Gericke manufactures for more than 100 years batch mixers. As a new development Gericke shows its single shaft mixer GBM (Gericke Batch Mixer). This mixer can be used for divers different processes. The GBM can be operated with Froude numbers varying from 1 to 3 which influences the energy input and mixing result. It is available pressure tight, and is suitable for heat exchange operation as well. For dispersion duties high speed rotating de-agglomerators can be integrated into the mixing chamber. The mixer is delivered as ATEX category 1, 2 or 3 equipment. Standard sizes are manufactured from 150 liter up to 3000 liter volume. The “clou” of the Gericke GBM is the expansion zone where particles can exchange easily their position. By this movement the axial dispersion can be improved. Optional are different drive units, rectangular standard or long outlets, inspection and cleaning doors and different surface finishes. The Gericke Batch Mixer stands for a robust

Gericke delivers for more than 60 year pneumatic conveying systems. Gericke delivers under the brand name pneuwork® dense phase conveying technology for abrasive or high temperature products. The construction of the pressure vessel and of its accessories is specially designed to ensure a reliable and durable operation in heavy duty industries. The vessel is equipped with a fluidising bottom, a special wear resistant conical inlet valve. Combined with the diverter valves and anti-abrasion deviation pot, the Gericke Pneuwork conveying technology incorporates all necessary parts for a robust and efficient material transfer. Gericke pneuwork® systems are placed in factories for building material, in power stations, waste treatment plants or steel and glass production. The conveying capacity ranges from some 100 kg/hr to 80 tons/hr. The vessels are in the standard execution manufactured for an operation temperature up to 300 °C and 6 bar conveying pressure. Trials

Visit us on stand J20 - J21, hall 5.0 ROTEX, the global leader in the development and supply of screening equipment and technology for the process industries will be exhibiting at ACHEMA, Frankfurt, the largest and the most important European exhibition for the bulk industry. It will be a pleasure to welcome you between 11-15 May 2009 to our stand J20-J21, hall 5.0. Our screening experts will be on hand to provide customised solutions to a wide range of processing applications and to show you our most popular machines: the ROTEX® screener, the MS™ screener and our newest machine, the APEX™ screener. You will have the opportunity to see the famous ROTEX gyratory movement in action and to test our new panel system on our new APEX™ machine. Visit our booth and the benefits of using Rotex machines and spare parts will become obvious. We look forward to seeing you there

Dispersion stability, particle size, particle shape, dielectric constant matter -Hall 6.3 P23-Q23 LUM GmbH welcomes you to inform about latest news in the field of dispersion analysis, particle and liquid characterization. Not only LUM products but also instruments for particle image analysis and the measurement of dielectric constants are presented. The Dispersion Analyzer LUMiSizer® made by L.U.M. GmbH is the complete dispersion lab in just one instrument. For real-time characterization L.U.M. GmbH is presenting the new product lines LUMiReader® and LUMiCheck®. The Demixing Tester LUMiCheck® is used for fast stability analysis and particle characterization with respect to comparison of different samples. Powdershape automatic (Innovative Sinter Technologien AG, CH) is an image analysis based system that enables to characterize statistically size and shape of fibres or fibre like objects by several parameters such as: grain (grit) size, max size, min size, ellipticity, convexity. With the new Liquid Dielectric Constant Meter 871 (Nihon Rufuto Co., Ltd., Japan)

On the 60th anniversary of the company, Berthold Technologies is launching the new detector generation SENSeries to the market and is setting new standards in the radiometric process control. The SENS-Detectors stand out by their unique and extreme high sensitivity to gamma radiation. New measurement accuracies can be achieved, well above those possible with radiometric systems to date. The extremely high sensitivity also means that existing sources can be used for a longer period. Instead of an expensive source exchange, the life of the existing sources can be extended by many years, or even decades, by using a new SENS-detector. Moreover, in new projects the high sensitivity results in a considerably high reduction of source activity. These characteristics are guaranteed by a patented process throughout the complete field of application and the total service-life. The SENSseries offers a suitable detector solution for each and every application. For the radiometric

