ENCODER-FLEX 1024 - Innovative Digital Rotary Encoder

4B has introduced the Encoder-Flex 1024, designed to monitor the position of rack and pinion gates, as well as shaft speed and angular position of distributors. 4B Group has introduced the Encoder-Flex 1024, designed to monitor the position of rack and pinion gates, as well as shaft speed and angular position of distributors. The new, ATEX-approved Encoder-Flex 1024 is changing the way slide gates are monitored. This compact rotary shaft encoder uses advanced technology to deliver a precise position from 0 to 100%. With a compact, sleek design, the Encoder-Flex 1024 removes the bulkiness associated with traditional shaft encoders and adds the benefit of easy calibration. There is no need to open up the unit; simply apply an external magnet briefly to calibrate. Providing even more flexibility, resolution can be programmed for 1 to 1024 pulses per rotation. All electronics on the Encoder-Flex 1024 are housed in a sealed stainless steel enclosure and are encapsulated in epoxy, protecting the device from moisture and the elements and providing maximum reliability in the field. In addition, the Encoder-Flex 1024 provides

07.09.2023 | 1990x | Product news | |

Sensor mounting kits for barrel sensors

Now available from 4B. The Sensor Mounting Kit is able to securely mount barrel sensors in position, including 4B’s range of 18 & 30mm wide inductive sensors. The 4B Sensor Mounting Kit is able to securely mount barrel sensors in position, including 4B’s range of 18 & 30mm wide inductive sensors. Made of Stainless Steel and Nylon 66, giving corrosion resistance as well as abrasion resistance and high melting points, the brackets are ideal for harsh environments. A flexible mounting head and foot can be rotated independently before being locked in the required position using the supplied screws.

02.06.2023 | 1981x | Product news |

ADB adjustable depth bearing temperature sensors

The ADB series have been designed to allow the depth of the sensor to be adjustable depending on your application. Versions are available with probe lengths of 50, 100, 200 and 300 mm. The ADB series have been designed to allow the depth of the sensor to be adjustable depending on your application. A number of versions are available with probe lengths of 50, 100, 200 and 300 mm. The sensors screw directly into a bearing housing through a 1/4” BSPT threaded grease zerk. Each sensor is fitted with a grease zerk to allow lubrication of the bearing without the need for removal of the sensor. The ADB series have NTC or PT100 type thermistors which allow for continuous temperature monitoring. The sensor is supplied with a 3m attached cable and can be connected to a PLC or to a hazard monitoring system, such as 4B’s Watchdog Super Elite, T500 Hotbus Elite or T400 NTC Elite. The connections are not polarity sensitive therefore special connection requirements are eliminated, and the cable can be extended in the field. Product Features * Screw in positive mount installation * Grease zerk for bearing lubrication * Adjustable depth probes (50, 100,

24.02.2023 | 2747x | Product news |

4B Nylathane - next generation industrial elevator buckets

4B’s Nylathane buckets offer the opportunity to replace traditional steel and ductile iron elevator buckets with a similarly durable but lighter weight option Industrial elevator bucket designs have not changed significantly since the 1950s. However, the introduction of Nylathane, by 4B Group, brings a new technology to the industry. Nylathane is a unique polymer that combines Nylon 6 with an elastomer. It has the durability of nylon with the slick release surfaces associated with polyurethane. This combination makes it ideal for bucket elevators in the cement industry where impact tolerance and discharge efficiency of sticky or powdery products are required to minimize downtime and maintain production efficiency. Prior to its use in elevator buckets, Nylathane has been field proven in even more demanding applications such as track pads for tractors. Iron or steel elevator buckets can be prone to deformation or breakage due to impact from foreign objects or operational issues. Once deformed their capacity and efficiency is diminished. Deformed elevator buckets pose a risk to further damaging the bucket elevator system

24.01.2023 | 1838x | White paper |

4B Launches New Interactive Website Feature

New and exclusive CGI (computer-generated imagery) product applications for bulk handling plant allows users to zoom into a material handling plant 4B Group - a worldwide manufacturer of bucket elevator and conveyor components and hazard monitoring equipment - has just added a new interactive CGI feature to its website. The new enhanced feature allows users to zoom into a material handling plant, such as a port terminal, drill into individual applications, like the bucket elevator, open or enclosed belt conveyors, chain conveyors and silos, to view products specific to the application. By selecting the “Information” icon , the user sees a concept model of the application where further “information” icon selections will provide detailed product information for 4B’s range of hazard and condition monitoring solutions. The information available includes product datasheets as well as product demonstration videos.

