In comparison to a standard screwdriving function module (SFM), on the DEPRAG E-SFM, the pneumatic feed is replaced by an electronic drive. The automotive technology company Blau, subsidiary of MAGNA Energy Storage Systems GesmbH in Weiz, Austria relies on state-of-the-art solutions and not only in the mobility sector. As one of the largest suppliers of the automotive industry, MAGNA depends on, amongst others, the expertise of DEPRAG. The screwdriving and assembly specialist is trusted with the functional testing of select products. In a test laboratory, fuel caps are put through their paces. The experts at DEPRAG SCHULZ GMBH u. CO. are continually working on new developments and enhancements. For this type of project, alongside tried and tested systems, they also utilise cutting-edge products: in this case, the DEPRAG screwdriver function module with electronic stroke (E-SFM). In comparison to a standard screwdriving function module (SFM), on the DEPRAG E-SFM, the pneumatic feed is replaced by an electronic drive. The E-SFM features optimum qualities to react flexibly to complex screwdriving tasks,

DEPRAG presents lightweight SFM for lightweight robots The increasing diversity of products, smaller batch numbers and shorter product life cycles all present new challenges for assembly. Automated processing steps are often uneconomical for small or medium-sized companies as they involve high costs. However, with the development of lightweight robots over the last few years, hopes have been raised. Manual assembly tasks can now be technically supported at a reasonable cost, thus utilising previously inaccessible automation potentials. Entirely new possibilities have opened up for assembly through the use of lightweight robots. Low investment costs enable the fast, economical implementation of applications: Robots with a low load capacity are significantly more affordable and the total size of the system or machine is substantially reduced when using smaller robots. Applications of this kind require assembly tools of an equivalently light weight. DEPRAG SCHULZ GMBH u. CO., renowned for their decades of experience in screwdriving

Screwdriver function modules for automated screw assembly SOGA Gallenbach GmbH in Pforzheim, Germany, designs and develops special purpose machines. This includes the multi-screwdriving unit to reliably join profile rails for ROMA, a leading manufacturer of sun screening systems. In this case, SOGA supplied a system with several assembly heads where screw depth and tightening torque are reliably monitored. The drive technology required for the head axes, such as servo-synchronous motors, planetary and rack and pinion drives, as well as drive regulator are provided by STÖBER. The extremely compact and dynamic LeanMotor is also used. The new encoderless motor class by STÖBER is a cost effective and robust alternative to the servo motor. In addition, STÖBER took care of the mechanical design and dimensioning. DEPRAG, the screwdriving specialists, complemented this partnership and supplied the necessary screwdriver function modules. “We provide our customers with special solutions which can be used in production immediately

Instruct, review and document with Deprag operator Guidance In almost any production environment, there are small, inconspicuous sources of error. All manufacturers dread the appearance of such errors in their assembly, because they can have such far-reaching consequences. If they result, for example, in product recalls, huge costs are incurred and significant damage can be caused to the company reputation. Alongside the selection of the optimal assembly tool, the use of high quality materials and the definition of processing parameters, error-free assembly plays a decisive role in guaranteeing reliability in production processes. Whilst at the same time, a high degree of flexibility is also a requirement in assembly. Businesses must be able to react quickly to changing quantities, models or degrees of automation. Even if systems are ready and available for operation within a short space of time, new sequences need to be integrated correctly into the production process and employees need to be trained. As a consequence, assembly

Convenient parameterisation using the ComCenter ED Innovative upgrades and continuous optimisation of existing product lines are the guiding principles of the screwdriving technology specialists Deprag schulz gmbh u. CO. The latest developments have resulted in the flexible low-cost electric handheld screwdriver MINIMAT-ED. This stunning all-rounder can, in conjunction with the ComCenter ED, be adapted quickly and simply to suit any screw joint. The ComCenter ED is operated via web interface and guarantees user-friendly and convenient parameterisation of the screwdriver. The base station can be connected either via Ethernet or WLAN to the network. To enable access via WLAN, the ComCenter ED can simply be set up as an Access Point on the integrated web interface. Access to settings or the creation and adjustment of screwdriving programs can therefore be carried out at any time using a smartphone, tablet or other mobile device. With the upgraded features of the ComCenter ED, control of the screwdriver is now possible

Thanks to the time saving QuickVChange vane exchange system Long system downtimes due to increasing maintenance works are still an issue in production. However, there are sometimes simple solutions which can significantly reduce maintenance time. For this reason, the engineers at Deprag schulz gmbh u. CO. developed the Basic line air vane motor, with a particularly attractive price-performance ratio. The one of a kind QuickVChange vane exchange system (the V stands for vane) is globally unique and is an enormous time saver. With just a few quick movements vanes are exchanged problem free. A lengthy system standstill is eliminated because vane exchange on the service friendly Basic line air motor takes place in situ on the machine without disassembly. Using an Allen key and tweezer, worn out vanes can be exchanged in next to no time – even by untrained personnel. After loosening the cylinder screws on the rear bearing cover and removing the end, vanes can be replaced quickly and simply. The whole job is competed within a couple

Live presentation impresses large audience At the MOTEK international trade fair for automation in production and assembly, Deprag schulz gmbh u. CO. showcased their extensive expertise in the field of modern screwdriving and assembly technology. Throngs of customers from Germany and abroad, visited the DEPRAG exhibition stand to gather information about their new products. Alongside tried and tested components, DEPRAG presented their latest highlights to support the interconnected digital factory: smart tools of the future, which can be combined with the newly developed Deprag cockpit software solution. The new Deprag cockpit software was presented live several times a day in front of a large audience during a series of talks entitled “The future of screwdriving technology”. DEPRAG specialists vividly illustrated the advantages of the software: all assembly tasks can be monitored, analysed and optimised centrally. This enables the user to recognise potentials at an early stage and react swiftly to changes.

Specialist is gearing up for the digital future All the big names in the industry are represented at the MOTEK international trade fair for automation in production and assembly at the Stuttgart Trade Fair Centre between the 7th and 10th of October 2019. Designers and operators will find cross-sector approaches, ranging from detailed solutions to turnkey system solutions. The unique industry platform showcases a wide range of cutting-edge solutions and the latest trends for optimisation in assembly processes. At the exhibition stand in hall 5, Deprag schulz gmbh u. CO. is presenting the new screwdriving system Deprag plus – the future of screwdriving technology. "This is not reinventing the wheel, it is a question of highly effective fine-tuning, as a result of technological advances, which have released enormous potential," explains Daniel Guttenberger, Product Manager for DEPRAG screwdriving technology. Connectivity, user-friendliness, flexibility, efficiency and documentation capabilities: these key characteristics

DEPRAG Cockpit ensures greater data transparency All the big names in the industry are represented at the MOTEK international trade fair for automation in production and assembly at the Stuttgart Trade Fair Centre between the 7th and 10th of October 2019. Designers and operators will find cross-sector approaches, ranging from detailed solutions to turnkey system solutions. The unique industry platform showcases a wide range of cutting-edge solutions and the latest trends for optimisation in assembly processes. In hall 5, at stand 5302, trade visitors can discover in-depth the latest innovations from DEPRAG. In addition to their diverse range of components, Deprag schulz gmbh u. CO. is presenting new highlights to support the interconnected digital factory: pioneering “Smart Tools” which can be connected to the newly developed Deprag cockpit software solution. All assembly tasks can be supervised, analysed and optimised centrally. Digital communication platform DEPRAG Cockpit is the new digital service facilitating

Majority shareholder Ingrid Schulz-Hallmann, Dr. Erik Hallmann and Dr. Rolf Pfeiffer inaugurated a new building at Deprag cz in Lázně Bělohrad on the 25th of July. Governor Dr. Jiří Štěpán and the mayor of Lázně Bělohrad, Ing. Pavel Šubr, attended the opening ceremony. The ultramodern building comprises 2.400 square meters of production, office and storage space. Dr. Erik Hallmann, Group CEO, said: “This significant investment of 3.4 m Euros in our Czech operation underscores our strategy of expanding internationally. Deprag cz combines resolutely modern production technology with a highly skilled workforce, all at an attractive cost. We will increase our market share and serve our global customers in the most efficient way. Our growing integration activities in special machines have met huge interest by our partners in Eastern European.” More information: Deprag schulz gmbh u. CO.

Specifically designed for longer screws Once the doors open, all the big names in the industry can be found at the MOTEK international trade fair for automation in production and assembly from the 7th to the 10th of October 2019 in Stuttgart. Designers and operators will find cross-sector approaches, ranging from detailed solutions to turnkey system solutions. The unique industry platform showcases a wide range of cutting-edge solutions and the latest trends for optimisation in assembly processes. In hall 5, at stand 5302, trade visitors can discover in-depth the latest innovations from DEPRAG. The focus is on the timely supply of parts and fasteners for assembly - a key component for the productivity and reliability of assembly processes. Feeding devices are designed to efficiently and precisely supply the required quantity of correctly aligned component parts and fasteners. Screws are the most common feed part automatically supplied, although other components include rivets, threaded pins, O-rings and labels. Deprag

The reliable assembly of fasteners Screwdriving technology is the key to numerous assembly tasks. Screw fastenings are popular due to their resilience, part reusability and because of the option of undoing the connection at any time without damaging parts. Therefore, screws are the most frequently utilised standardised machine elements and are available in a wide range of designs. The most important task for assembly fastening involves the application of a defined pre-load force. The pre-load force must be determined so that on one hand, the intended function can still be executed despite any applied operating force, and on the other hand, that the permissible load on the screw connection is not exceeded. It is the frequently unknown seating conditions of the screw connection which can be particularly problematic, as well as any assembly-related fluctuations of the pre-load force. Series screw assembly does not allow effective determination of the required preload force. Therefore, as an alternative,

Reliable assembly of tiny screws Electronic components in computers and smartphones, or in household, entertainment and automobile technology, are indispensable in innovations relating to all areas of modern technology. Usually hidden from view beneath the product surface, extremely complex electronic systems must be designed, manufactured and launched onto the market in the shortest time possible at an acceptable price. They also need to be totally reliable and energy efficient products. Rapidly increasing capabilities and constant miniaturisation have characterised developments in electronics for decades. Deprag schulz gmbh u. CO. is known for continuous optimisation of their products and for leading the way with new developments in the assembly of miniature components. The screwdriving technology specialists have a specific screwdriver in their program especially for intricate assemblies – the NANOMAT. This screwdriver reaches highly accurate, extremely low torques from 8 Nmm to 300 Nmm at

With advancing changes in the energy sector, interest in decentralised, variable power generators is growing. The use of waste heat from industrial processes can significantly contribute to increased energy efficiency and the generation of low carbon power. The Organic Rankine Cycle (ORC) takes a technological approach to the conversion of waste heat into power. For over 7 years, a Northern Bavarian consortium, consisting of the University of Bayreuth, OTH Amberg-Weiden Technical College and the company DEPRAG, have been successfully developing ORC systems, specifically, micro expansion turbines in low power ranges of under 50 kW (electric). The recovery of unused energy, such as the heat in exhaust gases from combustion engines or gas turbines or even the waste heat from industrial processes, is a promising strategy to address the challenge to increase energy efficiency. The existing technical solutions, such as downstream steam power processes or turbines as expanders

Energy efficient drive designs for almost every application Materials in winding applications place varied demands on drives: Sometimes the issue is high speeds, sometimes precision and in other applications, the challenge of a large mass. The wide spectrum of materials covers raw paper with a width of up to ten meters over a thin film, to carbon fibre threads with low elasticity and high tensile resistance. Paper webs, for example, are rolled with a diameter of around two metres at high speeds of up to 2,000 m/min. Films are sensitive materials which must be wound or unwound extremely precisely, and the winding of metals adds the issue of heavy masses which influence the winding process. One range of drives which embody the required versatility is found in the air motors from DEPRAG SCHULZ GMBH u. CO. The vane motor works according to a simple principle. The rotor turning in an eccentric cylinder is set into motion. Centrifugal force presses the vanes against the rotor wall and working chambers are built. In these working

DEPRAG announces the incorporation of its 100%-owned company DEPRAG announces the incorporation of its 100%-owned company “DEPRAG MEXICO Sociedad de Responsabilidad Limitada de Capital Variable”. The new subsidiary is located in the city of Guadalajara, western federal state of Jalisco. A brand new building with 560 square meters of combined office and production space has been rented in a resolutely modern industrial park. In light of DEPRAG’s strong sales growth in Mexico over the past years, the decision to open shop was only logical. The new operation will provide service and the integration of special machines for our customers. Guadalajara is Mexico’s second largest city with a metropolitan population of 5 m. The region is known as Mexico’s “Silicon Valley” because of the presence of major players in the electronics industry. DEPRAG’s globally active customers like Flex, Jabil, Continental and ZF all have production plants in Guadalajara. Dr. Erik Hallmann, CEO of DEPRAG, said: “Mexico has tremendous