RETSCH will present their latest product generation 2009 at ACHEMA. One of the highlights is the new CryoMill which was designed for efficient grinding with liquid nitrogen. This mill features a closed circulation system with automatic cooling of the grinding jar which makes it particularly safe to handle. A product innovation from the area of particle size analysis is the 3-D sieve shaker AS 450 which separates up to 20 kg of sample material. Due to an extremely high amplitude, this siever achieves excellent separation efficiency with short sieving times. Further new products which will have a world premier at Achema are the powerful Cutting Mill SM 300 with variable speed, the Knife Mill GM 300 for sample volumes up to 3.5 l and the air jet sieve AS 200. RETSCH will also have a competition at their booth with many valuable prizes. RETSCH at ACHEMA: Hall 5.1, Stand D18 – E20

Vacuum Dryer 5 liter Lab unit Hosokawa Micron B.V., leading in the field of powder processing technology and specialized in engineering, design and manufacture of equipment and systems for mechanical and thermal processing of powders, will participate in Achema 2009. Our core businesses mixing, drying and agglomeration will be well presented at our booth. During Achema, Hosokawa Micron B.V. will exhibit in Hall 5, Stand D38-E41 The Micron dryer, also called Drymeister is a unique flash mill dryer using hot air or gas as drying media and combines three unit operations: Drying, Grinding and Classifying in one machine! The Drymeister is able to handle a feed material coming out of the mechanical dewatering step directly into the dryer. based on its ability to handle high solid content feeds, the DMR can economize the drying process saving time and energy! See it at Achema and test it in our extended test station. More information? Please contact us by phone +31(0) 314 373 333 or by e-mail:

Hosokawa Micron B.V., leading in the field of powder processing technology and specialized in engineering, design and manufacture of equipment and systems for mechanical and thermal processing of powders, will participate in Achema 2009. Our core businesses mixing, drying and agglomeration will be well presented at our booth. During Achema, Hosokawa Micron B.V. will exhibit in Hall 5, Stand D38-E41 The Micron dryer, also called Drymeister is a unique flash mill dryer using hot air or gas as drying media and combines three unit operations: Drying, Grinding and Classifying in one machine! The Drymeister is able to handle a feed material coming out of the mechanical dewatering step directly into the dryer. based on its ability to handle high solid content feeds, the DMR can economize the drying process saving time and energy! See it at Achema and test it in our extended test station. More information? Please contact us by phone or by e-mail.

Flexomix FX 100 "Mixer - Agglomerator - Instantiser" Hosokawa Micron B.V., leading in the field of powder processing technology and specialized in engineering, design and manufacture of equipment and systems for mechanical and thermal processing of powders, will participate in Achema 2009. Our core businesses mixing, drying and agglomeration will be well presented at our booth. During Achema, Hosokawa Micron B.V. will exhibit in Hall 5, Stand D38-E41 Flexomix technology can be applied wherever small quantities of liquid are to be added to powders, or agglomerates have to be produced, in which large quantities of liquid are absorbed, and where the size of particles needs to be enlarged. For each specific application, pilot plant trials can be preformed for defining best process parameters for optimal aspects of the end product and for lowest energy consumption. The Hosokawa Flexomix is used in the chemical industry for: super absorbing polymers, phosphate-based products, horticultural fertilizer, crop protection agents,

welding machine Ex Scissors welding machine for closing bags, barrels and cardboard boxes with inliners. The machine is suitable for the welding of polyethylene, aluminium-laminated film, paper laminate, poyamide and polypropylene. The machine closes the filled bag, welds the bottom seam for the next bag an cuts the film between the two welds in one single operation. The machine is mounted on swivel arm. Widht of the welding jaws: 400-1000 mm Working high: 965 (+/- 250)mm Ex-protected implentation available for the Ex-category II 2GD Protection class: c EEx d e ib m 2B

Function of the module: Teh empty trading unit is aerated and the inliner is inflated i order to have an inert atmosphere inside. During the filling, 3-5 mb nitrogen is refed. The pressure and the pressure flow qantity are monitored in the process