13.10.2022 | 2073x | Press release |

RG Series Rotary Paddle Level Indicators (ATEX)

Easy to install, adaptable, versatile The RG Series Level Sensors have been designed to indicate the presence or absence of bulk materials such as grains, pellets, chemicals, wood chips and other powders. The detection of material is achieved by a rotating paddle. If material impedes the rotation of the paddle, the motor topples of its axis and triggers an alarm. The RG Series has a variety of compatible paddles which offer the ability to detect a wide range of products. The paddles are interchangeable, making the RG Sensors adaptable to different densities of measured materials. The sensors are customizable not only with paddles, but also with extensions and voltages. An easy to install instrument, the RG Series sensors do not require any calibration, maintenance or specific tool for their installation. The sensors are extremely versatile, and can be installed on tanks, hoppers, on walls or roofs of silos, in a vertical, horizontal or oblique position. Durable and reliable, the RG Series Sensors

03.10.2022 | 2125x | Product news |

4B TOUCHSWITCH – Belt & Pulley Alignment Sensor

The TouchSwitch is a mechanical pressure sensor without moving parts. It functions as a misalignment monitor for conveyors and elevators. 4B Touchswitch - side view, Touchswitch installed on elevator, Touchswitch detecting misaligned belt, Test button allows easy testing of Touchswitch

07.07.2022 | 3937x | Photo reportage |

4B Group Launches Nylathane Industrial Elevator Buckets

4B Group Launches Nylathane™ - The Next Generation of Industrial Elevator Buckets. Tough as Nylon - Slick as Urethane. 4B, a world leading supplier of bucket elevator and conveyor components, announces the release of its Nylathane™ line of industrial elevator buckets engineered for maximum durability and efficiency. Nylathane™ is a high-performance polyamide 6 (Nylon 6) based polymer that is toughened through the addition of an elastomer. Typical applications include ultra-high performance elevator buckets for high impact and high wear resistance industrial applications. Using Nylathane™ in lieu of steel can reduce part weight by as much as 75%. Lighter buckets can prolong the life of costly components such as elevator belting or chain, can help reduce energy consumption of the equipment, and can help improve personnel safety while handling the parts. Nylathane™ possesses anti-stick properties that help improve bucket fill and discharge efficiency, and static conductive properties that help improve safety when conveying materials that generate combustible dust. Nylathane™

06.04.2022 | 2875x | Product news |

Elevator handling recycled asphalt planings

Elevator design for recycled asphalt planings (RAP). Recommending speed, power, shaft & casing sizes, and component specs (SPS steel buckets & NBR belting) Challenge Asphalt is made from a mixture of aggregates, binder and filler, and is commonly used in constructing and maintaining roads surfaces. When the surface layer of tarmacked areas is removed, the resulting waste material known as planings, can be recycled and reused. BG Europa Ltd approached 4B Braime requesting technical advice on the manufacture of a new bucket & belt elevator to be installed at an Asphalt plant in South Wales. Although familiar with bucket & chain elevators, the customer had no technical experience with buckets & belts so requested the expertise of 4B Engineers. The bucket elevator would elevate RAP (Recycled Asphalt Planings), and use a belt instead of chain, and standard 4B pressed buckets instead of fabricated buckets commonly used in the construction industry. 4B Braime were asked to provide a design proposal detailing suitable speed, power requirements, shaft & casing sizes, and component specifications to achieve the desired

07.02.2022 | 3004x | Product news |

4B Group strengthens position with new French complex

The 4B Group has just celebrated the inauguration of its new office /warehouse facilities in France - strengthening the company’s position in Europe. 4B France, subsidiary of the 4B Group, a worldwide manufacturer of components for bucket elevators and conveyors and electronic monitoring equipment, has just celebrated the inauguration of its new facilities, a brand-new purpose-built office and warehouse complex, situated just 6km from the company’s old premises. The new facilities and warehouse complex bring a lot of opportunities for 4B, as well as strengthening the group’s position in Europe after Brexit. “Due to Brexit, we have made this major investment in France to build a new facility to increase 4B France’s activities and better support our customers in France and Europe”, explains the group’s chairman, Nicholas Braime. “90% of the 4B Group’s sales are made through global exports and the European market remains very important.” The new facility has been designed with the latest warehouse technology and high-level racking. The additional space and modern stock management system will significantly

06.01.2022 | 2686x | Press release |

4B Milli-Temp 4-20 mA Bearing Temperature Sensor (EX)

A loop powered analogue sensor with 4-20 mA linear output that is scaled across a temperature range for continuous bearing and surface temperature monitoring. 4B’s Milli-Temp, a loop powered analogue sensor with a 4-20 mA linear output that is scaled across a temperature range for continuous temperature monitoring - is now also available as an ATEX-certified version. Applicable everywhere The Milli-Temp series can be used on any application where bearing temperature monitoring is needed. The sensor has been designed to allow the depth of the probe to be adjustable depending on the application. This adjustability allows the tip of the probe to be placed in the optimal position for monitoring bearing temperature and also enables verification using the 4B ADB Tester. Using existing grease zerk threads The sensor screws directly into the bearing housing using the threads of the existing grease zerk. The body of the Milli-Temp has an integrated zerk, allowing lubrication of the bearing without the need to remove the sensor. The sensors are supplied with a 3m cable. The connections are not polarity sensitive therefore