An increased emphasis on flexibility, efficiency and technical cleanliness The year 1908 was one of the most historically significant years both for personal motorised transport and for industrial assembly. With the Model T, the Ford Motor Company launched an automobile on the market which could be manufactured for the first time in large numbers at an affordable price. This not only heralded the age of private transport for the masses, but this first assembly line also gave the green light to industrial series production in the automotive industry. Due to advancing rationalisation measures, amongst other things in the form of a comprehensive division of labour, production rose to the point where it was efficient enough to produce up to 9000 vehicles a day. Since then, despite an enormous increase in output, the basic principle of manual assembly work has essentially remained the same. Product assembly has been revolutionarily influenced by an increase in automation and digitalisation. Today, fully automatic systems can be remotely operated

The feedability analysis and its influencing factors Smartphones, cars or computers: product life cycles are getting shorter and shorter. Despite this, every new product still requires appropriate production equipment, which in turn, also needs to be planned and realised all the more quickly, as in the case of assembly systems which include feeding technology. A great deal of information and many parameters must be taken into consideration in order to achieve an optimal result in the interaction of the various components for smooth processing. Their many years of experience, ingenuity and the rapid availability of their standardised modules mean that DEPRAG SCHULZ GMBH is a global player in the market of feeding technology. Thomas Lederer, Application Specialist for Screwdriving Technology and Automation at DEPRAG has answered some questions on this topic in order to explain the various backgrounds and contexts for the feedability of fasteners and optimal design. Interviewer: Supply of fasteners, such as screws, via

Screw joint analysis assists in the selection of the best screwdriving tool In the world of technology, screw assembly is the procedure most frequently used to join components. Every manufacturer fears errors in assembly. If there is a need for product recall due to faulty screw connections, the economic impact is considerable. Along with the appropriate training of personnel and the use of high quality materials, the selection of the most suitable screwdriving tool for each application plays a major role in ensuring process reliability during assembly. A screwdriving task may only be executed reliably if precision screwdriving tools are used and the screwdriver has been optimally adapted to the application. Therefore, when making a selection, there is a wide range of criteria to consider – from flexibility and process reliability, to torque accuracy, production data acquisition, documentation requirements, investment needs, operating costs etc. In order to determine the necessary tightening parameters and to identify approaches to solutions,

Standardised modular components build the perfect ensemble Production downtime, assembly errors, product recalls – Who is not eager to avoid these horror scenarios for industrial series production. Contamination, defect parts or faulty screw joints are all examples of small issues creating major problems. Significant financial damages and loss of reputation lead to dramatic consequences which can be avoided if the utmost reliability is guaranteed. Industrial screwdriving and feeding assembly systems are composed of a variety of complex components, the sound interplay of which, is of decisive relevance for the reliability and productivity of the unit as a whole. In order to avoid interfacing issues between screw feeding and the screwdriving tool, DEPRAG SCHULZ GmbH from Amberg, Germany, provides a wide spectrum of requisite system components from a single source. With over 40 years of experience, the standardised modular design of their components enables wide-ranging and versatile combination options with fast delivery

Cooperation project partners develop ORC research power generator There are many weapons in the fight against climate change. One is the use of renewable energy. Another important element is the recovery of waste energy which is released by countless industrial processes. Unfortunately, it is often just lost into the atmosphere … “In many industrial activities process gas is lost into the atmosphere. The original plan was to find a way to utilise the potential of these gases”, explains DEPRAG Chief Operating Officer Dr.-Ing. Rolf Pfeiffer. The recovery of energy from process gases in not a new idea. “What is new, however, is that with our development, using a small, compact, decentralised energy recovery system, even small amounts of residual energy in the power range of 5 to 200 kilowatts can be converted into power”. The DEPRAG GET turbine generator can be used anywhere that surplus energy is created by industrial processes. The University of Bayreuth, the East Bavarian Technical College Amberg-Weiden (OTH) and the

Flexible assembly systems for every requirement Electro mobility is the definitive key technology for the sustainable transport system of the future. The policy-assisted development of E-mobility is moving in the right direction. The automotive industry and its suppliers, however still find themselves in a dilemma regarding the design and project planning of their production and assembly systems. Uncertainties in planning for volume and unknown practical values continue to be the greatest challenges. “This cutting-edge sector faces a conflict regarding the planning of assembly systems. The chosen technology must be able to flexibly adapt to increased capacities resulting from rising volume, reaching all the way up to fully automated systems. However, today’s assembly of smaller quantities must also ensure top processing reliability, because – as always in vehicle manufacture – errors in assembly are a real danger to life and limb”, explains Jürgen Hierold, Sales Manager at the machine builder DEPRAG

Press-insertion devices for handheld and stationary assembly tasks If you have ever punched a hole in a cover or pushed a tack or pin in a wall then you will know how much stress it causes your thumbs. It can be painful if your thumb is strained like this repeatedly over time. There are many applications in industrial production where it is often left to workers to push together fastening elements by hand in order to attach two components. Fitters may repeat the movements hundreds of times per day. For automotive assembly, interior trim is predominantly attached using trim clips, plastic expanding rivets or push-fit panel pins. These fasteners have one thing in common: They must be pressed into a pre-drilled hole to connect two components together. Press-insertion joining processes can be found in many other sectors as well as the automotive industry: from the aviation and aerospace industries or machine building, telecommunication and apparatus engineering up to modular assembly for electronics and vehicle technology. In order to

Shoe manufacture made simple The manufacture of footwear goes back a long way in history: Even 40,000 years ago humans felt the need to protect their feet from adverse outdoor conditions. Several hundred centuries passed however, before the modern aesthetic footwear of the present was developed and consequently also manifold procedures for the manufacture of shoes. Whereas in the pre-industrial era shoes were crafted by shoemakers, today shoe manufacture is largely an industrial process. Nevertheless, the manual aspect of production is still a significant part of the process. The manufacture process is composed of three key sections: development and design, manufacture of shoe uppers and the actual shoe production. First, a sketch of the shoe is created, pattern pieces for the various upper parts are made and the shoe lasts are manufactured. The last is the interior profile to which the uppers are shaped and joined to the sole of the shoe. Next the various parts for the uppers are cut and glued

Vibratory spiral feeders and sword feeders delivered swiftly It is a trend which began in the 80s and has continued to the present generation, almost becoming the accepted standard: vehicle manufacturers are bringing a growing number of models onto the market in increasingly fast succession. This has a noticeable impact on product development and production. There is particularly high demand for concepts which shorten the development period. For instance, one efficient method is to plan, design and order production systems and resources parallel to the development phase of a new car model rather than subsequently. Therefore, any alterations which may arise during product development have a direct influence on production resource planning, which consequently may need to be adapted. A suboptimal flow of information, as a consequence of multiple organisational interfaces, can increase the scope and complexity of required alterations and lead to delays in the overall development time. In this case, there is particularly high pressure

Prevent particle contamination of sensitive screw assembly components Just as an aggressive virus can cause illness in humans, the smallest particles can damage components and lead to malfunctions or, if used as system components, could even lead to a complete system failure. There are many reasons that such hazardous particles may be generated during production processes. In the automotive industry particles are predominantly created by abrasion during assembly. DEPRAG Schulz GmbH has therefore developed their ”CleanFeed” concept to prevent particle contamination of sensitive components which require a high standard of cleanliness during screw assembly. Technical cleanliness is increasingly being introduced in a wide range of sectors and is becoming an important quality requirement for the whole process chain: from production to logistics to assembly. The trend toward miniaturisation, as well as increased electronics and the greater use of new lightweight materials is primarily responsible for this. On the one hand, components

High specification acid and heat resistant stainless steel motors Fibres are dissolved in water and scooped out with a sieve. This paper web is later pressed and dried. Today gigantic paper machines are used in the various processing steps to turn the pulp into paper. Paper manufacture – this is an enormous challenge for machine builders, as individual components need to be able to withstand extreme pressures. DEPRAG SCHULZ GMBH u. CO. in Amberg, Germany manufactures stainless steel air vane motors which have proven to be the optimal drive solution for numerous areas of application. In stock preparation for paper machines for example: pulp and wood pulp as well as waste paper fibres are mixed in a certain proportion depending on the type of paper, and then dissolved in water. Chemical bulking agents and additives are also added. This aggressive liquid must be ”agitated” repeatedly. For this application, the engineers have developed DEPRAG POWER LINE air motors with acid-resistant stainless steel housing made from V4A material.

Energy efficient drive design for any application The selection of the correct drive is an important element in the development of a system. In order to design the most optimal motor for your individual machine, amongst other things, the torque and speed must be defined. It pays to make an exact calculation. Both an over-sized or under-sized drive can result in additional costs. If an air motor is too large, the initial outlay and air consumption is higher than necessary. Whereas, in the worst-case scenario, a drive which is too small must be redesigned and replaced with a larger one. The functional principle of an air vane motor is simple: An air vane motor consists of a rotor, which revolves in an eccentric cylinder. The vanes are pressed against the outside of the rotor wall by centrifugal force and build working chambers. The compressed air expands in these working chambers; pressure energy is converted into kinetic energy and the rotor turns. The air motors are characterised by their speed adaptation feature,

Superior production quality guaranteed In order to ensure the quality of screw connections in assembly processes, the tools responsible must undergo regular tests and calibration procedures. Usually these services, in the form of calibrations, must be carried out by the manufacturer of the screwdriving equipment in their own laboratories. If it is not possible to do without equipment for the few days it will take to send it away for calibration in an external laboratory the answer is: on-site calibration! DEPRAG SCHULZ GMBH u. CO. in Amberg, Germany offers this service feature. In interview with Tobias Dirrigl, Application Technician for EC Screwdriving Technology, the benefits to customers of mobile calibrations are explained in detail: Question: Danger to life and limb – an expression which is frequently associated with quality for assembly production. What role does calibration play? Dirrigl: The quality of screw assemblies is influenced by the precision of the screwdriving or measurement

Ensure quality regulations are met by using DEPRAG EC-Servo screwdrivers Every manufacturer fears errors in assembly. If defective screw connections result in product recall, the economic damage can be massive. Along with the training of staff, the use of high quality materials and the determination of processing parameters, it is the selection of the optimum screwdriving tool which plays a decisive role in guaranteeing the processing reliability of assembly procedures. Legal requirements and internal guidelines which must be adhered to can make the search for the right screwdriving tool a difficult one. DEPRAG SCHULZ GMBH u. CO. has made a name for itself in the field of screwdriving both for handheld and stationary usage. Jürgen Hierold, Sales Manager at DEPRAG: “We support our clients in the selection of appropriate screwdriving systems and tools, thereby preventing product recall caused by faulty screw connections.” One approach to fulfilling safety requirements is the selection of suitable screwdriving technology. Intelligent

Stirring and mixing underwater ”Anything is possible” is the motto of the DEPRAG engineers. They do not rush their client consultations. If there is no suitable air motor for the planned application in their catalogue then they explore individual drive solutions. The air motors have a wide spectrum of use due to their diverse application possibilities, simple design, low performance weight, broad speed range and explosion safety. DEPRAG air motors are used in almost every field of industry – even underwater. The ADVANCED LINE air motor series combines many advantages with their high quality stainless steel drives. Due to the robust design of the external parts in non-corrosive stainless steel and the sealing with two radial shaft sealing rings, these vane motors in the power range 120 W to 1.2 kW are predestined for use underwater. For underwater applications it is vital to consider how the motor will be deployed and at what water depth it will be operated. If the air motor has to start

POWER LINE air motors are now ATEX conform You need a motor to be light and small but with high torque! With the POWER LINE air motors the name says it all! The powerful air motors are distinguished by their unparalleled low performance weight. The required high torque is reached immediately after start-up. It is a motor, which not only shines in terms of economy: as well as the attractive price and fast delivery times, the POWER LINE motor is now available in the same size but with even more power. The foot and flange motors with robust cast-iron housing have a power range of 1.6 to 18 kW. The product spectrum already consists of a number of standard motors. Now the POWER LINE program has been extended and the ATEX certified motors have been added: the sizes from 1.6 to 6 kW are accredited in accordance with directive 2014/34/EU from 26th February 2014 for use according to EX II 2 GD c IIC T3 (200°C). In accordance with 2014/34/EU, machines in category 2 are designated for use in areas where a potentially