The new granulation and drying system from L.B. Bohle Continuous production for solid manufacturing is an FDA-approved and recommended tool to produce unmatched quality through improved process control and understanding. So Bohle developed the EASY FLOW® system that offers a lot of advantages in daily pharmaceutical production. When utilizing the EASY FLOW®, in-process inspections are not required because the process is monitored and controlled online continuously. Through the more compact design of the EASY FLOW® vs. batch installation, significantly lower investment is required. The system can be used for lab trials and clinical trials as well as for full production. An even higher savings potential can be obtained through operating costs. Staffing is significantly reduced because the system requires only monitoring. Further benefits result from the shorter and infrequent cleaning processes. In addition, there are significantly lower product losses. Hence continuous production is economical and beneficial. Scale-up

Dosing system Vibro-Dos devices are used in the pharmaceutical and chemical industry for filling of drums, cardboard boxes, containers and big-bags. The are capable of metering bulk materials of different flow characteristics reliably and exactly. The Vibro-Dos system basically consists of a supporting case, a plastic molding inner body and a butterfly valve which is brough to vibration by two pneumatic vibrating engines. The regulation of the aperture angle is carried out by a pneumatic cylinder with specifically developed electropneumatic activation which guarantees very short response time and a high repeatability of the aperture angle. All dosing parameters are specified at the balance terminal or the operation terminal of the PLC. Advantage of the Vibro-Dos system: - short, vertical product flow into the trading unit to be filled - few parts contacted by products - easy dismantling and therfore, best cleaning possibilites

For all particle size analyses where contamination of the sample with solder or epoxy must be avoided, RETSCH test sieves, which feature electro-welded mesh, are the products of choice. Thanks to the transition free one-piece construction of the sieve frame no foreign materials are involved in the process and there are no grooves where material might get caught. RETSCH test sieves are produced fully automatically, a process which is unique in the world. This allows for a previously unattained high quality and consistency of the sieves. In addition, a logistic manufacturing system makes it possible to record each and every material used in the process. RETSCH sieves comply with all prevalent international standards such as DIN ISO, ASTM and BS. The benefits at a glance: · Ultra-tight sieve fabric · Maximum corrosion resistance thanks to high-grade alloy steel (316L) · Autoclaveable o-rings for quiet operation and dust-tight sieve stack · 15 % lighter

Masterflex AG presents new connecting systems at Hanover Fair and Achema The novel clamping system developed by the Masterflex AG fits many wire-reinforced Masterflex hoses and ensures quick and easy hose installation. Consequently, the hose user can continue using most commercial connecting elements, which translates into direct cost savings. Whether common connectors such as Camlok, Storz, and TW couplings or customized coupling types are in use, all sorts of connectors can be easily screwed to the new clamping system. Moreover, connecting pieces with such geometries may be integrated into the hose. Combining great versatility, prompt availability, high quality standards, and good efficiency, this novel connecting system could become a trendsetter in the field of materials handling engineering. The advantages of the new clamping system at a glance: • The customer may continue using existing connecting pieces with standard or specific geometries. • The customer obtains a hose tailored to the existing connecting piece,

Interest of Exhibitors and Congress Participants remains strong ACHEMA 2009 from May 11th - 15th in Frankfurt am Main is still on the road to success. So far the econonomical situation has had no consequences for the leading worldwide event of the process industries. Exhibitors continue to show a high level of interest. As the most important international exhibition congress for chemical engineering and the process industries ACHEMA is the platform for new technologies and products, but also for worldwide exchange and setup of new business connections. Pumps, Compressors, Valves and Fittings make up the largest group of exhibitors. They are followed by Laboratory and Analytical Techniques, Engineering and Thermal Processes, Mechanical Processes, Instrumentation, Control and Automation Techniques and Pharmaceutical, Packaging and Storage Techniques. ACHEMA 2009 is once again the innovation forum for the process industry. Energy efficiency remains an important driver for innovation, as well for individual compo-nents as for measurement

New Rotex Germany office and with a new German Sales Engineer Due to its development on the German market and in order to support our new business flow, Rotex Europe opens a new office in the Remscheid region. Headed by Mr. Frank Spanknebel, recently entitled as Market Development Manager the office will be also supported by Mr. Frank Meier, who will act as Sales Engineer. Mr Meier, who will be based in the new office, will bring with him a wealth of technical and sales experience, providing a highly proactive and responsive service to the market.` Rotex Europe has already had a strong presence in Germany for many years, as its machines are well-suited to the region’s industrial development. Rotex provides screeners, conveyors and feeders for a number of industries including bulk food, animal/pet food, chemicals, mining, quarrying, fertilizer, glass, plastic, recycling, rubber, salt, sugar, wood, etc. Rotex also demonstrates its willingness to meet all bulk industries` requirements by adding new equipment to its long

