News items July 2005

For Dustcontrol and HVAC applications Dustcollectors and HVAC-installations which are placed in a ATEX-zone, must be equipped with suitable controls and measuring devices. In order to detect the saturation of filtermedia, a pressure differential module is extremely important! Currently a pressure differential module is introduced which is to be applied in zone 22 (dust). The pressure drop over the filter is measured and several signals are generated: start/ stop cleaningfunction and alarm. The actual value is read out locally and by means of 4-20mA analog signal. Specifications pressure differential module HE 5421: - To be used in zone 22 - Measuring range: 0...25/30/40/50/70/100mbar - Outputs: 1 x Analog 0(4)-20 mA/ 1 x Relay – alarm/ 1 x Relay – for cleaning - Sizes: 122 x 120 x 55 mm (H x W x D) - Display: 4-digit/ 7-segments - Media: Air and dry non-agressive gasses - Pressure connections: G¼” female - Electrical connection: 230 V AC/ 24 VDC - Protection class: IP 65 -

For reduction of the velocity and increase of the flow rate Pelletron, Lancaster, USA-based bulk material handling company, introduces its new, patented FlowEnhancer, which increases the capacity and reduces the conveying velocity of pneumatic transfer systems. Existing systems can be optimized without changing the conveying line size. Pelletron’s unique design ensures easy retrofit into existing systems and is upgraded by Pelletron’s pneumatic conveying expertise and outstanding performance. Design Principle: A special designed blow-off pipe section reduces the conveying air, controlled through an air management system. After filtration of the air, it will be released to the atmosphere.

For pressure range from 1 to 3.5 bar, with new inlet design Used in gravity or pneumatic conveying applications for granular products. Available in a low pressure version with a differential pressure of 1bar and a high pressure version for 3.5bar. Valves are designed in stainless steel and available in sizes 100 to 500 mm. Main features: • Patented anti shearing device • Double lip seals • Integrated leakage air vent for best filling efficiency • Closed end rotor • Up to 250 Degree C available • Polishing available • Many more options available on request

We stand up for increased safety and reduced wear When train speeds are high, there are two crucial requirements: safety and minimal wear. Only perfectly maintained bogies ensure that these demands are met. With MULTIRAIL® BogieLoad, Schenck is banking on safety through all around inspection. Electromechanically designed, the bogie test bed inspects the bogie using the so called spindle technology developed by Schenck. This novel feature increases repeatability and accuracy whilst reducing the maintenance expenditure. The new technology ensures a high degree of repeatability whilst reducing the susceptibility to failure. Positioning is more accurate. The automatic process with hauling equipment and fully automatic bogie centering eases the operation and provides added safety. The remarkable accuracy upon RH/LH inspection is said to be another striking advantage. Technical Data: · Dimensions: l = 5.4 m x w= 6 m x h = 5.82 m · Load generators in the upper portal: 250 KN max. test load · Vertical

LAS - a package solution that pays off! The Schenck Loading Automation System automates your entire shipping process using tailored solutions designed to save huge amounts of time, improve quality, avoid faults, increase efficiency and last but not least reduce cost. A web interface integrated into your PC network enables your dispatchers to conveniently process all orders using a standard browser. The new function is available as retrofit for any existing system. Also new and programmed for safety is the access to your system with the use of a transaction code (TAN) entered once-only. Perfectly tuned to one another, the LAS hardware and software modules automate the inbound and outbound material flow.All components can be tailored to the existing infrastructure, e.g. using touchless ID cards and terminals that can be operated by the truck driver single-handedly. As if by magic, doors and gates open, controllers come on, and defined loading and unloading operations are performed. Largely without operator

Throughout the mining industry, Schenck is renowned for powerful, reliable and versatile screening m The exacting demands of sand and gravel processing are a tough challenge to the screening machines. The high and varying delivery rates of rough gravel with a high portion of sand wreck many a machine. The Schenck vibratory machines, however, stand up to these requirements. The reliable directed force exciters of the DF series and the rotary force exciters cells of the VZ series ensure long life and minimal service at highest availability and exceptional ease of maintenance. The Schenck screening machines enjoy the image that they cannot be wrecked. They actually excel through long service lives and uptimes. The screening machines of the RotaClass, LinaClass and VarioClass series stand out against an intensely competitive market through individual system solutions. Thanks to their field-proven drive technology and the well balanced cost-performance ratio, the powerful screens have proven their worth in the most severe environments. Particularly appreciated is their

Protection of control cabinets against dust, moisture and hightemp Many controlcabinets are placed in an unfriendly and harsh environment. This means that sensitive electrical components inside the cabinet are exposed to dust, moisture and excessive heat. The Fiktech Vortex Coolers are equipped with an SS Vortex tube which uses compressed air to create a stream of cool air. This realizes a slight overpressure thus keeping unwanted particles outside! Mounting is very simple. Caracteristics and advantages: - Keeps dust and moisture out, preventing shortcircuiting. - Cooling capacity up to 820 W, without the use of environmentally dangerous gases. - IP 52 and IP 56 executions, Aluminium and SS 304/ SS 316 casings. - Ease of installation, compact, no moving parts. - Low noiselevel (<75 dB(A)). Applications - Control cabinets, switchboxes. - PLC’s, Motor Control Centers, CNC controls. - Computers, eletronical devices, CCTV camera’s. -

Modular valve with various pipe angles Pelletron Introduces new Ball Type Diverter valve DVB The new Ball Diverter is suitable for powders and pellets, Because of its modular design, the valve can be used for flow directions of 45, 90 and 135 degrees. The valve is designed in stainless steel, and available in sizes 1 ½” to 12” (40mm to 300mm). Main Features: • Full round passway design • Ball completely sealed • Differential pressures 60 psi (4 bar) • Surge pressure 90 psi (6bar) • Heavy duty pneumatic actuator • High temperature version available