Air-operated grinders with revolutionary technology which continuously tracks the device’s DEPRAG CZ a.s. opens up unimagined possibilities for your pneumatic tools through their new platform DIQ. The subsidiary of DEPRAG SCHULZ GMBH u. CO. is developing swiftly with new innovations and distinguishing itself with the recent design of an Industry 4.0/Smart Factory platform showcasing a brand new type of grinding technology which did not exist previously. Within the brand of DEPRAG INDUSTRIAL these professional air tools are distributed around the globe. Their revolutionary Industry 4.0/Smart Factory Platform DIQ has been created from a new technology which enables continuous monitoring of the grinders and displays the complexity in production companies. The Technical Director at DEPRAG CZ, Dr. Michal Hubálek, explains: ”Our clients often tell us that they are unable to acquire data relating to the operating time of the grinder, the impact of load and the total service outlay etc. Therefore, it is not possible to effectively utilize the machine’s working

Adaptive screwdriving procedure DEPRAG Clamp Force Control Screwdriving technology is the most widely used joining technology. Ever more complex assembly tasks, increased demand for processing reliability and higher quality standards require sophisticated procedures which are clever enough to cope with these complicated requirements. Aluminium and other lightweight metals and synthetics are increasingly being used in the automotive industry, for example, for lightweight construction. Housings for pumps, airbags or interior components – all these products are usually assembled using thread-forming or thread-cutting screws. Strongly contrasting tightening torques are generally required in these types of screw assemblies. The use of a torque controlled tightening procedure can cause wide variations in the resulting clamp force even with excellent shut-off accuracy. The new adaptive screwdriving procedure DEPRAG Clamp Force Control (CFC) works to counter this by eliminating all frictional influences up until the point of head

DEPRAG presents eacy feed, the new generation vibratory spiral feeder, at the MOTEK 2016 Reliable feeders are a vital requirement in attaining the best possible system reliability. But DEPRAG has proven that their feeders can deliver on a lot more than reliability with their new breakthrough. eacy feed, (Efficient Assembly Communication Yield) the new generation vibratory bowl feeder, is extremely energy-efficient and is Industry 4.0-capable. The basis for the intelligent and sustainable production of tomorrow is here today. Increased environmental awareness and growing energy costs have become a core issue for companies, bringing with them a demand for improved efficiency and energy savings. DEPRAG has met this demand for efficiency and sustainability with their innovative solution eacy feed. The inventive and effective utilization of physical responses has enabled the reduction of energy costs by around 80 %. The drive of the new eacy feed works using 24-volt oscillating magnets, whereby the maximum power consumption is dramatically reduced. The

Optimal processing due to automatic adaptation to altering parameters CO2 reduction and increased load cycles in E-mobility: both are aims which are becoming achievable due to lightweight vehicles. This has been recognised for a long time in modern automobile engineering and it has been relying on lightweight materials instead of conventional steel for chassis design. From high safety requirements, reliability of materials, simple repairs, easy replacement of bodywork components to recycling and the possibility of reuse - all are considerations which present challenges to the automotive industry. It necessitates a complete rethink, even in assembly: The choice of the correct joining technology is of decisive importance in lightweight construction. Flow drill screwdriving has established a place for itself within chassis design. The specially formed tip of the so-called flow drill or flow form screw generates frictional heat under high pressure and at high speeds, effecting a flow process in metal sheeting which has not been pre-drilled.

EACY FEED (Efficient, Assembly, Communication, Yield) is the next generation vibratory spiral feeder. Just in time for the AUTOMATICA, DEPRAG Schulz GmbH from Amberg, Germany present their innovative new development: energy-efficient Industry 4.0-capable feeding machines. EACY FEED devices are distinguished by dramatic energy savings of 80% in comparison to the previous generation of vibratory spiral feeders, which were themselves already very energy-efficient. There is a smart version available for Smart Factory systems. The extremely high energy efficiency of the EACY FEED is achieved through the low power consumption of the drive using 24 V oscillating magnets. The low voltage enables smooth and trouble-free operation and global application of the EACY FEED devices without the need for country-specific alterations, and they are not affected by network disruptions or varying local power supplies (voltage and frequency). The Industry 4.0-capable EACY FEED version

Utilisation of components with communication capabilities The DCAM (DEPRAG COMPACT ASSEMBLY MODULE) was first launched back when mobile phones were still assembled by hand. If your production was faster and more economical you had the upper hand. The DEPRAG assembly platform for industrial production came onto the market and has since become fully established worldwide. The DEPRAG engineers have been making continuous improvements to the well-known work station over the past 25 years. Any customer purchasing the optimised DCAM receives a standardised assembly platform with the recognised reliability and high functional safety of the customary assembly unit. By virtue of its modular concept the DCAM is available ”off the shelf”, making purchasing more easily calculable and with a clearly foreseeable delivery time. ”Up to now each DCAM was basically a custom-made product for each client. It would take a long time from initial consultation to design and manufacture and the high labour costs reflected negatively in investment

DEPRAG has been recognised as the ”Preferred System Integrator” of Stäubli Tec-Systems Robotics. This distinction demonstrates Stäubli’s appreciation of the loyal and reliable partnership between the companies. Over the many years of positive collaboration DEPRAG has integrated a significant number of Stäubli robots in innovative applications. Stäubli Robotics, a leading global robotics manufacturer, offers a high-performance product portfolio of four and six-axled robots with capacities of up to 190 kg. Their standard robot range has continuously expanded to include specialised series for customised applications such as for clean and ultra-clean rooms, steam, explosive and sterile environments. Today these precise and flexible robots can be found in all market sections in industries as varied as the automotive, food, life sciences, machine building and plastics. The sales strategy of Stäubli is built on long-term partnerships with system integrators.

Minimise downtime and save costs the easy way An estimated twelve kilos of screws are used to build a medium-sized vehicle. The safety risk ”danger to life and limb” applies to 15% of these. Precision and stability are vitally important for these components! If any fail, the resulting accident could cost human lives. In order to ensure the quality of screw connections the tools responsible must undergo regular tests and calibration procedures. Usually these services, in the form of calibrations, must be carried out by the manufacturers of the screwdriving equipment in their own laboratories. But now DEPRAG SCHULZ GMBH & CO. is also offering a diverse range of service options relating to calibration. The main feature: calibrations no longer have to be carried out in a calibration laboratory. Since January 2015 they have been offering on-site calibration with their mobile service unit! ”Since the introduction of this option, around 30% of all calibrations have been provided on-site at the customer’s

Turbine drive technology saves energy and gives high output power Sparks fly and the shipbuilding worker perspires under his safety goggles. In his gloved hands he is holding an angle-grinder. With strength and stamina he smoothes the bumps on the welded seams that join together the steel plates of the ship’s hull. It is a difficult job for man and machine, and it usually performed in piecework and multi-shift operation. The exhausting load created by the angle-grinder’s weight and its vibrations place heavy demands on a man’s strength. Any sign of fatigue in the worker has an immediate effect on the result of his work, and thus on productivity. That is why the ratio between weight and power in a tool comes into focus when selecting the right industrial tool. With their incredibly favourable power-to-weight ratio (kW/kg), the innovative turbine angle-grinders, powered by compressed air, score highly here, thus representing a convincing alternative to conventional devices. For decades compressed air specialist DEPRAG SCHULZ

Food processors must be ever more versatile Multi-functional food processors are still very much in vogue. In 2014 the sales of classical small electrical appliances such as food processors achieved an above-average growth rate – according to the findings of GfK TEMAX. The multi-talent Thermomix made by Vorwerk stands out in this market. For more than 50 years this smart kitchen appliance has been loved by over seven million users worldwide. And the new Thermomix Generation TM5 is now revolutionising the kitchen and stepping into the digital world with its innovative Recipe Chips, touch screen and unique Guided Cooking function. The latest Thermomix model TM5 has been available since the 6th September 2014 and is already proving extremely popular. The Thermomix combines twelve functions in one machine: It not only stirs, mixes, kneads and chops but also cooks, steams, weighs, blends, grinds, beats, heats and emulsifies. Enabling anyone to achieve complicated bain marie recipes such as hollandaise sauce or

The alternative to a stationary pneumatic screwdriver The trend in avoiding compressed air as a drive medium in various production and assembly processes can result in a great deal of expense when it comes to stationary automated screw assembly. The DEPRAG MINIMAT air screwdrivers guarantee reliability whilst retaining top functionality and torque accuracy. They have gained a reputation for this worldwide over many years. Those who want to follow the trend of reducing their use of compressed air were, up until now, compelled to switch to the relatively expensive alternative of electric screwdriving tools. These tools are best suited when high requirements are demanded relating to accuracy torque capability and flexibility. When this is not the case it can quickly lead to expensive ”over engineering”. The logical consequence was the unmistakable demand for electricity as a drive medium in combination with the mechanical shut-off clutch which has proved itself a thousand times over. DEPRAG SCHULZ GMBH u. CO. has

Complex and multi-stage screwdriving sequences complete the broad range of features Continuous and innovative expansion and optimisation of existing product lines are the key principles of DEPRAG SCHULZ GMBH & CO. At this year’s MOTEK trade fair the German machine builder will be presenting their latest developments in screwdriving technology – amongst others, the new MINIMAT-ED. The handy all-rounder can be quickly and simple adapted to any screw joint. The torque required for the screw assembly is set directly on the screwdriver at the push of a button. Up to five programs (with pre-defined torque or angle values) can be saved and selected as required. Screw assembly can then begin immediately. The electric screwdriver is precise and reliable, the tools shuts off once the target value is reached. Red and green LEDs light up immediately to show the operator whether the assembly was carried out successfully. The new MINIMAT-ED can also be used to implement more complex procedures without any difficulty. If a customer has several screw joints

Guidance and software now integrated in the base stand Although today many industrial procedures are already automated, the automation of applications is still becoming ever more popular, particularly in sectors where human hands are used to assemble products, tighten screws or glue together components. Nevertheless the flexibility of an employee working on assembly remains a key factor for competitive industries. For that reason the engineers at DEPRAG SCHULZ GMBH u. CO. are continually optimising and improving currently automated solutions whilst also advancing into sectors where automation has not previously been an efficient option. The solution, an innovative semi-automatic manual work station, is extremely productive, reliable and economically designed to provide an outstanding working environment for the operator. The “intelligent manual work station” combines manual work with processing reliability which is in no way inferior to automated production. In a well-conceived solution processing reliability is constantly

DEPRAG explains waste heat recovery using an ORC mini power generator Surplus heat from industrial processes is by and large an untapped resource. This unused potential is just waiting to be discovered! A joint cooperation project between the University of Bayreuth, the East Bavarian Technical College Amberg-Weiden and the company DEPRAG SCHULZ GMBH u. CO. has developed a new and innovative ORC mini power generator – supported by the Bavarian Research Foundation. The project partners have succeeded in efficiently converting existing waste heat into electrical energy. The basic idea: ”In many industrial activities process gas is lost into the atmosphere. The original plan was to find a way to utilise the potential of these gases”, explains DEPRAG Chief Operating Officer Dr.-Ing. Rolf Pfeiffer. The recovery of energy from process gases in not a new idea. ”What is new, however, is that with our development, using a small, compact, decentralised energy recovery system, even small amounts of residual energy in the power range of

Climeon has with its Climeon Ocean enabled highly efficient, profitable production of electricity, using hot water. With more than half of the world’s energy wasted as ”cold heat” or hot water there are vast market and environmental potentials. On the 26th of May Climeon AB and Deprag Schulz GmbH u. Co. signed a manufacturing agreement for a next generation turbine generator called C3-GET-R160. The new turbine generator system will enable further improvements to the already world class efficiency of the Climeon Ocean solution. The deal includes a production agreement allowing for large scale manufacturing and global deployment. The Climeon Ocean system uses low temperatures between 70 degrees and 120 degrees Celsius and converts this energy into electricity. At 90 degrees Celsius more than 10% of the heat is turned into electricity witch is more than 50% of the theoretical max. ”With this cooperation we expect a successful enlargement of our existing

Ensuring safe processing of foodstuffs In these times of rising costs, companies are increasingly reliant on pre-processing in automation. Even in the food industry automated production processes have gained in significance - hygiene is of equal importance as efficiency for the mechanical processing of foodstuffs. Whether for the production of fruit juice drinks or the preparation of kebab skewers, the handling of flour, the cutting of dough or the use of packaging machines, air motors are the perfect solution for all these varied drive applications. High quality stainless steel air vane motors are especially suited to these challenging applications. DEPRAG SCHULZ GMBH u. CO. is an international leading supplier of air motors, automation, screwdriving technology and air tools. The DEPRAG engineers have spent decades developing and continuously improving their pneumatic motors. Their ADVANCED LINE motor series provides systems engineers with quality stainless steel drives which combine many beneficial

