News items August 2005

for very thorough emptying of residues If it is important to have very high residual emptying rates, the amixon® conical mixers and mixer-dryers are particularly appropriate. Together with the patented "sliding blades", the conical base ensures residual emptying rates of almost 100%. With the "sliding blades", the mixing gear is tilted to a horizontal position. This improves removal of the product residues. Otherwise, the same requirements related to and governing the technical aspects of the process apply as have already been described for the vertical vacuum mixer-dryers with flat bases. Laboratory and Trials The Alloy and Hastelloy drying equipment in the amixon® Laboratory are already part of the apparatus manufacturer`s standard equipment. This offers a major advantage to all manufacturers and future customers interested in experimental trials: all products can be tested in their true form; it is not necessary to make use of a dummy product. amixon® mixer-dryers and reactors have hygienically

Our recommendation for all processing laboratories Our recommendation for all processing laboratories with a continuous delivery of brittle to very hard materials for batch or continuous fine grinding. The maximum feed particle size is approx. 20 mm edge length. The fineness attainable (d50) is down to approx. 12 mm (largest gap width) or 0.1 mm (smallest gap width). The maximum throughput of 150 kg/h depends on the gap setting and the hardness of the sample. The relatively large throughput enables it to be used in the pilot scale or in the small size production, for example: slag-disintegration for the reclamation of precious metals. Typical fields of application: Mining and steel industries, Ceramics, Rocks and soils, Glass, Soil research Features of performance: - reproducible grinding results through accurate gap setting (exactly 0.1 mm) - precision adjustment for setting gap - sight glass for checking gap width - centrally located toggle-type fastener for grinding chamber - divided, hinged grinding

XPT on-line measuremetn systems for particle size, count shape XPT XenParTec is a particle size, count and shape analyser based on real time image analysis with XPT program. XPT-C is a system with flow-through cells and can be used in lab and on-line in process. The elaborate software package has many options and additional to normal particle size analysis for example allows counting of particles depending on shape (application: fibres contamination detection), brightness differentiation (black-spec detection) or tracking of shape change in process. The system can also perform series measurements initiated by external signals coming from a production process and can trigger events depending on measurement results. The software is compatible with 21 CFR Part 11. XPT-C-C has another unique feature: the ability to fill suspensions in vials by counting the particles and starting and stopping pumps to have defined number of particles and liquid volume. One application is filling of encapsulated products. XPT-P are probe based

Shear tester for flowability measurement of powders ShearScan is a fully automated shear tester for measurement of flowability of powders under defined load. Different test cells (linear and rotational, different sizes) can be run on the same instrument for maximum flexibility. Applications: Powder and granulate production quality control Maintain flow out of hoppers, bins and storage containers Predict caking, bridging & non-uniform flow during manufacturing processes Evaluate ingredient suppliers for the choice of suppliers and quality components Reduce costs & increase production speed of powder processing, blending & tableting

Quality is measurable With the modular particle measuring device welas®, we offer an intelligent measuring system which is adjustable according to the individual requirements of the customer. The latest innovation is the welas® 3000 for quasi simultaneous measurements with two sensors at two different measuring points - the optimal and economic solution for special requirements like measurements in explosion hazardous areas, at temperatures of -90° up to 120°C, in over- and underpressure etc. The two sensors are connected to only one light source and only one optical receiver, therefore the measurements are particularly exact and simple. welas® measures with a very high classification precision also in high concentrations and is equipped with a coincidence detection. The patented T-aperture technology allows measurements without border zone error. The system can be used for various applications, e.g. - isotherm particle measurements in the industry - emission/immission measurements -

In many areas of the bulk and powder industry are the recording ot the Moisture content a substantial criterion during processing and storage. Also legal points enforce the observe of define quantities of water. Here we offer our infrared moisture sensor, a contactless, opto-electronic measurement. Since many years well proved we have enlarged our program with the model UR 5200 BIG SPOT. A sensor with an extra big lightspot to see a large quantity of material to measure. Also the sensitive of changing distances would be improved. Sensors deliverable under ATEX regulations too. The materialmoisture is a substantial parameter but to monitoring the material flow are more sensors necessary. The quantity with hopper and belt scales, the temperature with infrared and PT 100, the level by rotaring level sensors. Additional systems to add water on batch and continious processes with nozzels and batch controler. Al these sensors implemented in complete control

Increased life time compared to cast and other hard faced materials Wear test`s carried out by a specialised independent university have shown increased wear behavior compared to common hard faced materials on the market. Increase of up-to 47 times compared to other materials have been seen.