07.10.2021 | 3890x | Product news |

IE-Node - the future of hazard monitoring

Utilizing industrial Ethernet and cloud connectivity to share real-time sensor data, alongside historical analytics, with your PLC of choice. 4B’s IE-Node is the future of hazard monitoring. Utilising industrial Ethernet and cloud connectivity to share real-time sensor data, alongside historical analytics, with your PLC of choice — the IE-Node is truly intelligent. Sample code for a variety of PLC brands is available to help you connect your entire system and keep every component in constant communication for unprecedented hazard protection. The IE-NODE operates by reading its sensor inputs and sending processed data when requested by another system (e.g. PLC). The units are equipped with an RJ45 Ethernet socket and supports PROFINET, EtherNet/IP and Modbus TCP/IP protocols for easy integration with Siemens, Allen-Bradley Rockwell, Modicon and other PLC’s or automation devices. The IE-NODE’s network configurator software provides a visual view of all devices on the network. It allows for easy identification of each unit on the network and allows for network settings to be changed as needed.

12.08.2021 | 3416x | Product news | |

4B AM Nyrim Elevator Buckets in Oilseed Elevator Upgrade

The newly developed AM Nyrim elevator buckets offered more robust, higher capacity throughput without needing to carry out any drive changes. 4B recently assisted the largest UK producer of rape / canola oil in upgrading their main silo feed elevator to incorporate 4B’s advanced anti- static AM Nyrim elevator buckets. Increasing capacity by reducing material build-up in the buckets and improving hygiene throughout the production process. CHALLENGE Largest UK producer of rape / canola oil required an increase in the tonnage capacity of the elevator along with steps to improve hygiene and reduce the risk of salmonella contamination throughout their production facility. Oil and dust sticks to the traditional fabricated steel buckets building up and reducing capacity of the elevator. Over time these deposits grow and can reduce capacity of the buckets. These then start to break off in lumps and can contaminate the production process further along the refining process. SOLUTION Replacing the mild steel buckets with like for like would have no benefit in that they were susceptible to damage and build

16.07.2021 | 3609x | Product description |

4B Milli-Speed Switch now available with ATEX Certification

The 4B Milli-Speed Switch, a loop powered 4 - 20 mA analogue output speed switch for PLC, DCS or stand-alone controllers is now available as ATEX version. The Milli-Speed switch is designed to detect belt slip, belt underspeed, stop motion, low speed or zero speed on bucket elevators, conveyors, airlocks, mixers, fans, grinders and many other rotating machines. An inductive sensing device located in the nose of the Milli-Speed enclosure will detect a metal target. This target can be an existing bolt head or device attached to a shaft, such as 4B’s Whirligig® sensor mount. During installation, the Milli-Speed is set to the normal running RPM by simple magnetic calibration. Additionally, 4B’s SpeedMaster™ can be used with the Milli-Speed to test the functionality after the initial installation and during routine maintenance procedures. The SpeedMaster™ is the only device that accurately tests the calibration of a speed switch, and allows testing of the alarm and shutdown features of the sensor while installed on the machine shaft.

13.05.2021 | 3638x | Product news |

Chain Conveyor Upgrade - Corrosive Products

Problem with chain conveyors in corrosive application solved through use of the right components. Customer was struggling with their conveyors transporting a corrosive by-product of crude oil processing. The chain was breaking and wearing fast, causing much downtime. 4B heavy duty links with corrosion-resistant pins and circlips improved the conveyor life by at least 50%. Challenge The customer was struggling with the life of the chain inside their chain conveyors. The chain conveyors where transporting a by-product of crude oil processing and wearing extremely fast. The wear was mainly due to the corrosive nature of the product and the strength of the chain installed. The corrosion was wearing the chain links and pins quite rapidly and the low chain strength lead to rapid elongation of the links. These 2 issues combined resulted in many chain breaks and a lot of production time loss to maintenance on the conveyors. SOLUTION Use of 4B142HAD chain links with pins in AISI420 and circlips in AISI304. These pins had a higher resistance to corrosion and the

19.01.2021 | 5574x | Product news |

Monitoring for drag chain conveyors

4B WDA sensor used as solution to monitor chain slack or breakage By using a WDA sensor in combination with a speed relay, ferrous steel flights or bolts on plastic paddles are used to monitor for broken or slack chain issues on drag conveyors. The WDA is a non-contacting extended range magnetic proximity sensor, not affected by dust or material build up, used to detect moving ferrous material up to 75mm away from the sensor. The speed relay is used to monitor the speed of a rotating shaft and detect if it rises or falls below a preset safety level.