Patented vane exchange system reduces maintenance time Good things come to those who wait, but time costs money – especially concerning maintenance work, where in fact simple solutions can be employed to speed things up. The engineers at DEPRAG SCHULZ GMBH u. CO. have therefore developed the BASIC LINE air vane motor with a particularly attractive price to performance ratio. Their patented vane exchange system is unique throughout the world and is an enormous time-saver. In just a few movements the vanes can be replaced. Long periods where the system is out of action are completely avoided as vane exchange on the service friendly BASIC LINE air motors can be carried out in situ directly on the machine without the need for disassembly. Even untrained personnel can quickly replace worn vanes using only a screwdriver and tweezers. Once the cylinder screws on the rear bearing cover have been loosened and the rollers removed, replacement is easy. The complete maintenance is finished in a few minutes, much quicker than exchanging

Processing reliability in screwdriving assembly 2014 was a record year for vehicle recalls. The Center of Automotive Management (CAM) in Bergisch Gladbach published a study on 14.01.2015 which discovered that in the past year more vehicles than ever before had been recalled due to safety defects such as leaking brake lines, brake failure and defect airbags. One source for this was the US market where almost 63 million vehicles were recalled to garages due to safety issues – more than twice as many as the previous highest number in 2004. The factors responsible for this trend are structural causes, such as the increasing technological complexity of vehicles, the increased pressure to keep costs low and the use of modular and common part systems in production. In order to remain competitive in the fierce market the producers must guarantee the highest quality and safety at every single stage of production. DEPRAG supports their customers in this by fulfilling legal requirements for screwdriving systems and tools

DEPRAG screwdriving technology for low torque applications ”Electronic components simplify our lives. Both in the workplace and part of our daily routine, whether in computers and mobile telephones or in household, entertainment or automobile technology. They are indispensable in innovations relating to all areas of modern technology”. This is how the German Federal Ministry for Education and Research describes the role of microelectronics within their policy document from 24.06.2014. The Federal Government has recognised the meaning of this research arena for a long time and even considers this one of the central key technologies of modern industrial society. In the future research into micro and nano electronics will be even more strongly supported at the national and European level. The Federal Ministry for Education and Research will, within the framework of the development programme IKT 2020 Innovations, strengthen the dominant technological position of Germany in electronics in order to secure a competitive position

DEPRAG ensures the selection of the correct motor design for any application Winding drives can be found in many production processes: they wind continuous materials before or after their handling on spirals, rolls, reels or balls. The spectrum of material to be wound ranges from base paper of up to 10 metres wide or thin film with a thickness of 6 μm, to carbon fibre threads with low elasticity and high durability against tearing. Every material to be wound places different requirements on the winding drive due to their specific features in terms of surface, hardness, tensile strength, cross-section profile or thickness. Reams of paper with a roll diameter of around two metres for example are wound at a high speed of up to 2000 m/min. Films are a sensitive material which must be wound or unwound very precisely. The winding of metals on the other hand means that large masses are in play which influence the winding process. Pneumatic motors are safe and robust drive systems providing a drive solution for winding processes. A pneumatic vane

Perfect screw feeding with top processing reliability DEPRAG expands their wide range of intelligent manual work station solutions with the DFM There is an increasing trend in the assembly industry: Fully automatic assembly is taking a backseat to intelligent manual work stations. Around 15 years ago companies were investing in automatic systems to increase processing reliability – the required zero error quota or permissible deviations in the lowest ppm range were at this time not possible in manual assembly processes due to the unpredictable human factor involved. What came out of the economic crisis of 2008/2009 was that when orders rapidly decreased, fully automatic systems would not have a 100 percent and therefore, economic workload utilisation. If the demand increases unexpectedly and exceeds the capacity by the possible 100 percent then again automatic production cannot adapt to the overcapacity. The company cannot react adequately to the recovered full order books. Manual work stations are flexible and can

Processing reliability for the assembly of self-forming and self-cutting screws Screwdriving technology is the most popular form of joining technology. More and more complex assembly tasks, increasing requirements for processing reliability and higher quality standards require sophisticated procedures which can fulfil these high specifications. In the automobile industry for example, aluminium, light metals and plastics are used more frequently due to the need for lightweight construction. Housings for pumps, ECUs (Electronic Control Units), airbags, interior components – all these products are normally assembled using self-forming or self-cutting screws. In the processing of these screws a tapping drill hole is used, the screw itself however acts as the thread forming or cutting tool. However for assemblies usually in series assembly, for self-forming or self-cutting screws tightening based on a defined end torque is the established screwdriving procedure. The torque guided screwdriving process is always the most adequate solution if the forming

How to avoid design errors and save money Right from the initial selection of a drive, a designer has to make careful considerations when looking for the optimal motor for their application. Determining the torque and speed, selecting a pneumatic motor from suppliers’ catalogues and clarifying the size and connections required for the machine – sounds simple. But unfortunately it is not that easy, a rude awakening may follow if, after installation, the selected pneumatic motor does not produce the power required. Determining the problem may take weeks, in the worst case scenario the entire drive may have to be redesigned and purchased again. Therefore it is worthwhile to talk to the specialists at the beginning of the drive design phase. Product Manager for air motors at DEPRAG SCHULZ GMBH u. CO, Dagmar Dübbelde, has developed a simple guide with 6 steps to follow so that nothing is forgotten. “The selection of a pneumatic motor is not difficult. But particularly with pneumatic systems there are many

Innovative screwdriving system for vehicle bodywork production Whereas in the past, steel sheets were easy to join by spot welding or resistance welding, today this is no longer economical due to the modern material mix. The automobile industry is under pressure from legal requirements to reduce CO2 emissions, use lightweight construction and consequently to find alternative joining methods. Where access to both sides of the connection point is available this can be done using rivets. If however only one side is accessible then the well-established direct screwdriving flow form principle comes into use. A flow form screw is positioned on an aluminium or steel sheet without pre-drilled holes and the screwdriving process begins. The screw is applied with a high pressure down-force and rotates at high speed, generating a frictional heat which forms a crater through which the screw’s thread passes under reduced pressure. A machined thread is created, a normal screw can also pass through in the case of repairs. After the flow passage

Processing reliability ensured through intelligent manual work stations Peter Smith, production engineer at a well-known manufacturer of heating control units explains his situation: “Our heating control units are available, according to type and size of heating system, in the most varied of designs. With the recent introduction of our new control units we are starting three separate series, our HCU25, HCU50 and HCU100. When launching our new series onto the market we are unable to estimate the expected production amounts accurately. It is also difficult to plan out how the quantities required of each individual version will develop in relation to one other. It is for exactly this reason that we require highly flexible assembly equipment. Ideally production should be able to be simply, reliably and economically adapted to each of the product versions. Additionally for our HCU assembly we have the highest requirements for processing reliability as is usual for electronic components. The sequential order of assembly must be guaranteed and

Continuous prevention, reduction and removal of dirt particles in assembly processes Technical cleanliness is no trend. It is essential in the production and assembly of ever more complex products with increasing quality requirements. Components and units whose function can be impaired by dirt must be produced and assembled in a technically clean environment. It is for this reason that the renowned screwdriving technology specialists DEPRAG SCHULZ GMBH u. CO. have placed great emphasis on the realisation of technical cleanliness in assembly processes using standardised solutions as shown at the AUTOMATICA this year from the 3rd to the 6th of June in Munich. In Hall A6, at exhibition stand 310 the company demonstrates varied detailed solutions focusing on technical cleanliness in screw assembly. “For all the innovative individual solutions which we present at the trade fair, the complete assembly process should always be considered”, explains Jürgen Hierold, Sales Manager at DEPRAG. The approach towards technical cleanliness relates to all areas,

High-tech manufacturer provides optimal screwdriving technology for any application In order to discover the latest trends in screwdriving technology, I visited the AUTOMATICA trade fair; the leading platform for automation innovations. In Hall A6, Stand 310 at the DEPRAG exhibition stand three slogans caught my eye: “Technical – Clean – Screwdriving – DEPRAG”, “Intelligent – Manual – Assembly – DEPRAG”, “Sheet Metal – Direct – Screw Assembly – DEPRAG”. This seemed to be the right place to get all my questions answered. At the exhibition stand I met Jürgen Hierold, long-standing Sales Manager at DEPRAG SCHULZ GMBH u. CO. Q: Mr Hierold, can you answer my questions about the latest trends in screw assembly? A: Yes, you’ve come to the right address. To be able to appreciate the current trends in screw assembly you need also to have an understanding of past innovations and developments. I have been specialising in screwdriving technology and automation since the end of the seventies and so can look back on years

A comprehensive range of accessories is available for the DEPRAG GET turbine generator Floods in the past year, the mildest winter in a long time, springtime temperatures in January. Our climate is changing. Extreme weather is on the increase. Climate protection and efficient energy usage are more important than ever. It is high time that we started using energy wisely. In the European Union there are attempts underway to not only reduce emissions of the climate killer CO2 by 20 percent before 2020 but by 30 percent instead and also to make it a binding commitment. Research and industry are called upon to come up with innovative projects which will help protect our environment. The opportunities are numerous and wide-ranging. Unused potential is waiting for exploitation. In 2010 DEPRAG SCHULZ GMBH u. CO had already started an ambitious research project into the field of energy recovery. This project, sponsored by the German Federal Ministry for Economics and Technology as a result of a resolution by the German Bundestag (Germany’s parliament),

Integrated design for the reduction of contaminating particles Technical cleanliness is gaining increasing importance, particularly in automotive technology. Minute particles can cause devastating damage. For example when components are assembled onto a PCB a tiny stray piece of metal could connect two of the conducting strips and cause a short-circuit. Contaminating particles themselves have an effect on how components function. They can clog up jets and filters, block valves, or cause bearings to jam. The requirement for ever higher power density means that components and units are increasingly more complex, with much tighter tolerances. In recent years the importance of technical cleanliness has grown greatly. It started with active and passive driving safety systems such as ABS, progressed to include diesel and direct injection models, through to variable camshaft phasing and lead-free bearing cups. With the aim of preventing hazardous contamination caused by particles just 50 - 1000 µm in size, the VDA has created some

Make savings of over 30% using a turbine grinder with high quality abrasives Grinding as a geometrically undetermined machining process is widely employed, whether processing moulds or removing sprues in foundries, in machinery, tool or jig construction, in industrial steel construction or the automobile industry. Abrasives are used to process the surfaces of widely varied materials such as metal, wood or plastics or used to separate materials. Every grinding process is based on two components, whether manual or used in stationary applications, the grinder and the abrasive, and they must be carefully matched to obtain an optimal end result. Dr. Michal Hubálek, Head of Development at DEPRAG CZ a.s. and responsible for the pneumatic tool product area DEPRAG INDUSTRIAL gives us the inside story and reveals that it is this balance in particular which is indispensable for efficient and ergonomic processing within industry. When this balance is right, it can mean enormous savings in time and costs for many applications. “Our customer, a

Pneumatic tools for cutting and assembly DEPRAG acquires CHJ Kretzschmar Engineering KG If you are seeking a powerful aid for cutting and separating, for pressing and crimping, for assembly, or for embossing seals, the most effective tool is a modern set of pneumatic pliers. These handy universal tools have forged a firm place for themselves in industry. They carry out a myriad of tasks in series production, assembly and repairs within a huge variety of sectors, such as mechanical engineering, maintenance, the automotive industry or the assembly of household goods. The DEPRAG Group has expanded its range of high-quality pneumatically-driven pliers for industrial use by acquiring the pneumatic pliers business from market leaders CHJ Kretzschmar Engineering KG in Hamburg. Pavel Šilhán, Sales Manager at DEPRAG’s subsidiary in the Czech Republic sees good growth potential for the expanded product group. “With this acquisition we have expanded our pneumatic pliers range which promises much success, and

Short clamping times increase machining efficiency for workpieces These days it is common for robots to be deployed in the production of high quality workpieces. A clamping device is required to hold the components firmly in place ready for machining. However, when using a conventional palette storage system the machining steps can be carried out only in a fully automated process. Then, production flow is held up if components need turning or if clamping jaws - even entire fixtures - need to be changed. This is where ROEMHELD, the well-known specialist in clamping technology, can help. At EMO 2013, the international trade show for production technology, the company presented some very well received clamping solutions for automated workpiece processing - solutions that can be implemented sustainably from the smallest of batch sizes. QUESTION: Over the past 20 years international usage of machine tools has risen by 70 per cent. Half of all such machines come from Europe alone and are supplied to more than 70 countries. These are figures

