Innovation award for EURO-Jabelmann vending machine with SysTec weighing unit; egional food, cashless payment, availability around the clock and unpackaged sale. The vending machine Jafix UA for unpacked goods, developed by SysTec partner EURO-Jabelmann, meets four trends at once: regional food, cashless payment, availability around the clock and unpackaged sale. The vending machine, equipped with a SysTec IT8000ET weighing unit, won the expoDirekt Innovation Award. Thanks to special SysTec software with an intuitive user interface, consumers are easily guided through the product selection and payment process while the goods are weighed inside the vending machine and then dispensed. Due to its ruggedness and flexibility, SysTec weighing technology has proved its worth for several agribusiness applications. Thanks to free programmability, the weighing indicators can be customized to suit a wide range of applications. Essential features - Consumers can select their goods with the touchscreen of the SysTec weighing indicators and determine the amount using the dosing button - Dosing unit with three containers inside the lockable

Load cells for all areas of an industrial operation directly from the manufacturer, suited to your application, material choice, protection class, etc. Load cells for all areas of an industrial operation directly from the manufacturer. Weighing is carried out in all areas of industry and load cells of various types based on strain gauges are frequently used. The different load cells are presented and described in detail on our website. Suited to application Depending on the application, different features come to the fore and determine the choice of load cell type. While single point load cells are used for smaller platforms or in various systems, shear beam load cells are used in floor scales, hopper scales or silo scales. Some applications require very fast weight determination, where bending beam load cells have a clear advantage. Material choice The material is also often a selection criterion. Aluminium offers excellent properties for obtaining high-resolution results at smaller nominal loads. Tool steel is comparatively inexpensive and offers a wide range of applications. Stainless steel is indispensable

New, for low capacities. A high protection class and the accurate measurement of small weights is not an easy combination. The sealing against environmental pollution is as a matter of course a source of resistance. New in PENKO’s range of industrial load cells is a model, eliminating this effect; type HPS of Revere Transducers. The specifications are: • Carrying capacities from 6 up to 60 kg • Accuracy class C3 with a 25 % utilisation • Certified in accordance with OIML R60. • Suitable for trade applications. • Protection class IP68. • Stainless steel DIN1.4542. • Single point, for a platform size up to 350 x 350 mm. So in brief this is a load cell that can be used everywhere. Platform weighers, filling machines, check weighers and process control systems can be carried out now, even under not ideal environmental conditions such as in the chemical and food processing industry.

Calog loadcell Tester Zemic Europe has the pleasure to present the new design for our Calog Loadcell Tester. This device is ideal for loadcell trouble shooting in the field. For further technical details, please visit our website. Features: Measure, source and simulate 0 to 24 mA with 1uA resolution Measure 0 to 20 V with 1mV resolution Measure -4.5 to 35 mV with 1uV resolution Measure mV, mV & Mass or Mass & mV Source mV, mV & Mass or Mass & mV Simulate mA, mA & Mass or Mass & mA Built-in 24V power supply for mA loops 2 year guarantee (batteries not included) Carry case, protective rubber boot, charger and test leads supplied as standard Deze informatie is door de leverancier zelf geplaatst.

OIML approved The load cell H8Q has been awarded the OIML R60 C3 approval. The NMi (NL) have concluded that the cells have a Y-value of 15.000 for the standard C3 approval. Approved capacities are 200kg, 500kg and 1000kg. This low profile load cell (f. e. 500kg: height only 19.1mm!) is suitable for weighing applications where space is limited. Also weighing assembly is available.

With our steadily increasing number of load cell models (over 60 families) and OIML approvals, it is our duty to keep our customers informed, therefore we would like to inform you about 3 new OIML Approvals: BM8H Stainless steel IP68 shear beam load cel Hermetically sealed Suitable for hopper, platform and pallet scales High accuracy Current calibrated (sc‐option) OIML certificate for full capacity range: 500 kg - 5t L6P Low profile, parallel beam construction Anodized aluminum alloy IP65 sealed Easy installation OIML certificate for capacities: 22kg, 45kg, 100kg L6P1 Low profile Anodized aluminum alloy IP65 OIML certificate for capacity: 7.5kg

Mettler-Toledo has grown the proven product range of the Pinmount weigh module family with a 100-ton model. The new weigh module for heavy capacity tanks offers dual integrated safety features. Its rocker-pin load introduction ensures high accuracy plus horizontal tank expansion and contraction to compensate for temperature effects. The Pinmount weigh module family consists of seven models with capacities from 7.5 tons up to 100 tons. They are designed for building of tank, vessel, vehicle and conveyor scales with a high safety standard. ATEX and FM approvals allow for use in explosive environments. Their hermetically sealed stainless-steel load cells meet IP68 protection standards to ensure long life in harsh environments. Double Security Their dual anti-lift-up devices protect tanks and conveyors from tipping over in case of strong wind forces or seismic activity. Several integrated safeguards provide security in cases of extreme overload. Two optional stabilizers