23.11.2020 | 6489x | Product description |

RG1 Level sensor

Rotary Paddle Level Indicator The RG1 Level Sensor has been designed to indicate the presence or absence of bulk materials such as grains, pellets, chemicals, wood chips and other powders. The detection of material is achieved by a rotating paddle. If material impedes the rotation of the paddle, the motor topples of its axis and triggers an alarm. The RG1 has a variety of compatible paddles which offer the ability to detect a wide range of products.

16.10.2020 | 5973x | Product news |

Elevator Re-Design from Grain to "Green Malt"

Brewing & Malting: Elevator Design Improvements Challenge To utilise an existing Grain Elevator to transport “green malt”. After installation it was apparent the elevator was problematic and not functioning as expected. The installed buckets were CCS127 buckets, which replaced the obsolete J127 HDP buckets which were originally installed. After some discussion with 4B, the prognosis was the pulley may be too small for the projection of the CCS12x7 bucket. This was expected to be cured by installing CCS 12x6 but the problem still persisted although not as bad. SOLUTION After a site visit to inspect what they actually had, it was apparent the elevator was set up to transport free flowing grain. This setup was incorrect for the handling of green malt, which by nature is wet and sticky and does not flow well. The conclusion was the product was not fully discharging into the outlet but was in fact falling down the return leg back into the boot. 4B recommended two minor alterations to solve this problem. Modify

14.10.2020 | 8639x | Product news |

4B IE-Node – Remote Sensor Monitoring System

Provides Sensor Data to PLC’s and Automation Systems 4B Braime Components has introduced the Industrial Ethernet Node (IE-NODE) remote monitoring interface designed to provide sensor data to PLC’s or other automation and control systems. The IE-NODE is available in two versions, both with a total of 10 sensor inputs. Version 1 has eight contact or NTC temperature inputs, and two pulse or 4-20 mA (current loop) inputs. Version 2 has 10 inputs for 4-20 mA (current loop) sensors. Both units can be expanded to 16 sensor inputs with the installation of optional expansion boards. The IE-NODE operates by reading its sensor inputs and sending processed data when requested by another system (e.g. PLC). The units are equipped with an RJ45 Ethernet socket and supports Profinet, EtherNet/IP and Modbus TCP/IP protocols for easy integration with Siemens, Allen-Bradley Rockwell, Delta V, Modicon and other PLC’s or automation devices. The IE-NODE’s network configurator software provides a visual view of all devices on the network.

13.05.2020 | 7979x | Product news |

New 4B Catalogues - Elevator & Conveyor Components

4B's new catalogues now available - conveying and monitoring components

08.01.2020 | 7315x | Photo reportage |

4B Braime launches new mobile-friendly website

4B Braime Components, a world leader in material handling and electronic components for bucket elevators and conveyors, is inviting visitors to explore their new company website: . The new 4B website has been designed with the user experience in mind, offering a clean fresh look, mobile-friendly design, improved navigation and functionality throughout, while allowing customers to access product information and enriched content with ease. The 4B website has become a reference for many people in the bulk handling industry. One of the most comprehensive websites in the industry, the 4B website provides a wealth of technical information, from product specific datasheets and manuals, through to technical guides and advice. The multi-lingual 4B website now offers even more languages, 16 separate language sites in total, to allow most of the worldwide customer base to access information in their own language. In an industry where many components are sold as part of a

05.08.2019 | 6778x | Press release |

4B Deutschland at Powtech

Conveying and hazard monitoring components 4B Deutschland stand and team, 4B Deutschland stand, 4B hazard monitoring components and sensors, 4B Deutschland Team, 4B Deutschland stand at Powtech 2019, 4B Deutschland Stand, 4B forged chains

10.04.2019 | 7186x | Photo reportage |

4B BRAIME Group – Celebrating 130 Years

Engineering Excellence since 1888 The 4B Braime Group, headquartered in Leeds /UK and known across the bulk material handling industry for its range of bucket elevator and conveyor components, has just celebrated its 130th anniversary. In recognition of its continuous pursuit of “engineering excellence since 1888”, the company has been awarded the prestigious Yorkshire Society plaque. The Braime Group traces back its origins to the 19th century. Around 1900, the company pioneered the introduction of a new technology of Deep Drawn Steel Presswork, It began manufacturing pressed seamless steel elevator buckets, issuing its first catalogue in 1908 offering over 350 sizes. In the latter part of the 20th century, the group launched its 4B division, which specializes in components for material handling industries. Today the 4B Group operates in over 80 countries, with subsidiaries the US, France, Germany, Thailand, South Africa, Brazil and China, and the 4B brand stands for worldwide reliability

13.03.2019 | 7516x | Press release |

M3003 and M3007 Slipswitch

Underspeed Sensor for bucket elevators, conveyors and other rotating machinery The M300 Slipswitch is an easy-to-use inductive proximity shaft speed monitoring device with an adjustable 0 - 30 second start-up delay, all housed in a 30 mm diameter moulded body. The self-contained unit has a single set point, which signals when the shaft speed has dropped by 20% of normal running speed. It is used for detecting dangerous slow down and underspeed conditions on conveyors, bucket elevators, air locks, mixers, fans, grinders and many other machines. No connection is necessary between the sensor and the equipment being monitored. The proximity sensor detects a stud or bolt mounted on a shaft, or other suitable target. Ideally, the target should be of ferrous metal, but non-ferrous metal will be detected at a shorter range. Maximum range of ferrous targets is 8 mm (5/16”) and for non-ferrous targets is 5 mm (6/16”), assuming a 20 mm (3/4”) diameter target. Smaller targets may be used but operating distances will be reduced.

