - Hygienic Design for easiest cleaning with just a few simple steps - No loss of moisture during sample preparation for determining moisture Ideal for analysis of moisture, raw fibre and ash as well as for IR and NIR Thanks to its variable rotational speed, the FRITSCH P-29 comminutes especially grain and other seeds in an optimal way and with almost no loss of moisture. It thus fulfils

Particle analysis is essential: whether in production and quality control, research, development, laboratory or for controlling manufacturing processes. In all these cases fast, reliable and reproducible results are required. Find the perfect solution adapted to your application. Benefit from more than 35 years of experience in the field of particle technology. We help you to find the perfect measuring principle: static light scattering for analysis of particle size, or dynamic image analysis, if not only the particle size should be measured, but exact information on particle shape is required. Particle Size Analysis – unbeatably simple and affordable The two models of the NEW Laser Particle Sizers ANALYSETTE 22 NeXT provide you quickly and easily with reliable results on particle size using static light scattering. Choose according to your requirements: The ANALYSETTE 22 NeXT Micro with a measuring range of 0.5 – 1500 μm for all typical measurement tasks for the determination of the particle size distribution or the high-end instrument ANALYSETTE 22 NeXT Nano with an extra wide measuring range of 0.01 – 3800 μm for maximum precision and sensitivity for smallest particles with

Sample preparation is very important to obtain accurate data from analytical testing. To obtain this representative data, the entire sample must be properly comminuted. The Knife Mill PULVERISETTE 11 is perfectly suited for this task. Consistent, Representative, Accurate Consistent and viable representation of sample preparation leads to more accurate and repeatable results for analysis. Obstacles in handling or reducing materials with varied sample size, moisture levels, physical attributes, and material sensitivity create additional challenges in critical analysis. Obtaining a representative sample from an entire batch can be variable, complex, and time consuming. This is more complex when faced with a diverse sample load. While difficult, sample preparation is one of the most important steps in obtaining accurate data from analytical testing. In regards to comminution there are often limiting factors, like the rheological properties of a material, the ingredients, or the volatile components. In this case, consumer products such as blenders and coffee grinders are chosen for laboratory use. Industry quality knife mills offer specific utilization capabilities beyond consumer appliances. FRITSCH

DDW Die Deutsche Wirtschaft has identified FRITSCH as one of the 3,000 German companies in trend and growth markets. FRITSCH laboratory instruments for milling, sizing, sieving and dividing are worldwide standard and synonymous with efficient, reliable work in industry and research. The innovative ideas of the internal development department are inspired by the close exchange with customers and their practical work in the laboratory. This high level of innovation is one of the reasons for the award now received. DDW Die Deutsche Wirtschaft identified 3,000 German companies active in promising future fields from all company and sales sizes and weighted them according to importance. The evaluation took into account 28 different criteria. These included turnover, number of employees and more specific factors such as the number of patents and certifications and the training offered. With over 253 scoring points, FRITSCH was awarded the title “Excellence Made in Germany” in trend and growth markets in the Industry segment.

Fast and fine: Disk Mill PULVERISETTE 13 classic line. he ideal instrument for fine grinding of up to 150 kg per hour of soft to hard-brittle and temperature-sensitive solids, even in continuous operation. articularly ideal for medium particle sizes in the areas of mining and metallurgy, glass industry, ceramics industry, soil research, rocks and soils. The Disk Mill PULVERISETTE 13 classic line is the ideal instrument for fine grinding of up to 150 kg per hour of soft to hard-brittle and temperature-sensitive solids – even in continuous operation. The maximum feed size per piece is approximately 20 mm edge length, the final fineness is freely adjustable between 12 mm and 0.1 mm. Powerful fine grinding The material to be ground is comminuted by pressure and shearing action between two counteracting grinding disks with coarse interlocking teeth. The ground material automatically falls down through an output gap into the collection drawer. The desired final fineness can be defined from the outside by changing the gap width. Advantages PULVERISETTE 13 classic line: * High throughput up to 150 kg/h * Fine grinding down to 0.1 mm * Grinding disks are available

The cryogenic grinding of small pumpkin samples succeeds quickly and easily with the vibratory micro mill PULVERISETTE 0 and cryo attachment. Bishop’s cap, butternut, nutmeg or the popular Hokkaido: numerous variations of the colourful autumn vegetable are available in the fall. Unfortunately, however, pumpkin plants absorb organochlorine pesticides (OCPs), among other things, particularly easily from the soil as a result of earlier conventional cultivation. In most cases, however, the residues in samples from the European region are well below the legal maximum levels nevertheless an examination of pumpkins mandatory. In order to grind small amounts of the pumpkin sample to a fine powder, we equipped the laboratory mill with a stainless steel grinding set and a grinding ball with a diameter of 50 mm. Grinding parameters: - Feed quantity: 7 g - Feed size: 12 cm diameter - Grinding time: 1.5 min - Final fineness: fine powder 150 µm Test grinding In this test we used our Vibratory Micro Mill PULVERISETTE 0 with cryo-box and stainless steel grinding set. An amplitude of 3.0 mm was pre-programmed.

Pet food has to meet to strict guidelines. An effective sample preparation is essential for subsequent analysis. Dogs represent one of the most preferred pets across the globe. The general diet of a dog should comprise a combination of carbohydrates, minerals, proteins, fats, vitamins and water. Dog food manufacturers across the globe have been introducing products suitable for every stage of a dog’s life. Some of these products provide hypoallergenic nutrition, whereas other formulations are produced for controlling health conditions such as kidney and heart-related diseases[1]. Hence the importance of continued pet food testing for various ingredients or to even prevent contamination due to aflatoxin or salmonella. New technologies and testing methods for example are helping manufacturers and vet supply chains to keep products safe. FRITSCH Mills are perfectly suited for sample preparation prior to further testing of pet food. First test: Pulverisette 14 premium line In this trial we used our Variable Speed Rotor Mill Pulverisette 14 premium line converted into a cutting

Planetary Ball Mills – high-performance all-rounders in routine laboratory work. These mills are ideally suited for fast, loss-free fine grinding of hard, medium-hard, soft, brittle, tough and moist materials. FRITSCH Planetary Mills classic line are ideally suited for fast, loss-free fine grinding of hard, medium-hard, soft, brittle, tough and moist materials. They process samples from a few milligrams up to several kilograms, achieve finenesses of less than 1 μm, are absolutely reliable, very comfortable to use, easy to clean and guarantee a safe clamping of the grinding bowls. Depending on the fineness required, the grinding can be performed dry, in suspension or in inert gas. In addition to comminution, Planetary Mills can be used for mixing and homogenising of emulsions and pastes or for mechanical alloying and activation in material research. Your advantages with the Planetary Mills classic line: - Fast grinding to below 1 µm - Up to 800 rpm - Safe clamping of the bowls with the Safe-Lock-System - Simple, ergonomic handling and easy cleaning - Grinding bowls and balls in 7 different materials available to avoid undesired abrasion - Consistent reproducibility -

The Universal Grinder in the laboratory for every application: versatile use, gentle fine grinding, simple working, easy cleaning, practical cryogenic grinding. Thanks to its special mode of operation, the Fritsch Mortar Grinder Pulverisette 2 is the ideal universal grinder in the laboratory – for analysis, quality control and materials testing as well as for the mixing and homogenisation of pastes and creams on a laboratory scale. Its particularly gentle grinding by friction with almost no thermal load is ideal for the preparation of tablets in galenics. Using liquid nitrogen it also grinds difficult-to-mill samples with moist, fibrous or elastic structures. And the Pulverisette 2 is also ideally suited for mixing of solids or liquids and solids. With brief, reliably reproducible grinding and mixing times, it is loss and dust free. For a final fineness’s between 10 and 20 μm, with a feed size of 6 – 8 mm and a max. sample quantity of up to 190 ml. Areas of application Pharmacy, foodstuffs, chemistry, mining and metallurgy, geology and mineralogy, glass and ceramics industry, agriculture and forestry. The Fritsch

Size-reduction of different materials due to variable cutting speed adjustment The Universal Cutting Mills PULVERISETTE 19 from FRITSCH are ideal for comminution of dry, soft to hard, tough to brittle, fibrous as well as temperature-sensitive materials. Due to the variable speed adjustment between 300-3000 rpm, a fast and effective fine comminution is possible. With the slow-speed Universal Cutting Mill with 50-700 rpm, on the other hand, extremely powerful comminution is achieved even for smaller sample quantities. The Top 3 Advantages of the Universal Cutting Mills: -Variable adjustable rotor speed - for fine as well as powerful comminution -Residue-free cleaning – unbeatable fast, simple and efficient -Available as stainless-steel versions for the analytical sector, food and pharmaceutical industry Different rotors with various knife geometries, replaceable blades, practical sieve cassettes and a multitude of patented ideas make daily use simple and your work easier. A particularly effective comminution is achieved by combining

The ultra-compact FRITSCH Mini-Mill PULVERISETTE 23 is the ideal assistant for fine comminution of smallest quantities – for wet grinding as well as for dry or cryogenic grinding. Its special, spherical grinding bowl ensures much better performance in grinding, mixing and homogenising compared with similar models. With a footprint of just 20 x 30 cm and a weight of 7 kg, it easily fits anywhere. It’s smart, extremely user-friendly, inexpensive, and convinces with impressive results: small, fast, effective. For perfect, loss-free grinding results in shortest times. Ideal for Chemical analysis: Comminution and homogenisation of grinding samples for creation of compacts for x-ray fluorescence and infrared spectroscopy (e.g. potassium bromide tablets) Environmental research: Soils in contaminant analysis, humic acid determination, botanical materials in residue analysis of fertilisers and pesticides, pulping of seeds Pharmaceuticals and medicine: Kidney and gallstone analysis, breaking up tablets, pharmaceutical ingredients Forensic analysis: Hair analysis for genetic testing and drug tests, preparation of extremely small particles for chemical

A video on how you can fast and easily prepare cannabis plants for an efficient extraction of cannabis oil and receive a homogeneous sample. Cannabis has been used as a medicine in various cultures for thousands of years, for example as marijuana or as hashish. Today Tetrahydrocannabinol (THC) and Cannabidiol (CBD) are particularly isolated and researched from the multitude of active substances contained in the plant (in addition to other cannabinoids and terpenes) as pharmacologically effective components. The cannabis active ingredients are used therapeutically in particular * as pain reliever * for appetite stimulation * anti-inflammatory * antispasmodic Supercritical CO2 Extraction The most common method to extract the active ingredients from the cannabis plant is supercritical CO2 extraction. At above 31°C and with high pressure the CO2 gets into the "supercritical" state. It now acts as a solvent. It is passed through a chamber containing the plant material. The CO2 has still the density of a liquid, but can fill the entire chamber like a gas. This is ideal for extraction as it does

From 95 mm sample feed size down to 0.05 mm final fineness in a single step For especially fast and continuous pre- and fine-grinding of large quantities of hard to brittle materials, you can combine the Jaw Crusher PULVERISETTE 1 premium line and the Disk Mill PULVERISETTE 13 premium line to an efficient, heavy-duty, high-performance grinding instrument with integrated Riffle Sample Splitter. This gives you the full range of opportunities for optimal sample preparation with a feed size of up to 95 mm and final fineness of down to 0.05 mm – all in a single step. Ideal for pre- and fine grinding of very hard and brittle materials in the areas: Glass and Ceramics Industry, Mining and Metallurgy, Geology and Mineralogy, Chemical Industry and Soil Research premium-combination for integrated pre- and fine-grinding - Powerful continuous pre- and fine-grinding - Compact in a single instrument with Riffle Sample Splitter - High throughput for production of small amounts - Maximum feed size 95 mm - Minimum final fineness 0.05 mm - A wide

The dispersing system is especially suitable for fine particles, poorly flowing, fine-agglomerating or sticky materials that do not react in water or other liquids. The proven particle sizer ANALYSETTE 28 ImageSizer in combination with the NEW automatic and powerful wet dispersion is especially suitable for fine particles, poorly flowing, fine-agglomerating or sticky materials that do not react in water or other liquids. Simple wet measurement For perfect dispersion the sample material is fed into a closed liquid circulation system and is pumped with high power through the measuring cell between camera and LED strobe light. The continuously obtained images are the basis for the analysis with a variety of evaluation possibilities. Choice of 3 lenses for highest resolution For wet measurement, choose from 3 different bi-telecentric lenses for optimum adaptation of the total measuring range from 5 μm to 3 mm to your measuring task. In combination with the powerful industrial camera, they guarantee the highest accuracy of the imaging of each individual particle always at the same imaging scale and the highest shape accuracy

Fritsch laboratory mills are suitable for size reduction of latex products, so further analyses can be done, for example for the use of solvents and toxic substances. Latex, the milk-like plant sap of the tropical rubber tree (Hevea brasiliensis), was already brought to Europe from America 500 years ago. A special property of latex is its extraordinary elasticity, which cannot be matched by any synthetic product. Protective gloves made of latex are used in the food industry, hairdressing and by cleaners. However, latex gloves can cause allergies in frequent users. To prevent allergic reactions, latex products were comminuted for further analysis in the Variable Speed Rotor Mill Pulverisette 14 premium line. Variable Speed Rotor Mill Pulverisette 14 premium line For the test, the Pulverisette 14 premium line with the cutting rotor was used. To ensure a better air flow during the comminution process, the small volume Cyclone separator was connected. The mill was operated at a speed of 20,000 rpm. The latex products were manually pre-shredded down to a feed size of 1 cm. Second step The next step was to place the pre-crushed