Increased life time compared to cast and other hard faced materials Wear test`s carried out by a specialised independent university have shown increased wear behavior compared to common hard faced materials on the market. Increase of up-to 47 times compared to other materials have been seen.

with RETSCH Planetary Ball Mills When producing ultra-fine grinding material with a ball mill, certain stress mechanisms are necessary to ensure that the minute particles can be crushed at all. That is why ultra-fine grinding (colloidal grinding) through mechanical stress is mostly done in liquid media; moreover, it requires a high energy input and pressure and shearing forces which act upon the sample material. The RETSCH Planetary Ball Mill PM 100 meets these requirements. Thanks to the opposite rotation of sun wheel and grinding jar, the large effective sun wheel diameter and the high rotational speed of the sun wheel, the PM 100 possesses the required energy input for the production of nanoparticles. Eventually, the best possible combination of machine parameters and jar fillings determines the success of a colloidal grinding process. Above all, it is the selection of the grinding jar and the ball filling that has a substantial influence on the grinding results. Grinding jars and beads of zirconium

with the new laborscale-granulator A-WT25 and the pneumatic dense phase conveying system TPA The Austrian plant engineering and construction company AMMAG is specialised on spray granulation / coating and bulk material handling (conveying, silos, big bags, dosing and weighing). Own test plants in lab and pilot scale are used to test all process steps and to develop new products together with the customers. Toll manufacturing of these joint developments is possible, too. AMMAG has developed and constructed a novel laborscale spraygranulator A-WT 25. Air supply/-heating station and process-modul are designed in sparate units. Favorable design and a well elaborated plant concept, makes the A-WT 25 multi-purpose and in conformity with ATEX. The granulator can be operated in top - or bottom spray mode with different positions for the nozzels. An up-to-date control- and visualization system and changeable granulation-baskets for different batch-sizes give additional advantages to the user. Thus, first feasibility studies and small productions in the field

The future of mobile measurement acquisition The mobile acquisition of measurements through a data logger function is the task that can now be accomplished at a completely new level with the help of two new instruments. JUMO GmbH & Co. KG, Fulda, Germany, is presenting two new instruments at the Hanover Fair, as replacements for the existing portable digital thermometers that have been used in their thousands. Both versions have a sensor input for Pt100 resistance thermometers and type K thermocouples. The inputs can be set up as required, thus enabling the use of an extremely wide range of probe types. The temperature is indicated with an accuracy of 0.1% in a multi-line display. The JUMO TDA 300 has the capability to store up to 99 measurements within the instrument. Five different measurement point designations can also be assigned to these measurements. These values can then be shown very easily in the display at a later time, together with the date and time of the measurements. The JUMO TDA

The Adams/Ecolab range of disinfection products available from basan has been extended with the introduction of a new product. Acticlens – a sporicide cleaning and disinfection product based on peracetic acid and in powder form. The product is suitable for spore disinfection as necessary (as required by the FDA) as well as to extend the rotation of active agents required in both European and FDA guidelines. In a concentration of 2 per cent, Acticlens is approved as a bactericide (EN 1276), fungicide (EN 1650) and sporicide (EN 13704). Based on its almost neutral pH value in working concentration, the product shows an excellent material tolerance. Acticlens provides such an effective cleaning performance that routine cleaning and disinfection are mostly possible in a single step.

LUMiSizer® -Comprehensive and easy analysis of dispersions The new Dispersion Analyser LUMiSizer® of L.U.M. GmbH is your complete dispersion lab, all in one instrument. The quick characterization of any demixing phenomena, consolidation and measurement of particle size distributions make the LUMiSizer® the instrument of choice for research, development and QA/QC. The instrument determines demixing processes of dilute or concentrated suspensions/emulsions for up to 12 different samples simultaneously. Even different sample cell types and physical references can be measured at the same time. The demixing process can be accelerated by up to 4500x compared to traditional test tube tests. Fast stability analysis and shelf-life determinations of high concentrated dispersions are done in minutes/hours instead of months/years. The multisample analytical centrifuge is ideally suited for characterization and optimization of dispersion properties by measuring collective particle interactions, the compressional and elastic behaviour

Direct information makes it possible a fast capacity to act Meaningful and efficient use of new technology! OPDWIN has a module interface and a user surface, which are already for the employment adapted by industry PDA`s and prepared. Thus problem-free newest Rfid and bar code technology can be used, it made possible local -and time-independently customer-defined parameters to seize to query or change. Direct information exchange makes a fast capacity to act possible and increases thus the productivity, since the produktionsstillstand is minimized. A further substantial advantage of this technology is the flexibility of the plant drivers, since this no more is bound at a place to separate continuously production "locally" at the machine pursue can.

Demixing of dispersions under original storage conditions The Separation Analyser LUMiReader®, determines the demixing of suspensions and emulsions for a large range of particle sizes under original storage conditions, e.g. sedimentation, flocculation and clarification. The demixing process is accelerated using a patented measuring principle, without stressing the sample by additional mechanical forces. By means of L.U.M.´s well established STEP ® technology, the kinetics of the phase separation caused by any particle migration or alteration is recorded simultaneously over the whole sample height with a local resolution of < 100 µm. Three different samples are measured simultaneously, a high efficiency is achieved. Temperature control up to 60 °C meets the requirements of many applications in chemical, pharmaceutical, food and ceramic industries.

