Schenck Process employee Jan Krall wins Hessenmetall’s innovation competition Jan Krall, a student on a dual degree program working at Schenck Process Europe, won the “M+Eine Zukunft” innovation competition for the next generation, which took place on February 22 and is organized by the employers’ association Hessenmetall, with his project “Schenck Process becomes smart and sexy”. The jury acknowledged Mr. Krall’s commitment to making Schenck Process even more attractive with new ideas. With the help of Angela Metzger, the Head of Training, the junior mechatronics engineer won first place in the “Students on a Dual Degree Program” category. As part of his project, in the last year Jan Krall established the future lab, where Schenck Process pools expertise from a very wide range of areas and in which it involves not only its employees, but also its customers. Its goal is to produce marketable innovations and thus increase the customer benefits. The jury appeared impressed by the fact that the future lab had already achieved an

An easy way to measure the performance of vibrating machines with a smartphone Is your equipment giving you good vibes? Or is it time for a fitness check? With vibe2know™ from Schenck Process, anyone can determine a vibrating machine’s current performance. The user simply inserts a smartphone into the specially designed mount and attaches it to the equipment. The app then immediately measures vibratory amplitude, frequency, oscillating angle and operating speed, and enables the user to visualize the vibrating machine’s motion pattern. By getting a quick indication of these key parameters, operators can avoid a sudden production outage and plan a timely maintenance intervention. vibe2know™ is already available via app stores for iOS, Android and Windows. It is highly intuitive to use and includes a brief tutorial. The mount can be obtained directly from Schenck Process. Easily attached to equipment by means of a magnet on its reverse side, it is robust and dust-tight, specially designed to withstand the accelerations of a vibrating

New features improve the user experience Schenck Process has recently added new features to its DISOCONT® Loss in Weight feeder control platform that customize, simplify and enhance the user experience. Some of the key additions include a favorite’s folder, customizable calibration sequences, detailed event message text and the use of HTML5 for online equipment monitoring. Utilizing the Schenck Process Easy Serve Service Tool, a favorite’s folder can be created giving operators quick access to all the different parameters that are critical and unique to their individual process. Parameters that are rarely used can be hidden eliminating the need to search through multiple parameters that are not relevant for the user’s particular process. A customizable calibration sequence easily leads operators through the required calibrations. Sequence checkmarks indicating that a calibration has been completed, progress bars and detailed status and event messages are just a few of the enhanced operational

Optimized, low-maintenance, flexible Optimized design, flexible hopper walls and flexible installation options make the ProFlex® C a tailored solution for the compound and masterbatch industries. The ProFlex® C feeding system is used for the continuous feeding of bulk materials such as powder, granulates, pellets or fibers. With ProFlex® C 500, 3000 and 6000, Schenck Process offers three feeder sizes with a total of five extension hoppers. All ProFlex® models have extension hoppers which are easy to clean and an adaptable, space-saving design that enables optimum installation in existing and new production plants. The off-center feeder arrangement allows up to eight feeders with close-fitting discharge helixes and nozzles to be used. The drive and feeder setup can be customized during assembly. For maximum flexibility, the direction of the discharge side can be easily changed at any time. Schenck Process is now offering the choice between different discharge lengths as standard. Only two highly

Diagnosis via internet access reduces downtime and service costs Early identification and rapid response to potential faults are key to effective, predictive maintenance. With the PROXiQ Remote Access System from Schenck Process, experienced service technicians can now access machine controllers from anywhere in the world, 24/7, for early diagnosis. “An early intervention significantly drives down support and repair costs,” according to Manfred Bruckner, Global Director – Plastics at Schenck Process. “Combined with a service contract, the remote access concept behind PROXiQ also reduces or eliminates machine downtime by enabling better predictive maintenance.” Remote access is available to the customer’s own service group and, at the customer’s discretion, to Schenck Process staff worldwide. “The early detection of, for example, component fatigue by our expert technicians typically enables a simple fix,” said Manfred. With PROXiQ, a robust industrial router is installed in the vicinity of the machine, which

Darmstadt TestCenter now supports testing of complete integrated solutions Process industry professionals know that materials and equipment must be perfectly matched to deliver optimal results at lowest cost. Realistic and practical tests at Schenck Process TestCenters provide answers to their most searching questions. The company’s latest TestCenter installation, dedicated to pneumatic conveying, is now up and running in Darmstadt to help customers make the ideal choices. Pneumatic conveying offers flexible, clean and energy-efficient conveying solutions for maximum productivity. The facility now offers a choice of conveying technologies, allowing Schenck Process to closely match solutions to a customer’s specific requirements. The continuous dense phase pneumatic conveying system has an extremely low breakage rate for highly sensitive bulk material, while the dilute phase system can be optimized for rate or efficiency. Both can be configured over 50 or 100 meter loops and are capable of rates up to 15 tonnes per hour. The new Pneumatic

Schenck Process has announced the latest extension to its MULTIDOS® weighfeeder range. MULTIDOS® VDP-C is a new range of medium-sized and compact apron weighfeeders mainly suitable for raw material feeding, hot clinker feeding and similar applications. “MULTIDOS® VDP-C leverages the proven technical features and component reliability of the existing MULTIDOS® weigh- and apron feeder designs while addressing specific application scenarios. In particular, it offers a perfect solution wherever a regular rubber belt weighfeeder would otherwise be chosen but cannot be installed because of the physical, chemical and performance limits of a rubber belt,” according to Peter Groll, Managing Director Construction & Energy, Schenck Process EMEA. “Moreover, because we have taken a ‘designed straight for the job’ approach, the cost is significantly lower than competitor apron weighfeeders,” added Groll. With a completely enclosed design the MULTIDOS® VDP-C

