Prescision tensioning, lower tolerances SWECO Fusion Screens are the latest in a long line of technologically advanced products from SWECO, the originator of the vibratory round separator, Supertaut-Plus-Screens, Magnum-Screens and countless other innovations. Fusion Screens habe been designed to eliminate the use of adhesive, epoxy or silicone in screen manufacturing. Instead, the mesh is "fused" directly into the patented polymer construction tension ring. The repeatability of the robot construction assures precise tensioning, lower tolerances and smaller deviations of the screens. Fusion"s unitary construction integrates the screen gasket directly into the tension ring. This design eliminates the handling and stocking of separate gaskets and provides a precision fit into the separator. this unitary design also reduces cracks and crevices, producing a more "cleanable" screen with less potential for cross contamination. And the one-time use ring is disposable, saving handling and…

Three functions in one machine SWECO, the world leader in separation technology, introduces the DC Classifier, a multi-functional unit designed to dry, cool and classify all in one machine. Developed specifically for the plastic pellet industry, the DC-Classifier is perfect for any dry application requiring one, two or all three functions ... drying, cooling or classifying. The top two screens of the DC Classifier encompass the drying and cooling stages, using either positive or negative air flow to draw moisture and heat away from the particulates. The classifier can then contain either a single or double particle classifying deck where the sizing and dedusting of the material takes place. The DC Classifier was designed with modular decks for easy removal for cleaning in-between process changes when more than one material type or color is proccessed in the same machinge. The Classifier can also be designed with casters for trouble-free mobility around the lab or production facility. Dryer, Cooler,…

SWECO, the worldwide producer of separators for dry and wet products, invites you to visit its booth at : Easy Fairs SOLIDS (Antwerpen, Belgium) on 5-7/06/2007: Hall 4, Stand N° 4411 PulPaper (Helsinki, Finland) on 5-7/06/2007: Hall 6 Stand N° b21 Industrial Maintenance (Rotterdam, The Netherlands) on 5-7/06/2007: Stand N° 538 Polagra-Tech (Poznán, Poland) on 15-19/09/2007. Ouest Agro (Angers, France) on 02-04/10/2007. FoodPharmaTech (Herning, Denmark) on 13-15/11/2007: Hall J, Stand N° 7206 Pollutec (Paris, France) on 27-30/11/2007. We will exhibit namely our new Gyramax Gyratory Sifter. It maximizes productivity, provides maximum vibration control, and enables maximum recovery of clean, acceptable product. The GyraMax™ is specially designed for high capacity dry screening up to 6,6 M² of screen area per deck, it provides up to 5 decks of separation, high temperature applications are possible up to 120°C.

With over 50 years of design experiences in separators, Sweco has developed hundreds of options and components that can be used to optimize a solution for different processes. Our Separation Processes are: • Sizing for dry products (sugar, spices, starch, polystyrene beads, powdered pharmaceuticals …): segregation of a variety of solid particles into separate groups containing comparable sizes. Up to 5 separations simultaneously. • Scalping for dry material (powdered milk, cereals and grains, chocolate powder…): removal of a small quantity of undesirable oversize particles in a high-throughput process. • Gravity Filtering/Products Recovery for solid/liquid mixtures (fruit juices, fish, pulp and paper, ceramic…): filtering oversize solids from all types of slurries, or dewatering solid/liquids mixtures. Reclaiming usable solids or clarifying liquids, either of which has further economic value. • Wastewater clean-up and water pollution control…

Renewable Separate solids from liquids or segregate dry materials into various sizes. Particles as fine as 400 mesh (37 microns) can be screened with up to 4 screen decks incorporated in one Sweco Separator. No special flooring or foundation is needed unless working floor space is required. Simple and efficient design requires less horsepower. No one has more experience creating round separation solutions... we`ve been around for more than 50 years. Since a long time, SWECO offers equipment for better quality of bioethanol. SWECO 48" separator can filter 4000 l/hr at around 0,5 mm. SWECO has helped many plants for recirculation of Digester filtrate. SWECO Vibrating screen takes out all sort of dry undesirable stuff: fibers, sand, hairs... and protects all equipment behind, or reduces the mass of waste.