Fast, gentle, reproducible size-reduction and homogenisation in a very short time The Knife Mill PULVERISETTE 11 provides a homogeneous sample in a very short time due to its special design. Each subsample taken from any location in the grinding vessel is representative for the original sample and thus ensures an exact, significant analysis. And that for a wide range of different materials, regardless of whether the sample is dry, moist, soft, medium-hard, fibrous or oily. Ideal for sample preparation in the fields of foodstuffs or animal feed testing, agriculture and forestry, biology, pharmaceuticals and chemistry. The Top 3 Advantages of the PULVERISETTE 11 - Easy cleaning, efficient working – safe operating due to professional quality - Parts in contact with the sample are autoclavable for sterile comminution – safe contamination protection - Variable speed settings and turbo function, up to 56,000 cutting processes per minute Fast cryogenic comminution in a single step: Samples which are difficult to grind such as gummi bears, chocolate

The robust Heavy Duty Analytical Sieve Shaker from FRITSCH The ANALYSETTE 18 is the robust Heavy Duty Analytical Sieve Shaker from FRITSCH. It effortlessly sieves up to 15 kg of material between 20 μm and 125 mm. Specially designed for processing of large sieving quantities, it intentionally avoids the disadvantages of lighter sieve shakers in which the sample and sieve weights can sometimes significantly affect the sieving results. The three-dimensional sieving motion ensures particularly fast sieving results without manual re-sieving, and also optimal reproducibility. The ANALYSETTE 18 allows the use in pilot line production or for serial analysis of large quantities and can be used as testing equipment in accordance with DIN EN ISO 9001. Especially reproducible, comfortable, efficient There is always a constant amplitude due to the automatic amplitude control with continuous acceleration measurement of the whole sieve stack. Through a separate, handy operating unit, the ANALYSETTE 18 is especially comfortable to control.

Compact laser particle size analyser with extra wide measuring range saves money and avoids trouble with practically maintenance-free dispersion unit without soiling, without wear Select the Laser Particle Sizer according to your needs: either the Analysette 22 NeXT Micro for all typical measurement tasks from 0.5 - 1500 μm or the high-end instrument Analysette 22 NeXT Nano with an extra wide measuring range from 0.01 - 3800 μm for maximum precision and sensitivity even for smallest particles. The advantages of the NeXT Generation in overview: - Unbeatably priced particle size analyser with a unique measuring range from 0.01 – 3800 µm - Powerful, practically wear-free and maintenance-free dispersion unit, residue-free rinsing - Whole measuring process extremely flexible to program via SOPs and a measuring time typically < 1 minute - Reproducible results and the possibility to record additional parameters such as temperature and ph value during wet dispersion - Extremely simple to operate and clean A particle size analyser can only be as good as its dispersion capabilities. Due to the Analysette 22 NeXT‘s cleverly reduced

For exact results and can be attached and used with any sieve shaker The universal sieve clamping system TorqueMaster enables automatic and reproducible tensioning of the sieve stack on the sieve shaker during dry sieving with test sieves 200 mm/8’’ diameter. Although the tensioning has a great influence on the sieving result, it is relatively undefined in conventional systems. With the electric and easy-to-use sieve stack tensioning system TorqueMaster you can deliver a constant and reproducible clamping forces of ~ 1 kN to the sieve stack, enabling the calibration of the sieve tensioning – essential when using your sieve shaker as an instrument for inspection according to ISO 9001. The sieve stack tensioning system TorqueMaster consisting of clamping lid plexiglas for test sieves 200 mm/8" dia. and electrical tool 100-240 V/1~, 50-60 Hz and can be combined with any sieve shaker. Standardized for integration into a quality management system according to ISO 9001 The high performance Vibratory Sieve Shaker Analysette 3 PRO

Now even more efficient with the Fritsch cyclones The Fritsch Variable Speed Rotor Mill Pulverisette 14 classic line is the ideal mill for fast, effective comminution of soft to medium-hard, brittle and fibrous materials as well as temperature-sensitive samples – proven worldwide for the use in trace analysis. The motor speed can be varied between 6,000 and 20,000 rpm in increments of one-thousand – making it possible to adapt the mill to each specific application. An automatic speed compensation feature ensures an ideal adaptation of the grinding to the specific comminution behaviour of the sample. At the same time, reduces the fast, effective grinding through the efficient air routing inside the Pulverisette 14 classic line significantly the thermal strain on the sample. Efficient cooling The ingenious air routing of the Pulverisette 14 classic line ensures a constant airflow to cool the rotor, all motor components and the grinding material in the collecting vessel. At the same time, a large fan blows the

We take you with us on an exciting tour through our application technology laboratory in Idar-Oberstein Be our guest. Go on a virtual tour of discoveries and find out new things and many exciting facts about sample preparation and particle sizing. Explore our laboratory and get to know our instruments from all angles on the interactive 360°tour. What is the principle behind the ball mills? Why is it so easy to clean Fritsch cutting mills? Which processes are used to measure the shape and size of a particle and how exactly does this work? You can discover all this and much more during the tour. Experience our products live. Uncertainties continue to determine real working life. These are times when actual trade fairs are unthinkable and travelling also becomes problematic. Nevertheless, we do not want to forego the dialogue with you and simply present our new products online. With our virtual product presentation, you can experience our products for milling, sizing, sieving and dividing directly at your workplace. This is how it works. Simply fill out the form by briefly

Automatic grinding bowl clamping, imbalance control and comminution down to the nano range FRITSCH’s premium line Planetary Ball Mills Pulverisette 5 and 7 can grind, alloy, mix and homogenize reliably at bowl speeds of up to 2200 rpm. They let you effortlessly grind hard, medium, soft, brittle and moist samples down to a final fineness of < 100 nm in a very short time. Sample quantities of 1 to 60 ml (Pulverisette 7) or 15 to 450 ml (Pulverisette 5) can be processed simultaneously at the two grinding stations. The planetary mills premium line work particularly fast thanks to the high bowl speed of up to 2200 rpm and achieve a final fineness of up to < 100 nm in 3 minutes. The easy insertion of the grinding bowls and the blockage of the start in case of impermissible operating conditions make the Planetary Mills in combination with the automatic grinding bowl clamping system particularly user-friendly and safe. For both wet and dry grinding, the process is easy to start due to the guided positioning of the grinding bowl and the automatic bowl detection

Fritsch Vibrating Cup Mill Pulverisette 9 offers many practical advantages in all areas in which hard, brittle and fibrous material must be ground extremely quick down to analytical fineness. It is indispensable for fast sample preparation, for example in spectroscopy preparation, ore and geology laboratories, mining and metallurgy, ceramics industry, agriculture and environment, infrared and X-ray fluorescence analysis. The Pulverisette 9 is very powerful, especially quiet, simple to operate, quick to clean and has a well-conceived drive concept and the grinding set is safe and easy to tension. For perfect, loss-free grinding results in extremely short grinding time. Your advantages with the Vibrating Cup Mill Pulverisette 9 - High power with well-conceived drive concept - Extra-fast grinding with up to 1500 rpm - Grinding sets in 5 different materials and 3 different sizes from 50 ml to 250 ml volume are available – for each application the suitable one -

Reproducible Analysis of particle shape and size Whether in the field of production and quality control, research, development or the analytical laboratory, particle measurement is essential in many areas. This requires reproducible results, as with the Fritsch particle Sizers. But the choice is not always easy and must be specially adapted to the application. You can distinguish between different measuring principals. On the one hand for example the Static Light Scattering, ideal for particle sizing from 0.01 to 3800 µm. On the other hand for example Dynamic Image Analysis, for analysis of particle shape and size in an extra wide measuring range of 20 µm – 20 mm. Static Light Scattering With the completely revised Analysette 22 NeXT you choose according to your requirements: The Analysette 22 NeXT Micro with a measuring range of 0.5 – 1500 μm for all typical measurement tasks or the high-end instrument Analysette 22 NeXT Nano with an extra wide measuring range of 0.01 – 3800 μm for maximum precision

Multifunctional for efficient pre- and fine comminution – heavy-metal- and iron-free The Variable Speed Rotor Mill Pulverisette 14 premium line is ideal for soft, medium-hard, brittle, hard-brittle, fibrous, temperature-sensitive materials and all this with an extremely fast sample throughput. Overview of the main features: - Two mills in one instrument and the only Variable Speed Rotor Mill, which is suitable for cutting - Easier operation due to Intelligence-Safety-Control – the mill only starts once everything is correct - Parts in contact with the sample can be easily removed without tools, dishwasher safe, sterilizable The Variable Speed Rotor Mill Pulverisette 14 premium line offers impact, shearing and cutting comminution in one instrument - with higher performance, better cooling and significantly quieter than comparable instruments. With powerful 22,000 rpm of the impact rotor, as a centrifugal mill, it ensures a fast sample throughput of 15 l/h and more, which can be further increased by the use of the Fritsch cyclone separators. It

Ideal for particle size analysis in production and quality control, research and development With the completely revised Analysette 22 NeXT you choose according to your requirements: The Analysette 22 NeXT Micro with a measuring range of 0.05 – 1500 µm for all typical measurement tasks or the high-end instrument Analysette 22 NeXT Nano with an extra wide measuring range of 0.01 – 3800 µm for maximum precision and sensitivity for smallest particles with an additional detector system. Your advantage: Especially easy operation, short analysis times, reliably reproducible results and the recording of additional parameters such as temperature and pH value during wet dispersion. Only one laser for even faster measurement results The new generation Analysette 22 NeXT operates like every Fritsch laser Particle Sizer with the patented Reverse Fourier design which has established itself by now as a general standard. The Laser Particle Sizer operates with only one laser and does not need an additional light source even for backward scattering. Therefore it records

Ideal for size-reduction of different materials due to variable adjustment of the rotational speed Both models of the NEW Universal Cutting Mills from Fritsch are ideal for size-reduction for a wide range of diverse materials due to variable adjustment of the rotational speed of the rotor, different rotors with various knife geometries, replaceable blades, practical sieve cassettes and that with an unmatched ease of cleaning. NEW: Wear-free labyrinth seals made of stainless steel on both sides of the rotor – on the shaft and in the lid – offer effective contamination protection and no additional heat effect for your samples. They can be removed for fast, residue-free cleaning. Variable 300-3000 rpm for fine comminution The high-speed Universal Cutting Mill Pulverisette 19 comminutes up to 60 l/h of soft to medium-hard sample materials and fibrous materials at a torque of up to 30 Nm with reliable reproducible results. The great advantage: The variable rotational speed adjustment in increments of hundred between 300 and 3000 rpm enables fine tuning of the comminution

After almost 40 years as managing director of Fritsch gmbH, Robert Fritsch was bit farewell Robert Fritsch was bit farewell on his retirement on 1st January 2020. He looks back on times of modernization, economic growth and success. In 1920 the medium-sized family business was fund in Idar-Oberstein as a technical precious stones trade by Max and Alfred Fritsch. After the Second World War Willi and Paul Fritsch, sons of Alfred Fritsch, took over the management. As the second generation of the company, they were looking for a new business idea, because more and more synthetic materials found their way into the application area of FRITSCH. Soon it became clear to focus on the niche market of application-oriented laboratory instruments for sample preparation and particle sizing. This specialization led the laboratory instrument manufacturer to success: Already since the mid-1950s Fritsch has been one of the leading manufacturers in this field. The first patent application for a fully automatic planetary mill followed in 1962. In the following years Fritsch

Efficient pre- and fine grinding in one instrument with impact or cutting rotor The Fritsch variable Speed Rotor Mill Pulverisette 14 premium line offers impact, shearing and cutting comminution in one instrument – with a higher performance, better cooling and significantly quieter than comparable instruments. Its powerful motor is ideal for the particularly fast comminution of soft to medium-hard, brittle as well as fibrous materials and temperature-sensitive samples with an extremely fast sample throughput, which can be further increased by the use of the Fritsch cyclone separators. Overview of the features: - Powerful grinding with 22,000 rpm for particularly fast sample throughput - Max. feed size < 15 mm, sample throughput of up to 15 l/h and more - AutoLOCK grinding chamber for particularly safe work - Final fineness down to d50 < 40 μm, sieve rings 0.08 – 6 mm - Particularly good cooling of the grinding material - Pleasantly quiet operation - Very easy to clean due to Clean Design FRITSCH premium-Plus: Two instruments

Fast analysis of particle shape and size of suspensions and emulsions Wet dispersion is particularly suitable for fine particles, poorly flowing, fine-agglomerating or sticky materials, which do not react in water or other liquids. The measuring time depending on the sample quantity, is under 5 minutes. And the result is available immediately. This makes the Analysette 28 ImageSizer the perfect measuring instrument for the easy quality control, as well as for research and for laboratory tasks – and it is the fast alternative to sieving. Your advantages - Extra wide measuring range of 20 μm – 2.8 mm - Strong, freely adjustable ultrasonic power for deagglomeration - Extremely quiet dispersion with strong pumping power - Benzine, alcohol and many organic solvents can also be used as suspension liquid as a standard feature - Automatic rinsing cycle - No dead space in measuring and rinsing circulation system - Fast and consistent cleaning Easy wet measurement The Fritsch analysette 28 ImageSizer is in combination with the

