Case study: SysTec controller for olive oil filling station, automated weighing system for the production process of oil mills. The Portuguese olive oil producer SAOV uses W&M approved discontinuous totalizers for weighing and filling tasks. Efficient processes are ensured by the SysTec IT6000E controller and the BULK E application software. The recent project was realized by the SysTec partner Barcelbal. This Portuguese company has many years of expertise in the integration of automated weighing systems into the production process of oil mills. The process After harvesting, the olives are transported to the mill, where they are cleaned of deposits and washed. In the next step, a conveyor belt transports the olives to the pre-hopper of the MCA-TG receiving scale. A SysTec weighing controller, such as IT6000E, captures the total weight of the olives discontinuously via a weighing hopper equipped with four load cells. Then, the olives are transported to the next processing step via another conveyor belt. The robust SysTec controller is ideally suited to the hygienic requirements of the food

The SysTec control system ensures efficient processes in the automated filling system for precise and fast acid filling into IBC containers. The electrometallurgy specialist GfE offers around 250 material compounds on the global market, including vanadium-containing acids for energy storage systems. An automated filling system implemented for GfE by SysTec partner KESTERMANN GmbH is used for precise and fast filling of the acid into IBC containers. The powerful SysTec IT8000E filling controller, together with the FILL E application software, ensure high throughput. The process As soon as the operator has entered the product number of the acid to be filled and the target weight, the system is ready for automatic filling using the bottom filling method. The interaction of the powerful SysTec weighing electronics, the PROFINET-PLC-connection, and the labeling system are important aspects for the smooth functioning of the system processes. The IBCs are moved onto the roller conveyor of the system by forklift trucks and detected by a sensor. In the next step, the IBC is moved to the first turntable, where

Weighing technology combines innovation with tradition For 30 years now, SysTec has been a synonym for globally established weighing technology. Ever since SysTec Systemtechnik und Industrieautomation GmbH was founded in 1994, the company’s focus has always been on innovative weighing indicators and software for industrial scales and systems. The company’s anniversary with the weighing technology expertise gained over decades in research, development and practice forms a strong basis for future business activities. ”Flexibility is a key feature that has strongly contributed to our success. Thanks to the free progammability, our weighing indicators can be adapted to a wide range of customer requirements. The ongoing dialog with our customers provides us with important inputs for our agile product and application development,” says SysTec Managing Director Rainer Junglas. ”But the ability to adapt to difficult environmental conditions is also crucial – such as dealing with the challenges of the pandemic or the

Innovation award for EURO-Jabelmann vending machine with SysTec weighing unit; egional food, cashless payment, availability around the clock and unpackaged sale. The vending machine Jafix UA for unpacked goods, developed by SysTec partner EURO-Jabelmann, meets four trends at once: regional food, cashless payment, availability around the clock and unpackaged sale. The vending machine, equipped with a SysTec IT8000ET weighing unit, won the expoDirekt Innovation Award. Thanks to special SysTec software with an intuitive user interface, consumers are easily guided through the product selection and payment process while the goods are weighed inside the vending machine and then dispensed. Due to its ruggedness and flexibility, SysTec weighing technology has proved its worth for several agribusiness applications. Thanks to free programmability, the weighing indicators can be customized to suit a wide range of applications. Essential features - Consumers can select their goods with the touchscreen of the SysTec weighing indicators and determine the amount using the dosing button - Dosing unit with three containers inside the lockable

High throughput with automatic discontinuous totalizers for bulk weighing of grain Totalizing hopper scales are designed for accurate and versatile monitoring of material flows. Various process steps can be managed effciently, such as raw material receiving, unloading, and dosing. FLINTAB is an expert in this field and has been using SysTec IT8000E weighing electronics and customized BULK E software for years to master these demanding applications flawlessly. Recently, FLINTAB has sucessfully realized two projects with automatic discontinuous totalizers in Romania for the companies AMEROPA / CHIMPEX and TTS. The goal was to carry out the loading of ships/barges with bulk material with high throughputs and metrological accuracy. Facts: AMEROPA / CHIMPEX project - 4 hopper scale systems located in Constanța - Up to 1,200 cubic meters of grain per hour are weighed with the totalizing hopper scales and then transported to the final destination by sea Facts: TTS project - 3 hopper scale systems located in cities near Danube river (Giurgiu, Braila) -

Thanks to the powerful weighing and control technology, up to 40 big bags can be filled per hour. Each big bag has a net weight of 1200 kg. High throughput with W&M approved SysTec weighing indicators When it comes to filling raw materials into big bags, high throughputs are crucial. Therefore, SIBELCO uses a fully automatic EMDE station for cristobalite filling with a W&M approved SysTec weighing indicator IT8000E. Products: * IT8000E: robust SysTec weighing terminal for continuous operation * SysTec application software BIG BAG E ensures fast big bag filling processes * Fully automatic EMDE filling station with robot handling The key facts * 40 filled big bags per hour * 1200 kg net weight per big bag * W&M approved weighing electronics * Recipe management via PLC * Fast implementation of the fully automatic filling station by EMDE In Dessel, Belgium, SIBELCO operates the fully automatic filling station for cristobalite - designed and installed by the plant manufacturer EMDE within a short period of time. Thanks to the powerful weighing and control technology, up to 40 big bags can be filled per hour. Each big bag has a net weight of 1200 kg.
