By gravity... - CFE-K Containment means highest safety for product and operator, for HECHT it means even more: safe, clean and efficient. Due to our vision we developed two systems for containment drum discharging, which are especially tailored to the requirements of our customers. The focus has been on easy handling of the discharging station and also of the local conditions of our customers. This challenge made us devise two solutions for the discharging of drums, which have the same containment level (OEB 5), but with different working processes exactly optimized for the requirements of our customers. The Containment Drum discharging station with glovebox and integrated lifting device is one of the leading systems in the dust- and contamination free bulk solids industry. The easy handling during the discharging process as well as the simplicity of the drum connection is unique. Depending on your requirements, the transport to the next process step is possible by gravity (multi floor…

... or via suction lance - CFE-L If there is less space at your production side or if you want a weight controlled dosing out of the drum, the Containment drum discharging station CFE-L is an innovative possibility to discharge drums dust- and contamination free. The drum is positioned under the isolator by the automatic lifting device and connected to the box via a roller conveyor. The drum can be discharged completely by using the suction lance with linear guidance and, as an option, with actuator. The window provides a clear view into the glovebox. The ProClean conveyor transports your bulk solids to the next process step. As an option, inerting with N² is available. The isolator box perfectly suited for low space processing, because of its compact design. Automation and integration into an existing roller conveying system is also possible.

The new ProClean PCC 700 series is, up to now, the most powerful of the pneumatic conveying systems from HECHT. As an addition to the compact PCC-series (100-300) the PCC 700 have got more conveying power and the ability to transport your bulk solid long distances and heights. If you want further information do not hesitate to contact us.

Vacuum conveyor for safe and gentle conveying of powders and granules With the new development of the ProClean® Conveyor, we have succeeded in making use of this knowledge and presenting our own vacuum conveyor. In particular in the pharmaceutical, food and chemical industry, the ProClean® Conveyor can prove its superiority in the safe and gentle conveyance of powders and granules. The heart of the ProClean® Conveyor is its filter head. There, the innovative and powerful ring filter system is located. It is available in different versions, features a big filter surface, is easily cleanable, long-lived, robust and enables fast dilute phase as well as safe and gentle plug conveying. The cover of the filter head is free of connections. Thus it can be opened quickly and the filter can be replaced easily and without much effort. The optional installation of a sight glass or a level indicator permits the system to be checked easily without having to open the cover. The ProClean® Conveyor sets new standards in terms of operator…

Advantages: + Smooth, vase-shaped contour + Proper decoupling of weighing unit + No residues inside + Transparent + FDA conform + CIP-capable + Highly flexible Materials: Silicone VMQ or flourosilicone FMQ (in preparation) Possible connections: Hose clamp connection Direct connection to clamp connection piece (other possible connections on request

Connection System for Big Bags with integrated filter When discharging FIBCs, the leakage of product dust must be prevented without causing overpressure or low pressure in the system. An efficient outlet connection system performs the following tasks: Sealing the FIBC outlet safely, Preventing overpressure in the system, Preventing suction of product. A filter has been integrated into the ring filter connection system. External filters as well as the cross containment and carryover of product involved belong to the past. Advantages: no cross contamination, no carryover of product, no need for external filters.