The Universal Grinder for every application Thanks to its special mode of operation, the Fritsch mortar Grinder Pulverisette 2 is the ideal universal grinder in the laboratory – for analysis, quality control and materials testing as well as for the mixing and homogenisation of pastes and creams on a laboratory scale. Its particularly gentle grinding by friction with almost no thermal load is ideal for the preparation of tablets in galenics. Using liquid nitrogen it also grinds difficult-to-mill samples with moist, fibrous or elastic structures. And the Pulverisette 2 is also ideally suited for mixing of solids or liquids and solids. With brief, reliably reproducible grinding and mixing times, it is loss and dust free. For a final fineness’s between 10 and 20 μm, with a feed size of 6 – 8 mm and a max. sample quantity of up to 190 ml. Areas of application Pharmacy, foodstuffs, chemistry, mining and metallurgy, geology and mineralogy, glass and ceramics industry, agriculture and forestry. The Fritsch

Reliable Automatic Sample Feeding The Vibratory Feeder Laborette 24 is ideal for automatic, uniform feeding of free-flowing materials into sample dividers, mills or mixers in your laboratory. The vibration, which is controlled by a micropro-cessor, conveys the sample material out of the funnel over the V or U-shaped stainless steel channel into the respective equipment. The flow rate can be individually adjusted; the vibration amplitude is precisely controlled – for absolute uniform feed of even smallest quantities. Safe and reliable. Suitable for both: coarse and fine materials which can be conveyed reproducibly with a material feed between 1 g/min up to 2.500 g/min. Your advantages with the NEW control unit: - Setting of the maximum feed quantity in the setup mode by the user - Adjustment of the feed intensity and time via display - Fine adjustment of the material flow even of smallest quantities - Reproducible setting of the feed rate, when changing the material - Digital display of the

The Fritsch vibrating Cup Mill Pulverisette 9 offers many practical advantages in all areas in which hard, brittle and fibrous material must be ground extremely quick down to analytical fineness. She is indispensable for fast sample preparation, for example in spectroscopy preparation, ore and geology laboratories, mining and metallurgy, ceramics industry, agriculture and environment, infrared and X-ray fluorescence analysis. The Pulverisette 9 is very powerful, especially quiet, simple to operate, quick to clean and has a well-conceived drive concept and the grinding set is safe and easy to tension. For perfect, loss-free grinding results in extremely short grinding time. Your advantages with the Vibrating Cup Mill Pulverisette 9 - High power with well-conceived drive concept - Extra-fast grinding with up to 1500 rpm - Grinding sets in 5 different materials and 3 different sizes from 50 ml to 250 ml volume are available – for each application the suitable

Convenient – Precise - Reliable The Fritsch sieve range is the focused answer to all typical sieving tasks in the laboratory: three well-conceived instruments for every application, with Fritsch concepts that make the work simpler and faster – easy to operate, reliable and long-lasting. Fritsch sieve Shakers are ideal for - Dry, wet and micro-precision sieving - Measuring the quantitative particle size distribution of solids and suspensions - Separating and fractioning - Simple, ergonomic operation - Fast, reproducible results - Sample quantities between 0.05 g and 15 kg - Sieve diameter from 100 mm to 450 mm, mesh widths from 5 μm – 125 mm - Can be used as testing equipment in accordance with Din en iso 9001 - Automatic sieve evaluation with the Fritsch software Autosieve Vibratory Sieve Shaker Analysette 3 PRO – precise sieving with amplitude control The high performance Vibratory Sieve Shaker Analysette 3 PRO offers everything you need for fast determination of quantitative

Fast, simple, safe Fritsch Planetary Mills premium line are extremely strong all-purpose mills that offer premium performance, usability and safety. Due to revolutionary rotational speeds of up to 1100 rpm, ultra-fine results are achieved by powerful wet and dry comminution of hard, medium-hard, soft, brittle and moist samples by the high-energy impact of grinding balls in rotating grinding bowls. Your advantage: extremely short grinding times and reliably reproducible results down into the nano range. Fritsch Planetary Mills premium line are also a perfect choice for highly efficient mixing and homogenising or for mechanical activation and alloying in materials research. Choose according to your needs: High-performance grinding down into the nano range – Planetary Mill Pulverisette 5 premium line: - Extra strong 2.2 kW drive power and extremely high centrifugal acceleration up to 64 g and up to 800 rpm (Rotational speed of the bowl 1600 rpm) - Motor-driven ServoLOCK clamping of

Fast, gentle comminution and homogenisation The Knife Mill Pulverisette 11 provides a homogeneous sample in a very short time due to its special design. Each subsample taken from any location in the grinding vessel is representative for the original sample and thus ensures an exact, significant analysis. And that for a wide range of different materials, regardless of whether the sample is dry, moist, soft, medium-hard, fibrous or oily. Ideal for sample preparation in the fields of foodstuffs or animal feed testing, agriculture and forestry, biology, pharmaceuticals and chemistry. For each application the perfect accessories The standard knife made of stainless steel can be used for comminution of nearly all materials due to its four blades and a well-conceived geometry. For comminution of brittle, hard samples we recommend the sickle knife made of stainless steel. The sickle knife with serrated blades is ideal for grinding especially fibrous, tough or sinewy samples, such as fish, meat, asparagus or bamboo. Even

Guaranteed representative sample division! The most precise way of sample division – guaranteed of up to 99.9 % A perfect sample preparation is the indispensable foundation for every analysis – because any errors will be reflected in the results later on. Therefore the reliable creation of guaranteed representative subsamples plays an absolutely central role. The FRITSCH Rotary Cone Sample Divider LABORETTE 27 offers the ideal conditions: it is the only sample divider on the market dividing your samples with up to 3,000 dividing steps per minute centred over a rotating dividing cone into up to 30 separate channels. Each individual sample with identical chemical and physical properties – and with 99.9 % accuracy for many more sample materials than any other similar method. The best sample division, possible today. The FRITSCH ADVANTAGES - The sample delivery funnel guides the sample material exactly centred on the tip of the rotating cone – for even more accuracy during sample division.

of hard and very hard brittle materials Ideal as the classic workhorse for pre-crushing of brittle materials in the areas of mining and metallurgy, chemistry, geology and mineralogy, glass industry, ceramics industry, rocks and soils. The compact FRITSCH Jaw Crusher PULVERISETTE 1 classic line is the ideal instrument for fast and effective pre-crushing of hard and very hard brittle materials – even ferrous alloys are no problem for this instrument! Choose according to your tasks between two different models for various feed sizes and sample quantities: Jaw Crusher model I: Max. feed size: 60 mm, max. continuous throughput: 140 kg/h Jaw Crusher model II: Max. feed size: 95 mm, max. continuous throughput: 200 kg/h Powerful pre-crushing The powerful comminution of the sample takes place in the Jaw Crusher under high pressure between one fixed and one movable crushing jaw in an enclosed grinding chamber. The final fineness is easily set from the outside with the 10-stage adjustable gap width

Reproducible Analysis of particle shape and size Whether in the field of production and quality control, research, developement or the analytical laboratory, particle measurement is essential in many areas. This requires reproducible results, as with the FRITSCH Particle Sizers. But the choice is not always easy and must be specially adapted to the application. You can distinguish between different measuring principals. On the one hand for example the Static Light Scattering, ideal for particle sizing from 0.01 to 2100 µm. On the other hand for example Dynamic Image Analysis, for analysis of particle shape and size in an extra wide measuring range of 20µm – 20mm. Static Light Scattering The ANALYSETTE 22 NanoTec is the ideal Laser Particle Sizer for the determination of the particle size distrubutions of powdery samples, of solids in suspension and of emulsions. The instrument is perfectly suitable for the utilisation in production and quality control as well as in research and development. Your advantage:

Vibrating Cup Mill PULVERISETTE 9 The completely modified FRITSCH Vibrating Cup Mill PULVERISETTE 9 offers many practical advantages in all areas in which hard, brittle and fibrous material must be ground extremely quick down to analytical fineness. And ideal for fast sample preparation, such as in the areas of spectroscopy preparation, ore and geology laboratories, mining and metallurgy, ceramics industry, agriculture and environmental science, infrared and x-ray fluorescence analysis. With increased grinding power and a completely new drive concept, even safer and easier to tension the grinding set, especially quiet, simple to operate and quick to clean. For precise, loss-free grinding results in shortest times! Easy working The working position is ergonomically optimised; the ease of cleaning is without match. The grinding sets are especially light, and do not have to be placed directly on the vibrating plate in the centre of the mill. The grinding set is simply placed on the guide rail and easily

Distributors as well as consumer have a great interest in their products meeting quality standards. For chemical analysis and quality control is a diligent sample preparation as a prerequisite for a fine analysis essential, in order to observe the predefined critical values and tolerance values. Perfectly suitable for the comminution of nuts are the FRITSCH Cutting Mills. Consumer protection Food inspections concentrate on verifying harmful substances like toxins, heavy metals and non-permitted pesticides. The consumers trust that top limits of harmful substances are not exceeded and therefore contaminated products not sold. Nuts are considered a problematic product in food inspections since the shell gives no clue about whether the core has the adequate quality. The inside may contain fungal spores or toxins which simply can not be perceived from the outside. With defined methods, samples may be tested for their safety. Research and development in chemical analysis

Generation of representative samples Detailed sample preparation of nuts according to regulation (EG) no. 401/2006 with tips, approaches and photos of the individual steps With the REGULATION (EG) no. 401/2006 of the COMMISSION of 23rd February 2006 binding standards for sampling procedures and analysis methods for the official testing of the mycotoxin content of food stuffs for example nuts was established. The task in the laboratory is as follows: „Each laboratory sample is to be prepared with a verifiable procedure which guarantees a complete homogenisation, ground finely and meticulously mixed. “ The regulation allows two means: 1. The nuts in the shell may be peeled and the aflatoxin content is to be determined for the edible share. This might be still feasible for peanuts. With walnuts, filberts or almonds this is very problematic though. 2. The other possibility is to use the nuts „inside the shell“ for the sample preparation. The task: 10 kg peanuts, walnuts, filberts, Brazil nuts

Automatic Dispersion with Little Liquid! Worldwide the Laser Particle Sizer ANALYSETTE 22 ensure precise determination of particle size distributions in an extremely wide measuring range of 0.01 – 2100 µm – in production and quality control as well as in research and development. Benefit from decisive advantages: extremely simple operation and short analysis times for consistently reproducible and reliable results. Small Volume Wet Dispersion Unit The FRITSCH small volume wet dispersion unit SVA ensures perfect, fully automatic dispersion of samples which are only available in a minimal quantity. And for measurements in organic solvents, the unit needs less than 50 ml liquid for the entire measurement circuit. This minimises the disposal costs and decreases environmental pollution. - Very small sample quantities in below 50 ml of liquid - Almost all dispersion liquids can be used - Resistant to chemicals - Very strong and controllable ultrasonic power of 100 Watt - Practical, illuminated dispersion

Simply place our instruments in your laboratory via AR-App and experience the innovations Augmented reality (AR) is a technology that superimposes a computer-generated image on an user’s view of the real world, thus providing a composite view. In soccer broadcasts, for example, you’ll find augmented reality when superimposing distances of free kicks using a circle or a line. We took advantage of this effect and programmed an app for you. For example, our knife mill PULVERISETTE 11 appeals to you, but you do not yet know whether it is the right instrument for your laboratory? No problem! Simply place the instrument in a free space in your laboratory using a mobile device and discover the many functions of the instrument. You can also watch the corresponding product video with valuable information in the app. Have we roused your interest? Just use the enclosed contact form. Try it yourself and download the app directly from the app store of your mobile device:

FRITSCH • Milling and Sizing! FRITSCH is an internationally respected manufacturer of application-oriented laboratory instruments for sample preparation and particle sizing. This year FRITSCH also got something new to discover. Convince yourself and experience the FRITSCH innovations live during ACHEMA 2018 • Hall 4.1 • Booth J49 FRITSCH innovations in the field of size-reduction NEW: Universal Cutting Mills PULVERISETTE 19 The new FRITSCH Universal Cutting Mills PULVERISETTE 19 are ideal for size-reduction for a wide range of different materials due to variable adjustment of the rotational speed of the rotor, various knife geometries, replaceable blades, practical sieve cassettes and that with an unmatched ease of cleaning. Knife Mill PULVERISETTE 11 The new FRITSCH Knife Mill PULVERISETTE 11 is ideal for very fast and gentle comminution and homogenization of moist, oily, fatty, soft, medium-hard and fibrous samples. Variable Speed Rotor Mill PULVERISETTE 14 premium line

