POWTECH 2010

The NürnbergMesse Group is one of the 15 largest exhibition companies in the world and organizer of POWTECH - International Processing Trade Fair for Powder, Bulk Solids, Fluids and Liquids. It includes NürnbergMesse GmbH and that company’s 15 subsidiaries and affiliates. The Group employs more some 900 people at eleven locations in Germany, Brazil, China, India, Italy, Greece, Austria and the USA. It also has a network of international representatives in more than 100 countries. Its portfolio comprises some 120 national and international exhibitions and conferences held in person and as digital events, focusing on five general fields: Retail & Consumer Goods, Building & Construction, Process Technology, Electronics & Security, and Social & Public.

This item is only available in German

This item is only available in German

Gravimetric metering feeders for the food industry Great demands on hygiene in the food industry do not only require easy cleanability of machines applied but also involve a wide range of additional measures to prevent contamination with microbiological, chemical and physiological contaminants. Equipment suppliers must make sure to comply with hygienic design principles. For the field of bulk ingredient metering Brabender Technologie has therefore developed the "Brabender Food Line" in close cooperation with leading food companies, resulting in an array of metering feeders strictly complying with all relevant standards, guidelines and recommendations for the food industry (DIN EN 1672-2, EHEDG, FDA, etc.). On the one hand, special attention was given to technical solutions allowing particularly quick and easy cleaning. On the other hand, however, the development especially focused on preventive measures to avoid contaminations, for instance plain stainless steel surfaces, non-porous and ground welding seams

Optical Particle Analysis with the new CAMSIZER XT from Retsch Technology The quality control of fine powders can be substantially improved with the new CAMSIZER XT: More precise and faster analysis of particle size and particle shape helps to improve the product quality, reduce rejects and save labor costs, energy and raw materials. The design of the Camsizer XT is based on the well-proven optical particle measurement system Camsizer but is optimized for finer samples. Not only the improved optical resolution but also new options for material feeding allow for an extended application range. Fine particles tend to agglomerate which makes it difficult to record the properties of a single particle. Therefore, it is important to have various possibilities of feeding the sample to the analysis area to be able to find for each material the optimum between the desired dispersion of the agglomerates and the undesired destruction of the individual particle. The CAMSIZER XT offers flexible solutions, from the free fall mode, which is the most gentle

At the POWTECH 2010 trade fair S+S focuses on metal separators of the Rapid series At the POWTECH 2010 in Nuremberg (hall 7, stand 7-667) S+S Separation and Sorting Technology GmbH of Schönberg presents the highly sophisticated metal separators of the Rapid series that separate magnetic and non-magnetic metal particles (steel, stainless steel, aluminium, ...) from free-falling bulk materials. By the way: The Rapid series, which was introduced on the market in 1980, formed the basis for the leading position S+S today has in the field of industrial metal separation. In the year 2010 S+S celebrates 30 years of experience in the metal separa-tion of bulk materials. The new, extremely compact Rapid 8000 metal separator is designed for high throughput rates with nominal widths starting from 200 mm. It can be universally used for the inspection of a wide range of products covering powdery, fibrous, and chunky products. The completely new reject mechanism of the Rapid 8000 metal separator reliably prevents any jamming of coarse-grained and badly pourable

New trends on the scientific congress in Nuremberg LUM GmbH, Berlin, Germany, presents new scientific results from the comprehensive characterization of dispersions and particles during two talks and in 8 posters on the 6th World Congress on Particle Technology (WCPT6) in Nuremberg from 26 – 29 April 2010. LUM GmbH is market leader in innovative instruments for direct and fast stability analysis and particle characterization of dispersions. Using LUM’s extremely powerful measurement instrumentation demixing processes in dispersions can be analysed in a rapid, efficient and reliable way, a comprehensive characterization of dispersions is provided. Besides the provision of innovative measurement instrumentation LUM supports the development of the subject area of „Basics and Applications of Dispersions“. Recent scientific results, partly obtained together with national and international co-operation partners, are presented to the international audience on WCPT6. The focus of the contributions is on the direct