Solving the problem of fluctuating production rates and short life cycles Old heating pumps are secret power guzzlers. Few people think about these hidden “service providers” when seeking to save on electricity. Even with oil and gas heating systems, electric pumps ensure that hot water circulates from the boiler to the radiators and the hot water points. Many old pumps operate round the clock, even if no water is being heated or drawn off. On the other hand, modern, intelligent heating pumps only switch on when they are needed. That represents an energy saving of up to 70 percent. The new generation of pumps - known as ultra-efficient pumps (energy efficiency class A) - uses 400 - 700 kilowatt hours less energy. So it is not just consumers’ electricity bills that go down, but experts calculate that 240 kilograms less of climate-harming CO² per year is released into the atmosphere. Incentive programs have therefore been set up, with the aim of hastening the change to improved pumping technology. New EU directives also aim to ensure

On the DEPRAG exhibition stand - well founded advice results in the right assembly line Well over 1000 exhibitors and more than 35,000 visitors are expected to be at the 32nd MOTEK exhibition in Stuttgart from 7th to 10th October. MOTEK is the leading trade show for handling and assembly technology. Each year industry experts come together to catch up with the latest developments in assembly automation. The organisers of MOTEK 2013 have announced that the exhibition is more dedicated than ever to showing complete system solutions and that there will be many examples of automation used in particular applications. But there will still be plenty of individual components, component assemblies and sub-systems on view. So what are the trends and changes that the experts visiting MOTEK 2013 expect to see in the automation industry? For many years Jürgen Hierold, Sales Manager at DEPRAG SCHULZ GMBH u. CO. has attended MOTEK both as a visitor and as a specialist exhibitor. Our editor Trixy Schmidt asked him about his expectations for this year’s specialist trade

Great power-weight ratio while also delivering high revolution rates in continuous operation What happens when the power from your drive unit simply isn’t enough? When the motor for your robot-controlled plant has to supply maximum power yet has to be physically very small? When it has to produce very high revolution speeds, yet be fit for continuous operation? The automatic processes used to manufacture today’s modern materials place heavy demands on the equipment that drives them. Plant engineers often anguish over the choice of motor to carry out the job. Technical journalist and editor Trixy Schmidt talked to two prominent plant engineers to find out more. During the interview the Managing Director of DEPRAG, Dr. Rolf Pfeiffer, and air motors product manager, Dagmar Dübbelde, provided an intriguing answer: in some applications, a pneumatically driven turbine, with its excellent power-weight ratio, is the ideal solution to the problem of motor selection. Trixy Schmidt: If I am a plant engineer in search of the ideal motor for my application I basically

With innovation it is possible to save energy and further exploit the advantages of proven technolog Compressed air technology provides indispensable services – in the modern day, people no longer think of industry and technology without it. It is compressed air technology which enables the filling of widespread PET bottles with compressed air, and compressed air helps in the purification of water in sewage treatment facilities. However, the economic and energy efficiency factors of compressed air as a working fluid are common topics of criticism. Compressed air technology expert Prof. Dr.-Ing. A. P. Weiß, of the Amberg-Weiden university of applied sciences, has conceded. “In the past, it was the efficacy which most came to the fore […] not the expenditure / benefit ratio”. Climate protection and energy conversion have called for people to revise their thinking. “The focus is now on efficiency.” As it is, economic and scientific fields have for a long time pursued new examples whereby proven technology goes hand in hand with innovation. The common aims

Every component comes from a single source in this assembly unit built by DEPRAG The rear doors of the goods lorry clank shut and the engine purrs. A consignment of carefully packed components for a new assembly system is leaving the DEPRAG factory in Amberg. Behind it lie 14 weeks of work - from the date of the order to acceptance - and it is now on its way to the customer. Systems engineer Markus Solfrank loves his “constantly exciting” job. And as the brand new assembly system leaves the factory gates, his satisfaction in having done a good job is tinged with a little sadness. It will take another six hours for the client’s service personnel to assemble the compact rotary indexing machine - it measures less than four metres in every dimension - and put it into operation. Once complete, the semi-automatic assembly unit will start assembling high quality door fittings. “In a cycle time of under ten seconds it joins the door hinges, monitors them for quality and sends them on, ready for packing”, said Markus Solfrank, as he explained

POWER LINE air motors are distinctive for their high power density Motors should be small and light - yet they must also achieve high torque values! DEPRAG are currently lauching their enhanced POWER LINE air motors on the market and the name says it all. With their unbeaten low power-weight ratio these powerful air motors score top marks. They reach the high torque value required the instant they start. The engineers put the pneumatic motor on the test bench and gave it a complete design overhaul. From this rigorous process emerged an air motor that is a shining light of economy: an attractive price and fast delivery lead times speak for themselves. The 54, 55 and 65 motors have been completely redesigned. The designers have standardised the structure with the aim of enabling a more effective, and thus more economical, manufacturing process for these drives. DEPRAG’s product manager, Dagmar Dübbelde, said: “With this redesign we have achieved our aim and we are passing on the benefits directly to our customers. We are now able

DEPRAG enhances its range of grinding motors for deburring systems What do metal castings, products made from composite materials, and brake disc blanks have in common? When all of the above items are machined, any sharp edges, burrs, fraying or chips produced during the manufacturing process need to have the edges smoothed and chips removed in a deburring process. Anywhere cutting processes such as turning, milling, drilling or thread-cutting are involved, the manufacturing process will almost always also include a deburring stage on the workpiece. This guarantees the quality of the component to comply with technical specifications. Automated deburring systems in which robots undertake many of the tasks such as milling, polishing and grinding, are becoming the norm throughout the industry. Automated processes are coming to the fore in foundries too. The job of cleaning the raw castings - an expensive and time-consuming job - is increasingly being carried out as part of the automated production process. The practice can also be observed

Traffic is flowing on the roads without interruption. The column of cars moves forward, motorcycles putter along, heavy goods vehicles rumble their way through - just like always. Yet underneath the road surface something is happening. Almost unnoticed by road users, the sewers and drains are being rehabilitated. With no sign of a road digger! Torn up roads are a thing of the past. Modern sewer rehabilitation concepts have done away with the need for several days of road works, along with the stress for digger operators and impatient motorists. No mess, no jams and no potholes in the road. Today’s sewer maintenance tools are special cameras and milling robots. Günter Meister, managing director of BRM GmbH in Biebergemünd, explains what actually goes on in the darkness of the sewer pipes: “The manhole cover is the doorway into this underworld. First, the maintenance operatives lower a special camera trolley into the pipe. Using this camera they carry out a visual

DEPRAG supplies new assembly line for power controllers A million electric cars on Germany’s roads by 2020. This is the ambitious target set by the Federal Government in its bid to continue the battle against climate-destroying CO2 emissions. It believes that e-mobility is a significant key technology to create a sustainable transport system for the future, especially where the power is produced from renewable energy sources. Yet e-mobility is still in its infancy: it is estimated that there are only around 1500 electrically powered vehicles on our roads today. That is why all those involved - policy-makers, industrialists and scientists - are working flat out to resolve all the outstanding issues. A great deal more research and development work is required before electric cars are fully ready for the market and before consumers will accept them. Lithium ion batteries replace the fuel tank in an electric car. Intensive research is under way to improve these. In a statement, industry policy-makers said: “Our aim is

Turbine drive technology saves energy and gives high output power Sparks fly and the shipbuilding worker perspires under his safety goggles. In his gloved hands he is holding an angle-grinder. With strength and stamina he smoothes the bumps on the welded seams that join together the steel plates of the ship’s hull. It is a difficult job for man and machine, and it usually performed in piecework and multi-shift operation. The exhausting load created by the angle-grinder’s weight and its vibrations place heavy demands on a man’s strength. Any sign of fatigue in the worker has an immediate effect on the result of his work, and thus on productivity. That is why the ratio between weight and power in a tool comes into focus when selecting the right industrial tool. With their incredibly favourable power-to-weight ratio (kW/kg), the innovative turbine angle-grinders, powered by compressed air, score highly here, thus representing a convincing alternative to conventional devices. For decades compressed air specialist DEPRAG SCHULZ

The story of the successful assembly platform continues The DCAM (DEPRAG COMPACT ASSEMBLY MODULE) came into the world at a time when mobile phones were still being assembled by time-consuming manual procedures. Any manufacturer that could produce mobile phones faster and more cost-effectively would be ahead of the game. The assembly platform for use in industrial manufacture came into being and began on its course to conquer the world. That was over 25 years ago and today the greatly admired assembly cell is well established all over the world. And of course over those years the engineers at DEPRAG SCHULZ GMBH u. CO have constantly been enhancing their much emulated work platform. A pioneering optimised and modular form of the DCAM has recently been launched on the market. In an interview with Norbert Widder, Automation Sales Manager at DEPRAG, technical journalist and editor Trixy Schmidt discussed the benefits for customers. Trixy Schmidt: Over the past 25 years the DCAM has made a name for itself throughout the world.

The DEPRAG screwdriving function module sets flowform screws even in confined spaces Lightweight construction takes priority! The energy-efficient car of the future has an extremely light bodywork structure made from various materials. Conventional assembly is being replaced by alternative technologies. One of these joining techniques is that of flowform fastening. Technical journalist Trixy Schmidt talked to Jürgen Hierold, Sales Manager at screwdriving specialists DEPRAG SCHULZ GMBH u. CO, based in Amberg, Germany, to discover more about the advantages of this joining technique for the lightweight structures now used in the production of vehicle bodies. Trixy Schmidt: Lightweight vehicles are coming up in the fast lane because it is only such vehicles that meet the demands imposed by government policy and by consumers as regards energy consumption and CO2 emissions. What does that mean for car body construction? Jürgen Hierold: Today’s car body structures combine materials such as steel, aluminium and magnesium alloys. So traditional assembly

A pleasing appearance stimulates consumer buying decision ATEX-certified air motor lifts and lowers the ink sumps It’s all down to the packaging. Most consumer purchasing decisions are made on the spot, in just a couple of seconds. The design, shape and presentation of the pack make the difference - guiding consumers towards making their selection from the overflowing retail shelves and multiple products so prevalent in today’s market. The machine engineering company H.C. Moog GmbH has been developing and building sheet-fed gravure printing presses for the production of high-quality packaging materials. But what actually is gravure printing? Gravure printing means that the printing elements are in the form of etched depressions - known as cells - nowadays generally produced by laser onto the printing form (cylinder or polymer plate). Before printing, the entire printing form is dipped into the ink bath, and excess ink at the surface of the print cylinder is then removed by a doctor blade. Only the ink for printing

Focusing on high quality stainless steel drives What do tasty shish kebabs, weather-proof paints and varnishes, delicious fruit juice drinks and newsprint have in common? At first glance, very little. But if we take a look at how they are made, we see the question in a different light. The manufacturing processes of all four of these products utilise stainless steel air vane motors. These high quality drives are the number one choice when high torques are required in confined spaces, or where strict hygiene rules apply in the food processing and medical technology sectors. When deployed in aggressive environments - even under water - the stainless steel drive proves indestructible. Airmotors specialist DEPRAG, in Germany, is presenting the most comprehensive international range of stainless steel vanemotors. The airmotors are designed using the latest sophisticated technology and they receive highly specific finishing treatment at the company’s own hardening shop, thus ensuring that they are the very best drive

Accurate and reliable screwdriving even in confined spaces At the AUTOMATICA DEPRAG presented their new cordless EC angled screwdrivers Every two years, technical experts from all round the world meet at the AUTOMATICA in Munich. This year, over an exhibition area covering 55,000 square metres, the leading European trade fair showcased automation solutions for every sector of industry. Experts from Germany and abroad visited the exhibition so that they could keep up to date with trends. Their aim is to manufacture better quality products faster and more cost-effectively. Many innovative ideas for production process optimisation attracted the interest of large numbers of visitors. Internationally renowned exhibitors used the opportunity to present their new and innovative automation and mechatronic products. Sales Manager of DEPRAG SCHULZ GMBH u. CO., Jürgen Hierold, took advantage of the AUTOMATICA to get a feel for the latest trends in automation. Technical journalist and editor, Trixy Schmidt, interviewed him. Question:

Versatile assembly components from a single source Automation partner DEPRAG - top-notch expertise on show The player with the best recall wins the game! In the popular memory game of “Memory” (or Pairs) the person who best remembers which pairs of pictures go together is the winner. This also applies in the choice of a partner when I want to build an assembly system,” explained Jürgen Hierold, marketing manager at DEPRAG. “All I have to do is remember DEPRAG’s top-notch expertise in feed systems, handling, screwdriving, assembly, inspecting, testing, evaluating, analysing and data recording, and I am already ahead.” The assembly specialist means to take this message and increase awareness in visitors to the AUTOMATICA trade fair in Munich (22 to 25 May 2012). Those who remember the name of DEPRAG when it comes to automation will win the game. “Automation partner DEPRAG - for us that means telling visitors to our exhibition stand about our expertise gained from 80 years of machine manufacture, 40