Variable rotational speed for optimal adjustment of the cutting speed to your sample The NEW Universal Cutting Mill from FRITSCH is ideal for size-reduction for a wide range of different materials due to variable adjustment of the rotational speed of the rotor, various knife geometries, replaceable blades, practical sieve cassettes and that with an unmatched ease of cleaning. The fast solution for all your needs The high-speed Universal Cutting Mill PULVERISETTE 19 with variable rotational speed adjustment between 300-3000 rpm comminutes with a maximum feed size of 70 x 80 mm and a throughput quantity of up to 60 l/h fast and effectively dry, soft to medium-hard sample materials as well as fibrous materials and plastics with reliable reproducible results. One special advantage: Straw, films and similar materials can be fed in their full length without additional preparation. And the PULVERISETTE 19 is also ideal for RoHS tests. The powerful solution for gentle comminution The low-speed Universal Cutting Mill PULVERISETTE 19 with variable rotational

A culture of contradictions? Again and again consumers are confronted with scandals in the foodstuff industry. The latest case is the Fipronil egg scandal in the laying hen farming in the Netherlands and in Lower Saxony (Germany). What actually do foodstuff producers and marketers do to avoid such cases? A lot, if you believe the rising costs in the area of modern foodstuff analysis. So during the last decades, always newer and more sophisticated processes will be and were developed with the most sensitive detection thresholds (ELISA, PCR or the mycotoxin analysis) for quality control, in order to lower the number or even eliminate such scandals and the potential danger for consumers. So now, in the context of these analytical processes again and again, methods for sample preparation of the most diverse matrixes were developed. Because especially food- stuffs and the raw materials, respectively convenience products are often composed clearly more heterogeneous like all other substance groups. Especially

Homogeneous samples in the shortest time The new FRITSCH PULVERISETTE 11 is the ideal Knife Mill for very fast and gentle comminution and homogenisation of moist, oily and fatty as well as of dry, soft, medium-hard and fibrous samples. This makes it a perfect all-rounder with many advantages for sample preparation in the fields of foodstuffs or animal feed testing; pharmaceuticals and chemistry and many other applications. Your advantages with the Knife Mill PULVERISETTE 11: - Extremely fast comminution, homogenisation and mixing - Extra strong motor power up to 1250 watt - Max. feed size 40 mm, final fineness < 300 μm - Knife blades with up to 4 cutting edges – up to 56,000 cutting processes per minute - Up to 1,400 ml useful capacity of the grinding vessel plus Vario-Lid system for variable volume - 20 SOPs can be saved and USB interface for SOP management - Continuous, reverse and interval mode Easy cleaning and safe operating due to professional quality The special safety is ensured

AND CRITERIA FOR ITS COMMINUTION FROM CONSTRUCTION MATERIAL TO SEMICONDUCTOR TECHNOLOGY On planet earth sand is a very common unconsolidated sedimentary rock. It is characterized by a particle size between 0.063 and 2.0 mm. The mineral composition can vary extremely. Many occurrences consist of quartz respectively silicon dioxide (SiO2). Due to its physical and chemical characteristics sand is mainly used in the construction and glass industry. The analytical evaluation of the chemical composition and therefore the aptness for the intended uses make the comminution of quartz sand a prerequisite. FRITSCH offers a wide spectrum of suitable mills for this. For the characterization of the particle size distribution, FRITSCH offers sieve shakers and instruments for particle sizing via static laser scattering as well as instruments for the dynamic image analysis. With these technologies, the tracking and optimization of the comminution processes can be excellently accomplished. COMPOSITION OF SILICON

Unbelievable how fast time passes! Since decades FRITSCH is involved in international markets and of course also in the Chinese market. In order to serve the growing customer base in a continuative, flexible, and customer oriented manner a subsidiary was founded directly in Beijing (in October 2012). On October 14th and 15th, 2017 the 5th founding anniversary took place in Beijing. Customers from various industries, as well as FRITSCH employees and partners were present. At the beginning of the anniversary ceremony FRITSCH employee Mr. Li Xiao introduced important guests and FRITSCH customers and looked back on the five previous successful years. One of the many highlights of the ceremony was the introduction of the new FRITSCH knife mill PULVERISETTE 11 through our General Sales Manager Wolfgang Simon. The special feature of this laboratory instrument is the very fast and gentle comminution and homogenization of moist, oily, fatty, soft, medium-hard and fibrous samples and thus perfectly suitable

Measurement of particle shape and size The FRITSCH ANALYSETTE 28 ImageSizer for dry and wet measurement is the ideal Particle Sizer for all applications that require accurate and reproducible measuring results for both particle shape and size. The optical process of Dynamic Image Analysis provides results for a wide measuring range, delivers multiple shape parameters and evaluation possibilities for particle size. The measuring time depending on the sample quantity, is under 5 minutes. And the result is available immediately. Your advantage: Great flexibility for different measurement tasks for particle sizes of 20 µm – 20 mm in quality control, research and laboratory – and is a very easy and cost-effective alternative to sieving. Easy wet measurement of suspensions and emulsions The ANALYSETTE 28 ImageSizer is in combination with the corresponding wet dispersion unit ideal for measurement of particle shape and size of suspensions and emulsions. Wet dispersion is particularly suitable for fine

Wet and dry grinding down into the nano range! With two grinding stations, we have developed the NEW FRITSCH Planetary Mill PULVERISETTE 5 premium line as the ‘big sister’ to the PULVERISETTE 7 premium line: The ideal mill for fast wet and dry grinding of hard, medium-hard, soft, brittle and moist samples as well as for mechanical alloying, mixing and homogenising with reliable results down into the nano range – and an absolutely secure automatic clamping of the bowls by the mill. Your advantages with the Planetary Mill PULVERISETTE 5 premium line: - Extra strong 2.2 kW drive power and extremely high centrifugal acceleration up to 64 g and up to 800 rpm (rotational speed of the bowl 1600 rpm) - Sample quantities up to 450 ml, max. feed size up to 10 mm - Motor-driven ServoLOCK clamping of the grinding bowls - Safe and user-independent reproducible clamping - 2 grinding stations for grinding bowls 125 - 500 ml volume - Intuitive touchscreen operation with colour display Grinding has never been safer With

with impact or cutting rotor The FRITSCH Variable Speed Rotor Mill PULVERISETTE 14 premium line offers impact, shearing and cutting comminution in one instrument – with a higher performance, better cooling and significantly quieter than comparable instruments. Its powerful motor is ideal for the particularly fast comminution of soft to medium-hard, brittle as well as fibrous materials and temperature-sensitive samples with an extremely fast sample throughput of up to 15 litres and more per hour, depending on the material and parameter settings. Overview of the premium features: - Powerful grinding with 22,000 rpm for particularly fast sample throughput - Extremely high impact speed of the rotor (111 m/s = 399.6 km/h) - Max. feed size < 15 mm, sample throughput of up to 15 l/h and more - Multifunctional with impact or cutting rotor in one instrument - AutoLOCK grinding chamber for particularly safe work - Final fineness down to d50 < 40 μm, sieve rings 0.08 – 6 mm - Particularly

Innovations at POWTECH 2017 - Hall 2 • Stand 227 FRITSCH, an internationally respected manufacturer of application-oriented laboratory instruments for sample preparation and particle sizing, is again one step ahead. Convince yourself and discover the FRITSCH innovations live during POWTECH 2017: Hall 2 • Stand 227! -> High-tech laboratory mills for a wide range of applications -> Efficient sieve analysis -> Innovative particle sizing -> Well-conceived sample dividing, feeding and cleaning FRITSCH innovations in the field of size-reduction -> Knife Mill PULVERISETTE 11 Ideal for fast gentle grinding and homogenising of moist, oily and fatty, soft, medium-hard and fibrous samples. -> Variable Speed Rotor Mill PULVERISETTE 14 premium line The new extra powerful Variable Speed Rotor Mill PULVERISETTE 14 premium line offers impact, shearing and cutting comminution in one instrument with extremely fast sample throughput of up to 15 litres and more per hour. -> Planetary Mill PULVERISETTE 6

of suspensions and emulsions in an extra wide measuring range of 20 µm – 2.8 mm! The FRITSCH ANALYSETTE 28 ImageSizer is in combination with the corresponding wet dispersion unit ideal for measurement of particle shape and size of suspensions and emulsions. Wet dispersion is particularly suitable for fine particles, poorly flowing, fine-agglomerating or sticky materials, which do not react in water or other liquids. The measuring time depending on the sample quantity, is under 5 minutes. And the result is available immediately. This makes the ANALYSETTE 28 ImageSizer the perfect measuring instrument for the easy quality control, as well as for research and for laboratory tasks – and it is the fast alternative to sieving. Your advantages - Extra wide measuring range of 20 μm – 2.8 mm - Strong, freely adjustable ultrasonic power for deagglomeration - Extremely quiet dispersion with strong pumping power - Benzine, alcohol and many organic solvents can also be used as suspension liquid as a standard feature - Automatic rinsing

New FRITSCH subsidiary Besides branches in Singapore, Russia, China and France now FRITSCH opened its first subsidiary in the US: Fritsch Milling and Sizing Inc. For a long time we have been serving customers in the USA but in order to meet the demands of our customers in a growing market it was time to have a FRITSCH branch directly in the US. The new FRITSCH Headquarters USA is located in North Carolina and is part of the so called “Research Triangle” consisting of numerous research institutes, established companies as well as renowned universities. President FRITSCH USA Melissa Fauth considers this an ideal environment for FRITSCH. The FRITSCH Team has offices, a storage facility and an applications laboratory stocked with numerous FRITSCH instruments at their disposal. Melissa Fauth and service technician Bradley Miller can introduce FRITSCH instruments here and if needed conduct tests and sample grindings for customers. The team is supported by Robert Fauth which is in charge

International. User-friendly. Informative. A few days ago, the redesigned FRITSCH website went online featuring several languages. In addition to numerous languages like for example Italian, Spanish, France, Russian and Chinese, we now offer an own Website for our Portuguese customers. Besides invisible changes, like for example an update of the content management system, the layout was also completely overhauled and now appears in a fresh, pure design. Decisive for a relaunch were besides the technical improvements, also improvements in usability. Instead of pages with too much information we concentrated on the essence and now offer a modern layout with powerful photos and logically divided content. The separation of the homepage in milling and sizing is obsolete now and therefore improving navigation. Here a brief overview of the most important new features: - Utilizing the Geo IP for contacting FRITSCH Worldwide, you can see the appropriate point of contact of your current geographical

Simple. Flexible. Reliable. Worldwide the Laser Particle Sizer ANALYSETTE 22 ensures precise determination of particle size distributions in an extremely wide measuring range of 0.01 – 2100 µm – in production and quality control as well as in research and development. Benefit from decisive advantages: extremely simple operation and short analysis times for consistently reproducible and reliable results. AutoSampler Ideal for efficient automation of measurement series: The practical AutoSampler provides automatic sample feeding as a simple attachment for the wet dispersion unit of the ANALYSETTE 22. - Work completely independently, right from the start - 26 positions for 40 ml standard containers - Reliable complete sample feeding due to tilt function and programmable rinsing function with a strong spray jet - Automatic assignment of the position and measuring result by means the software - All function sequences, such as the dispersion and measurement duration, can be specified for

Dynamic Image Analysis instead of a microscope The new ANALYSETTE 28 ImageSizer is the ideal instrument for analysis of particle shape and size with Dynamic Image Analysis of dry, free-flowing powders and bulk solids in a measuring range from 20 µm to 20 mm. Via the optical analysis of particle shape and particle size, damaged particles, contaminates, agglomerates or oversized or undersized particles are identified accurately and fast, and can be viewed as single images. At the same time, the instrument offers a fast and efficient particle size measurement. The measuring time, depending on the sample quantity, is below 5 minutes and the result is available immediately. This makes the ANALYSETTE 28 ImageSizer the perfect measuring instrument for the easy quality control, as well as for research and for laboratory tasks – and it is the fast alternative to sieving. Dynamic Image Analysis instead of a microscope With the principle of Dynamic Image Analysis, both ANALYSETTE 28 models offer the same benefits

Fast fine grinding dry, in suspension or in inert gas FRITSCH Planetary Mills classic line are most effective for rapid loss-free and reproducible ultra-fine grinding of hard, medium-hard, brittle and fibrous materials dry or in suspension, for mixing and homogenising as well as for mechanical alloying/activation in materials research. Samples can be processed from a few milligrams to several kilograms at a wide range of fineness levels down to less than 1 μm. They are absolutely reliable, especially easy to operate and clean. Matching grinding parts of various materials are also available to provide maximum protection against undesired contamination of the samples. Fast and fine – easy to operate! Your advantages with FRITSCH Planetary Mills classic line - Fast grinding to below 1 μm - Up to 800 rpm - Safe clamping of the bowls with the Safe-Lock-System - Simple, ergonomic handling and easy cleaning - Grinding bowls and balls in 8 different materials to suit all needs and avoidance of contamination