Dispersion stability, particle size & more - POWTECH 6-114 L.U.M. GmbH welcomes all visitors to present innovations for dispersion analysis & particle characterization. During POWTECH besides L.U.M. products also new instruments for particle shape analysis and flowability of powders are presented. Non-spherical reference particles complete the presented highlights. The new Demixing Tester LUMiCheck® (L.U.M. GmbH) is your first step in dispersion analysis. This instrument is especially designed for the quality assurance lab. It is used for the uncomplicated, comparative stability analysis & particle characterization of dispersions in their original state (without sample preparation or dilution). The fast quantitative comparison of different samples and the qualitative characterization of demixing behaviour, flocculation, sediment formation and stability make LUMiCheck the instrument of choice for the measurement of beverages and food, construction material, fuel and lubricants, and generally speaking for a large variety of

This item is only available in German

• Varied supporting programme provides broad spectrum of practical solutions POWTECH 2010 from 27–29 April again offers the around 15,000 expected trade visitors the opportunity for three days of intensive exchange of views with well-known manufacturers, developers and production experts. This year, almost 700 exhibitors present pioneering products, the latest technologies and future trends at the leading exhibition for powder, granule and bulk solids technologies. The extensive supporting programme offers a variety of ideas for everyday work at events ranging from explosion protection and nanotechnology live to free presentations in the halls. For example: Nanotechnology live At least one of the dimensions of length, width and height of the structures that scientists investigate in nanotechnology is smaller than 100 nanometres. The Federal Ministry of Education and Research presents its “nanoTruck” again at this year’s POWTECH/TechnoPharm. This is a roadshow and communication centre that presents nanotechnology live at two levels

This item is only available in German

The microwave barrier VEGAMIP 61 is especially designed for the requirements and special needs of the bulk solids industry. Since the microwave barrier measures contactlessly, VEGAMIP has no direct contact with the medium. This is advantageous particularly for abrasive products or very high temperatures. In such cases VEGAMIP 61 can simply measure from the outside through a microwave-permeable window, for example, of ceramic or plastic. Also in the area of liquid level detection or object detection, the microwave barrier offers many advantages over other measuring principles. The microwave barrier consists of a VEGAMIP T61 transmitter and one or several VEGAMIP R61 receivers. The receiver measures the attenuation of the received microwave signal and generates a switching signal from it. VEGAMIP can be used as a maximum or minimum sensor. Its switching delay can be set between 0.1 and 20 s. VEGAMIP 61 is fully integrated in VEGA`s plics concept and offers all

Feeding particularly low feed rates when hygiene is a central issue presents challenges of its own during production. This situation mostly arises when cost-intensive products are being handled or when small amounts of ingredients already have a decisive influence on the final product. The new DIW-PE-GZD200 „Small Scale Feeder“ with its innovative details has been specially designed for the requirements of minor ingredient addition. The modern weighing system ensures highly accurate feeding results in connection with the twin-screw GZD 200 Loss-in-Weight Feeder. The GZD200 Hygienic Feeder comes with specially polished surfaces, machined sealing grooves and is suitable for quick and easy disassembly and easy cleaning. This device corresponds to the requirements of the food and pharmaceutical industries on account of its modular design. The feeder is suitable for feed rates ranging from 0.2 l/h – 10 l/h. The mass flow is virtually pulsation free. Conveying of

Gericke’s Multiflux® mixer GMS creates with its 2 horizontal, overlapping mixing rotors a fluidized bed. As a mixing process is based on the exchange of the particles in a volume by convection, this principle is very efficient for the energy-saving and product respecting mixing. The GMS mixer is known as long-lasting and reliable process equipment. In order to complete its existing range, Gericke has made a redesign of the GMS Multiflux mixer that responds to the increasing demand for hygienic execution in the food and pharmaceutical industry. The new model is called GMS C. C stands for cantilevered and refers to the 2 shafts that are cantilevered, offering many advantages. Not only the number of sealing is divided by 2. Due to the construction, the front side of the mixer can be opened entirely. In the high end version, named the GMS ECD, the operator can even pull out the complete drive and mixing shafts out of the body. Large lateral doors offer an easy access

Feeding and discharging technology: new developments and product line cross section Being one of the traditional POWTECH participants, Brabender Technologie KG of Duisburg, Germany, are once again exhibiting their latest developments and a representative cross-section of their comprehensive product line for powder and bulk solids metering and discharging. Visitors from all bulk solids processing industries will find an ample variety of interesting state of the art feeding and discharging systems, for instance ● The Brabender FlexWall®Plus Feeder in classic design featuring single and twin screws ● The Brabender DualTray Feeder with mass flow metering unit for damageable or lumpy ingredients ● The Brabender field bus system for multiple feeder installations with touch screen operating panel ● The Brabender JetFilter filtering exhaust air streams displaced during metering feeder refilling ● The Brabender bulk bag unloader "BagMaster" featuring a unique massage ring mechanism ● The Brabender bin activator