Agreement to sell Schenck Process with private equity funds by Blackstone reached Headquartered in Darmstadt, Germany, Schenck develops and manufactures innovative solutions for a wide range of industrial processes including weighing, feeding, conveying and filtration. With over 2,300 employees’ worldwide and significant operations across Europe, North and South America, China, India and Australia, Schenck serves a diversified customer base across a variety of industries, including food, chemicals, mining and construction. “Schenck is an innovative and unrivalled leader, and we see considerable opportunity to grow the business both organically and by acquisitions in its various end markets. We are excited to team up with management and accompany Schenck in the next stage of its development,” said Lionel Assant, Head of European Private Equity at Blackstone. “This investment underlines our strong commitment to the German market as we continue to evaluate further opportunities across Europe. Blackstone has a proud record of working with

Schenck Process E-finity® is a patented continuous dense phase conveying system for fragile materials. Precise pressure monitoring and airflow corrections allow the system to operate efficiently under all conditions, while gently inducing materials through the convey line in slug form. E-finity® is ideally suited for granular and pelleted materials, and has proven itself on many projects for pet foods, cereals, nuts, grains, prills, and pelleted material. Unique E-finity® air controls can employ a single air source to operate 2-3 different systems simultaneously. The result is a significant cost savings in both equipment and installation, with continued savings in operation and maintenance moving forward. Our abilities to design, size, sell, fabricate, and integrate other OEM processes as well as installing and providing ongoing support delivers full control. As the primary equipment manufacturer, we manage production schedules for faster lead times on highly-engineered,

Schenck Process Condition Monitoring System maximizes vibrating machine uptime Inspection and maintenance account for up to a third of the indirect costs in production plants. Condition monitoring systems enable companies to realign their maintenance strategies around fault detection and prevention and save money. CONiQ from Schenck Process offers distinct advantages as a CM system specially designed for vibrating machines, with unique six-dimensional vibration measurement. With CONiQ, Schenck process consolidates its position as a provider of intelligent Industry 4.0 applications. Proactively avoid interruptions to production “In heavy industries such as mining or steel manufacturing, machines are confronted with unparalleled harsh conditions,” says Jan Schäfer, Product Manager, Schenck Process R&D. “Short maintenance intervals, unplanned machine breakdowns and the damage that can result are the attendant consequences. Companies that until now have relied on corrective maintenance need to change their thinking in a competitive environment,

Presenting the MULTIDOS® F weigh feeder: a hygienic design The tried-and-tested MULTIDOS® F weigh feeder from Schenck Process is available in a hygienic design version, extending its area of application. It has been specially adapted for the needs of the food industry, making the MULTIDOS® F the optimum solution for gravimetric feeding and recording mass flows. The system not only allows Schenck Process to meet the stringent hygienic requirements of the food industry, it also offers numerous other benefits: The weighing module is incredibly simple to dismantle and assemble, saving time and effort where frequent cleaning is required. Wet cleaning with a jet of steam is also very straightforward and hassle free. All parts that require cleaning are secured with easy-to-use plug connections. It is also available with a dust proof housing if required by the customer. If the installation height is very low and gaps in transport need bridging, it’s certainly the right system: economic, space-saving and virtually maintenance-free.

The new ProFlex® F for optimum solutions in the foodstuffs industry What is the right amount of seasoning added to a ready meal? For products to ultimately taste as they should, the foodstuffs industry requires recipes that are accurate to the gram. This demands a lot from the feeder, which not only has to be matched perfectly to the properties of bulk materials and feed rates, but must be able to fit flexibly into any space too. The solution is the ProFlex® F from Schenck Process. The experts from Schenck Process present the new ProFlex® F, a version of the tried-and-tested ProFlex® feeder system boasting hygienic design for the food industry. It makes light work of both gravimetric and volumetric continuous feeding of food products. The new innovation from Schenck Process is available in hygiene standard one for dry cleaning and hygiene standard two for wet cleaning. Customers can pick from three ProFlex® F sizes (F500/F3000/F6000), and various feed hoppers, augers and spirals for optimum adaptation to the relevant material

Screen panels allow the efficient separation of bulk materials The efficient separation of bulk materials is a basic requirement for a high-quality product. Screen panels from Schenck Process ensure that aggregates and material from the steel industry are correctly graded. And now, in addition to production facilities in Australia, Brazil and China, the screen panels are also manufactured at in-house facilities in Germany. Customers’ requirements specify the screen panel to be used with a particular screening machine. Schenck Process offers system screen modules made from highly wear-resistant polyurethane in hardness ranges between 55 and 90 on the Shore A hardness scale. Production is tailor-made, and mechanical finishing ensures the most precise fit. Depending on customers’ requirements, the system screen modules can be made from various wear-resistant materials in a polyurethane frame. The considerable advantages of screening equipment from Schenck Process: The customer receives a complete screening machine from a single

Big isn`t always better. From Schenck Process there is now an ideal solution for feeding very small volumes of powder, and it`s called MechaTron® Min. This gravimetric feeder has a delivery rate between 100 g/h and 10 kg/h. Typical applications include laboratory and test facilities for feeding extruders, mixers, mills and granulators. The MechaTron® Min features a double shaft and vertical agitator. It is designed to allow quick dismantling for cleaning and replacement of the discharge devices. Two different feed hoppers are available to suit different products and delivery rates. The 4 l hopper with negative taper has an agitator that works near the base and is suitable for manual filling and small outputs. The 8 l hopper is conical and also has an agitator that works near the walls and a cover with refill and ventilation necks for larger outputs and automatic refilling. Both versions come with integrated measurement, control and regulation electronics of

