Ceramic material is highly abrasion-resistant, but is vulnerable for breaking due to impact at an angle of of 90/60°. The impact energy is not absorbed and the ceramic could crack. Kryptile ceramic liners combine the properties of aluminium oxide ceramics with the huge impact resistance and toughness of Kryptane polyurethane. This protects the very fragile ceramic against a direct impact at an angle of 90/60° and is ideal for impact situations with large quantities of sharp and coarse product. This is the ultimate solution for aggressive applications.
Kryptile liners are all designed in line with the customer’s requirements and can be supplied in the exact shape of, for example, a chute, bin or hopper and ensure a perfect fit. This prevents unnecessarily long installation downtime. The standard panel dimensions can be supplied in the exact dimension of 300 x 300 mm. This includes a cast steel plate with welded nut. The so-called Redi-Liners are fitted at the place of impact, and can be exchanged with each other over time so each part is fully utilised.
Redi-Liners are available with Kryptile KS, KC and KT. Download the technical datasheet for more information:
Technical datasheet