02.08.2018 | 11769x | Product news |

Watchdog™ Super Elite (WDC4)

Bucket Elevator & Conveyor Hazard Monitor 4B Braime Components, a worldwide manufacturer of material handling and electronic components, has released the all new fourth generation Watchdog™ control unit for monitoring bucket elevators and conveyors. The Watchdog™ Super Elite (WDC4) is easy to install and simple to set-up. The system processes signals from up to 15 sensors for belt speed, belt misalignment, continuous bearing temperature, pulley misalignment and plug conditions on bucket elevators or conveyors. When an alarm condition is detected the system will log the details, sound an alarm and provide shutdown control of the elevator/conveyor and feeding system. A new 3.5” colour graphic LCD screen displays the entire system status at a glance. The WDC4 model now supports belt speed monitoring for variable frequency drives (VFD’s), and belt misalignment inputs for contact, pulse and temperature (brass rub block) sensors. The WDC4 also has jog and acceleration monitoring for detecting any

02.05.2017 | 13237x | Product news |

4B Braime launches new website

4B Braime Components, a worldwide manufacturer of material handling and electronic components for bucket elevators and conveyors, has just announced the launch of their new company website, which comes with an extended product section, streamlined navigation and improved multi-lingual features. Structured into 3 main applications -bucket elevator components, chain conveyor components and electronic monitoring equipment – the product section provides comprehensive information, all in an easy to use format. Each product is presented with detailed technical information and advice, including manuals, certificates, CAD drawings, installation guides, videos, FAQ’s, etc… as well as links to accessories and other relevant products. 4B Braime says that feedback from 4B’s customers has so far been very positive, with customers finding the new site convenient to use, professional and very engaging. The 4B website has become a reference for many people in the bulk

18.06.2015 | 10867x | Press release |

4B releases new elevator bucket catalog

4B’s new elevator buckets catalogue has just come out. The catalogue includes new SPS bucket sizes, improved capacities for Starco buckets, the new JCC-S ultra heavy duty elevator bucket and high efficiency buckets. 4B has the world’s largest range of elevator buckets. -With over 400 different sizes and styles, 4B has an elevator bucket for any product and any application. Steel & stainless steel elevator buckets (pressed / seamless or fabricated); Plastic / non-metallic elevator buckets (nylon, HDP or polyurethane); Elevator buckets for agricultural applications (e.g. grain, feed, seeds, sugar); Elevator buckets for industrial applications (e.g. as cement, lime, gypsum, aggregates, coal, fertilizer)

06.03.2015 | 5240x | Press release |

Hazardmon

Revolutionising Site Monitoring and Maintenance 4B Components have created a new hazard monitoring solution that will revolutionize the industry by introducing a greater level of transparency and record keeping. Hazardmon.com is a secure cloud based industrial monitoring solution that allows any registered user to login and see all their facilities in real-time from anywhere in the world. This product offers seamless integration with 4B’s communication BUS system – the T500 Elite “Hotbus”. Hazardmon.com Platform Features • The website is designed to be modern, simple and user friendly. • Secure and encrypted login and data transfer of industrial strength – 256bit SSL. This ensures website security and data safety. • No on-site server or PLC needed. No upkeep and upgrade costs. No hardware to replace or backup. The F500 unit sends data directly to our server in the cloud. • All the data is stored in the cloud and backed up in multiple locations making the data extremely secure. The end user

11.09.2013 | 17529x | Product news | |

WDA Sensor -Alignment Sensor for Bucket Elevators or Slack C

High Power Magnetic Proximity Sensor Non-contacting extended range magnetic proximity sensor, not affected by dust or material build up, used to detect moving ferrous material up to 75mm away from the sensor. The WDA sensor is designed for use with bucket elevators to detect the buckets in order to measure speed and alignment. It can also detect screw conveyor flights, and ferrous bolts when attached to non-ferrous buckets. A more specialized use of the WDA sensor is for broken/slack chain detection. The sensor is used in conjunction with a PLC or with 4B’s Watchdog™ Elite or A400 Elite control units. Two output signals are provided: one signal is a pulse output, representing each bucket detected: the second signal is a continuous output when moving buckets are detected. FEATURES ►Adjustable Sensing Range 25mm to 75 mm ►LED Indication ►Mounting Bracket Included ►½” NTP Conduit Entry ►Stainless Steel Construction ►High Temperature Version Available ►IP66