DISOCONT® from Schenck Process has always been synonymous with reliable measurement, control and regulation for continuous feeding. Now, the improved electronic system DISOCONT® Tersus takes the previous standards to a new level with intuitive touchscreen operation, intelligent interfaces and optimised modularity. Say goodbye to limits The aim of the DISOCONT® Tersus developers was to create a system for all. The result is a modular structure with several optional add-ons. Users can simply combine the units they require to produce an optimised and cost-effective solution for their particular application. The software has been enhanced to automate additional functions. The modular system adapts to applications of any complexity, and for ease of use the controls for standard applications have been reduced to the bare essentials. This is a system that delivers on its promises. Users can deploy the system in such a way as to fulfil their exact requirements. The

How do you add more convenience, performance and quality to a multi-functional solution that is already successfully established on the market? With new and improved features that respond to the requirements of tomorrow. That`s exactly what you get with the DISOBOX® Plus. Analogue scales: upgrade to digital and go one better than conventional solutions The main feature of the DISOBOX® Plus is the fact that it provides a simple solution to a complex requirement. It cost-effectively converts any conventional analogue scale into a high-performance digital scale. Combined with evaluation units from the DISOMAT® range or the PC software DISOVIEW E, it creates legal-for-trade mechatronic weighing systems with almost unlimited applications. To put it another way, it transforms traditional scales into multi-functional precision weighing solutions for the challenges of tomorrow. Separate digitisation processes for more accurate results The most important feature

Schenck Process presents a new force sensor shaped by interoperability The InnoTrans trade fair running from 21 to 24 September 2010 in Berlin is focusing on road- and rail-based measuring technology. Schenck Process specialists will be presenting their new MULTIRAIL® InterScan flat sleeper with Y/Q option. The major advantage of this new product is that Q and Y forces are localised when measuring the wheel loads passing over it. High loading in a Q or Y direction can thereby be recognised in good time, making needs-based maintenance possible and delivering major potential cost savings. The special MULTIRAIL® force sensor also ensures increased reliability. Excess axle loads, uneven distribution of loads or impermissible lateral forces can result in tilted vehicles and cause accidents or costly damage. In the worst case scenario, trains can even derail - but thanks to MULTIRAIL® InterScan, such events are consigned to history. MULTIRAIL® InterScan also calculates dynamic wheel forces, most of which are caused by wheel flats. This

Proven technology + state-of-the-art design = the ultimate solution for feeding solid fuels For more than six decades, Schenck Process weighfeeders have been paradigms of reliability, precision and operational safety. While these long-established products have enjoyed a glorious history, their quality, functional, software and stability features have now been further refined. The Stock Equipment Company* has been part of the Schenck Process Group since 2006. This company has long been a leader in shock pressure-proof systems. The MULTIDOS® High Pressure Gravimetric (HPG) weighfeeder is the result of collaborative work between the two companies. It is a new generation of weighfeeders/coal conveyors resistant to 3.5 bar shock pressure, offering greater efficiency than ever before. The first choice for fuel feeding The gravimetric feeding technologies constructed by Schenck Process for coal feeding since the 1930s are considered highly reliable and as the standard for accurate raw coal weighing and feeding; something proven by the fact that more than

Partnership between weighing technology leader and material analysis innovator creates new possibili Partnership between weighing technology leader and material analysis innovator creates new possibilities for effective process automation strategies across multiple process industries Schenck Process GmbH of Germany (“Schenck Process”) and FCT-ACTech Pty Ltd of Australia (“FCT”) are pleased to announce the signing of a Sales Representation Agreement for the promotion of FCT’s unique Continuous On-Stream Mineral Analyser (COSMA) by Schenck Process in multiple territories including the European Union (excluding Scandinavia), North and South America, Russia, Ukraine, Africa, India and China. FCT have developed and patented the first continuous field-based on-stream mineral analyser based on innovative XRD analysis technology and is set to revolutionise the field of quality control and subsequently the optimisation of production costs in a wide range of industries from cement and fertilisers to steel and non-ferrous metals. Therefore, this co-operation

Wirelessly configuring and monitoring scales from "a safe distance" Weighing and feeding can be a very elaborate, time-consuming and costly process. Configuration, monitoring and maintenance work are significant factors depending on the raw materials to be processed and the system properties. In some cases, scale controls used in tough environments incur high maintenance and repair costs. Ten years ago Schenck Process took its first major step towards improving cost/benefit ratios with specially designed mechatronic weighfeeders. These feature mechanics and electronics in a shared sturdy unit which makes them particularly robust, durable, easy to maintain and highly interoperable as various interfaces allow them to be linked to virtually any automation system. EasyServe. The name says it all The EasyServe service program can be used to conveniently install, configure and monitor the weighfeeders using a laptop. And thanks to new Bluetooth wireless modules, this process went wireless two years ago. A process requiring

The volumetric version of the gravimetric ProFlex® C feeder is a low-cost alternative to a proven Schenck Process product. It is also used to feed additives and fillers in powder, granulate or fibre form. One particularly appealing feature of the volumetric feeder is that it requires no maintenance. Its well thought-out design also makes flexible installation possible. Available in two feeder sizes and a total of three container sizes, the system fits in any available space. Up to eight feeders can be installed in a very compact space to form one complete feeder station as the augers are positioned off-centre. The position of the drive and auger can be changed at any time and they can easily be modified later on. Vertical container walls mean that optimum use is made of the space available and this also impacts positively on how the bulk material flows. The ProFlex® C feeder system is available in two discharge lengths for feed rates of up to 9500 dm3/hr. Maintenance-free