Convenient – Precise - Reliable! The FRITSCH sieve range is the focused answer to all typical sieving tasks in the laboratory: three well-conceived instruments for every application, with FRITSCH concepts that make the work simpler and faster – easy to operate, reliable and long-lasting. FRITSCH Sieve Shakers are ideal for - Dry, wet and micro-precision sieving - Measuring the quantitative particle size distribution of solids and suspensions - Separating and fractioning - Simple, ergonomic operation - Fast, reproducible results - Sample quantities between 0.05 g and 15 kg - Sieve diameter from 100 mm to 450 mm, mesh widths from 5 μm – 125 mm - Can be used as testing equipment in accordance with DIN EN ISO 9001 - Automatic sieve evaluation with the FRITSCH software AUTOSIEVE Vibratory Sieve Shaker ANALYSETTE 3 PRO – precise sieving with amplitude control The high performance Vibratory Sieve Shaker ANALYSETTE 3 PRO offers everything you need for fast determination of quantitative

FRITSCH Cutting Mills Ideal for size reduction of soft to medium-hard, tough-elastic and fibrous materials as well as for heterogeneous mixtures. They are indispensable in the areas of environment, plastics, agriculture, forestry, construction materials, textiles, chemistry and foodstuffs as well as for analytic and sample preparation for RoHS-analyses, like for example mobile phone LCD glass, mobile phone keypads, electronic chips, circuit boards. While you are still tightening the screws on other mills, your FRITSCH Cutting Mill is already clean! Because the entire grinding chamber can be opened easily in seconds and both the rotor and the sieve can simply be removed with simple motions. Only at FRITSCH Cutting Mills it is possible to lift open the entire top part of the housing as well as the door – in fact, the door can be completely removed. And that’s not all: The rotor of the FRITSCH Cutting Mills can be removed easily without tools for quick cleaning in between and it can

The INDUSTRIEPREIS 2016 - Best of 2016 - and Best Products award of the EuroLab 2016! The Centrifugal Mill convinced the Jury For the eleventh time the Huber publishing house for Neue Medien GmbH (New Media) selects outstanding companies from the industry for the INDUSTRIEPREIS (industry award) within the time period of the HANNOVER MESSE. And the winners for progressive products and solutions are chosen: the FRITSCH Variable Speed Rotor Mill PULVERISETTE 14 premium line belongs to the best solutions of the INDUSTRIEPREIS 2016 in the category „Research and Development“. About the INDUSTRIEPREIS Since 2006 the Huber publishing house for Neue Medien GmbH annually awards the INDUSTRIEPREIS to the best and most progressive companies from Germany, Austria and Switzerland. Any sized companies can apply for the popular award, which due to its large and high-calibre jury enjoys an excellent reputation. The jury evaluates the submissions in regards to their technological, economical, ecological or usefulness for society. The new mill also won the

The new standard for Variable Speed Rotor Mills During the annual trade fair EUROLAB in Warsaw, the new Variable-Speed Rotor Mill PULVERISETTE 14 premium line secured an award in the Best Products competition. During the traditional exhibitor evening, FRITSCH sales representative for Eastern Europe, Mr. Marcel Hopfe, was presented with the award certificate. The independent, high calibre jury, consisting of engineers from the State Institutes of Geology and Research, judged the numerous exhibited laboratory instruments and the FRITSCH PULVERISETTE 14 premium line for efficient pre- and fine grinding of soft to medium-hard, brittle, fibrous and temperature-sensitive samples, scored in the category laboratory technology. The new standard for Variable-Speed Rotor Mills The FRITSCH Variable-Speed Rotor Mill PULVERISETTE 14 premium line offers impact, shearing and cutting comminution in one instrument – with a higher performance, better cooling and significantly quieter than comparable instruments. Its

FRITSCH innovations in the field of particle sizing and size-reduction FRITSCH, an internationally respected manufacturer of application-oriented laboratory instruments for sample preparation and particle sizing, is again one step ahead. Convince yourself and discover the FRITSCH innovations live during POWTECH 2016: Hall H2 • Stand 218! - Innovative particle sizing - High-tech laboratory mills for a wide range of applications - Efficient sieve analysis - Well-conceived sample dividing, feeding and cleaning FRITSCH innovations in the field of Particle Sizing - Particle Sizer ANALYSETTE 28 ImageSizer Ideal for fast analysis of particle shape and size with Dynamic Image Analysis of dry, free-flowing powders and bulk solids in a measuring range from 20 µm to 20 mm. Ideal for uncomplicated quality control and the fast alternative to sieving! - Laser Particle Sizer ANALYSETTE 22 NanoTec Ideal for fast analysis of particle size with Static Light Scattering. Due to the particularly wide measuring range of 0.01 to 2100 µm,

for sample quantities up to 450 ml and a max. feed size up to 10 mm With two grinding stations, we have developed the NEW FRITSCH Planetary Mill PULVERISETTE 6 premium line as the ‘big sister’ to the PULVERISETTE 7 premium line: Your ideal mill for fast wet and dry grinding of hard, medium-hard, soft, brittle and moist samples as well as for mechanical alloying, mixing and homogenising of larger sample quantities with reliable results down into the nano range – and an absolutely secure automatic clamping of the bowls by the mill. Your advantages with the Planetary Mill PULVERISETTE 6 premium line: - Extra strong 2.2 kW drive power and extremely high centrifugal acceleration up to 64 g and up to 800 rpm (rotational speed of the bowl 1600 rpm) - Motor-driven ServoLOCK clamping of the grinding bowls - Safe and user-independent reproducible clamping - 2 grinding stations for grinding bowls 160 ml, 250 ml and 500 ml volume - Intuitive touchscreen operation with colour display Grinding has never been safer With the completely

Impact, shearing and cutting comminution in one instrument The FRITSCH Variable Speed Rotor Mill PULVERISETTE 14 premium line offers impact, shearing and cutting comminution in one instrument – with a higher performance, better cooling and significantly quieter than comparable instruments. Its powerful motor is ideal for the particularly fast comminution of soft to medium-hard, brittle as well as fibrous materials and temperature-sensitive samples with an extremely fast sample throughput of up to 15 litres and more per hour, depending on the material and parameter settings. Overview of the premium features: - Powerful grinding with 22,000 rpm for particularly fast sample throughput - Max. feed size « 15 mm, sample throughput of up to 15 l/h and more - AutoLOCK grinding chamber for particularly safe work - Final fineness down to d50 « 40 μm, sieve rings 0.08 – 6 mm - Particularly good cooling of the grinding material - Pleasantly quiet operation - Very easy to clean due to Clean Design FRITSCH premium

Now with a new optical design - simple operation – fully automatic measurement! With the FRITSCH Laser Particle Sizers ANALYSETTE 22 NanoTec particle measurement becomes a simple matter, for professionals as well as for any employee – in production and quality control or in research and development. No prior knowledge is required. Just start the programme, select a SOP and add the sample – the rest takes place completely automatic. Fast. Reliable. Efficient. New optical design The very large measuring range of 0.01 µm up to 2100 µm of the ANALYSETTE 22 NanoTec results from the combination of two lasers with two different measuring cell detector spacings: Large particles are detected using an infrared laser with a large distance to the measuring cell, for small particles a green laser with a small distance to the cell is used, which permits the detection of the forward scattered light up to a scattering angle of 65°. The measurement of smallest particles down into the nano range is performed by the green laser light for backward scattering.

ANALYSETTE 28 ImageTec and ImageSizer! Both models of the Particle Sizer ANALYSETTE 28 ImageTec (wet measurement) und ImageSizer (dry measurement) are ideal for all applications where not only the particle size is measured but especially reliable statements about the particle shape are of importance. Via the optical analysis of particle shape and particle size, damaged particles, contaminates, agglomerates and oversized or undersized particles are identified accurately and fast, and can be viewed as single images. At the same time, the instrument offers a fast and efficient particle size measurement. The measuring time depending on the sample quantity, is under 5 minutes and the result is available immediately. This makes the ANALYSETTE 28 the perfect measuring instrument for the easy quality control, as well as for research and for laboratory tasks – and it is the fast alternative to sieving. Fast analysis of particle shape and size - Extra-wide measuring range, individually adjustable - High-performance

NEW: Planetary Mill PULVERISETTE 6 premium line! The new FRITSCH Planetary Mill PULVERISETTE 6 premium line has been developed as a ‚big sister‘ to the PULVERISETTE 7 premium line for fast and powerful wet and dry grinding, mechanical alloying, mixing and homogenising of larger sample quantities with reliable results down into the nano range. With double drive power, even faster comminution and a brand new automatic clamping of the bowls, the mill is easier and safer than ever to use. Overview of the premium features: - Extra strong 2.2 kW drive power and extremely high centrifugal acceleration - Brand new motor-driven grinding bowl clamping ServoLOCK - 2 working stations for grinding bowls with up to 500 ml volume - Tightly sealed grinding bowls even under overpressure - Touchscreen operation with colour display The Planetary Mill PULVERISETTE 6 premium line is ideal for size reduction of hard, medium-hard, soft, brittle, tough and moist samples. It is functionally designed to the smallest detail, even

Especially for the analytical sector and applications in the food and pharmaceutical indus FRITSCH Cutting Mills are ideal for size reduction of soft to medium-hard, tough-elastic and fibrous materials. The samples are comminuted by cutting and shearing forces, and the selected sieve cassette determines the desired final fineness. Various knife geometries and replaceable blades ensure maximum flexibility and durability. Your advantages with the FRITSCH Universal Cutting Mill PULVERISETTE 19 – completely in stainless steel: - Ideal for soft to medium-hard, tough-elastic and fibrous materials - Especially for the analytical sector, the food and pharmaceutical industry - Completely designed in stainless steel 316L – corrosion-resistant - Particularly resistant to alkalis, acids and media containing chloride - Easy operation and cleaning - Materials comply with the FDA and EU directives for the food and pharmaceutical industry NEW: The FRITSCH high-performance Cyclone separator – for optimal sample exhaustion! The compact FRITSCH high-performance

The NEW high-tech standard! The FRITSCH Variable Speed Rotor Mill PULVERISETTE 14 premium line offers impact, shearing and cutting comminution in one instrument – with a higher performance, better cooling and significantly quieter than comparable instruments. Its powerful motor is ideal for the particularly fast comminution of soft to medium-hard, brittle as well as fibrous materials and temperature-sensitive samples with an extremely fast sample throughput of up to 15 litres and more per hour, depending on the material and parameter settings. Overview of the premium features: - Powerful grinding with 22,000 rpm for particularly fast sample throughput - Max. feed size « 15 mm, sample throughput of up to 15 l/h and more - AutoLOCK grinding chamber for particularly safe work - Final fineness down to d50 « 40 μm, sieve rings 0.08 – 6 mm - Particularly good cooling of the grinding material - Pleasantly quiet operation - Very easy to clean due to Clean Design FRITSCH premium

ACHEMA 2015 - Hall 4.1 • Stand J 49 FRITSCH, an internationally respected manufacturer of application-oriented laboratory instruments for sample preparation and particle sizing, is again one step ahead. Convince yourself and discover the FRITSCH innovations live during ACHEMA 2015: Hall 4.1 • Stand J49! - high-tech laboratory mills for a wide range of applications - efficient sieve analysis - innovative particle sizing - well-conceived sample dividing, feeding and cleaning FRITSCH innovations in the field of size-reduction - Knife Mill PULVERISETTE 11 Ideal for fast gentle grinding and homogenising of moist, oily and fatty samples as well as of soft, medium-hard and fibrous materials – especially in the food industry. - Variable Speed Rotor Mill PULVERISETTE 14 premium line The new extra powerful Variable Speed Rotor Mill PULVERISETTE 14 premium line offers impact, shearing and cutting comminution in one instrument with extremely fast sample throughput of up to 15 litres and more

FRITSCH Planetary Mills premium line Discover with the new FRITSCH premium line a completely new dimension in high-tech milling. For the first time ever, never known before, rotational speeds and ultrafine grinding results down into the nano range are achieved. Due to the time-saving premium grinding bowl locking-system, the automatic checking of the locks in the mill, the blocking in event of impermissible operating states and the new automatic shut-off function in event of an imbalance, man and the machine are kept safer than ever. Grinding has never been as fast and safe! Your advantages with the FRITSCH premium line: FASTER With the FRITSCH premium line you can achieve for the first time revolutionary rotation speeds of up to 1100 rpm and a sensational acceleration of 95 times the force of gravity. The resulting energy application is roughly 150% greater than classic planetary mills. Your practical advantage: Tasks are more economical and considerably finer grinding results in shorter times

Often an extreme challenge Probably one of the most difficult tasks was the fine distribution of pure liquid mercury in a mixture of fine solid metal powders. Already during the manual mixing with a spatula, with careless work methods without a problem up to 3 mm large amalgam grains were produced. The solution was added to the Mortar Grinder PULVERISETTE 2, with an agate grinding set and special adjustments for the minimizing of the application of energy found. From the area of mixtures liquid – solid is the production of filled pastes to be mentioned. Especially challenging here is to add as much as possible solids in the high viscosity organic phase. An additional example for this is, when one has to add to organic binder (for example synthetic resin or varnish or in the simplest case oil) fine metallic, ceramic or inorganic powders. High viscosity pastes evolve which can be compared with shoe polish in a tube. Experts often talk about filled composite materials. Often the increase