08.08.2013 | 18970x | Product news |

High efficiency elevator buckets

Modern vs. traditional design An elevator bucket is an elevator bucket, right? Not anymore. Recent advances in design technology have brought the advent of the modern high efficiency centrifugal discharge elevator bucket. High efficiency elevator buckets push the traditional limits of carrying capacity, input flow and discharge, construction materials and diminished shipping space. A high efficiency elevator bucket has ALL of the following characteristics: • Smooth interior front faces, with no breaks, that provide an efficient discharge over higher speeds • They can be mounted closely together to deliver the greatest, and thereby, most efficient throughput • A tapered bottom that allows the buckets to fill and discharge efficiently • The tapered bottom allows the buckets to nest inside one another, for more efficient shipping and storage • Wing-less sidewalls, making the design more cost efficient and thereby reducing material costs The “breaks” or “angles” seen

15.07.2013 | 11845x | Press release | |

JUMBO CC-S® Elevator Bucket

New ultra heavy duty elevator bucket line 4B Braime Elevator Components, a worldwide manufacturer of material handling and electronic components, has designed a new large sized ultra-heavy duty elevator bucket line intended for the most severe agro-industrial uses, such as port and river terminals, ethanol and fertilizer plants, or frac sand and aggregate operations. The new super strong JUMBO CC-S® bucket offers greater carrying capacity, along with ultra-durability and wear resistance. It has the thickest front lip, front corners and walls available for longer life. The JUMBO CC-S® is a High-Efficiency™ elevator bucket, and comes in six sizes ranging from 14x8 to 24x8 with additional sizes pending. As an extension of the proven and successful heavy duty CC-S® elevator bucket, the JUMBO CC-S® also incorporates the long lasting Iceberg® Edge front wear lip and the unique tapered bottom. Designed for the closest possible vertical spacing (up to 4.6 buckets/metre) the tapered bottom ensures efficient

20.03.2013 | 18217x | Product news | |

4B increases capacity of STARCO steel elevator buckets

4B Braime has invested in tooling to increase the capacities of their popular STARCO steel elevator buckets; as a result, all 4B’s STARCO steel buckets now have the same or greater capacities than comparable buckets of their competitors. The Starco bucket was originally invented by 4B Braime’s French subsidiary, SETEM, in the 1980s and was the first low profile elevator bucket to use centrifugal discharge on a parabolic elevator head to achieve much higher capacities on a given elevator leg. As such, the STARCO bucket has revolutionised the elevator buckets market. The Starco elevator bucket has been engineered to provide perfect fill & discharge for a wide range of products. It operates at wide speed range, up to 4.55m/s. It is not surprising that the STARCO bucket has become a very popular bucket, and has been copied by a number of companies, with varying results. In a range of tests that 4B has carried out to compare their own 4B STARCO buckets with

07.12.2012 | 17976x | Product news |

4B extends range of deep drawn SPS Super Starco Elevator Buckets

4B are pleased to announce the introduction of more and bigger sizes of the popular pressed steel SPS elevator bucket. The biggest bucket of the range is now the SPS 630-215; and there are also more stainless steel options available. The deep low profile design of the Super Starco™ elevator bucket is the result of intensive research to achieve the maximum individual bucket capacity. Additional capacity has been engineered into the bucket while still maintaining the perfect fill and discharge characteristics of the original Starco™ bucket. This means that less buckets are required per metre, less bolts and punching, reducing cost for belt and bucket installation. The SPS elevator bucket is a versatile bucket, available in many sizes and suitable for a wide range of applications, from grain, feed and pellets through to sticky materials, chemicals, sand, cement, coal, aggregates, powder and fertilizer. 4B also offer FREE ENGINEERING to compliment their elevator

16.11.2012 | 17822x | Product news |

WDB7 bearing temperature sensor

Lug style surface temperature sensor The WDB7 series is a lug style NTC thermistor or platinum RTD (PT100) type for continuous temperature monitoring. It is designed to bolt directly onto a bearing housing, motor, gearbox, or machine casing. The mounting hole is M8 which can be drilled out up to M10 diameter. The sensor can be connected to a PLC or to a hazard monitoring system, such as 4B’s T500 Hotbus Elite, Watchdog Elite, or T400 Elite. The connections are not polarity sensitive therefore special connections requirements are eliminated. The WDB7 series is approved for use in ATEX and IECEx Zone 20 dust hazard locations.