Hygienic design for MULTIDOS® L Weighfeeder The MULTIDOS® L Weighfeeder from Schenck Process delivers outstanding results in gravimetric feeding tasks or when recording mass flows of special products. If the installation height is very low and transport distances need to be covered, it"s certainly the right system: economic, space-saving and virtually maintenance-free. MULTIDOS® L is available both as an open design and with a dustproof housing variant. It is either supplied in its standard industrial design or special designs for a host of different industry sectors. This weighfeeder has an individual, customised solution for any application. MULTIDOS® L with hygienic design The MULTIDOS® L is now available with a hygienic design which satisfies the most stringent hygienic requirements of the food industry and offers numerous benefits. For example, the weighing module is incredibly easy to dismantle and assemble, saving time and effort for frequent cleaning intervals and wet cleaning. All relevant

Schenck Process is pleased to announce the acquisition of the bulk material handling assets of the TEDO Company s.r.o., Czech Republic. This acquisition further strengthens the position of Schenck Process as a global supplier of solutions throughout the process industries. Founded in 1993, TEDO have profound engineering competencies within the field of bulk material handling and serve a similar customer base to Schenck Process in the cement and power industries. TEDO’s innovative range of tube conveyors, conveyors with u-shaped rubber belts and vertical bucket conveyors compliments Schenck Process’ existing range of bulk material handling applications and strengthens our position in the European market. As a result of this acquisition, TEDO’s highly experienced engineering and design team will be integrated into Schenck Process’ Czech Republic organisation, Schenck Process s.r.o., located in Prague. Schenck Process with headquarters located in Darmstadt,

Kemutec Powder Technologies announces the installation of a high specification package for GSK. GSK had several requirements for the package to fulfil, central of which was to accommodate a multi-product process train. This was achieved by designing in quick change operating parameters, equipment speeds, type of grinding media and sieve and screen type. The package consists of two RB100 screw feeders, which lead into two KEK Under-Driven Cone Mills. These in turn feed into two KEK Centrifugal Sifters. Mobile and sliding support mechanisms were developed to allow a milling or sieving operation to be added or removed from the process quickly and easily. The sifters are mounted on moveable structures, as GSK required them to be interchangeable with two existing flat-deck machines. Impressively, all machines used in the package are manufactured in C22 Hastelloy, thus accommodating the corrosive nature of materials and cleaning fluids. All of the machines were pressure

Recognised as a world market leader by the Hesse Ministry of Economics Schenck Process has a high standing in Hesse. On the 28th of October 2008, Schenck Process GmbH was awarded first prize in the `World Market Leader` category of the `Hessen-Champions 2008` competition for its world leading and outstanding performance in measuring and process technology. The Darmstadt-based company not only feels honoured that it has received this award but warmly welcomes the acknowledgment of a successful development and strengthening of its strategy by the awarding committee. Schenck Process has played a role in measuring and process technology for more than 125 years and offers innovative solutions to its customers all over the world time and again. The solutions include feeding and measuring technology in diverse industrial sectors e.g. cement, food, mining, pharmaceutical, power, steel and transport industries. With its feeders, the company ensures for example that industrially produced pizza dough has just the right pinch of salt and that

Schenck Process, Germany, is pleased to announce agreement on the acquisition of Screenex Pty Ltd (`Screenex`) of Australia from the Locker Group. Serving both the pre and after sales markets, this acquisition further strengthens the position of Schenck Process as a global supplier of solutions throughout the process industries. Founded in 1983, Screenex is a leading manufacturer and supplier of screening products and solutions used in vibratory screening equipment. Screenex achieved its leading position through the focussed application of technology, innovation and design based on many years of servicing the mining and heavy industries. Dr Jochen Weyrauch, President & CEO Schenck Process, commented: `We warmly welcome Screenex into the Schenck Process Group. The combined product offering now enables customers to purchase both their capital equipment vibratory screening machines and wear parts from one source. Operating in often the harshest of environments in

Perfect feeding from 1 to 6,000 l/hr Recipes harmonised down to the last gram are a guarantee of quality in the compound and masterbatch industry. The ideal feeders must therefore be fully harmonised to the properties of the bulk materials and feed rates and need to be flexible in terms of spatial requirements as well. As previously announced, Schenck Process has extended the ProFlex® C feed system to include the 6000 Series for this very reason. The ProFlex® C feed system unveiled at POWTECH 2008 is used for volumetric and gravimetric feeding of additives and fillers in powder, granulate or fibre form, which are needed for the refinement of plastics. Depending on feed rate requirements, we would recommend using either the ProFlex® C500 or ProFlex® C6000 variants. Both basic models can be complemented with various feed hoppers, feed screws and spirals. Space-saving, flexible, quality-enhancing. The ProFlex® C500 and ProFlex® C6000 Series from Schenck Process are characterised by their

INTECONT® Opus offers user friendliness and precision in the 0.5 accuracy class What would weighing and feeding technology be without precise analysis systems? The answer is obvious – and Schenck Process, the global market leader in measuring and process technology, is regularly spurred on to deliver the best performance in this area. Schenck Process has successfully produced another such highlight with the development of the INTECONT® Opus especially for legal-for-trade belt scales, which has just been launched. It replaces the INTECONT® PLUS for legal-for-trade belt scales that have been used for evaluation electronics in Germany and other countries for many years. The level of proven quality is once again raised in the INTECONT® Opus. In comparison with its predecessor, it offers impressive state-of-the-art technology, as it is based on the ultra modern ARM9-based processor platform. This is yet another major advancement in measuring technology, because approval for the new product not only includes the previous 1 and 2 accuracy classes