Laser Particle Sizers from FRITSCH – Simple. Flexible. Reliable. In the field of paints and coatings the evaluation and verification of particle sizes are very important - as the particle size has a decisive influence on the colour and shade. Therefore the FRITSCH Laser Particle Sizers ANALYSETTE 22 are worldwide used. Benefit from its decisive advantages: extremely simple operation, short analysis times and consistently reproducible and reliable results. And of course getting the best value for your money. Your advantages with the ANALYSETTE 22 models: - Measuring range 0.01 – 2000 μm - Short measuring time - High measurement precision - Consistent reproducibility - Reliable comparability - User-friendly operation Two models for all applications Choose according to your needs: either the ANALYSETTE 22 MicroTec plus – the perfect all-round-laser with a measuring range of 0.08 – 2000 μm for all typical measurement tasks; or the ANALYSETTE 22 NanoTec plus, the highend instrument for measurements down

in the paint and coatings industry FRITSCH is an internationally respected manufacturer of laboratory mills for grinding and mixing of different materials and mixtures and for particle size analyses according to laser diffraction, dynamic light scattering, dynamic image analysis and sieving. Here a short view of the FRITSCH instrument ranges: - Mills for crushing, micro-milling, mixing, homogenising of hard-brittle, fibrous, elastic and or soft materials dry or in suspension - Instruments for particle size determination by means of static and dynamic light scattering, dynamic image analysis and sieving - Laboratory Instruments for representative dividing of dry and wet samples, controlled sample feeding, ultrasonic cleaning Laboratories worldwide count on our quality and experience – for the fast industrial application as well as for the especially accurate research technology applications in the industry- and research laboratories. In the paint and coatings industry, the Variable Speed

Straw, hay, dried plants; herbal teas are mostly very bulky samples. An average shopping bag contains 300 g straw or expressed like this: 100 g of uncomminuted straw take up the space of 1 to 2 litres. These materials are very voluminous. For the comminution only a cutting mill with a high rotor speed can be considered. So the choice is between the Cutting mill PULVERISETTE 15 and the Universal Cutting Mill PULVERISETTE 19. The reasonably priced Cutting Mill PULVERISETTE 15 is to be recommended if: • only a few samples per week are to be comminuted • the sample amount is small • the linear expansion has been reduced via chaffing for example • if a low carry over of sample material to the next sample is tolerable • more time for cleaning is available Are the recommendations in regards to cleaning and expenditure of time higher though, the Universal Cutting Mill PULVERISETTE 19 is implicitly to be recommended. Extremely positive effects

Reliable Automatic Sample Feeding The Vibratory Feeder LABORETTE 24 is ideal for automatic, uniform feeding of free-flowing materials into sample dividers, mills or mixers in your laboratory. The vibration, which is controlled by a microprocessor, conveys the sample material out of the funnel over the V or U-shaped stainless steel channel into the respective equipment. The flow rate can be individually adjusted; the vibration amplitude is precisely controlled – for absolute uniform feed of even smallest quantities. Safe and reliable. Suitable for both: coarse and fine materials which can be conveyed reproducibly with a material feed between 1 g/min up to 2.500 g/min. Your advantages with the NEW control unit: - Setting of the maximum feed quantity in the setup mode by the user - Adjustment of the feed intensity and time via display - Fine adjustment of the material flow even of smallest quantities - Reproducible setting of the feed rate, when changing the material - Digital display of

Powerful size-reduction absolutely reproducible with digital gap width setting via display The premium model of the FRITSCH Disk Mill for efficient fine grinding of hard-brittle to medium-hard solids: Even safer due to the automatic locking of the collecting vessel and grinding chamber, even easier to operate due to the convenient motor-driven grinding gap adjustment with digital gap display. A well-designed display shows all of the parameters. Ideal for medium particle sizes in the areas of mining and metallurgy, ceramics industry, rocks and soils, glass industry, soil research. In the Disk Mill, the material to be ground is comminuted by pressure and shearing action between two counteracting grinding disks with coarse interlocking teeth. The ground material automatically falls down through the pre-set grinding gap into the collection drawer. The desired final fineness can be defined reproducibly by simply adjusting the digital setting of the gap width. Efficient premium fine grinding - Easy, motor-driven grinding gap adjustment with digital gap

Fast. Safe. Easy. - Discover the Possibilities! The new ANALYSETTE 28 ImageSizer is the ideal instrument for analysis of particle shape and size of dry, free-flowing powders and bulk solids in a measuring range from 20 µm to 20 mm. Via the optical analysis of particle shape and particle size, damaged particles, contaminates, agglomerates or oversized- or undersized-particles are recognized accurate and fast and can be viewed as single images. At the same time, the instrument offers a fast and efficient particle size measurement. The measuring time, depending on the sample quantity, is below 5 minutes and the result is available immediately. This makes the ANALYSETTE 28 ImageSizer the perfect measuring instrument for the easy quality control, as well as for research and for laboratory tasks – and it is the fast alternative to sieving. Fast and Economic Alternative to Sieving If you perform many and frequent sieve analyses, the ANALYSETTE 28 ImageSizer is the ideal, time-saving alternative in just three motions:

For powerful size reduction of a feed size of 95 mm down to 0.05 mm in a single step! For especially fast continuous premium pre- and fine-grinding of large quantities of coarse material, the combination of the Jaw Crusher PULVERISETTE 1 premium line and the Disk Mill PULVERISETTE 13 premium line is the ideal solution. Together, they form an efficient, heavy-duty, high-performance grinding instrument with integrated Riffle Sample Splitter. This gives you the full range of opportunities for optimal sample preparation with a feed size of up to 95 mm and final fineness of down to 0.05 mm – all in a single step. premium combination for integrated pre- and fine-grinding - Powerful continuous pre- and fine-grinding - Compact in a single instrument with integrated Riffle Sample Splitter - High throughput for production of small amounts - Maximum feed size 95 mm - Minimum final fineness 0.05 mm Integrated representative sample division After the comminution in the Jaw Crusher PULVERISETTE 1 premium line, the ground material falls directly into the

FRITSCH EASY GTM - Gas pressure and temperature measuring system Transform your Planetary Ball Mill into an analytical measuring system by using two EASY GTM-bowls with special lids and a transmitter as well as a receiver board. The receiver unit needs only to be inserted and adjusted just once – regardless of the number of EASY GTM-bowls used. It enables the simple and easy monitoring of thermal effects, physical and chemical reactions or increase or decrease in pressure due to continuous measurement of gas pressure and temperature directly in the grinding bowl. And the mill is automatically controlled in a manner that the set parameters are not exceeded. The new FRITSCH EASY GTM grinding bowls are available in agate, sintered corundum, silicon nitride, zirconium oxide, stainless steel, tempered steel and hardmetal tungsten carbide with a bowl volume of 80 ml.

Unmatched ease of cleaning Ideal for size reduction of soft to medium-hard, tough-elastic and fibrous materials as well as for heterogeneous mixtures. They are indispensable in the areas of environment, plastics, agriculture, forestry, construction materials, textiles, chemistry and as well as for analytic and sample preparation for RoHS-analysis. Unmatched ease of cleaning A particularly important criterion for a Cutting Mill is the question how fast and easy it can be cleaned in daily laboratory use. Therefore we have placed particular value on the easy cleaning when we developed the FRITSCH PULVERISETTE 19. While you are still tightening the screws on other mills, your FRITSCH Cutting Mill is already clean! Because the entire grinding chamber can be opened easily in seconds and both the rotor and the sieve can simply be removed with simple motions. Only at FRITSCH Cutting Mills it is possible to lift open the entire top part of the housing as well as the door – in fact, the door

The premium version with very high throughput The most powerful FRITSCH Jaw Crusher ever: up to 3 kW drive power ensure an exceptionally high throughput during pre-crushing of hard or very hard, brittle materials. For easy cleaning, the crushing jaws can be completely swivelled out or removed. The integrated dust exhaust channels provide optimal working conditions. And with two models, you can choose the Jaw Crusher that is perfect for your feed size and your sample quantity. Ideal for pre-crushing in the areas: Mining and metallurgy, chemical industry, geology and mineralogy, glass and ceramics industry and soil research. As with all of the instruments in the FRITSCH premium line, we’ve put a great deal of thought into how to make your daily work even easier and time-saving: FRITSCH premium advantage: Only the PULVERISETTE 1 premium line has a completely accessible grinding chamber, because the fixed crushing jaw is mounted in a guide and can be removed with a single motion. Also the movable crushing

High performance in minimum space FRITSCH Planetary Mills of the classic line are ideally suited for wet and dry comminution of hard, medium-hard, brittle and fibrous materials. Samples can be processed from a few milligrams to several kilograms at a wide range of fineness levels down to less than 1 μm. They are absolutely reliable, especially easy to operate and clean. Matching grinding parts of various materials are also available to provide maximum protection against undesired contamination of the samples. The Planetary Mono Mill PULVERISETTE 6 classic line is a high-performance Planetary Ball Mill with a single grinding bowl mount and practical, easily adjustable imbalance compensation. Your advantage: Particularly easy use and high-energy effect up to 650 rpm. This ensures a constantly high grinding performance with extremely low space requirements for loss-free grinding results even in suspension. The electronic timer adjustable to one second and the programma-ble, automated reversing

ideal for wet and dry grinding, mechanical alloying and activation FRITSCH Planetary Mills classic line are the most effective laboratory mills for rapid loss-free ultra fine grinding down to colloidal fineness of hard to soft materials dry or in suspension. In addition to Comminution, you can also use them for mixing and homogenising of emulsions and pastes or for mechanical alloying and activation in materials research. Your advantages with FRITSCH Planetary Mills classic line - Fast grinding to below 1 μm - Up to 800 rpm - Safe clamping of the bowls with the Safe-Lock-System - Simple, ergonomic handling and easy cleaning - Grinding bowls and balls in 8 different materials to suit all needs and avoidance of contamination through abrasion – maximum protection against undesired contamination of the samples - Consistent reproducibility - Long, reliable service life even under continuous, heavy duty usage Ideal for Comminution of samples with a maximum feed particle size of up to 10 mm and a sample quantity of 0.5

ideal for grinding of tablets, dragées and pharmaceuticals The FRITSCH Variable Speed Rotor Mill PULVERISETTE 14 grinds rapid and effectively soft to medium-hard, brittle as well as fibrous samples. Even the comminution of samples, which are difficult to grind or temperature-sensitive samples like tablets, dragées and pharmaceuticals are no problem for the PULVERISETTE 14 due to its very efficient air cooling. In addition to the special air cooling of the PULVERISETTE 14, we have developed the FRITSCH-impact blades: Due to its clever design it allows together with a sieve ring a very gentle grinding of the sample, which in many cases without impact blades would not be possible. The result: Increased grinding action for a particularly fast and effective grinding, the heat load is minimized. And the ideal solution for especially temperature-sensitive materials such as powder coatings or plastics, as well as for smoothly pre- and fine grinding of hard-brittle to soft, fatty sample or samples with a residual moisture! The

The premium version with very high throughput The most powerful FRITSCH Jaw Crusher ever: up to 3 kW drive power ensure an exceptionally high throughput during pre-crushing of hard and very hard brittle materials. The crushing jaws are completely retractable resp. removable for easy cleaning. And the integrated dust exhaust channels provide optimal working conditions. Ideal for pre-crushing in the areas: Mining and Metallurgy, chemistry, geology and mineralogy, glass industry, ceramics industry, rocks and solids. Overview of the premium features: premium Extra powerful with up to 3 kW drive power premium Extremely robust for toughest loads premium Easy zero-point and gap width adjustment via double eccentric premium Well-conceived Clean Design for easiest cleaning – with integrated dust exhaust channels and removable fixed and completely retractable movable crushing jaw premium Optimal sound insulation due to foam-filled side walls Absolutely simple and reproducible to operate: The gap width adjustment

FRITSCH - Milling and Sizing! FRITSCH, an internationally respected manufacturer of application-oriented laboratory instruments for sample preparation and particle sizing, is again one step ahead. Convince yourself and discover the new models of the FRITSCH premium line as well as further interesting innovations in the field of particle sizing live during POWTECH 2013 - Hall 5 • Booth 5-362 FRITSCH Size-reduction Discover the new dimension in grinding with the new high-tech laboratory mills FRITSCH premium line: - Jaw Crusher PULVERISETTE 1 premium line The most powerful FRITSCH Jaw Crusher ever: up to 3 kW drive power ensure an exceptionally high throughput during pre-crushing of hard and very hard brittle materials. - Disk Mill PULVERISETTE 13 premium line For efficient fine grinding of hard-brittle to medium-hard solids: even more powerful and safer with easy reproducible gap width setting via display. You should be excited! FRITSCH Particle Sizing Discover the new dimension

The most precise way of sample division - guaranteed of up to 99.9 % A perfect sample preparation is the indispensable foundation for every analysis – because any errors will be reflected in the results later on. Therefore the reliable creation of guaranteed representative subsamples plays an absolutely central role. The FRITSCH Rotary Cone Sample Divider LABORETTE 27 offers the ideal conditions: it is the only sample divider on the market dividing your samples with up to 3,000 dividing steps per minute centred over a rotating dividing cone into up to 30 separate channels. Each individual sample with identical chemical and physical properties – and with 99.9 % accuracy for many more sample materials than any other similar method. The best sample division, possible today. The FRITSCH ADVANTAGES - The sample delivery funnel guides the sample material exactly centred on the tip of the rotating cone – for even more accuracy during sample division. - Division of liquid samples – without modification – by simply repositioning