Sensor-controlled EC servo screwdriver - now even better DEPRAG presents its new generation of screwdrivers to its trade fair public When, from 22 to 25 May, AUTOMATICA 2012, the 5th international automation and mechatronics industry show, opens its doors in the new Exhibition Hall in Munich, the key players in the automation solutions sector will be showing off their wares on 55,000 square meters of floor space. In the quest to manufacture higher quality products faster and more cost-effectively this unique exhibition will be showcasing a host of innovative solutions and the latest trends in product process optimisation. In the screwdriving technology section, on stand 311, Hall A1, DEPRAG SCHULZ GMBH u. CO. will be presenting the latest generation of its successful MINIMAT®-EC servo screwdrivers. This 311E series of transducer-controlled screwdrivers, with its AST40 sequence controller, replaces the current EC-Servo system which has been proving its worth over many years in a wide variety of applications. Transducer-controlled

Minimising harmful particles in the clean room Technical cleanliness is the latest quality feature in screw fastening assembly In miniaturised technology, the elimination of tiny particles while fastening screws during the assembly process is a new quality feature. If when a circuit board is being assembled, a microscopic piece of steel - invisible to the naked eye - escapes, a disaster is sure to happen. A short-circuit will occur if the tiny chip accidentally connects two of the conducting tracks. As assembly parts become ever smaller even microscopic particles, measuring a mere 500, 200, or just 100?, can cause a malfunction. Which is why what has become known in joining technology as “technical cleanliness” is of increasing importance in the design and building of screw fastening assembly systems. The technical requirements are becoming stricter. Jürgen Hierold, Sales Manager at DEPRAG sees this trend as “an opportunity for specialists”. He adds: “DEPRAG has taken up this opportunity.” As early

A powerhouse in the drainpipe - and supplier of green electricity Four applications demonstrate powerful versatility of air motors. Dagmar Dübbelde, from drive specialists DEPRAG SCHULZ GMBH u. CO., described the air motor as a “universal genius”, and gave four impromptu and exciting examples of how such motors are deployed. As a compact power pack, it helps a cutting robot to battle its way through the muck inside the drainpipe. The air motor adds enormous power to a truly amazing transporter device. As an ATEX-compliant brake motor for potentially explosive areas its job here is to optimise a barrel emptying system. As an innovative GET turbine generator its energy recovery credentials are extremely “green”; it even generates power from small amounts of process gas. Temperatures globally have been rising inexorably for 30 years now. Researchers and industrialists have struggled to counter the effects of climate change with innovative products and processes. At its test laboratory DEPRAG is producing the prototype of

DEPRAG presents a screwdriving device for reliable hearing aid assembly DEPRAG follows the trend towards miniaturization in assembly technology Every 8th adult suffers from hearing problems. But only one third of them in Germany use a hearing aid. However, according to an extended study of impaired hearing, those who decide in favour of a hearing aid experience a indisputably better quality of life. As people are living ever longer the hearing aid market is expected to be a growth market. Due to aesthetics many sufferers have hesitated to use a hearing aid until now. The full digital hearing aids of today are of higher performance and much smaller in size than in the past. Hearing aid manufacturers have successfully endeavoured to miniaturize their products and to lower the inhibition threshold for users. About 45 000 people in Germany, France and Great Britain have been questioned by the market research company “Züricher Marktforschungsinstitut Anovum” on behalf of EHIMA (European Hearing Instrument Manufacturers Association).

Torque in calibration lab on the test bench DEPRAG Support: making quality management for screwdriver assembly systems easier Vehicle manufacturers can tell you a thing or two about it: recall actions harm your image and destroy customers` trust [in your product]. In its annual report for 2009 the German Federal Motor Transport Authority in Flensburg listed a total of 140 recalls, affecting 617,000 vehicle owners. According to the report, 60 percent of the recalls were the result of mechanical defects. At 17.3 percent, vehicle brake systems are frequently affected. An example from April 2009: an incorrect torque was the probable cause of a recall, in which 10,000 owners were obliged to return their compact cars to the workshop. A screw on the rear brake anchor plate was incorrectly tightened. It threatened to come loose and fall into the brake drum. In a worst case scenario, the rear wheel could have seized. It follows that preventing screw tightening faults during assembly is of the utmost importance. By

Assembly platform now available in modular structure Fixed investment costs and rapid delivery time to benefit customers A success story continues. The DCAM assembly station (DEPRAG COMPACT ASSEMBLY MODULE), which has proven itself many hundreds of times all over the world, is now 25 years old. But this is no reason for the DEPRAG engineers to rest on their laurels. They have optimised their “baby” and equipped it for the future. At the MOTEK 2011 show in Stuttgart DEPRAG, the automation experts, presented the DCAM in its pioneering new, modular form, providing customers with some major benefits. The DCAM’s legendary reliability and high level of functional safety is now available “out of the box”, which means that the standardised assembly platform is now more cost-effective, and delivery times are shorter. The DCAM came about when mobile phone assembly was still in its infancy. Mobile phones used to be assembled individually by hand - an expensive and time-consuming process. The company that could produce

DEPRAG presents the latest generation of screwdriving function modules Achieving big time and money savings at the early planning stage Screwdriving function modules form the basis of all automated, process-reliable screwdriving assembly operations. Visitors to the MOTEK 2011 trade exhibition in Stuttgart showed great enthusiasm for DEPRAG’s new - thousandfold proven - generation of screwdriver units. The pioneering modular structure of the SFMs shown promises major benefits for system integration and plant engineers, offering advanced screwdriving technology at reasonable terms. Reliable timescale and cost data are known right from the planning stage. With six standard structures, there are no restrictions to covering every requirement of modern screwdriver assembly technology. The normal version, with its slim design, is designed to carry out horizontal screwdriving tasks, or operations from above. The short version is particularly suited to operations where space is restricted. The under-floor version was designed

Using the right technology to fasten miniature screws to the frame DEPRAG places the focus firmly on innovative technology for micro-assembly operations Anyone looking for an overview of innovative technology for micro-assembly operations should venture a look at the DEPRAG stand at MOTEK 2011 this October, where the focus is on modern micro-assembly operations - and ground breaking new products are on display. Trendy sunglasses will be assembled live before visitors` eyes. At a single glance visitors to the exhibition will obtain a well-founded overview of how fasteners - barely visible to the naked eye - are assembled using a process-reliable method. Screwdriver, process controller, screw feeder, position control stand, electronic measurement and the DCOS control unit concept - everything on this semi-automatic assembly station is designed towards miniaturisation in the production process. Whether the task is to assemble a hearing aid, a heart pacemaker, a satellite navigation unit, a mobile phone or fashionable sunglasses - micro-assembly

Battery operated screw driving with highest accuracy Angle-head screwdrivers for assembly in restricted space The more that compressed air hoses or electric cables hinder assembly work, the more battery-powered EC-screwdrivers are favoured in industrial production. The better the performance of modern batteries, the more applicable battery powered tools are to industrial application. The proven DEPRAG precision screwdriving technology is now also available in battery powered form. At this year’s MOTEK fair from the 10th to 13th of October in Stuttgart, DEPRAG‘s screwdriving experts will present its new battery-driven EC-angle-head screwdriver. Whether screwdrivers are needed for assembly in the interior of a car, or used for equipping caravans, compressed air hoses and electric cables hinder the work process in restricted spaces.(DEPRAG sales manager Jürgen Hierold: “Here, the use of an industrial battery-driven screwdriver can help tremendously”. On assembly lines where the conveyor belts are moving for

Screws are accurately positioned on the screwdriver Expansion of range with 1.2 l bowl and mini-device with piezo technology One of the main issues related to automated assembly of components is the precise feeding of the assembly components. Regardless of whether you are assembling extremely small screws or larger hexagon nuts – their availability on time and accurately positioned for the assembly process determines the productivity of a system. 30 years of experience in feeding technology for automatic feeding of screws, rivets, bolts, nuts, washers, O-rings, symmetrical and non-symmetrical components, form the basis for new developments guaranteeing nothing but the highest precision and reliability. Valuable additions to the wide assortment of feeding technology, tailormade to customer requirements, are to be introduced by the automation expert DEPRAG SCHULZ GMBH u. CO. at this year’s MOTEK fair in Stuttgart. The “6” Series program of vibratory bowl feeders for handheld screwdrivers will now be extended

Practical entry into the complex world of screwdriving technology and automation The new DEPRAG Website answers all questions about assembly technology The engineer Peter Feldmeier (Dipl.Ing. (FH)) is studying the construction plans. He looks once more at the specification of the assembly equipment for which the medium-sized engineering office IBF has secured the order for project planning and construction. For production start-up, a process-safe manual workstation will do, he thinks. Later when the volume of production increases, partially or fully automated assembly equipment will be recommended. But what he needs now is detailed information and an informed introduction to screwdriving and assembly technology. Best would be information from one source is clear, concise and understandable. He thinks that the Internet would be a good source for information. This should result in consultation with a competent equipment manufacturer. Peter Feldmeier sighs. He thinks of surfing for hours and hours in the Internet to find answers to his many questions

Smart Sensor regulates nominal speed A motor needs to be powerful while still being small and robust. During the selection of an air-motor for the automated technology, especially its small size and mass are convincing advantages. An air-motor offers notable significance in both areas. When compared with an equivalent electric motor, an air-motor has only one-third of the size and one-fifth of the mass. This advantage is a supreme argument for the use of an air-motor in handheld machines and also in stationary equipment. However until now, there was a deficiency - the speed regulation. DEPRAG SCHULZ GMBH u. CO. has now set a new standard with an innovative speed regulator offered for their air motors: With help of a thought-out sensor technology, the powerful air-motor will always hold the desired, preset speed. Product manager Dagmar Dübbelde explained: “It is characteristic for an air-motor, that it can be operated in a wide field of changing loads. When operated without load, the motor runs at

DEPRAG flowform screw fastening assembly system also copes with tight spaces Mixed materials for car bodies require alternative fastening techniques. Fierce competition has broken out in the automotive industry. Who can build the lightest car? The less a vehicle weighs, the more likely it is to meet maximum energy efficiency requirements. Cars of the future will be measured by their fuel consumption and CO2 emissions. Regardless of whether the car is powered by an electric drive system, a hybrid drive, or has a conventional combustion engine - the lightweights will come out top! However, car bodies must lose none of the necessary rigidity. Modern car body engineers are experimenting with suitable compound materials, combining different metals such as steel and aluminium. This meant a rethink of the assembly processes. With these material pairings, conventional fastening techniques such as resistance welding are extremely impractical and have to be achieved by other joining processes. Fasteners such as rivets are experiencing a revival, where

Innovative research project by DEPRAG sends a signal: Generating electricity from small amounts of process gas Time is pressing. Global temperatures have been rising unrelentingly for 30 years. Experts expect 2010 to set a new temperature record, since weather records began. The continued growth in the number of extreme natural disasters speaks clearly. At the climate summit in Cancun, the world community took a small step forward and officially set a limit for global warming to a maximum of two degrees Celsius. In the European Union, there are efforts under way to reduce emissions of the climate killer CO2 by 2020 not just by 20 percent, but by 30 percent, and to make this a binding target. Research and industry are called upon to draw up and implement innovative climate protection projects. There are a variety of different approaches. Many industrial processes release and waste surplus energy. The recovery of untapped energy potential is therefore a crucial part of the fight against global warming. An ambitious

Expert answers to questions from technicians Installation and assembly of Air Motors made easy Whether as a high torque motor in the agitator system of a paint and coating manufacturer, as a highly durable stainless steel motor in newspaper print production, or as a compact power pack for an innovative roller transport device: An air motor is in many ways the right choice when it comes to specifying a drive system for a manual device or a complex industrial system. Compact and light weight, an air motor represents only 1/3rd of the size and 1/5th of the mass of a standard electric motor with the same power output, offering outstanding power density. Due to numerous model variants, simple construction, favourable performance to weight ratio, large speed range, or the inherent combustion safety feature, air motors can be employed in a wide application spectrum. Their rugged construction and durable performance combined with ease of installation, service and assembly speak for themselves. Air motors work based

Quality management begins with the selection of the stationary screwdriver. EC motor or compressed air screwdriver? What determines the type of drive? The achievement of zero defect production has the highest priority in industrial assembly. Time and again we hear of product recalls due to defective screw joints. The associated material damage and loss of brand image is the dread of every industry. And when it relates to safety-relevant components such as in the automotive industry then the manufactures make every conceivable effort to ensure maximum process reliability throughout the installation process. The selection of the correct tightening tool for industrial mass production is the cornerstone in creating a high quality fault free production system. A threaded fastener is intended to clamp components together so that external forces cannot cause them to come apart and the parts essentially behave like a single unit. The designer calculates how high the applied clamping force must be so that the screwed or bolted component can withstand