ProJet smart, the new compact filter of Intensiv-Filter, is introduced first on the POWTECH. The internationally established POWTECH offers the ideal platform for a product presentation, because no comparable fair offers such a concentrated range of mechanical processing technologies. Intensiv-Filter uses the exhibition as an occasion to introduce the small brother of the process filter class "ProJet mega®", which was introduced in 2008 also on the POWTECH. The filters of the new - inexpensive and easily available – type series bear the name „ProJet smart“ and are suitable for many ranges of application with volume flows of about 20,000 m ³/h. Compact filters of the design ProJet smart are especially compact bag filters with integrated fan, silencer and accompanying cleaning control system. The function of the filters is based on the jet pulse principle. The filters are cleaned by means of the highly efficient Intensive-Filter injector system with "ideal nozzle". The fully automatic cleaning system is part of the scope. The ProJet

Vertical Helix-Dryer for Dietary supplements For a big manufacturer of dietary supplements in Germany a dryer-project has just been realized, which once more was a real challenge to the flexibility and modifiability of drying technologies. In this case there was a process of evaporating, in which the product in dependency of the inner pressure of the vessel has been brought to its boiling temperature. By applying of vacuum in the AVA-Dryer the product temperature is adjusted exactly according to the vapour pressure graph of the liquid component, which is to be vaporized. Through this an especially efficient and gentle drying is reached. The heat input is effected over the heated outer vessel wall, in which the heating medium is circulating. For rising of the drying capacity and to avoid caking the main shaft of the dryer as well as the whole helix can be heated over a rotary connection. The mixing procedure bases on a counter flow of product within the vessel. The AVA-Helix conveys the product continuously along

with the air jet sieving machine AS 200 jet The new air jet sieve AS 200 jet is particularly suitable for low density materials with particle sizes in the lower micron range. It is used with 203 mm (8’’) sieves of 10 microns mesh size or more. An industrial vacuum cleaner generates a jet of air which disperses the particles on the sieve through a slotted nozzle. The material which passes the sieve is transported to the vacuum cleaner or to a cyclone for recovery. The procedure is very gentle on the material, the average sieving time only takes 2-3 minutes. A special feature of the AS 200 jet is the Open Mesh Function which helps to greatly reduce the number of near-mesh particles. This provides optimum separation efficiency and also excellent reproducibility. Operation of the sieving machine is very simple. The Quick Start Mode allows to start the sieving process without previous programming. Benefits at a glance: • Gentle sieving with short sieving times • Reproducible results due to Open Mesh

Parallel event: the World Congress on Particle Technology Suppliers and production specialists from all over the world meet to discuss the latest innovations at POWTECH 2010 from 27-29 April 2010. Next year’s POWTECH will again prove its top position as Trade Fair for Mechanical Processing Technologies and Instrumentation. No other exhibition in the world offers such a combination of concentrated themes and a large number of international exhibitors and trade visitors. At the last event in 2008, 707 companies – including 209 international exhibitors from 26 countries – presented their products to more than 15,000 trade visitors. WCPT6, the World Congress on Particle Technology sponsored by PARTEC, takes place parallel to POWTECH next year, starting a day earlier on 26 April. WCPT6: news from particle technology The World Congress on Particle Technology (WCPT), supported by the PARTEC Congress, takes place next year for the second time parallel to the POWTECH/TechnoPharm duo. This world congress will concentrate and

This item is only available in German

This year PAYPER will participate in different international events. Firstly, the company will be one of the speakers at BULKSOLIDS INDIA 2010 International Conference and Exhibition Storage, Handling and Processing of bulk solids and powders, to be held in that country from 3 to 5 March. In this case, the presentation will focus on `Bags, bagging bulk products & systems - A general overview of the worldwide market and technology bagging”. PAYPER has entered strongly in the Indian market after securing an important contract in 2008 and 2009 with two petrochemical companies and expects to strengthen its presence in the country in future projects. Furthermore, PAYPER will also be present at POWTECH 2010 the International Exhibition for Mechanical and Process Technologies, to be held in Nuremberg (Germany) from 27 to 29 April. The participation will be carried out in cooperation with its German representative, the company SSB Wägetechnik; and both of them will take the opportunity to show their latest technology for the bagging