Zemic Europe proudly presents the new Top-Sensors line. We would like to introduce our T1 and T2 load cell transmitters. Features T1 Transmitters: • Weight transmitter and indicator for Omega/Din rail mounting. • EC Type-Approval Certificate DK 0199.367. • 0.2 µV/VSI, 10.000 divisions range. • 0.01 μV/VSI, 1.000.000 divisions range (for internal use). • Opto-isolated 16-bit analog output (4-20mA (max 300 ohm), 0-20mA, 0-10V, +/-10V, 0-5V, +/-5V (minimum 10 Kohm)). • Serial port RS485 for connection to PC/PLC by ASCII or ModBus RTU. • Optional protocols: Profibus DP, Ethernet/Modbus TCP, USB and Radio by appropriate converter. • 300 conversions/sec. (300 Hz) Features T2 Transmitters: •Weight transmitter and indicator for Omega/Din rail mounting • 0.2 μV/VSI, 10.000 divisions range. • 0.01 μV/VSI, 1.000.000 divisions range (for internal use). • Opto-isolated 16-bit analog output (4-20mA (max

A new sensor for estalishment of the load. To monitor the loading of tanks and silos a variety of load cells are available. A number of these has the disadvantage of only detecting whether the material inside the container is located above or below the sensor line. Other systems are indeed able to measure fill levels, the limitation however, is the surface of the material in the silo or tank. This surface depends on the product and is not necessarily representative of the true volume. Bulk loading and unloading for example, leaves a slope which may be asymmetrical. Typically bulk material will also vary in density when it enters the silo to the subsequent compacting as it settles. Fluids measuring, on the other hand, is effected by the formation of foam and/or the viscosity of the fluid against the container. There is a solution to this. By combining a special mounting kit with a specific load cell, it is possible to directly determined the content load of a silo or tank at the base of the container stilts.

The Netherlands - The single point load cell B6F from Zemic has been awarded the OIML R60 C3 approval for ”legal-for-trade” applications. The NMI in the Netherlands have examined and tested the B6F and concluded that an approval with a Y-value of 12.000 for standard C3 is applicable. Approved capacities from 500 kg to 2.000 kg are available. Features This load cell has a robust construction and is made of 17-4-PH stainless steel. The B6F has an IP67 protection class. For an explosive environment an Atex-certificate is optional for this load cell. Applications The B6F load cells are ideal for the following applications: • Conveyor scales • Hopper and tank weighing systems • Platform scales • Belt scales • Onboard weighing systems The maximum platform size for this single point load cell for the capacity 500kg is 600 x 800 mm and for the capacities 750 to 2000kg the maximum size is 1200 x 1200mm.

New OIML stainless steel IP69K single point load cell The single point load cell BM6G from Zemic has been awarded the OIML R60 approval for ¡±legal-for-trade¡± applications. The PTB in Germany has examined and tested the BM6G and concluded that an approval with a Y-value of 10000 for standard C3 is applicable and a Y-value of 15000 for C3 Multiple Range (MR) should apply. Furthermore a Z-value of 12000 is allowed to be used for both C3 and C3 MR. Approved capacities from 100 kg to 500 kg are available. Samples are also being prepared for a future OIML approval for the capacities 10 - 50 kg. The BM6G has been corner corrected to fit platform sizes up to 800 x 800 mm for 100 to 500kg. The unique selling point for this load cell is the combination of stainless steel and IP69K. IP69K is the Ingress Protection classification for devices that can be cleaned by high pressure water jets. This combination makes it very suitable for application in weighing devices used in the food-industry. The BM6G has several other

Extensive range of weighing and electronics components METTLER TOLEDO is a leading manufacturer of weighing components for constructors of instruments, machines, systems and equipment. The comprehensive range of weighing cells covers everything between 120g and 300t, with the smallest readout accuracy being 0.01mg. The range of electronics covers complete weighing terminals for fitting in control panels, as well as components available for fitting in DIN rails in switch cabinets. Depending on the version, the electronics can be integrated in superordinate controls using analog or serial interfaces, Profibus DP, Profinet IO, Ethernet IP, Modbus, DeviceNet or ControlNet The extensive range is presented clearly in the 180 pages of the new catalogue, which also features drawings and installation instructions. Order the latest catalogue through the link on our company page (click the link below:)

Ranges from 20 tons up to 100 tons Features and benefits include: - Capacities of 20t, 30t, 50t and 100t. - Self-contained design with built-in check rod and optional anti-uplift protection. - Available in both nickel plated mild steel and electropolished 304 stainless. - Integral safety support block to limit downward travel. - Based on the analog model 0782 load cell which has the following features: - Self-restoring rocker column design - Hermetically sealed stainless steel with IP68 protection - Global approvals as standard on each cell, including ATEX, FM, OIML and NTEP.