Process reliability starts with the selection of tools Basic information regarding screw assembly technology In the domain of technology, screw joints are the most frequently used method for joining components and, in many cases, to separate them again. Screws can be tightened and loosened again without damaging the connected components in most applications. In today"s environmentally aware times, people have come to understand the value of the materials contained in defunct consumer goods. The edict is "prudent reuse of resources". If we consider recycling demands alone, it can be argued that screwed connections have their undeniable place in modern assembly processes. One can only effectively disassemble an item for targeted re-use if it was screwed together. The screw assembly process gives the impression of being a very simple task, but in the assembly process it is encumbered with many potential pitfalls. From the moment the screw is seated, the assembled components behave like a single part. It

Intelligent dust bag mops up virtually all dust during vacuuming Uncompromising processing quality through stable assembly system processes Nagging sneezing and coughing after getting up in the morning, teary eyes, running nose or headaches can be an indication of an allergy to the droppings of house dust mites. According to experts, about 3.5 million people in Germany suffer from this form of allergy. With a portion of 25%, this allergy occupies rank two on the list of allergic respiratory diseases, close on the heels of hay fever. The house dust mite, which is inevitably found in every household, is the main instigator. It thrives in the humid, warm climate of rooms and therefore feels especially at home in mattresses, bed linen, carpets and upholstery. But it is not the mites themselves that cause illness, but their droppings, which disintegrate into smallest particles, which are raised into the ambient air and then end up in the inhaled air. Therefore effective management of house dust is indispensable for affected allergy

Robust screw presenters ensure productivity in mass production Mobile telephones connect all people across the world What started off in 1983 as a 800 gm Motorola device, sneeringly called `jingling bone`, has embarked on an unbelievable triumphal procession around the entire globe: the mobile telephone. Experts meanwhile estimate there to be 4 billion mobile phone users worldwide. The market is flooded with a multitude of mobile phone models, which can do a lot more than just phone. The Finnish giant in this sector, Nokia, is the largest producer of mobile telephones, followed by Samsung. Today`s handys weigh less than 80 gm, they take photos, record and play back videos, surf the Internet or are navigators for drivers and pedestrians who are unfamiliar with the surroundings. Mobile phones are produced in an industrial mass production environment. Three-shift production operation places high demands on people and material. The often quoted maxim `time is money` demands robust, low maintenance machines, which operate smoothly,

What lipstick, a fridge, a light switch, and vehicle instruments have in common Screw joint analysis ensures correct fastening torque parameters Almost everyone has used one – a lip balm stick that gives relief to cracked and dry lips. Twist the balm out of the practical rotating sleeve; apply balm onto the lips, done! What appears so easy can actually prove to be a brain-teaser for industrial production. What happens if problems arise in the assembly of the lip balm’s plastic components? What if waste is produced time and again in the screw assembly of the lip balm casing? The error analysis on site may take weeks, or even months. This is when a detailed screw joint analysis from the screwdriving specialists pays off. In his laboratory for screw joint analysis, application engineer Rudolf Schmidbauer is holding three plastic parts in his hands: the casing, the piston, and the spindle for the lip balm. During assembly, the piston is first inserted into the casing. It is actually the second step that leads to most problems. This is

Manoeuvre parked aircraft by hand! An air motor powers an innovative transport device designed for wheeled equipment Moving heavy rolls of paper, railway wagons, and even parked aircrafts by hand may sound like magic, but it is humanly possible! The unassuming "Easy Roller" works just as its name implies. With this device, you can easily manoeuvre up to 100 tons without exerting great effort. The secret lies within the device"s utilization of the wheeled object"s net mass to its own advantage. Without having to climb into the driver"s cab or even turn on the engine, the mechatronics engineer can effortlessly manoeuvre the articulated lorry over the repair pit. It"s not even necessary to know how to drive one! In one hand, the engineer holds the handle of the "Easy Roller". The air motor, which powers the transport system, is hardly audible. Moreover, it does not produce any exhaust fumes, thus proving to be environmentally sound. Aside from the usual odour

Seven sequences with 99 respective screwdriving programs realizable Flexibility and functionality, and high process reliability with low investment costs, these are the industry’s demands to master the control tasks in screwdriving and assembly technologies, which are becoming increasingly complex. With the introduction of their new function control fc20 for pneumatic and electric screwdrivers at the AUTOMATICA in Munich this year, DEPRAG SCHULZ GMBH & Co. has succeeded in satisfying these demands. The automation specialists combined all their expertise in the further development of the fc10 control. The new fc20 impresses with its extensive user-friendliness, its high flexibility and the numerous possibilities of individual screwdriving process configuration. With the introduction of the fc20, DEPRAG is staying true to its company policy – Improving what has proven successful and setting standards through innovation. The new function control fc20 was developed for use in combination with DEPRAG pneumatic screwdrivers: MICROMAT®-F,

Control systems and process control at highest industry level An estimated 300 million people worldwide have bronchial asthma. About 5% of children suffer from this chronic infection of the bronchial system. However, the exact origin of the disease is still unclear. Allergies as well as genetic factors play an important role. However, it is certain that with a series of proven treatment methods the symptoms can be relieved and the number of dreaded asthma attacks can be reduced. One of the most effective therapies is inhalation. An efficient, easy to handle inhaler facilitates the treatment of the chronically sick and improves quality of life. The automated assembly of drug delivery systems requires the highest quality standards, as always when a person’s health and life are at stake. When assembling an inhaler for the pharmaceutical industry, the first step is to screw the top part of the case to the bottom part and then the mouth piece is clipped into the casing. In medical technology, mistakes in assembly are not acceptable.

A change of direction towards "intelligent workstations" can pay off A change of direction towards `intelligent workstations` can pay off. Back on the road to success with flexibility and process reliability. Combining manual and automated assembly processes. The manufacturing industry is in an unprecedented recession. Due to the economic crisis large systems in many production halls are standing still, or working at low capacity. The only way to reach positive results in assembly processes is to quickly adjust to varying production rates. Manufacturing specialists still lack medium term planning certainty; sales forecasts are inaccurate and remain speculative. Flexibility is the right strategy to pursue. In assembly engineering this leads to an increased demand for `intelligent workstations` that make a combination of manual and automated assembly possible. Quick adjustment to unexpected rises in unit numbers is usually dealt with through additional manpower. Tried and tested system modules, combined with a system that has high

Miniaturisation: New generation of machines delivers top processing reliability The tide of ever smaller, ever lighter electronics cannot be stopped. Whether a mobile phone on your wrist or an electronic controller for the petrol saving start-stop-system in vehicles, the demand on engineers is always the same: Maximised potential in electronics for minimum weight and size. In all areas of industry the answer is miniaturisation. This creates another challenging task for automation experts, since every day in industrial production millions of screws are assembled and of course even the tiniest of screws must be analysed for the utmost processing reliability. Screw joints are again in vogue and screwdriving technology is currently experiencing a striking upturn. In times of shortage of resources and environmentalism, system designers must stay abreast of new demands: devices should be repairable and recyclable. Although reworking is almost impossible with other joining technologies such as gluing and laser welding, this is just one of the advantages

Automatic Assembly & routing of flat conductor cable reduces cost and weight Research: Assembly alternatives for wiring harnesses in vehicle dashboards. The automotive industry has set the course for change. In the battle against global warming politicians and consumers are now demanding cars which use less fuel and emit significantly less CO2. In addition to research into a dependable alternative drive to the conventional Internal Combustion Engine, cost-saving potential is also in focus. One approach is the reduction of vehicle weight. Today the most popular accessories in a new car are the electronic devices. However it is these vehicle instruments which drive up the cost and weight of a vehicle. Weight, because the conventional wiring harnesses have increased so much in volume and costs because automatic alignment and assembly of wiring harnesses based on existing assembly and connecting technologies is almost impossible. Installing flexible flat conductor cable instead of standard wiring harnesses could reduce the cost and weight

Restoration counts for more than half of all building work these days. Since the 1970s the renovation of old buildings has become increasingly important. Both buildings from the post-war era and historic buildings must be adapted to conform to current standards. This conformity is not only important for thermal insulation and energy consumption but also all household technical and electrical systems. For example almost no old buildings have sufficient electric wiring, plugs and switches and they do not correspond with modern standards especially safety standards. If renovations are being carried out in an occupied house then the resulting disturbance from noise and dirt must be kept to a minimum. A 1920s house can be updated to our multimedia era without cutting new channels in the walls. New plugs and light switches are increasingly attached onto the outside of plaster walls and the necessary wiring is carried in the skirting board along the surface of the wall.

Leading edge measurement technology helps to prevent product recalls Monitoring the screwdriving assembly process to detect errors sooner Product recalls are the fear of every industry. Automobile defects are especially in the public eye. An automobile recall is mandatory when stemming from an unforeseen, unavoidable and imminent threat to personal safety. When a particular vehicle type is identified as a risk, the original automobile manufacturer will initiate a “vehicle recall”. With the support of the government automobile registration authority, individual owners of the affected vehicles are identified. With this information the manufacturer can notify the owners directly to return the vehicle to their local service provider for modification. Additional to this the automobile registration authority maintains the statistics for vehicle recalls. For example: in 2008 the German “Kraftfahrtbundesamt” documented 148 cases involving 726,000 vehicles which were recalled by the manufacturer. For the past few years vehicle recall

No Metal: Amazing air motors made from ceramic Developed for MRI (Magnetic Resonance Imaging) No Metal: Amazing air motors made from ceramic Generating growth and expanding market leadership with brand new concepts It is a company’s manpower which makes it more successful than its competitors, the decisive ambitious factor which results in constant development and realisation of new and innovative ideas. Highly motivated employees who provide a combination of creativity and knowledge make all the difference. Growth and expansion of a market position begins with a key person driving the ideas factory within the company. Germany’s machine industry is extremely competitive. It is a race to bag the contract as companies compete to provide the most suitable solution, quickly and flexibly, designed to fit the customer’s application and all at a great value price. Medium sized businesses such as DEPRAG SCHULZ GMBH & CO. rely on the inventiveness and expertise of their engineers. The internationally renowned

An even wider range of motors lowers operating costs DEPRAG SCHULZ & CO. GMBH, the air motor specialists are widening the gap between themselves and their nearest competitors. The combination of innovative ideas and expertise bred from decades of experience result in the production and development of top quality devices?. Three new high power 900 W and 1.2 kW motor models have been added to the machine manufacturer’s range of products. They have expanded their great value BASIC LINE series, air motors with cast iron housing, and now have two more performance classes with 900 W and 1.2 kW and the ADVANCED LINE stainless steel motor series now has a 900 W class. The guiding principle of DEPRAG engineers is to use successful, tried and tested methods whilst also furthering new technological advances. The company fulfils the current requirements for modern drive technology with their development and construction of outstanding state-of-the-art air motors. Consequently DEPRAG air motors are the authoritative choice for

Long life-span, consistency and robustness are the attributes of a modern high performance air vane motor. Consistent, regulated air pressure induces the rotor of a 120 W air vane motor to rotate 11,000 times a minute within an eccentric cylinder under load. When, for example, after 1,000 hours of operation the vanes in the drive need to be changed for the first time then the rotor has already turned on its axis 660 million times. The steel for such a heavily stressed machine component must be particularly resilient. Special hardening procedures improve the microstructure of the steel material and increase its mechanical durability. DEPRAG SCHULZ GmbH & Co., based in Amberg, Germany, is an international supplier for quality air motors, automation, screwdriving technology and air tools to major conglomerates and industries. The company has decades of experience in processing steel as a raw material. Professionals in special heat treatment procedures, DEPRAG provides

Power package with a small diameter achieves a high torque with the lowest rpm For protection against the elements in historic building refurbishment or for protecting against corrosion in the shipbuilding industry – paint or coatings come into play. According to its own figures, the German paint and coatings industry, which employs about 25,000 people and has revenues of some 6.7 billion Euros annually, produced approximately 2.6 million tons of paint, coatings and ink in 2008. In the industry’s roughly 250 paint and print ink factories throughout Germany, production is achieved through the use of robust and cost-efficient components offering a low price-performance ratio. Among these various components, air powered, high torque, stainless steel motors are an excellent solution for blending and mixing applications in this industry. All mixing equipment used in the paint industry has one thing on common: a space saving motor with ample power to operate mixers and agitators at full production. A compact, light but extremely strong airmotor