14.09.2012 | 18220x | Product news |

Remote Auto-Set

Remote Radio-Frequency Level Indicator The Remote Auto-Set is a radio-frequency level indicator that allows single point level detection of most liquids and bulk granular materials such as powders, grain, sugar, cement etc… The remote version allows the programming and monitoring to be achieved at a distance of up to 100 metres between the control module and the transponder. The Remote version is recommended for situations where - the level probe is not easily accessible - regular recalibration is necessary i.e. for various products used in feeders etc - the level indicator is exposed to vibration and possible impact. - the product is at temperatures up to 250ºC The control module ATSR1V0A has a display and is simply programmed using push-buttons and switches. Like the standard version, it has a power shield function that enables it to automatically compensate for material build-up on the probe. ATEX-approved for zones 20, 21 & 22

18.06.2012 | 13261x | Product news

Rub Block vs. Touchswitch

Choosing the right belt alignment sensor Belt misalignment is a common problem in belt conveyors and bucket elevators. When the belt is severely misaligned it can cause damage to the machine casing while generating dangerous heat in dust hazard environments. Two typical methods of detecting belt misalignment are the rub block and the Touchswitch. The Rub Block consists of soft brass with an embedded temperature sensor. The sensor alarms when the brass heats to the trip temperature. Three main drawbacks exist for this sensor. First, by the time the brass heats, the belt has already been misaligning for a period of time. Second, the belt could periodically rub against the brass and move away, wearing through the rub block without ever giving an alarm, leaving you unprotected. Finally, there is no simple way to test the rub block without introducing heat into a potentially hazardous environment. The Touchswitch design addresses these 3 issues. First, it detects the lateral force of the belt, and gives

09.05.2012 | 19361x | Product news |

4B SpeedMaster™

Speed Switches Calibration & Testing Tool 4B has launched a new maintenance tool that makes the testing of 4B speed switch sensors quick, easy and accurate. The SpeedMaster™ is the only device that accurately tests the calibration of speed switches and their alarm and shutdown underspeed relays. The SpeedMaster™ operates in two modes; input mode provides the user with the machine’s actual running speed, and output mode allows the user to test the speed switch at set underspeed trip points for real time verification of the monitoring system`s alarm and shutdown functions. There is no need to remove the sensor from the machine shaft or change any system connections in order to use the SpeedMaster™. Maintenance and safety personnel can now quickly, easily and accurately test 4B speed switches during recommended inspection schedules. The new Patent Pending technology of the Speedmaster will change the way plants use underspeed monitoring systems and will make the plants safer.

11.04.2012 | 15361x | Product news | |

Touchswitch

Mechanical belt misalignment sensor Belt misalignment on an elevator is a problem that is difficult to solve because it needs to be adapted for each elevator and type of elevator. When traditional techniques are used such as inductive, magnetic and capacitance sensors, different factors need to be considered: elevator size, bucket size, bucket type (steel, stainless steel, “plastic”, aluminium…), type of transported product, because in this case it is the buckets that the sensors detect. This is not always easy and sometimes difficult to realize. The TOUCHSWITCH is a new type of stainless steel sensor that has been designed to solve the problem of belt misalignment detection in zone 20 on conveyors and especially on elevators. The Touchswitch reacts to the pressure exerted on its front cover by the misaligned belt or pulley. The sensor communicates with a relay contact which triggers an alarm or stops the machine. The sensor is easy to adjust and can be used with pressures between 2 and 5 kg.

14.12.2011 | 13752x | Product news |

4B Bulldog

Belt Alignment & Rip Detection Switch 4B have launched the new 4B Bulldog belt alignment and rip detection switch. This electro-mechanical system has been designed to detect dangerous misalignment of the conveyor and also detection of belt tear damage. The switch will detect horizontal misalignment of belts when contact is made with the roller; the roller arm will be forced to pivot by the belt activating a switch at 15º to trigger an alarm, and 30º to trigger a shut down procedure of the conveyor. The sensors are usually installed in pairs on opposite sides of the belt. A steel flexible wire is set below the running conveyor belt approx 20-30mm attached by a rare earth magnet at each end. If the belt is ripped or damaged the wire is pulled away releasing the magnet connection which in turn will activate a switch. The Bulldog’s robust design makes it suitable for the use in heavy duty applications such as quarrying and mining. It is easy to install and doesn’t need calibrating. The Bulldog is compatible

14.09.2011 | 16273x | Product news |

Atlas AM Elevator Bucket

Versatile, robust bucket, ideal for Atex applications 4B are pleased to announce the introduction of the new heavy duty Atlas AM Nyrim elevator bucket. Thanks to its antistatic material, the Atlas AM bucket has excellent surface resistivity dissipating properties, making it ideal for ATEX applications. The bucket’s non-stick properties are enhanced by its smooth surface finish and open design. The Atlas AM is a very tough, long life elevator bucket with ultra heavy duty design and construction; the material makes this bucket up to 6 times stronger than other industrial elevator buckets. A very versatile elevator bucket, the Atlas AM is suitable for heavy industrial applications as well as grain and sticky materials. 4B offers the world’s largest range of elevator buckets, bolts and belts and looks back on more than 120 years of supplying the industry with material handling components. The company offers a free engineering service as well, helping customers with the design of their new bucket elevators or the upgrade