FRITSCH Laser Particle Sizers: Simple. Flexible. Reliable. Worldwide the Laser Particle Sizers ANALYSETTE 22 ensure precise determination of particle size distributions, by Static Laser Scattering – in production and quality control as well as in research and development. Benefit from their decisive advantages: extremely simple operation, short analysis times and consistently reproducible and reliable results. NEW: Small Volume Wet Dispersion Unit Ideal for measurements in organic solvents or if only minimal sample quantities are available. The Small Volume Wet Dispersion Unit is suitable for all kinds of dispersion liquids and needs less than 50 ml liquid for the whole measuring circuit. Automatic measurement, rinsing and analysis are guaranteed. - Strong 100 watt (!) ultrasonic power, controllable - Automatic Rinsing for fast cleaning - Liquid circulation system without dead space - All functions are SOP-controlled Choose according to your needs! The NEW Small Volume Wet Dispersion Unit can be combined with

Versatile use - gentle fine grinding - simple working - easy cleaning - practical cryogenic grinding Thanks to its special mode of operation, the FRITSCH Mortar Grinder PULVERISETTE 2 is the ideal universal grinder in the laboratory – for analysis, quality control and materials testing as well as for the mixing and homogenisation of pastes and creams on a laboratory scale. Its particularly gentle grinding by friction with almost no thermal load is ideal for the preparation of tablets in galenics. Using liquid nitrogen it also grinds difficult-to-mill samples with moist, fibrous or elastic structures. And the PULVERISETTE 2 is also ideally suited for mixing of solids or liquids and solids. With brief, reliably reproducible grinding and mixing times, it is loss and dust free. For final finenesses of between 10 and 20 μm, with a feed size of 6 – 8 mm and a max. sample quantity of up to 190 ml. The FRITSCH Advantages: - Easy setting and re-adjustment of the pestle pressure on the mortar wall – for perfect grinding. - The essential downward pestle pressure

Fine comminution and sieving in one unit! The FRITSCH Vibratory Micro Mill PULVERISETTE 0 is the ideal laboratory mill for fine comminution of medium-hard, brittle, moist or temperature-sensitive samples – dry or in suspension – as well as for homogenising of emulsions and pastes. For perfect, loss-free grinding results in shortest times! Ideal for - Chemical analysis: Electron microscopy - Environmental research: Soil samples, comminution of botanical materials – also possible deep frozen - Pharmaceuticals and medicine: Ophthalmological agents, gels, creams, extracts, drugs, pastes, dragées, tablets - Biotechnology: Tissue samples, botanical matter - Forensic analysis: Teeth, bones - Materials technology: Pigments, precious materials, new materials - RoHS: Mobile phone circuit boards, mobile phone cameras, mobile phone LCD glass panels, mobile phone keypads, electronic chips, LCD diffusion panels Cryogenic grinding For fast embrittlement of soft, slightly oily, fatty or moist materials

The smallest instrument for small quantities! The ultra-compact FRITSCH Mini-Mill PULVERISETTE 23 is the ideal assistant for fine comminution of smallest quantities – for wet grinding as well as for dry or cryogenic grinding. Its special, spherical grinding bowl ensures much better performance in grinding, mixing and homogenising compared with similar models. With a footprint of just 20 x 30 cm and a weight of 7 kg, it easily fits anywhere. It’s smart, is extremely user-friendly, inexpensive, and convinces with impressive results: small, fast, effective. For perfect, loss-free grinding results in shortest times! Ideal for Chemical analysis: Comminution and homogenisation of grinding samples for creation of compacts for x-ray fluorescence and infrared spectroscopy (e.g. potassium bromide tablets) Environmental research: Soils in contaminant analysis, humic acid determination, botanical materials in residue analysis of fertilisers and pesticides, pulping of seeds Pharmaceuticals and medicine: Kidney

Manual. Hydraulic. Easy! Manual hydraulic Pellet Press for the preparation of pellets with a smooth, homogeneous surface for spectral analyses such as X-ray fluorescence analysis or infrared spectroscopy for elementary analysis. Ideal for the manufacturing of both: solid and highly permeable pellets of solid samples – fast and easy. Pellet press – ideal for high-quality pellets • Pressing tools: 40 mm diameter included, 32 mm diameter optional • Variable pressure force up to 250 kN • Clearly designed pressure force display in 10 kN steps • Simple operation via hand lever • Easy cleaning • Single-stage piston stroke of max. 25 mm • Automatic pressure relief in case of overstress • Solid and compact with impact-resistant cladding The pressure force is variable up to max. 250 kN and is automatically relieved in case of overstress. The pressing tool for pellets with 40 mm diameter is included in delivery, a 32 mm diameter pressing tool is optional. It"s

Stronger. Faster. Better! The new, completely modified FRITSCH Vibrating Cup Mill PULVERISETTE 9 offers many practical advantages in all areas in which hard, brittle and fibrous material must be ground extremely quick down to analytical fineness. The Vibrating Cup Mill is indispensable for all areas in which hard, brittle and fibrous materials must be ground extremely quick down to analytical fineness. And ideal for fast sample preparation, such as in the areas of spectroscopy preparation, ore and geology laboratories, mining and metallurgy, ceramics industry, agriculture and environmental science, infrared and x-ray fluorescence analysis. Now with increased grinding power and a completely new drive concept, even safer and easier to tension the grinding set, especially quiet, simple to operate and quick to clean. For perfect, loss-free grinding results in shortest times! Easy working No similar mill offers a more convenient operation: The working position is ergonomically optimised; the

The 4th Innovation-Award during the POWTECH 2011 for innovative products For the 4th consecutive time, the media brands PROCESS, PharmaTEC and Schüttgut presented the Innovation-Award during the POWTECH/TechnoPharm 2011 in October. This price recognizes manufacturers for trend-setting new products. Every one and a half year this competition is held during the trade fair of the bulk industry and the publishing company Vogel. A panel of experts selects from the submitted nominations initially three short-list candidates and then a winner. Sought-after were the most innovative instruments and procedures from various categories for example basic procedures for powder and bulk solids or apparatus manufacture and process techniques. Among 70 submitted applications, FRITSCH convinced the jury in the category Particle/ Material Analysis and Characterization and won the Shortlist-Award with the Laser Particle Sizers NanoTec plus and MicroTec plus. Important criteria in order to be considered for the final selection: The introduced solutions,

Optimal for comminution with minimal cleaning effort Ideal for size reduction of soft to medium-hard, tough-elastic and fibrous materials as well as for heterogeneous mixtures. They are indispensable in the areas of plastics, textiles, agriculture, forestry, environment, construction materials, chemistry and foodstuffs as well as for analytic and sample preparation for RoHS-analysis. Unmatched ease of cleaning A particularly important criterion for a Cutting Mill is the question how fast and easy it can be cleaned in daily laboratory use. Therefore we have placed particular value on the easy cleaning when we developed the FRITSCH PULVERISETTE 19. Unbeatable fast, simple and efficient cleaning! The entire grinding chamber can be opened easily in seconds and both the rotor and the sieve can simply be removed with simple motions. Only at FRITSCH Cutting Mills it is possible to lift open the entire top part of the housing as well as the door – in fact, the door can be completely removed. And that’s not

Improved sieving effect for faster results - and the most efficient wet sieving! We have developed a new clamping lid with 2 rotation nozzles for wet sieving with test sieves 200 mm/8“ dia. This special FRITSCH wet sieving lid enables due to its 2 permanently rotating nozzles a better and uniform spraying of the material to be sieved from above. Special interposed sieving rings with three nozzles are available for simultaneous spraying of the top and bottom sieves. Your benefit: improved sieving effect and faster results in shorter times! The FRITSCH Sieve Shakers: convenient, precise, reliable! - Dry, wet and micro-precision sieving - Simple, ergonomic operation - Fast, reproducible results - Sample quantities between 0.05 g and 6 kg - Sieve diameter from 100 mm to 450 mm - Mesh widths from 5 µm – 125 mm - Can be used as testing equipment according to DIN EN ISO 9001 - Automatic sieve evaluation with free-of-charge AUTOSIEVE software Well-conceived Sieve Shakers with FRITSCH concepts that make the work simpler and faster – easy

Optimal for fine grinding of temperature-sensitive samples and for higher throughput! The FRITSCH Variable Speed Rotor Mill PULVERISETTE 14 grinds rapidly and effectively soft to medium-hard, brittle as well as fibrous samples. Due to its very efficient air cooling and the cyclone, even the comminution of difficult to grind samples like temperature-sensitive powder coatings and plastic samples or slightly moist materials such as herbs, leaves or teas are no problem for the PULVERISETTE 14. The efficient air routing inside the PULVERISETTE 14 and the powerful air vortex within the FRITSCH Cyclone cools the sample during grinding, reduces the thermal load of the sample, minimises clogging of the sieve rings while simultaneously increasing the throughput significantly. Also, the cleaning of the mill itself is reduced to a minimum. The air flow inside the FRITSCH Cyclone leads the ground sample directly into the screwed-on sample glass. This type of sample discharge is the most convenient, because the ground material is drawn directly into the glass

Cutting Mill P-19 with cyclone - optimal for the preparation of the lignocellulose materials However, in the past months and years bio fuels had the reputation to generate a social- und environmental dilemma. For example, in developing countries large areas were cleared and used for sugar cane bio fuel monocultures or similar and therefore were at the same time unintentionally in competition with the production of food. Inevitably, this well known problem leads to the development of more climate friendly and socially acceptable uses of second generation bio fuels. For the production of the second generation bio fuels not the starch respectively oil containing plant parts are used, but rather only the cellulose-containing parts of the plant. This means the starch containing plant parts, like for example the maize kernels, can still be used for the production of food. Bio ethanol is produced and obtained via bio catalysis (fermentation) and bio process technology. In order to run such well-engineered bio process technology plants, as a rule, a preparation

for grinding of soft to hard-tough samples, fibrous materials as well as plastics. Typical fields of application: waste recovery and waste disposal, garbage (non metallic), computer and electronic scrap, batteries, wood, plants, bones, horn, compacted sewage sludge, plastic profiles, rolling hides, rubber, leather, cardboard, coal The PULVERISETTE 25 is an extremely powerful cutting mill, which can also be used for pre-crushing. Different configurations enable an optimal adjustment of the system to the application. The casing can be opened by a central shutter with one hand. For easy cleaning and changing of the sieve cassette the casing top and the cover can be opened and the cover is additionally removable. Technical Data Power Cutting Mill PULVERISETTE 25 max. feed particle size: 120 x 85 mm Throughput: up to 85 kg/h Sieve inserts: 1 – 10 mm

ideal for rapid loss-free ultra fine grinding down to colloidal fineness The planetary mill with one working station offered by Fritsch Gmbh, Germany for fine-grinding of laboratory samples down to < 1 µm as well as for mixing, homogenising, emulsifying and alloying. With this universal mill the sample preparation and the sample analysis have again equal rights on the laboratory bench. Typical fields of application: geology, mineralogy, metallurgy, soil research, electrical industry, chemistry, ceramics industry, glass industry, nuclear research, pharmacy research. The PULVERISETTE 6 is a planetary ball mill with one grinding station and an internal unbalance compensation. Because of the high ball acceleration a significantly higher comminution rate is achieved compared with centrifugal ball mills. The comminution in closed vessels guarantees loss-free milling (including suspensions). All grinding parameters, like grinding time, interval-, break times and rotational speed are adjustable via membrane keyboard. Grinding bowls

for grinding of soft to medium-hard samples, fibrous materials as well as plastics Typical fields of application: Rubber, leather, paper, cardboard, tissue, plastics (in pieces, profiles, tulic, strips), wood, waste (non metallic), coal, animal feed (also pellets), maize, grain, confectionery, malt, farinaceous products, spices, meat (dried), bones, horn, dragees, leaves (dry), fibres, straw, peat, roots, tobacco, cork. The PULVERISETTE 19 is a rapidly running cutting mill. Different funnels, rotors, sieve cassettes and collecting vessels enable an optimal adjustment of the system to the application. A sample exhauster with cyclone dust chamber can be used for materials which are difficult to grind. The casing can be opened by a central shutter with one hand. For easy cleaning and changing of the sieve cassette the casing top and the cover can be opened and the cover is additionally removable. Technical data PULVERISETTE 19 Funnel opening: 70 x 105 mm max. feed particle size: 70 x 80 mm Throughput: up to 60 kg/h Sieve inserts: 0.25 – 6 mm

PULVERISETTE 5 classic line With this modified universal mill the sample preparation and the sample analysis have again equal rights on the laboratory bench. The well-known and reliable Planetary mill reduces hard to soft sample dry or in suspension down to final fineness of < 1 µm and now with the following new and very interesting modifications. - Synchronous toothed belt drive of the bowls to guarantee a slip-free and constant transmission ratio between the bowls and main disc - automatic reverse (direction of rotation reversed periodically) to improve the grinding results - unbalance detection. If the unbalance is too great, the instrument switches off - New smaller housing in the equipment family design with most innovative technology - bench top model with 25% smaller footprint - lighter in weight - Integral fan located in the grinding chamber for additional cooling permits longer grinding process. Naturally, the tried and tested features of its predecessors, like maintenance-free