DFT truck scales, the fifth generation The experience gained from the DFT variant of the truck scales of which, more than 2,700 have been sold throughout Europe to date, can be seen in the fifth generation’s optimised concept. For example, the entire truck scales are pre-fabricated out of high-quality precast concrete parts of the C45/55 strength class. When combined with the robust, zero-maintenance RTN ring torsion load cells and suitable elastomer mount elements or the new low-cost VDW load cell, we supply a complete model that can be installed in just one day. Depending on the length of the scales, they may be supplied in a pit version as a one- or two-part weighbridge with foundation bed, or as an above-ground version, in the following standard designs. With a single weighbridge in sizes: 8m, 10m, 12m. With two weighbridges in sizes: 16m, 18m, 20m, 24m, 25m. Special sizes can be supplied in various versions. The benefits at a glance: · Pit or above-ground version made from precast concrete

Low-cost VDW load cell and DFT truck scales For many years, the RTN load cell used in Schenck Process’ truck scales has been a reliable guarantee for high quality standards. And now, the new low-cost VDW load cell for the latest generation of DFT truck scales offers customers even more alternatives. Schenck Process sells truck scales of various designs all over the globe. Depending on where they are used, both technical standards and local competition may vary. The truck scale solutions deployed reflect these variations. Until now the only common denominator has been the robust, durable RTN load cell. But markets around the world are changing. Economic requirements are changing at an ever increasing speed. Demand for simpler, lower cost and electromechanical scale solutions is growing all the time. And Schenck Process has come up with the new high-quality, self-centring VDW pressure load cell for this very reason. Many of its details are based on the experiences gleaned from the long-established RTN load

An outstanding employer As a result of a study conducted by CRF, Schenck Process has been awarded the `Top employer for engineers 2008` seal in Germany alongside 24 other well-known companies. Here are five good reasons why: ·Internationality – with 25 sites around the world, Schenck Process gives its staff the opportunity to deploy their know-how around the globe. ·Open company structure – we give our staff room to develop their own careers – they can for example switch from a technical position to a management career path. ·Flexible working hours model – staff have time accounts to which overtime is credited and can then be changed into time off. We have no core working hours, which means that staff are relatively free to determine their working hours with their team. ·Prospects for the future – whether they are looking for a work placement, apprenticeship or first job after graduating, Schenck Process offers young people the ideal springboard for their career. We

Award for Mechanical Engineering Companies Schenck Process is the best example of the successes a good strategy process can deliver. In recognition of the successful definition and ongoing realisation of its growth strategy, the Schenck Process Group are delighted to announce that management consults Oliver Wyman and the Produktion business journal have conferred their 2007 Strategy Award for Mechanical Engineering Companies in the category of `Best Growth Strategy` on the Schenck Process Group. Citing ability to achieve targeted financial results, in presenting the award Oliver Wyman acknowledges Schenck Process’ transition from a component supplier to a leading provider of complete solutions. `The focus lies on the production of key components and on solutions with a clear differentiation and high customer benefit,` says Thomas Kautzsch, Partner at Oliver Wyman in Munich. Additionally, selective acquisitions as well as the exemplary growth of its service business further convinced the awarding jury. The

Which feeder is best for which bulk material? In order to provide customers with accurate answers to this question, Schenck Process GmbH are now offering tests at their new, modern TestCenter in Darmstadt that are based on real life situations. The specialist in measuring and process technologies invited its customers to the centre`s official opening on 27 February. More than 100 people attended the event to learn more about what the new centre has to offer. Just like at a trade fair, the event enabled them to view several highlights under one roof. More test rigs and an improved level of automation mean that the TestCenter can now run even more accurate tests, all very closely based on actual processing circumstances. Just like real life Tests in the four test labs can be run in parallel without impacting negatively on one another. Three of the test labs feature different equipment for filling the feeders with bulk bags or pneumatic feeding and complete cycle

in the Weighing and Feeding Equipment Market Frost & Sullivan confers its 2007 European Growth Strategy Leadership Award on the Schenck Process Group (Schenck Process) acknowledging the company’s structured approach to its business via 5 International Business Segments, broad product portfolio, ability to provide complete solutions to its customers and capacity to deliver continuous local support while maintaining a global presence. Acknowledging the unique way the company leverages its solutions in weighing and feeding technology across a wide spectrum of end-user industries and applications, Frost & Sullivan analyst Karthikeyan Balasubramaniyam notes ” The Schenck Process Group has fortified its position in the European weighing machinery and feeding equipment market under a collective impact of balanced business approach, vast process industry experience, technological expertise, broad market coverage and strong sales and service network. The success of the company in being able to synergise these key

The new generation of feeders for the compound industry How can you make something good even better? By bringing together the best solutions and developing them consistently. The ProFlex® C special feeder with its proven Schenck Process quality and stability has been developed in this way and is based on the experience of two generations of feeders with flexible troughs. Save space and time, adapt flexibly and improve quality When fitting in existing and new production facilities, every millimetre counts. That’s why the engineers who developed this product were especially keen to produce a design that can be flexibly adjusted to any specific space using two feeder sizes and a total of three container sizes. The special characteristics of the ProFlex® C can be seen even during installation. The off-centre arrangement of the augers allows up to eight feeders to be installed in the optimum space. The arrangements for both the drive and augers can be adjusted during installation at the build end-user. Two discharge

Schenck Process is extending its core competency in the 500 g/hr to 150 kg/hr range. The PureFeed® AP auger feeder satisfies the stringent requirements of hygienic design. The feed system is suitable for gravimetric or volumetric feeding of powders and granulates. It is used in the pharmaceuticals, nutraceuticals and cosmetics industries for the feeding of mills, mixers, extruders and compounders. Given the external non-intrusive agitation of its flexible feed hopper, the PureFeed® AP discharges the product gently, ensuring optimum bulk material flow. The penetration depth and frequency of the external agitation can be conveniently set to product specific requirements. The auger feeder is available in various geometries which can be easily adjusted to the application and also handle challenging feeding tasks. Pulsation can be reduced at low delivery rates thanks to the innovative “Wire Helix” auger geometry (patent pending). Feed hoppers of various sizes