17.05.2011 | 15736x | Product news |

Adjustable Depth Bearing Temperature Sensors (ADB)

4B’s adjustable depth bearing (ADB) temperature sensors have been designed to allow the depth of the probe to be adjustable depending on the application. The ADB series are available with three standard probe lengths of 2, 4 or 8 inches (50, 100 and 200mm), and screw directly into a bearing housing through the existing grease zerk thread. There is no need to remove the sensor for bearing lubrication since each sensor is fitted with its own grease zerk. The ADB series have NTC type thermistors which allow for continuous temperature monitoring, and they can be connected to a PLC or to a hazard monitoring system, such as 4B’s T500 Hotbus Elite or Watchdog Elite. The ADB Series of bearing temperature sensors have been approved for use in hazardous areas according to ATEX, CSA and IECEx. 4B Braime Elevator Components is a leading supplier of level controls, intelligent sensors and safety control systems that prevent costly downtime and minimize the risk of explosion

08.12.2010 | 16820x | Product news |

RLI "Shaker"

Rotary Level Indicator 4B Braime have launched a new type of rotary level indicator, the RLI “Shaker”. A rotary paddle switch,to detect high / low levels of bulk granular solids in bins, tanks and silos, the RLI "Shaker" can also be used to detect plug conditions in spouts, where long life and failsafe detection is required. Utilizing a unique stepper motor drive, the RLI “Shaker” rotates clockwise, then counter-clockwise and then shakes to shed any excess material build up. If the paddle rotation is impeded at any time by the bulk material then the electronic circuit provides a signal for level indication or control. The RLI “Shaker” uses fewer mechanical parts compared with standard rotary level indicators. No gearbox or clutch is required as the stepper motor drive is directly coupled to the output shaft and is practically indestructible and cannot be damaged by forced or backwards rotation. Also, an adjustable torque control allows one unit to cover many different

08.12.2010 | 15492x | Product news |

4B Drop Forged Chain

New Sizes and Styles now available 4B’s forged chain is machined to precise tolerances and heat treated to endure high temperature and highly abrasive applications. Made from the best materials, 4B’s drop forged chain also maintains the highest tensile test results on a consistent basis. In addition to the popular 102, 142, 216 and 260 mm chain pitches together with accessories to suit, 4B now manufactures 125, 150, 160, 175, 200 and 250 mm chain pitches as well. For specialized, high capacity applications, 4B also offers double and triple chain links. New sizes on request. 4B"s drop forged conveyor chain has been used in the following industries: Commercial Grain Terminals, Commercial Grain Processing, Oils, Sweeteners, Ethanol, Flour, Feeds, Dewatered Sewage Sludge, Incineration, Calcined Petroleum Coke, Calcined Limestone, Calcium Carbonate, Calcined Zinc, Raw Gypsum (and DSG), Coal and Coal Ash, General Ash Handling, Refuse Incineration, Refuse Ash, Cement Clinker, Meal and Portland

24.09.2009 | 17598x | Product news | |

The PNEUMAG

Magnetic separator for conveying lines The PneuMag is a high intensity magnetic separator designed to remove ferrous and stainless steel scrapings from pneumatic conveying lines operating at up to 25m/s. It features a centrally positioned high intensity magnetic grid with quick release toggle clamps, tamper proof cover plate and totally stainless steel construction. The PneuMag is particularly suited to flour, sugar and other powder and granulate processing. It is Atex certified for zones 20 interior and 21 exterior. • High magnetic performance - 9000 Gauss • Reduces `spark` risk • 316 grade stainless steel construction • Cleaned in under 30 seconds • Tamper proof guard • Silicon rubber, metal detectable seal

03.02.2009 | 16535x | Product news |

4B Watchdog Elite

Monitoring system for bucket elevators and conveyors The latest NTC Watchdog Elite now incorporates continuous bearing temperature monitoring as well as fixed trip point monitoring. The system uses solid state NTC sensors or PTC sensors, allowing the user to set a temperature trip point and to monitor actual bearing temperatures in real time. Continuous temperature reading outputs can be monitored in any combination of up to 6 bearings, gearboxes, or machine surfaces. As with our previous Watchdog Elite control units, you will also be able to monitor belt speed, belt and head pulley alignment, and plug condition on a single bucket elevator or belt conveyor. The LCD screen displays machine status (available in 4 different languages) and a super-bright LED display shows belt speed. It is easy to calibrate and setup using a simple front-panel touch button interface. The system includes alarm and shutdown contacts, RS485 output, and an optional PLC interface. Cert: ATEX/ IECEx Zones 21 & 22, & CSA Indication of

02.02.2009 | 9354x | Press release |