Fast, safe, simple - easy to clean! With decades of experience in the production of cutting mills we have invested our vast experience in our latest model achieving significantly improved grinding material feeding and ground material recovery. The head of our laboratory is justifiably excited by there improvements. Typical fields of application: Grinding of soft to medium-hard dry materials and fibrous materials or materials containing cellulose including rubber, leather, paper, cardboard, textiles, plastics, wood, metal-free waste, coal, feedstuffs, maize, grain, confectionery, malt, noodles, herbs and spices, dried meat, bone, horn, pills, tablets, foliage, fibres, peat, roots, tobacco, cork. Straw, stalks foils and similar long, thin samples can be fed full-length into the instrument. Method of operation: In the grinding chamber of the PULVERISETTE 15 laboratory cutting mill, four knives rotate against three stationary knives in the cutting action to reduce the sample. The material remains

Unique: with variable transmission ratio In contrast to conventional Planetary Mills, the rotational speed of the grinding bowls and supporting disk can be configured separately in the PULVERISETTE 4 classic line. Advantage to you: A single mill for mechanical activating and alloying and material research providing optimum grinding conditions suited to the respective material to be ground and the size of the grinding bowls and balls! For results that cannot be achieved with other Ball Mills. Method of operation: With standard planetary ball mills the grinding bowls are rotating and mounted eccentrically on a rotating support disc. The rotational speed of the supporting disc can be selected at will; the grinding bowl rotates at a fixed transmission ratio. Due to the overlapping of grinding bowls and supporting disc, the material to be ground and the grinding balls execute movements and trajectories in the grinding bowl, which are defined by the transmission ratio. With the PULVERISETTE 4 classic line

Grinding with the Vibratory Micro Mill PULVERISETTE 0 Relatively new on the market are scented toys. Not only do these substances smell good, but they also possess an allergenic potential. It exists EU directive in regards to the regulation of chemical safety of toys was passed. The contained critical values are by all means questionable. Derived from this difficulty the task was drafted, to comminute a sample of a “scented toy horse” in such a manner so that a powder evolves. The scents can not be lost though. Scents are relatively slightly elusive in order to be smelled. Therefore it has to be assumed that with the amplification of the surface, a faster transition into the ambient air occurs. Therefore the substances would elude analysis. In order to avoid this to the greatest possible extend, the sample was comminuted during permanent cooling with liquid nitrogen. For this 8 x 8 mm large chunks were cut from the toys and comminuted with the Vibratory Micro Mill PULVERISETTE 0, equipped with a cryo-box,

the compact pre-crusher Ideal as the classic workhorse for pre-crushing of brittle materials in the areas of mining and metallurgy, chemistry, geology and mineralogy, glass industry, ceramics industry, rocks and soils. The compact FRITSCH Jaw Crusher PULVERISETTE 1 is the ideal instrument for fast and effective pre-crushing of hard and very hard brittle materials – even ferrous alloys are no problem for this instrument! The powerful comminution of the sample takes place in the Jaw Crusher under high pressure between one fixed and one movable crushing jaw in an enclosed grinding chamber. The final fineness is easily set from the outside with the 10-stage adjustable gap width between the crushing jaws. The ground sample automatically falls downward – into a drawer for batchwise comminution or via a chute into a larger collection container for continuous operation or directly into a FRITSCH Disk Mill PULVERISETTE 13 for further comminution. Your advantages with the FRITSCH Jaw Crushers: -

Size reduction of very hard materials with a feed size < 100 mm down to 0.1 mm final fineness Wherever large pieces of brittle samples had to be prepared for analysis, many laboratories employed a jaw crusher such as Fritsch"s PULVERISETTE 1 for the pre-crushing stage, since the original feed size was too large to be handled by the final grinding mill. Previously samples could not be prepared for analysis in a single operation because a jaw crusher could not achieve an adequate product fineness and because grinding mills can only handle a limited range of feed size. Fritsch have applied themselves to this particular problem and have developed a disk mill PULVERISETTE 13. In a relatively short processing time this mill can reduce material of a preset grain size to a fineness of minimum 0.1 mm even when processing relatively large samples (up to 20 mm edge length). If the required fineness is of this order but the samples supplied to the laboratory include pieces with an edge length of over 20 mm, Fritsch can supply the perfect solution for this problem: Both

with the Mortar Grinder PULVERISETTE 2 In the pharmaceutical technology (formerly galenics) one is occupied with the production of various pharmaceutical forms like for example tablets, pastilles or dragées. In these the desired active pharmaceutical ingredients are added. In order to verify in regards to quality management that the desired amount of pharmaceutical ingredients was added in a tablet, an element analysis is performed. Hereby the tablet is pulverized. With the mortar mill FRITSCH PULVERISETTE 2, 10-20 tablets are ground. In order for no ingredients to disappear due to the application of energy, the mortar mill is the proper choice. The grinding action of the pestle does not increase the temperature during the grinding process. The pharmaceutical ingredients remain constant. After a grinding duration of 1-5 minutes a homogenous powder is achieved with a particle size of < 100µm. We recommend grinding sets made of agate or hard porcelain. Even dragées or coated tablets may be ground. But

FRITSCH EASY GTM - Gas pressure and temperature measuring system Transform your Planetary Ball Mill into an analytical measuring system by using two EASY GTM-bowls with special lids and a transmitter as well as a receiver board. The receiver unit needs only to be inserted and adjusted just once – regardless of the number of EASY GTM-bowls used. It enables the simple and easy monitoring of thermal effects, physical and chemical reactions or increase or decrease in pressure due to continuous measurement of gas pressure and temperature directly in the grinding bowl. And the grinding process is automatically controlled in a manner that the set parameters are not exceeded. The new FRITSCH EASY GTM grinding bowls are available in tempered steel, hardmetal tungsten carbide and zirconium oxide with a bowl volume of 80 ml.

unlocks new possibilities, which otherwise would not be possible Available only with FRITSCH Cutting Mills: The patented FRITSCH sample exhauster with Cyclone separator with its based on negative pressure powerful vacuum function, ensures a simple feeding, fast throughput and a good cooling, effectively prevents sample material from escaping during feeding and unlocks up new possibilities in the processing of heterogeneous mixtures of materials, like for example derived fuels in the cement industry. Also this is only possible with FRITSCH Cutting Mills: While you are still tightening the screws on other mills, your FRITSCH Cutting Mill is already clean. Because the entire grinding chamber can be opened completely and all grinding parts can be removed for cleaning in just a few seconds without tools – unbeatable fast, simple and efficient! This makes the FRITSCH Cutting Mills the ideal, time-saving assistants in the comminution of soft to medium-hard as well as fibrous or also tough materials. They are indispensable in

AEO-F - Authorized Economic Operator A seal of quality identifies the FRITSCH GmbH • Milling and Sizing since the end of October 2008, as a `safe partner in trade” towards custom offices and customers. In regards to the safety initiative of the European Union was the status of the so called Authorised Economic Operator implemented Europe wide on January 1st, 2008. The international supply chain from the manufacturers of a product to the end user will therefore become safer. An Authorized Economic Operator possesses a special status: They are recognized by custom administrations as especially safe, dependable and trustworthy. Here special advantages in regards to customs transactions may be claimed – which in transboundary trade can lead to time and cost saving advantages. As one of the first manufacturers of application-oriented laboratory instruments, the FRITSCH GmbH • Milling and Sizing, received the status of an Authorized Economic Operator. The FRITSCH Company was awarded the

FRITSCH Planetary Mills classic line are the most effective laboratory mills for rapid loss-free ultra fine grinding down to colloidal fineness of hard to soft materials dry or in suspension. In addition to Comminution, you can also use them for mixing and homogenising of emulsions and pastes or for mechanical alloying and activation in materials research. Your advantages with FRITSCH Planetary Mills classic line - Fast grinding to below 1 μm - Up to 800 rpm - Safe clamping of the bowls with the Safe-Lock-System - Simple, ergonomic handling and easy cleaning - Grinding bowls and balls in 8 different materials to suit all needs and avoidance of contamination through abrasion – maximum protection against undesired contamination of the samples - Consistent reproducibility - Long, reliable service life even under continuous, heavy duty usage Ideal for Comminution of samples with a maximum feed particle size of up to 10 mm and a sample quantity of 0.5

The matured timber statute dedicates itself with the utilization and application of matured timber. It especially includes rules concerning analysis for the examination of matured timber in regards to heavy metals (lead, cadmium, chromium etc.) arsen, as well as PCP and PCB (pentachlorophenol and polychlorinated biphenyl). For the sample preparation (after a suitable sampling) a composite sample of 500g is needed. This is divided into two subspecimens. After drying, the sample is reduced with the universal cutting mill FRITSCH-PULVERISETTE 19 or with the power cutting mill FRITSCH PULVERISETTE 25, down to < 2mm. The obtained homogenous sample is perforated with aqua regia and then with ICP-OES or AAS analysed.

Quality and process standards assurance Clays, chamottes and ceramics are used in various ways and must therefore be in accordance with different degrees of quality standards. These quality standards have especially in recent years gained in significance for the processing industry and therefore at the same time for the producers of such chamottes and ceramics. Based on the risen quality standards more and more often, the crude materials and also the finished products are more precisely analyzed. Considered are the classic chemical and physical variables, as well as the technological data of crude materials and finished parts like for example Geochemical and mineralogical composition, Thermal endurance, Heat conductance & coefficient of thermal expansion, Breaking resistance & flexural strength. Based on the very inhomogeneous composition of clays, which are mostly composed of various clay minerals, a sample preparation in a clay and ceramics laboratory for further analytical use via x-ray fluorescence,

Your FRITSCH Cutting Mill is already clean! Available only with FRITSCH Cutting Mills: All grinding parts can be removed for cleaning in just a few seconds without tools – unbeatable fast, simple and efficient! This makes them ideal, time-saving assistants in the comminution of fibrous and tough materials, plastics and heterogeneous mixture of materials and for sample preparation for RoHS and WEEE analysis. You may browse experience oriented examples as well as comparison grindings online at www.fritsch.de in the area SOLUTIONS. YOUR ADVANTAGES WITH FRITSCH CUTTING MILLS - Especially simple operation for fast work - Unmatched ease of cleaning thanks to patented quick opening facility - Optimum airflow for particularly fast grinding and secure protection against clogging - More stable running and low wear due to the patented double cone bearing of the rotor - Exceptionally long service life through use of replaceable and fixed knives - Unique grinding chamber geometry: minimal dead space and progressive

Sample Preparation for the analysis The last months showed that there is a specific need for the careful inspection and analysis of various toys. Especially the cases of toxic lead in paints. Lead is a toxic heavy metall. Approx. 90% of the incorporated lead is deposited in the bones and the teeth. Because lead is released very slowly, it will be accumulated over the time in the body. This is dangerous especially for children. The European Norm EN 71-3 regulates the limit of lead in toys. Furthermore the US norm ASTM F 963-07 regulates the concentration of lead in paints and coatings for toys (max. 600mg/kg). For the analyses, if toys fulfil these norms, the samples must be grind for example with FRITSCH cutting mills. For the pre-grinding we use the Universal Cutting Mill PULVERISETTE 19 or the Power Cutting Mill PULVERISETTE 25. The main advantage of these mills is, that you can remove all grinding parts without an additional tool. This makes them very easy to clean and cross-contaminations are

Optimal sample preparation for the RoHS/WEEE Analysis Considering the characteristics of materials used for the construction of a cell phone the whole spectrum of hard-tough to hard-brittle up to soft, tough-elastic materials is found. Mentioned should be metals, ceramic parts and the most various plastics. Whereas the hard-brittle materials are easily ground with impact energy, the comminution of tough-elastic materials is only achieved with cutting force. Tough-elastic materials may be embrittled with liquid nitrogen and then ground with impact force. The Power Cutting Mill PULVERISETTE 25 was chosen as the first level of comminution of a complete cell phone. Once reduced to 10 mm the Vibrating Cup Mill PULVERISETTE 9 was supposed to complete the rest. This experiment was unsuccessful. Therefore the PULVERISETTE 25 with a 4 mm sieve was used again. For the next level, the Universal Cutting Mill PULVERISETTE 19 was chosen. With cutting tools made of hard metal tungsten carbide the remainder was comminuted down

Sample preparation - one of the most important steps in the Laboratory Progress is chemical analysis technology has produced equipment with astonishing performances. To illustrate this performance, comparisons are often made such as „Our measuring equipment can detect a cube of sugar which has been dissolved in Lake Constance“. This may be true as far as the detection capability is concerned, but does this really tell us anything? All too often, expensive analytical instruments are purchased without due regard to the collection and preparation of the sample to ensure that the analysis is carried out on a homogeneous, representative, reproducible and uncontaminated sample. Unless the sample is reduced in size and accurately sub-divided without risk of contamination, we cannot be certain that sampling error may be greater than measuring error! Returning to the question of the sugar cube, how was Lake Constance stirred? From which location was the sample taken? This is why we are offering our 80 years of experience as a company