LUMiSizer® -Comprehensive and easy analysis of dispersions The new Dispersion Analyser LUMiSizer® of L.U.M. GmbH is your complete dispersion lab, all in one instrument. The quick characterization of any demixing phenomena, consolidation and measurement of particle size distributions make the LUMiSizer® the instrument of choice for research, development and QA/QC. The instrument determines demixing processes of dilute or concentrated suspensions/emulsions for up to 12 different samples simultaneously. Fast stability analysis and shelf-life determinations of high concentrated dispersions are done in minutes/hours instead of months/years. The concentration, viscosity, complexity and particle size of a wide range of dispersions are easily analyzed. The multisample analytical centrifuge allows a fast selection of flocculants and demulsifiers by tracing the kinetics and extent of separation and consolidation. Furthermore, an insight into the separation in a centrifugal field is gained to optimise solid-liquid separation,

Separation Analyser LUMiReader® The Separation Analyser LUMiReader®, determines the demixing of suspensions and emulsions for a large range of particle sizes under normal gravity, e.g. sedimentation, flocculation and clarification. By means of L.U.M.´s well established STEP®-technology, the kinetics of the phase separation caused by any particle migration or alteration is recorded simultaneously over the whole sample height with a local resolution of < 100 µm. Three different samples are measured simultaneously, a high efficiency is achieved. Temperature control up to 60 °C meets the requirements of many applications in filtration and separation technology.

intended for use in potentially explosive Atmospheres TECTUS Transponder Technology GmbH (located in Moers, Germany) is a leading and innovative RFID system component manufacturer and specialised expert company for applications industry & logistics, security & access and animal identification. Since June 2005 TECTUS is certified manufacturer according to the ATEX regulations for RFID readers and transponders of low frequency range 125 kHz. TECTUS belongs now to only a few ATEX certified RFID manufacturers worldwide. Additional to the stationary heavy duty RFID reader TPF-35 the TPA series of standard antennas complete the reader system. A certain product range of different ATEX certified RFID TAGs and also the available ATEX handheld PDA RFID reader TRISP (TECTUS Rugged Intrinsic safe PDA) allows the use of RFID technology in hazardous explosion proof areas like gas filling stations, chemical plants, mining and offshore industry etc.

Intended for use in potentially Explosive Atmosheres TECTUS Transponder Technology GmbH (located in Moers, Germany) is a leading and innovative RFID system component manufacturer and specialised expert company for applications industry & logistics, security & access and animal identification. Since June 2005 TECTUS is certified manufacturer according to the ATEX regulations for RFID readers and transponders of low frequency range 125 kHz. TECTUS belongs now to only a few ATEX certified RFID manufacturers worldwide. Additional to the stationary heavy duty RFID reader TPF-35 the TPA series of standard antennas complete the reader system. A certain product range of different ATEX certified RFID TAGs and also the available ATEX handheld PDA RFID reader TRISP (TECTUS Rugged Intrinsic safe PDA) allows the use of RFID technology in hazardous explosion proof areas like gas filling stations, chemical plants, mining and offshore industry etc.

... reliably prevents fire in dryers, filters and silos The occurrence of glowing or hot particles cannot be completely excluded from many processes. If ignition sources are transported into filters and silos via the extraction system or other conveying facilities, devastating fires and explosions can be triggered. By means of infrared sensors and downstream extinguishing nozzles, the ignition sources in mechanical and pneumatic conveying systems are reliably detected and extinguished before they reach plant areas at risk. For those applications in which water extinguishment is not possible or reasonable, GreCon developed special fire traps or diversion gates, which prevent the damaging effects of the ignition sources as quickly as the water extinguishment. Not only has the technical implementation of the principle “extinguish sparks before fire occurs” been permanently improved and optimised until now. A high level has been reached especially regarding the operation of the system and the documentation of alarms and

Bulkflow Technologies Inc. will present an innovative HT cooler for high temperature applications, designed for product temperatures up to 1000°C. The concept uses horizontal, water cooled tubes in a “serpentine” configuration, which prevents high local stresses and hot spots. The tube walls are typically refractory lined. As in the well-proven plate design heat exchangers from Bulkflow Technologies Inc, the product flows in mass flow, by gravity through the tube bundle. Applications for this high temperature cooler are catalysts, minerals such as alumina, ash and char from boilers and furnaces. Bulkflow will also present a paper during the BULKDAYS (see "Calendar`), a seminar held during Powtech and organized by the Bulk Academy. This paper covers the importance of cooling for improved storage, handling and quality of powders and granules with the indirect cooling technology of the Bulkflow Plate Heat Exchanger. This concept offers many advantages compared