Schenck Process is breaking into new ground in applications for feeding very small volumes of bulk material. Its latest feed system, PureFeed® DP, is particularly well suited to continuous, gravimetric feeding of tiny volumes of powder with manual refills. The innovative technology deployed in the PureFeed® DP allows for high-accuracy feeding of small volumes from between 20 g/hr to 2 kg/hr using a speed-controlled, ceramic feed disc which rotates at the base of a cylindrical hopper and acts as the discharge mechanism. This disc separates the material supply from the outlet opening, avoids uncontrolled outflow and prevents the bulk material which is already contained within the feeder from compacting. The moving parts operate at low levels of interfering force. The pulsation-free feed principle and the wide adjustment range allow for precise, gravimetric feeding, especially of tiny volumes, without the discharge mechanism having to be replaced. A patent for

One of the most innovative products presented at Powtech and TechnoPharm 2007 in Nürnberg came from Schenck Process. This was the decision of the panel of jurors from Process magazine and its sister publication Schüttgut, who presented the Innovation Award for the first time at this event. 50 companies nominated their latest products for the award, five of which were chosen to receive the honour from the two trade journals for chemical and pharmaceutical engineering. To convince the jury the winning products not only had to be innovative but cost-effective for the user. Schenck Process won the special award in the Apparatus Construction and Process Components category for its PureFeed® DP system. This feed system is particularly suitable for the continuous gravimetric feeding of very small quantities of powder. The system allows for precise feeding of small volumes while also offering user-friendly maintenance, cleaning and disassembly. The awards were

Frost & Sullivan confers its` 2006 Product Line Leadership of the Year Award` on the Schenck Process Group (Schenck Process) for its comprehensive weighing and feeding product and service offerings in industrial production processes. In presenting this award, Frost & Sullivan commends Schenck Process for its success in providing integrated solutions in weighing and feeding technology across a wide spectrum of end-user industries. "The unique position of Schenck Process is a result of a combination of strategic decisions in terms of product line, combined with outstanding operational execution of product research & development and the tailored implementation of its solutions suited to clients` needs," notes Frost & Sullivan Industry Analyst Titus Hocevar. Titus Hocevar continues, "Providing weighing, feeding, screening and other automation solutions for end users in many different industries, the company has gained importance as the

Darmstadt, Germany, 1st of June 2006. Schenck Process announces agreement on the acquisition of Stock Equipment Company (“Stock”). This acquisition further strengthens the position of Schenck Process as the leading global supplier of weighing, feeding, screening and automation solutions throughout the process industries. Stock together with its Redler and Solvera products is the global leader in the design, manufacture and sale of highly engineered bulk material handling systems and electronic controls for coal-fired power plants and other process industries. Founded in 1929, Stock has the most extensive bulk material handling product offering in the industry with their portfolio including feeding systems, chain conveyors, speciality valves, electronic controls and other accessory products. Headquartered in Chagrin Falls, Ohio, USA with operations in China, India, Japan and the United Kingdom, Stock is well positioned to serve both its international customer

Extensive know-how, product solutions for every application area, extreme reliability and durability Based on a tried & tested and continually developed modular system with standardised assemblies, the different assemblies of the LinaClass product family solve even the most difficult sieving problems – economically and with easy maintainability. The perfectly adapted solution for the sieving of rough sand: the LinaClass 10/55 “SLK” Double-Decker Linear Vibrating Sieve Sieved rough sand has a particle size of 0 – 6 or 4 mm and is fed into the following processing stages. A reliable product result requires the use of an extremely robust sieving machine such as the LinaClass 10/55 “SLK”. This perfectly adapted product solution from Schenck Process consists of a two-part upper deck with PU and weld-gap sieve linings arranged in horizontal and ascending order, enabling the rough sand to be agitated and sieved off. In the further course of the process, clumps of sand are broken down and crushed and fed to the lower deck, where fine and accurate classification

The demands on vibrating machines are enormous when it comes to the classification of quartz sand, where it is essential to achieve extremely fine granulation and perfectly adjusted classification. Other requirements include the ability to be installed in the smallest possible area, completely dust-proof design, synchronously vibrating outlets for the upper and lower deck and a synchronously vibrating sieve basin. They must also be suitable for 24-hour operation low maintenance, reliable and durable. The universal solution from the engineers of Schenck Process: the RotaClass 13/40 “SKG” Double-Decker Rotary Vibrating Sieve The Double-Decker rotary vibrating sieve is suitable for separation at 1.6 mm in the upper deck and 1 mm in the lower deck, driven by rotary agitator cells. Lubricated by oil, the rotary agitator cells of the RotaClass Vibrating Sieves stand out for their long bearing life, simplified accessibility & maintenance and favourable price. Designed

Compact, capable of calibration and equipped with the latest processor and field bus technology, the latest edition to the proven DISOMAT® family demonstrates that logistics solutions with calibration capability can also be cost-effective. The new device is astonishingly capable and versatile, presenting the ideal solution for all straightforward logistics tasks. The Multi-talented electronic with a huge application spectrum. The DISOMAT® Opus has been developed on the basis of the field proven DISOMAT® B plus weighing terminal. Smaller, more compact and offering outstanding value; designed as a multi-talented device for a wide application spectrum: The DISOMAT® Opus weighing indicator is ideally suited for all applications in which weight values must be recorded, displayed, printed & transmitted to a higher-level system for further processing, and also is capable of calibration. Additionally, component/system calibration is possible with the DISOMAT®