World technology summit of the process industry Around 4,000 exhibitors from all continents, 180,000 visitors from 100 different countries and 30,000 executives will meet at ACHEMA 2009 in Frankfurt from 11 to 15 May. The process industry – chemical industry, biotechnology, pharmaceutical and food industries, environmental technology, materials technology and energy production – constantly faces new challenges; they can only be overcome by focussed interaction between the various disciplines. This explains why many companies seize the opportunity to present their innovations and technological trends at ACHEMA. The Congress programme, a second cornerstone of ACHEMA, encompasses 900 lectures . Numerous special and guest events, panel discussions, expert round tables and plenary lectures reflect the variety of process technology. Parallel to the exhibition the ACHEMA Congress spans the complete spectrum of process engineering and complements the classical aspects with a number of special, topical lecture series. ACHEMA`s

New version CMpro 2.0 Organize, manage and document your activities electronically with our CMpro maintenance, calibration and qualification software. With CMpro you can reduce unnecessary machine down time for maintenance work. CMpro reduces the `paperwork` and makes many checks unnecessary (for instance: checks that determin whether calibration work is acquired correctly). Your CMpro advantages: reduce costs with preventive planning; GMP-compliant verification of maintenance, calibration and qualification activities; higher system availability rate from status control; deviation trends; timely maintenance; and easy integration of external service providers for the system (i.e., maintenance companies).

The Netzsch De-Aerator is established as „the wonder machine“ for the de-aeration of liquid products. With this machine, it is possible to simply remove micronised gas and air pockets of liquids with different viscosities or of viscous masses and pastes. According to the VTR principle (Vacuum-Thin layer-Rotational procedure) different products with low viscosity to flowable masses are processed with minimum product loss. Depending on the machine size and viscosity of the products throughput rates of 50 – 4,000 kg per hour can be achieved. The Netzsch De-Aerator can be used to de-aerate both small quantities using changeable tanks in batch operation or for large processes in continuous operation. This compact machine does not require an additional feed or transfer pump – depending on the product viscosity – and can be arranged in series with filling machines to accommodate shorter production times directly from a mixer into barrels. Further advantages of the

The new agitator bead mill ZETA® RS of Netzsch-Feinmahltechnik GmbH is a logically consistent advancement of the model LMZ system ZETA® agitator bead mill that is specially designed for comminution and dispersion in the nanometer range. With the ZETA® RS it is possible to employ even smaller grinding media (300 to 50 µm) and – thanks to the modified separation system – to reliably hold them back, even at low circumferential speeds or high product viscosities. In the planning stages for the new agitator bead mill and in its implementation in practice, particular emphasis was placed on an appealing, modern design and easy handling – especially when dealing with very small grinding media. Similar to our laboratory mills the ZETA® RS agitator bead mill, is designed such that the grinding chamber can be pivoted to different positions to be emptied, filled and for operation.

A combination that fits L.B. Bohle Maschinen + Verfahren GmbH from Ennigerloh, Germany has started a cooperative with the research and development company, Formula – Pharmazeutische und Chemische Entwicklungsgesellschaft mbH from Berlin, Germany. The basis of this cooperation was the newly founded L.B. Bohle Formula. Pharma Services GmbH at the end of 2007. In April 2008, L.B. Bohle Maschinen + Verfahren GmbH received authorization to produce (§13 AMG) clinical batches in bulk and market products in pilot/production scale (5 – 20 kgs). The new company merges the core competencies of plant engineering with research and development expertise into a qualified partner for pharmaceutical companies. The L.B. Bohle Service Center provides well-known, state of the art production equipment. In addition to feasibility studies and clinical supplies, pharmaceutical products for marketing purposes are being manufactured under GMP conditions. Dr. Christian Brätter, CEO of L.B. Bohle Formula. Pharma

Double chamber sampler Ex The douple chamber sampler is used for all products which must be protected against impurity. The extending piston rod of the pneumatic cylinder always remains in the area of the protective chamber. Thus is prevents foreign parts, e.g. abrasion from the bearing, to get in contact with the products