Bursting with energy and vitamins, from the humble apple to exotic combinations such as lychee and guava, there are fruit juices on the market to satisfy every taste. The drinks provide countless vitamins and minerals and are perfect for the health conscious. Many scientific studies underline the connection between an ample and varied intake of fruit and vegetables and the reduction of diet-related illnesses. The initiative group “5 a day” has the goal of persuading people to eat 5 pieces of fruit or vegetables per day in order to meet all the body’s needs. If you require a quick fix then the practical answer is a portion of fruit or vegetable juice. DEPRAG SCHULZ GMBH & CO. in Amberg, Germany is a global supplier and specialist in the production of air vane motors. The DEPRAG Advanced Line motor range is recommended for use in the food industry. This range has a comprehensive selection of non-corrosive, sealed air vane motors suitable for oil-free use. The

DEPRAG SCHULZ GMBH u. CO. is confronting the growing challenges within the industry of series assembly with the innovative redesign of its existing product families. In July 2009, the experienced automation specialists, with particular expertise in the field of feeding technology, are launching a new generation of screw feeding machines, Series 6, onto the market. DEPRAG has improved on its renowned machines by augmenting the range of functions, heightening processing reliability and further increasing user-friendliness. Billions of screws are assembled every day in worldwide industrial production—screws with diverse dimensions, light and heavy, screws that you can hardly grasp with your fingers, screws for electrical toothbrushes, mobile phones, kitchen mixers, screws for automotive or aircraft parts, and many more applications. They are all assembled in manual workstations or positioned by semi-automated or complex fully automated production systems. No matter

The greatest thing since sliced bread! Germany is known worldwide for its wide-ranging selection of breads and pastries. This, in turn, poses a serious challenge to the country’s over 700 mills, which supply Germany’s baking industry with high-quality milled grains. According to the Verband Deutscher Müller ( Association of German Millers), more than 6,000 Germans now earn their daily bread milling grain. In Germany, the per-capita-consumption of milled grains is 67.1 kilograms per year, and increasing. In all Germany’s milling industry generates revenues of about 2.1 billion Euros. In contrast to years past, when the milling process consisted of hauling around sacks, sweeping up and manually changing mill wheels, today’s mills employ a wide range of cutting-edge technologies, including high-tech digital milling programs, and computer controlled systems and quality monitoring in the milling laboratory. Automation is also on the rise, especially in the

The German machine building industry has been badly affected by the global economic crisis. Despite the slight lift in spirits in Germany’s economy, which was reflected in the Ifo Business Climate Index at the beginning of the year, order rates in the industrial goods industry are unsteady. Pessimists anticipate not only a decline in exports, but also a slump in production investments at home. Reduced workloads on existing equipment and machines are an additional concern to those in positions of responsibility. Work places are in danger. However, within the crisis there is also opportunity. There is a recognisable trend in systems technology which moves away from large fully automated machines and leans towards variable manual systems. According to the January survey of the Munich Ifo Institute for Economic Research, approximately 7000 companies reported increased business expectations in comparison to last month. However, in these times of economic uncertainty

Motor Systems in Medical Technology In Europe at least 50,000 patients a year die from infections which they acquire in hospital. Due to this alarming number, at the beginning of 2008 the German Association for Hospital Hygiene (DGKH) highlighted the dangers of this increasingly sore subject: Antibiotic resistant bacteria are on the rise in hospitals. Surgical tools are also covered in the demand for heightened hygiene in operating theatres. Medical power tools, such as drills, saws or milling machines are needed today in many surgical procedures and orthopaedic operations. Drills and screwdrivers are for example, used to fix broken bones with a plate during an osteosynthesis procedure and in the field of prosthetics, bone surfaces are cleaned for an optimal bone cement interface using a practical lavage system. After any operation the tool must be thoroughly cleaned and sterilised. Therefore steam sterilisation is the most common method of destroying microorganisms

Screw assembly error – 15,000 cars recalled to the factory! Headlines such as these shatter car owners’ confidence and damage the image of an automobile manufacturer. A car contains around 1200 to 1400 screws and various assembly tools are employed in the automotive sub supply industry as well as by the OEM manufacturer. Diverse safety requirements set high demands on quality management. DEPRAG SCHULZ GmbH & CO. now has a calibration laboratory accredited by the Deutscher Kalibrierdienst (DKD), in which torque testing instruments can be checked and recalibrated with the highest precision. Roughly 12 kilos of screws are used in the construction of a medium sized vehicle. 15 percent of these are subject to the safety hazard marking “Danger to life and limb”. Precision and stability is vital for these components! If brakes fail, a resulting accident could have catastrophic effects. If paneling constantly rattles, although this does not influence safety, it does

DEPRAG SCHULZ GmbH & CO. has set a new standard on the market by restructuring the brand portfolio for their successful range of air motors. The company’s contemporary website presents a logically structured overview of the popular air motors. The new English product names for the air vane motor programme: Basic Line, Advanced Line, Power Line and Individual Line highlight the international role of the company as a leading supplier of air motors, automation, screwdriving technology and air tools. DEPRAG is working towards the future with 600 employees in over 40 countries. The company’s philosophy has always been to expand on achievements and set the trend for future innovations. The new layout provides customers with a clear outline of all the important information concerning DEPRAG’s various motor lines. The sophisticated visual features optimise navigation through the wide range of uses and clearly explain which air motors are particularly suitable for which

Ever had to brush your teeth between shivers because the previous bathroom user tilted the window open and forgot to close it again? Extremely unpleasant! The cold creeps into the bathroom and then finds its way into the other rooms. It takes time for a piercing cold room to heat up again. This requires not only time, money is also spent unnecessarily. The experts are agreed on the benefits of proper ventilation: brief periods of ventilation several times a day promotes a healthy room climate, saves heating costs and aside from that, the contribution to climate protection is not insignificant. However how often is a tilted window left open and forgotten? The innovative window closer WINFLIP® is an effective remedy. After five minutes or up to a maximum of five hours this nifty device closes a tilted window without the need for electricity or batteries. It’s impossible to forget! Letting heat escape out the window is a thing of the past. Now you can open the window

For the first time, it is possible to exchange the vanes on an air motor without completely disassembling the motor or even uninstalling the motor. This feature, which allows the motor to remain attached to the equipment, does not waste valuable production time needed for the removal of a motor for maintenance. By using an Allen-key and a tweezers, it is now possible to exchange the vanes within the shortest possible time and by untrained personnel. Therefore, the maintenance requirements, when compares with other commonly known motors, is considerable reduced. This new development is patented by DEPRAG SCHULZ GMBH & CO. and is available for the Basic Line Air-Motor series. The Basic Line Motors include three power-class series with 200W, 400W and 600W. There are eight different planetary-gears available for each power stage. Each gear-stage is equipped with high-grade, anti-friction planetary gears, which assure a high longevity even at the highest load. These

DEPRAG SCHULZ GMBH & CO. has developed into the predestined problem-solver with the expansion of our service to include a comprehensive power-analysis. Such a power-analysis can be performed to help select a drive-system for an individual application or it can be used to test existing drives, such as air-motors, hydraulic or electric drives, grinders, drills, etc. It is now possible to perform – within a relative short time – comprehensive tests and to simplify the selection of a suitable drive system, using our new, innovative, and freely-programmable power-test-stand, which features a maximum torque range of 500 Nm and a maximum speed of up to 12,000 rpm. While performing in a four-quadrant operation, it is now possible to carry out power-tests up to 22 kW. Beyond power, speed and torque, it is also possible to measure operating pressure and air-consumption. Each test-specimen is individually movable in 3-axes and the system may be flexibly adjusted

Air Motors in the Food Processing Industry During food preparation using machines, hygiene is just as important as efficiency, therefore air motors are ideally suited for use within the food processing industry because of their adaptability to such moisture prone conditions. It’s the best kept secret of any barbeque: Who took all the time and effort to lovingly and carefully skewer each piece of food in place? Whose job is it in those popular restaurants where the guest expects high service and quality of presentation? In today`s market where increasing costs of production are a deciding factor in the survival of every business, optimal use of resources is the best recipe for profit. Automation and pre-processing can provide this. Not only fast, efficient machine processing of food must be achieved but also hygiene standards upheld. If the customer is to be more than just satisfied but also a big fan and even promoter of the business then the end product must be something special in itself.

Screwdriving has never been easier! Screwdriving has never been easier! DEPRAG, a market leader in superior screwdriving technology, presents a world’s first: They are introducing an innovative electric screwdriver, the MINIMAT-ED, which is the first screwdriver with an integrated electromagnetic shut-off clutch, a convenient torque setting by the push of a button and a digital torque-display that is directly located on the screwdriver housing. The new and handy “All-in-one-Tool” can be adapted, quickly and easily, to fit each new screw assembly requirement. The MINIMAT-ED incorporates many of the advantages that are part of the well-known DEPRAG air-operated screwdriver series. The MINIMAT-ED is recommended for all tightening applications, particularly those that require variable torque-settings. This new tool is perfectly suited for the use in rework areas with ever-changing parameters such as in the manufacturing of controllers or control boxes, as well as in all industries having mass

Assembly in the smallest of work areas - the new DCAM-XS is a giant achievement! Assembly in the smallest of work areas- the new DCAM-XS is a giant achievement! The innovative Micro-Assembly-System from DEPRAG SCHULZ GMBH u. CO. attracts a lot of attention at the AUTOMATICA 2008 in Munich. The DCAM-XS fulfils all market requirements for a modern micro-assembly-machine. It is extremely small, fast, precise and flexible. The new model has been developed from the successful DCAM family (DEPRAG Compact Assembly Module) by the specialists for automation and assembly from Amberg, Bavaria. The outstanding characteristics: Extremely small size and unrivalled short conversion times of the module. Screwdriving, labelling, palletising, clipping, laser inscribing, welding, and gluing of the smallest components- the new assembly machine can carry out numerous functions. Many small component parts can be assembled, a razor put together, an electric toothbrush or a digital camera…The DCAM-XS is converted in a few minutes for various assembly steps. So

Competition and pressure to keep costs low are no strangers to modern aircraft manufacture, especially against the backdrop of the weak US dollar. Nevertheless safety and technical reliability are still top priority. Requirements for efficiency and environmental considerations for wide-bodied aircraft demand research and innovation from every conceivable field. A Bavarian scientific and industrial consortium is breaking the mould in the construction of aircraft doors and emergency opening systems. Weight minimisation is a particular challenge in the construction of jets. Aircraft doors are a critical factor in this weight balance. The safety-sensitive classified emergency opening systems are an area where highly specific weights and costs are demanded. This is where the ambitious research project PYROTAK comes in. It is a collaboration of research projects from Bavarian businesses and universities which is already a success. The participating businesses and universities

Extremely small and also extremely tough Drainage repair is a challenge for underground engineering specialists. A common scene used to be that of stressed excavator operators, annoyed residents and impatient drivers. Today however, modern restructuring concepts leave torn up road surfaces a thing of the past. A resilient milling robot can carry out the dirty work in drainage pipes. Extremely small and also extremely tough, it eats through any obstacle in the drain networks. Now the digger can stay in its depot, as digging for days on end is no longer necessary. Defective drainage pipes are not replaced but restored. The milling robot used by Bodenbender GmbH located in Hessen for their PL-Inliner drain sanitation system is a type EU Robot 150 made by BRM GmbH in Biebergemünd. It is inserted through a manhole into the defective drain pipe. Now the preliminary work can begin for perfect repair. Debris is cleared, pipe sockets straightened, protruding supports bevelled and in-growing roots removed. The

Germany’s paper industry is the no. 1 in Europe and with a turnover of approximately 14.9 billion euro it makes the no. 4 spot worldwide behind the USA, China and Japan. A total of 3000 different kinds of paper are manufactured at around 180 production locations. 44,000 employees work to produce around 23.2 million tons of paper per year. The innovative paper manufacturing machinery ensures that the ravenous paper appetite of industrial nations is continuously satisfied. How did paper originate? The procedure has changed very little since 105 AD, the date when the process of paper manufacture was first recorded. Fibres are moistened in water and then scooped out with a sieve. This paper web is later pressed and dried. Today gigantic paper machines are used in the various processing steps to turn the pulp into paper. This is an enormous challenge for machine constructors as individual components have to be able to withstand extreme pressures. DEPRAG SCHULZ GmbH &

Innovative Complete System of Air Motor, Holding Brake and Gear Explosion prevention is a hot topic within the field of systems engineering today. Friction, overheating or sparks could lead to a horror show in potentially explosive environments. DEPRAG, one of the leaders in the field of air motors, has mastered this challenge with an innovative drive system. DEPRAG engineers have developed an entire system consisting of motor, integrated brake assembly and gears which fully corresponds with ATEX standards and is made out of stainless steel. The new customer orientated air brake motor has a compact, innovative design. Its main feature is the separately controlled holding brake driven by air. It has been designed for vat draining equipment used in the chemical industry where highly toxic powders are emptied. This motor is now available as standard from DEPRAG`s 1.2 stainless steel motor programme.