Visitors to Anuga 2006 will be able to enjoy a complete product presentation of the DISOBOX®, where Schenck Process specialists will be presenting the functionality of all system components. At Schenck Process the future began a long time ago. This is confirmed by the impressive demonstration of the DISOBOX® monitoring principle beginning with the amazingly simple on-site installation of the system. The DISOBOX® demonstrates its strengths in individual weight recording using a special exhibition model of a platform scale with four load cells of different nominal loads. The load on each individual weighing point can be read off separately – for monitoring of the cells or analysis of the load distribution on the scale. Established weighing data are transmitted to the customer’s network either by field bus or serial interface. DISOBOX® turns every conventional analog scale into a digital scale. DISOBOX® turns every conventional analog scale into

Schenck Process Your Food Technology Partner. The food industry demands that finished products arrive on the market in exact accordance with the recipe. The essential requirements include: the optimum recipe itself and weighing & dosing solutions for accurate, consistent process control – all in a hygienic design. Two “à la Carte” solutions, so that foods meet your taste. Complex requirements demand adaptable solutions. Schenck Process offers individually adaptable solutions for the dosing of main and subsidiary ingredients to the perfect recipe e.g. we ensure that salt, sugar, flour and starch are processed reliably, consistently and economically. So that cereals meet with your taste, pizza tastes “Italian” and rolls taste as if fresh from the baker. Continual, reliable dosing or monitoring of mass flow. Wherever dosing has to be carried out with high accuracy in continual processes, the MechaTron® Gravimteric Feeder is used. For Cereals, flour, starch, salt, mustard seeds,

Semi-mobile Compact System for Secondary Fuels in the Cement Production The challenge for the developers at Schenck was to save material and costs in an effective manner when optimising the compact system. The result is a total solution which still does the entire job on a floor space of 9 x 6 m only. With New Features Virtually Wear-free Since the admission of alternative cost-saving fuels, such as household refuse and waste, which nowadays already replace up to 50 % of the primary energy, the demands on the feeding and conveying systems have become more and more exacting. Because fuel is not always optimally processed, material conglomerates with pieces of more than 100 mm might occur. Those can possibly clog the pneumatic conveyor line. As a remedy a so-called star screen is used, which removes such material accumulations from the process. Metallic parts contained in the fuels may increase wear of the plant, especially affecting the blow through rotary starfeeder. By integrating a metal separator upstream of the endangered

Think big! This saying currently takes on a new meaning. The linear-motion Vibro Screen Feeder type SLG4099XFC by Schenck is gigantic and goes beyond the scope of anything you ever saw so far. It is the largest Schenck screen ever built. Made, assembled, and tested by Schenck Australia. Supplied to Canada. A screen of that size, what is it made for? In brief: for the most severe requirements, for the most extreme envi- ronmental conditions, for the most difficult to handle, non-homogenous bulk solids with the most diverse flow properties. The screen was designed to handle up to 10,000 t/h bulk solids containing thick frozen lumps of up to 1 m in diameter. The oil/sand material contains max. 15% bitumen with strongly varying flow behaviour, depending on the contents of bitumen, geologic properties, and seasonal influences. The feed comprises easily flowing or frozen lumpy material up to a cohesive mat. Material which, from experience, is difficult to break

Bulk Solids Handling Made Easy Production plants have to be adapted to changing and increasing demands at ever shorter cycles. Constant change in the raw materials used is now the norm: Extruders are charged, for instance, with bulk solids ranging from granules to highly adhesive powders - with feeding accuracy having top priority. Adaptation to a new product is „learnt“ by the system through procedures prepared during the first start-up. Thus, the bulk solids can be switched smoothly, meaning a saving in costly working time. Control and coordination of the weighfeeders are taken on by the DISOCONT® MASTER TOUCH. Besides portioning of the various raw materials and the total throughput, the parameter sets of the subordinate feeding control are selected from here. For internal monitoring or evidence for the end-user the Schenck feeding control supports the operator in an optimal way. As proof the process data are recorded and made available for analysis

Gentle Feeding Without Material Arching The SolidsFlow® fibrous material feeder is preferred by drywall producers worldwide for feeding wet chopped fiberglass. Arching or hang-ups in the hopper are prevented and no flow-aid devices are required. The feeder utilizes a special one-piece vibratory feed-tray specifically designed to the material’s unique flow characteristics. This special design allows instantaneous and complete cut-off once the drive is turned off, preventing trickle feed. By the horizontal motion applied to the feed tray a consistent uniform material flow is produced when the feeder is turned on - without damage to the integrity of the fibers. Advantages and Technical Details at a Glance: • Uniform material discharge • No flow-aid devices needed • No moving parts, hence minimum maintenance cost • “Instant cut-off” for optimum batch accuracy • Suitable for continuous or batch operation • Volumetric or gravimetric feeding Fibrous Materials Fed: • chopped

Complex Multi-functionality Monitored by Radio! In combination with the weighing electronics of the DISOMAT® series or the PC software DISOVIEW-E highly precise multi-talented weighing systems evolve. During commissioning, for instance, an exact analysis of the deadload distribution can be made as well as a convenient electronic corner comparison. During operation, the load distribution on the scale is analysed and each load cell is individually monitored. In case of faults the affected component is quickly detected. In the end, this means a considerable saving in time, material, and cost as well as a distinct process safety. Technical Data: ~ Installation of the DISOBOX® in a housing of protection type IP 65. ~ The unit comprises up to eight high-resolution signal channels measuring synchronously and aditional binary inputs and outputs. ~ Universal utilization. ~ When used as 8-times converter up to eight hopper scales can be acquired decentrally and interfaced directly with the existing host system