INFASTAUB launches the new silo vent filter in rectangular design Filtering separators are essential for silos. The INFA-JETRON silo vent filter; type AJB 800, has proven performance for this application. The "Filtration + Separation" magazine has already commended the bestseller and its performance. INFASTAUB from Bad Homburg uses the experience of the reliable AJB 800 and launches the silo vent filter, type AJP 224, in rectangular design. The construction of the newly engineered cartridge filter combines both the strengths and benefits of the AJB and of the mechanical shaking filter AM 204, which has been installed on many silos for many years. It focuses on the identical dimensions of the AM 204 and the pneumatically cleaned AJP 224. Consequently, the connecting flanges on the silos don’t have to be modified, if you want to change the filter type. This saves costs in a new investment. In addition, the standardisation allows very versatile applications. Without making alterations to the flange connections, the AM 204

This item is only available in German

The new vibratory sieve shaker AS 450 control accepts loads of up to 20 kg With the analytical sieve shaker AS 450 control RETSCH have designed their first siever for 400 mm and 450 mm sieves which operates with a three-dimensional sieving motion. It can be used for dry and wet sieving. The optimized electromagnetic drive allows for an amplitude up to 2.2 mm which renders the separation process much more effective than with other sieve shakers of this type. Reproducibility plays an important role: The amplitude - which is independent of the sieve load - is continually adjusted. The three-dimensional sieving motion lets the sample material move equally over the complete sieving surface. This results in high load capacity, extremely smooth operation and short sieving times with high separation efficiency. When it comes to operating comfort, the AS 450 control meets all the requirements of a modern laboratory. All parameters such as amplitude, time and interval are digitally set, displayed and controlled. It is possible to store up to 9 parameter

Grain Silo The new bulk storage terminal that Ultra-Brag AG operates in the Rhine port of Kleinhüningen is an impressive structure, with overall height of 83 meters, it clearly dominates the Basel port skyline. This height required a number of special measures: The structure has to be earthquake-proof, it must be resilient enough to absorb wind loads, and its immense weight must be reliably supported by its relatively small footprint of 27 by 40 meters. The concrete structure, which was built by the slip-forming method in three stages, therefore stands on a large number of piles with a thickness of up to 1.2 meters and a length of 28 meters. The bulk storage section houses 32 round storage bins plus 15 interstice bins, which hold more than 40,000 cubic meters of material. Most of the Buhler supplied equipment is installed in the headhouse of the elevator building. The core systems of the entire installation are the two 87-meter-tall belt-and-bucket elevator legs which elevate

Stanelle Silos + Automation GmbH of Southern Germany offers four different types of loading assemblies as part of its component range. Type Rondo 250 for loading abrasive material into bulk road tankers or onto open lorries; Type Quadro 220 with retractable and conical seal for loading bulk road tankers with hygroscopic and other pulverulent media; Type Rondo 500 to 800 for coarse grain bulk solids for ship, rail and open lorry loading of bulk road tankers; and Type Tele-Rondo for the loading of bulk road tankers with heterogeneous bulk solids. On loading bulk tankers, the discharge aperture of the loading assembly positions itself on the dome opening of the tanker to be filled, in a way that no dust can escape, the emission levels are optimized in conjunction with a filter unit. Rondo 250’s retractable buckets feeds the loading material and protects the exterior collapsible bellows from wear and tear. Quadro loading spout exclusively applicable to bulk tanker loading,

This item is only available in German

Silo discharge blocking problems with powdery, lumpy or granulated bulk goods overcomes a vibrating cage. Suitable for all silo types it gets installed onto the silo cone end. This only activates that part of the stored bulk goods to be discharged immediately. Short operating cycles with vibration-free intervals save energy. There will be no fluidizing air in the bulk material which can cause problems in subsequent operation such as dosing or weighing sacking. Maintenance free seals prevent leakage of the silo. Even difficult products such as sewage sludge are handled with a special, up to 3 bar pressure surge proof model. Another model is pressure resistant up to 7 bar.