The economic response to European Parliament Directive 2003/53/EC The above Directive specifies that as of the end of 2004 cement and cement-containing preparations must not contain more than 0.0002 % (2 ppm) soluble chrome-VI since that can cause severe allergic reactions when in contact with the skin for longer periods. Hence, over 350 cement plants throughout Europe had to be upgraded in a hurry. Iron-II and tin-II sulphates reduce the chrome content. With re-ducing agents and water chromate-VI is converted into antisoluble chromate-III hy-droxide harmless to the skin. 0.3 to 0.5 % tin/Fe(II) sulphates must be added. The MechaTron®, designed for 0.5 to 600 t/hr, offers all requisite properties. There are different MechaTron® variants available, depending on material properties and feed rates. For the sluggish Fe(II) sulphate there is the Coni-Flex® variant with flexible dis-charge hopper, for the even more difficult to handle tin sulphate Coni-Steel® with in-ternal agitator is the choice. MechaTronâ systems,

We stand up for increased safety and reduced wear When train speeds are high, there are two crucial requirements: safety and minimal wear. Only perfectly maintained bogies ensure that these demands are met. With MULTIRAIL® BogieLoad, Schenck is banking on safety through all around inspection. Electromechanically designed, the bogie test bed inspects the bogie using the so called spindle technology developed by Schenck. This novel feature increases repeatability and accuracy whilst reducing the maintenance expenditure. The new technology ensures a high degree of repeatability whilst reducing the susceptibility to failure. Positioning is more accurate. The automatic process with hauling equipment and fully automatic bogie centering eases the operation and provides added safety. The remarkable accuracy upon RH/LH inspection is said to be another striking advantage. Technical Data: · Dimensions: l = 5.4 m x w= 6 m x h = 5.82 m · Load generators in the upper portal: 250 KN max. test load · Vertical

LAS - a package solution that pays off! The Schenck Loading Automation System automates your entire shipping process using tailored solutions designed to save huge amounts of time, improve quality, avoid faults, increase efficiency and last but not least reduce cost. A web interface integrated into your PC network enables your dispatchers to conveniently process all orders using a standard browser. The new function is available as retrofit for any existing system. Also new and programmed for safety is the access to your system with the use of a transaction code (TAN) entered once-only. Perfectly tuned to one another, the LAS hardware and software modules automate the inbound and outbound material flow.All components can be tailored to the existing infrastructure, e.g. using touchless ID cards and terminals that can be operated by the truck driver single-handedly. As if by magic, doors and gates open, controllers come on, and defined loading and unloading operations are performed. Largely without operator

Throughout the mining industry, Schenck is renowned for powerful, reliable and versatile screening m The exacting demands of sand and gravel processing are a tough challenge to the screening machines. The high and varying delivery rates of rough gravel with a high portion of sand wreck many a machine. The Schenck vibratory machines, however, stand up to these requirements. The reliable directed force exciters of the DF series and the rotary force exciters cells of the VZ series ensure long life and minimal service at highest availability and exceptional ease of maintenance. The Schenck screening machines enjoy the image that they cannot be wrecked. They actually excel through long service lives and uptimes. The screening machines of the RotaClass, LinaClass and VarioClass series stand out against an intensely competitive market through individual system solutions. Thanks to their field-proven drive technology and the well balanced cost-performance ratio, the powerful screens have proven their worth in the most severe environments. Particularly appreciated is their

The MULTIGRAV Mulit-station Feed System MULTIGRAV® in action So as the need grows, so can the MULTIGRAV® multi-station feed system of the plastics and chemical industries. But this is all mere theory. Come to experience how the granules are fed into the process via a vibro feeder The system module, consisting of the scale hopper and the vibro feeder, is connected in an statically balanced way to an environmentally protected scale module. Each system module operates according to the loss-in-weight principle, with a controlled loss in weight per time unit with a possible setting range of the feed rate of 1:80 and highest feed accuracy and constancy. For the formation of a mixed, the vibro feeders convey the material into a blending vessel specially equipped for optimum blending quality of the various materials to be mixed. Depending on requirements, the blending vessel can also be used as buffer for the downstream process.

Weighfeeder MULTIDOS L in MechaTronic Design Whether granules, flakes, fibres or powdery products in the plastics industry, powder and agglomerates for the detergent industry, or the feeding of flour, powder, cereals, biscuits, salt, etc. for the food processing industry - as measuring or feeding system - MULTIDOS L can be optimised for any particular range of application. - Supplied with standard housing, fully made of stainless steel - FDA-approved conveying belt in white - QuickClean design with detachable side panels, allowing removal of the mechanics to the side - Easy and rapid belt exchange without auxiliary devices - Drive unit fixed outside the housing, without chain drive, with plug-in connector - Modern MechaTronic drive with integral frequency converter, configuration ready, and fully wired with the electronics (Plug and Play) - Wide capacity range of up to 170 m³/h with high measuring and feeding accuracy of 0.25 to 0.5 % - Batching operation with coarse/fine flow function and charging

MULTIGRAV Multi-feed Station Now With EasyClean For ages Schenck Process has been offering specific solutions for the most diverse industries, e.g. for the carpet fibre industry feeding PP granules, master batches and stabilisers. For these processes, quick and clean product change is an important consideration. Based on the classic MULTIGRAV, Schenck Process specialists have developed a tailored solution with a new feature: the MULTIGRAV EasyClean Multifeed Station designed to handle feed rates from 300 g/h to 200 kg/h. - Product change in a few seconds, virtually maintenance-free - Easy access and simple cleaning - High feed constancy and accuracy (better than + 0.5%) through optimised vibro feeder - Nominal feed rate per system module between 0.3 and 400 kg/h (EasyClean: up to 200 kg/h) - Optimal accuracy over a wide setting range - Reduced cabling requirements through MechaTronic installation
